FEC AM-1017 User guide

System Manual
Model Name:
AM-1017
Document Version: I
Customer
Checked &
Approved by
Date
FEC
Prepared by
FEC
Approved by
Date
_________

System Manual
Aer Monitor
User's Manual
Version-0.2

System Manual
Copyright Notice
This document is copyrighted, © 2013. All rights are reserved. Firich Enterprise Co., Ltd reserves
the right to make improvements of the product described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by
any means without the prior written permission from Firich Enterprise Co., Ltd. Information
provided in this manual is intended to be accurate and reliable. However, Firich Enterprise Co.,
Ltd assumes no responsibility for its use, nor for any infringements upon the rights of third parties,
which may result from its use.
The material in this document is for product information only and is subject to change without
notice. While reasonable efforts have been made in the preparation of this document to assure its
accuracy, Firich Enterprise Co., Ltd, assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
Record of Revision
Date
Specs Ver.
Description
Note
2013.10.17
V0.1
Initial
Julie
2013.11.21
V0.2
Julie

System Manual
Safety and Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray
detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near the equipment and must be
easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating.
DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power
cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or electrical shock.
13. Never open the equipment. For safety reasons, only qualified service personnel should open
the equipment.
14. If any of the following situations arises, get the equipment checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT WHERE
THE STORAGE TEMPERATURE IS BELOW -20°C (-4°F) OR ABOVE 60°C (140°F). IT MAY
DAMAGE THE EQUIPMENT.

System Manual
Table of Content
Chapter 1 1
Introduction 1
AerMonitor ( AM-1017 ) Introduction....................................................................................1
A Quick Tour for AM-1017...................................................................................................3
AM-1017 Dimension .....................................................................................................5
Rear I/O Panel Connectivity.................................................................................................7
Aer Monitor AM-1017 Packing List.......................................................................................7
Chapter 2 8
MSR / Finger Print Reader/ RFID / i-Button Installation........................................................8
15” 2nd Pole Type VFD / LCM Installation............................................................................9
Note : They should connect to the system. ..........................................................................9
17” 1st Touch Display Installation & Swapping ...................................................................10
OSD Function and Adjustment...........................................................................................11
Chapter 3 12
Software Installation and Setup 12
FEC P-Capacitive/ Resistive Touch Utility (EETI Controller)..............................................12
EETI TouchKit Tools Installation........................................................................................13
TouchKit Control Panel for P-Capacitive/ Resistive Touch.................................................16
Chapter 4 17
Specifications 17
AM-1017 Specifications....................................................................................................17
Chapter 5 18
Troubleshooting 19
Touch Panel Does Not Work.......................................................................................19
OSD Panel Cannot Work Precisely.............................................................................19

[鍵入文字]
AerM AerMonitor AM-101onitor AM-101
1
C
Ch ha ap pt te er r 1 1
Introduction
AerMonitor ( AM-1017 ) Introduction
AerMonitor is a 17 inch bezel free monitor which is slim, compact, and yet tough enough for any
environment. With easy accessed on screen display controls, users can adjust brightness and
display is a compatible component and can be easily removed and installed on the FEC AerPOS
Terminal Series.
Main Features:
Reliable Tempered Glass on Projective Capacity Touch ; Bezel Free Design
The high quality of resistive touch or durable tempered glass of projective capacitive
touch both are IP65 front panel compliant.
Space Efficiency and compact Size - Fits for any kinds of POS applications
Various peripheral devices support.
Integrated VFD/LCM customer display and the 2nd 15” LCD pole display.

System Manual
2
AM-1017

System Manual
3
A Quick Tour for AM-1017

System Manual
4
17” Touch Display
Display OSD
Display OSD
Menu item up select, item
value increase and auto tune
Menu item down select and
item value decrease
Display OSD menu and enter
Next page
MSR
Finger Print Receiver
RFID
i-Button
Power Switch / Status
Blue LED: Power ON
Red LED: Power Off / Standby
Note: All buttons are invisible till one touch of any. After 5 seconds, the lights will back to
invisible without further touch.

System Manual
5
AM-1017 Dimension

System Manual
6
H: 382mm
W: 409.9mm
D: 212.3mm

System Manual
7
Rear I/O Panel Connectivity
Stand Type
Aer Monitor AM-1017 Packing List
I/O Port
Connector Type
Description
DC IN
DC IN connector
Connect the 12V power adaptor to this port
USB
B Type
Connect to touch screen
VGA
D-Sub 15
Connect 2nd LCD screen or CRT monitors
DVI
D-Sub 25
Connect 2nd LCD screen or CRT monitors
Line in
Phone Jack
Connector
Connect speakers to this port
Standard
Optional & Peripherals
1
17” AM-1017 Aer Monitor Touch Terminal
1
MSR / RFID / Finger Print Receiver
I-Button
2
50W (12V/4.16A) External Power Adaptor
2
20x2 VFD / 20x2 LCM / 240x64 LCM
3
AC Cord
3
15” 2nd Display Pole Type
4
Aer monitor base
4
2-in-1 peripherals module

System Manual
8
C
Ch ha ap pt te er r 2 2
MSR / Finger Print Reader/ RFID / i-Button Installation
1. Remove the plastic cover
at the back of Touch
Display Module
2. Insert the MSR / RFID /
Finger Print Reader / I-
button Module into USB A-
Type Connector. Fix the
Touch Display Module with
one screw.
3. Make sure the USB connected and screw is fastened well.
4. If you are looking for the detail Utility of MCR, Finger Print Reader, I-button Reader,
RFID Reader, please contact FEC’s FAE.

System Manual
9
15” 2nd Pole Type VFD / LCM Installation
1. Assemble the 2nd
screen with pole type
with 2 screws
2. Assemble the 2nd
Screen with pole type
to Terminal.
3. Plug in VGA and DC
12V cables
Note : They should connect to the system.

System Manual
10
17” 1st Touch Display Installation & Swapping
1. Release 2 thumb screw at the
back side of Display
2. Lift the Display Module up to
disassemble from the main
unit of terminal
3. Display and Aer monitor base
are separated.

System Manual
11
4. Reverse the process can
assembly back the touch
display module.
** please make sure the touch
display module is firmly
connected to the docking slot
**
**Note**
During the process of disassembly and installation, please ensure the terminal is
“Power Off” and remove AC.
OSD Function and Adjustment
OSD function and adjustment
Menu Function Introduction
Back Light Power (finger touch for 5 seconds)
Back Light Power On –Blue LED indication
Back Light Power Off –Red LED indication
Menu item up select, item value increase and auto
tune
Menu item down select and item value decrease
Display OSD menu and enter
Next page
All buttons are invisible till one touch of any. After 5 seconds, the lights will back to invisible without further touch.

System Manual
12
Menu
Function
1) AUTO SETUP
auto tune
2)BRIGHTNESS
brightness adjustment
3)CONTRAST
picture contrast adjustment
4)DISPLAY ADJUST
picture parameter adjustment
5)COLOR TEMPERATURE
color temperature adjustment
6)LANGUAGE
multi-language setup
7)OSD DISPLAY
OSD parameter setup
8)VGA/DVI
VGA/DVI signal setup
9)AUDIO
audio function adjustment
10)RECALL
reset all menu item value to default setting
11)EXIT
exit OSD menu
C
Ch ha ap pt te er r 3 3
Software Installation and Setup
AM-1017omes with a variety of drivers for different operating systems.
You can download all the necessary drivers and utilities from http://www.fecpos.com.
FEC P-Capacitive/ Resistive Touch Utility (EETI Controller)

System Manual
13
FEC Projective –Capacitive Touch Utility Introduces:
1. Mode of FEC Capacitive Touch Panel and default settings
2. EETI TouchKit Tools Installation
Mode of FEC P-Capacitive/ Resistive Touch Panel
Win XP, POS Ready 2009
Win7, POS Ready7
Mouse Mode
Yes
Driver Needed
Yes
Driver Needed
Touch Mode
N/A
Yes
No Driver Needed
EETI TouchKit Tools Installation
EETI TouchKit Tools Installation for Windows XP
1. Down load Touch Kit for WinXP from FEC website.
2. Execute Setup.exe
3. Click Next
4. Click Next

System Manual
14
5. Click Next and do not choose RS232
6. Select None

System Manual
15
7. Click Next for further installation process
8. Select No
