PARTS AND SERVICE MANUAL
FOR
COMPACT FIREPLACE
Model DFB4047

1
TABLE OF CONTENTS
OPERATION PAGE 1
PARTS DRAWING PAGE 3
PARTS LIST PAGE 4
LIGHT BULB REPLACEMENT PAGE 5
HEATER ON/OFF SWITCH REPLACEMENT PAGE 6
THERMOSTAT CONTROL REPLACEMENT PAGE 7
FLAME MOTOR/FLAME ROD REPLACEMENT PAGE 8
HEATER ASSEMBLY REPLACEMENT PAGE 9
CIRCUIT BOARD REPLACEMENT PAGE 10
POWER CORD REPLACEMENT PAGE 11
TERMINAL BLOCK/CAPACITOR REPLACEMENT PAGE 12

2
DFB4047
OPERATION
The fireplace is supplied with an integrated on/off remote control.
Note: Ensure that the fireplace 3 position switch is set to
the remote control setting.
To operate, push the ON button to turn fireplace on, push the
OFF button to turn the fireplace off.
BATTERY REPLACEMENT
To replace the battery, slide battery cover open on the hand
held transmitter.
Correctly install one 12 volt (A23) battery in the battery holder.
Close the batter cover.
Resetting the temperature cutoff switch
The heater is protected with a safety device to prevent overheating. Should the heater
overheat, an automatic cut out will turn the heater off and it will not come back on without
being reset. It can be reset by switching the ON/OFF SWITCH to OFF and waiting 5
minutes before switching the unit back on.
Caution
If you need to continuously reset the heater, unplug the unit and call your local dealer.
ON OFF
BATTERY
COVER

3
Three position ON/OFF switch
The switch has two ON positions marked with “-“ and “=”.
The “-“ position is for manual operation.
In this position the built-in remote control is bypassed.
The “=” position is for operating the unit with the provided remote control.
When in “=” position the unit is operated with the ON and OFF buttons of the remote
control.
When the switch is in the center position the unit is off.
Heat switch
The HEAT ON/OFF SWITCH supplies power to the heater fan and the heater element.
When the switch is in the ON position the heater operates if the thermostat calls for heat.
Heater thermostat control
To adjust the temperature to your individual requirements, turn the thermostat control
clockwise all the way to turn on the heater. When the room reaches the desired
temperature, turn the thermostat knob counter clockwise until you hear a click. Leave in
this position to maintain the room temperature at this setting. For additional heat, turn
clockwise until you hear the click again and the heater will turn on.
MAIN THREE
POSITION
ON/OFF
SWITCH
THERMOSTAT
HEAT
SWITCH
MANUAL
OPERATION
OFF
REMOTE
CONTROL

4
DFB4047
12
1
13
14
6
9
16 5
11
16
15 2
8
10
3
4
7

5
DFB4047
REPLACEMENT PARTS
COMPACT FIREPLACE
PART NO. 6901740000
MOD LEVEL: NONE
MADE IN: CHINA
REPLACEMENT PART REPLACEMENT PART NO.
1. LOGSET 0438200700RP
2. FLAME MOTOR 2000220100RP
3. HEATER ASSEMBLY 2200490300RP
4. CUTOUT 2300270100RP
5. THERMOSTAT 2300150100RP
6. HEATER SWITCH 2800070200RP
7. ON/OFF SWITCH 2800071100RP
8. CAPACITOR 3200030100RP
9. TERMINAL BLOCK 4000070100RP
10.CORD SET 4100090100RP
11.REFLECTOR ROD 5900340100RP
12.MIRROR 5900350100RP
13.FRONT GLASS 5900380100RP
14.BUSHING, SNAP-IN 8500000400RP
15.FLICKER CONNECTOR 8500680100RP
16.CONTROL KNOB 8800000300RP
17.LAMPHOLDER ASSEMBLY 4200120800RP
18.HEYCO STRAIN RELIEF 8500260003RP
19.REMOTE (INTEGRAL) 3000400100RP

6
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
Light bulbs need to be replaced when you notice a dark section of the flame. There are
four bulbs under the log set which generate the flames and embers.
It is a good idea to replace all of the light bulbs at one time if they are close to the end of
their rated life. Group replacement will reduce the number of times you need to open
the unit to replace the light bulbs.
BULB REPLACEMENT
1. Open the front control cover.
2. Remove front glass by removing the 2 outer screws holding the class clips.
3. Remove the log grate by removing the 4 mounting screws.
4. Remove the log set by lifting straight up.
5. Slide the light assembly slightly out of the insert approximately 1”.
6. Examine bulbs to determine which bulbs require replacement.
7. Hold the socket while unscrewing the old bulb.
8. Hold the socket while screwing in the new bulb.
9. Reassemble in the reverse order as above.

7
LIGHT BULB REQUIREMENTS
Quantity of 4 clear chandelier or candelabra bulbs with an E-12 (small) socket base,
60 watt rating.
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE MAIN ON/OFF AND HEATER SWITCHES
1. Open the front control cover.
2. Remove front glass by removing the 2 outer screws holding the class clips.
3. Remove the log grate by removing the 4 mounting screws.
4. Remove the log set by lifting straight up.
5. Lay the insert on its back and remove the 2 switch control cover screws located on
the bottom of the insert.
6. Locate the switch to be replaced and disconnect the wiring clips and connections
noting their original locations.
7. Depress the retainer clips on the rear of the switch and push the switch out of the
rear of the cover.
8. Reassemble in the reverse order as above.

8
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE THERMOSTAT CONTROL
1. Open the front control cover.
2. Remove front glass by removing the 2 outer screws holding the class clips.
3. Remove the log grate by removing the 4 mounting screws.
4. Remove the log set by lifting straight up.
5. Lay the insert on its back and remove the 2 switch control cover screws located on
the bottom of the insert.
6. Locate the thermostat control and disconnect the wiring clips and connections noting
their original locations.
7. Remove the thermostat control knob by pulling straight out.
8. Remove the 2 mounting screws and remove the old thermostat control.
9. Reassemble in the reverse order as above.

9
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE FLAME MOTOR/REFLECTOR ROD
1. Open the front control cover.
2. Remove front glass by removing the 2 outer screws holding the class clips.
3. Remove the log grate by removing the 4 mounting screws.
4. Remove the log set by lifting straight up.
5. Slide the light assembly slightly and lift out of the insert being careful not to damage any
of the wiring.
6. Remove the reflector rod from the flame motor by pulling the end of the rod to the left
and separating it from the rubber sleeve.
7. Remove the rubber sleeve from the motor shaft.
8. Disconnect the flame motor wire from the terminal block, noting their original locations
9. Remove the 2 motor mounting screws and remove the flame motor.
10.Discard the old flame motor.
11.Reassemble in the reverse order as above

10
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE THE HEATER ASSEMBLY
1. Remove the 4 retaining screws and lift the top cover off of the insert being careful not to
damage the wiring.
2. Remove the 4 heater mounting screws from the top of the top cover to separate the
heater assembly.
3. Remove the 2 heater mounting brackets from the heater assembly.
4. Disconnect the 2 heater switch leads from the heater noting their original locations.
5. Disconnect the thermal cut-out wire from the wire nut.
6. Reassemble in the reverse order as above

11
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE THE CIRCUIT BOARD
1. Remove the 4 retaining screws and lift the top cover off of the insert being careful
not to damage the wiring.
2. Disconnect the wire connections from the circuit board noting their original locations.
3. Lower the grill covering the controls.
4. Remove the (10) retaining screws on the top panel and remove the top being careful
not to damage any of the wiring.
5. Remove wiring connections from circuit board noting their original locations.
6. From inside the insert, break off the six mounting studs on the circuit board by
grasping with pliers and twisting on the protruding part of the stud, push the
remainder of the studs out through the top panel.
NOTE: New mounting studs are supplied with the replacement circuit board.
7. Properly orientate the new circuit board and connect all of the wiring connections.

12
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE THE POWER CORD
1. Open the front control cover.
2. Remove front glass by removing the 2 outer screws holding the class clips.
3. Remove the log grate by removing the 4 mounting screws.
4. Remove the log set by lifting straight up.
5. Lay the insert on it’s back and remove the 2 switch control cover screws located on the
bottom of the insert.
6. Disconnect the power cord wires from the terminal block
7. With needle nose pliers grasp the power cord strain relief grommet from inside the rear
panel and push while twisting to remove.
8. Pull the power cord out through the hole in the rear cover.
9. Install the new cord set through the hole in the rear cover by placing the strain relief
over the cord, hold the strain relief with pliers and slide into mounting hole.
10.Connect all of the wiring connections in their original locations on the terminal block.
11.Reassemble in the reverse order as above.

13
DFB4047
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE THE CAPACITOR AND TERMINAL BLOCK
1. Open the front control cover.
2. Remove front glass by removing the 2 outer screws holding the class clips.
3. Remove the log grate by removing the 4 mounting screws.
4. Remove the log set by lifting straight up.
5. Slide the light assembly slightly and lift out of the insert being careful not to damage any
of the wiring.
6. Remove the terminal block cover by removing the 2 retaining screws.
7. Disconnect the wiring from the terminal block noting their original locations.
8. Disconnect the capacitor from the terminal block.
9. Remove the terminal bloc from the light assembly.
10. Reassemble in the reverse order as above
