FEC AM-1022 Series User manual
User’s Manual
I
Aer Monitor
AM-1022
User Manual
V0.2
December 1, 2016
User’s Manual
I
Copyright Notice
This document is copyrighted, © 2014. All rights are reserved. Firich Enterprises Co.,
Ltd reserves the right to make improvements of the product described in this manual
at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission from Firich Enterprise Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable.
However, Firich Enterprise Co., Ltd assumes no responsibility for its use, nor for any
infringements upon the rights of third parties, which may result from its use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the preparation
of this document to assure its accuracy, Firich Enterprise Co., Ltd, assumes no
liabilities resulting from errors or omissions in this document, or from the use of the
information contained herein.
User’s Manual
II
Revision Record
Date
Version
Description
Note
August 8,2015
0.1
Draft
Elio Chen
December 1,2016
0.2
Add Stand Installation
Elio Chen
User’s Manual
III
Safety Precaution
Please observe the following precautions to ensure safe use of equipment.
1. Disconnect the equipment from AC outlet before cleaning.
Use only moist cloth (with water). Do not use detergent.
2. Power outlet must be easily accessible and near the equipment.
3. Keep the equipment away from humid and dusty environment.
4. Place the equipment on a stable surface during installation and operation.
5. Do not place any load on the power cord.
6. All cautions and warnings on the equipment should be noted.
7. When the equipment is not in use, disconnect it from the power source to avoid
damage by transient over-voltage.
8. Liquid into the equipment may cause fire or electrical shock.
9. Only qualified service personnel should be allowed to open the equipment.
10. If any of the following situations arises, ask service personnel to check the
equipment:
A. Power cord / plug is damaged
B. Liquid penetrates into the equipment
C. The equipment does not function properly and/or cannot work according to
the User Manual
D. The equipment has been dropped
E. The equipment shows signs of damage
11. Temperature below 0°C (32°F) or above 60°C (140°F) may damage the
equipment
User’s Manual
IV
T
Ta
ab
bl
le
e
o
of
f
C
Co
on
nt
te
en
nt
t
C
Co
op
py
yr
ri
ig
gh
ht
t
N
No
ot
ti
ic
ce
e
I
I
R
Re
ev
vi
is
si
io
on
n
R
Re
ec
co
or
rd
d
I
II
I
S
Sa
af
fe
et
ty
y
P
Pr
re
ec
ca
au
ut
ti
io
on
n
I
II
II
I
T
Ta
ab
bl
le
e
o
of
f
C
Co
on
nt
te
en
nt
t
I
IV
V
C
CH
HA
AP
PT
TE
ER
R
1
1
1
1
1.1 Introduction 1
1.2 Overview 2
1.3 Dimension 3
1.4 I/O Connectivity 4
1.5 Packing List 4
C
CH
HA
AP
PT
TE
ER
R
2
2
5
5
2.1 Hardware Installation 5
2.1.1 Automatic adjusting the monitor resolution...................................................................5
2.1.2 Cable and Cabling...................................................................................................6
2.1.3 Wall Mount Installation...........................................................................................7
2.1.4 Stand Installation....................................................................................................9
2.2 Hardware Setup 11
2.2.1 OSD Usage............................................................................................................11
2.2.2 OSD Menu .............................................................................................................12
C
CH
HA
AP
PT
TE
ER
R
3
3
1
13
3
3.1 Software Installation and Setup 13
3.1.1 Touch Utility - Mouse Mode Setting .....................................................................13
C
CH
HA
AP
PT
TE
ER
R
4
4
1
15
5
4.1 Specifications 15
C
CH
HA
AP
PT
TE
ER
R
5
5
1
16
6
User’s Manual
1
CHAPTER 1
1.1 Introduction
AM-1022 is the latest member of Aer Monitor series that features a slim design with
22”screen. It can be easily configured to meet the demand of different store
environments as a desktop, wall-mount or pole-mount digital signage.
AM-1022 is a 21.5 inch bezel free monitor which is in die-cast aluminum chassis that
withstands harsh environments. With easy access on screen display controls, users
can adjust the settings easily and can be congruence with the FEC AerPOS Terminal
Series.
Key Features
Slim & Sleek
High resolution for display
Desktop, Wall-Mount or Pole-Mount, Panel-mount
Projected Capacitive Touch (IP65 front panel)
User’s Manual
2
1.2 Overview
22”Touch Display
22”Touch Display
Power Switch
(OFF / Red ; ON / Blue)
Speakers
Speakers
Panel Mount (M4)
SATA Storage
100 mm
100 mm
100 mm
100 mm
75 mm
75 mm
VESA Mount (M4 x 8)
SATA Storage
User’s Manual
3
1.3 Dimension
49 mm
H: 338.05mm
W: 530.05mm
220 mm
220 mm
395 mm
90∘
User’s Manual
4
1.4 I/O Connectivity
1.5 Packing List
Standard
Optional
1
AM-1022
1
DVI Cable
2
Power Adapter (50w)
3
AC Power Cord
4
VGA Cable
5
USB A Type-B Type Cable
12V
User’s Manual
5
CHAPTER 2
2.1 Hardware Installation
2.1.1 Automatic adjusting the monitor resolution.
SWITCH OFF POWER AND UNPLUG POWER CORD BEFORE
User’s Manual
6
2.1.2 Cable and Cabling
As the picture shown below, the cables are DC cable 5.5mm, USB Type B cable,
VGA cable, DVI cable, and phone jack 3.5mm cable from left to right.
User’s Manual
7
2.1.3 Wall Mount Installation
1. Prepare the AM-1022 and the wall mount kit.
2. Set up the wall mount kit on AM-1022 and tighten four M4 x 8 screws.
3. Set up another part of wall mount kit on the wall with four self-tapping screws.
User’s Manual
8
4. Assembly two parts of wall mount kit.
5. Tighten the hand screw on the top of wall mount kit.
User’s Manual
9
2.1.4 Stand Installation
1. Prepare the PP-8632, one stand, four M4 x 8 screws, and screwdriver.
2. Tighten four screws on the back cover.
User’s Manual
10
User’s Manual
11
2.2 Hardware Setup
2.2.1 OSD Usage
*Attention: Hold about 5 seconds then power button & menu button works.
Function
1
Power
2
Down
3
Up
4
Menu
21.5”Touch Display
22”Touch Display
User’s Manual
12
2.2.2 OSD Menu
You can see the menu shown below when touch menu button for 5 seconds.
Auto Setup
Auto adjustment (only in Analog signal)
Brightness
Bright adjustment
Contrast
Contrast adjustment
Display Adjust
(only in Analog signal)
Color Temp.
RGB color adjustment
Language
Language Select
OSD Display
OSD Menu location, transparency adjustment
VGA/DVI
Signal input select
Audio
Volume adjustment
USB Sleep fun.
Recall
Restore to the last setting
Exit
Close menu
User’s Manual
13
CHAPTER 3
3.1 Software Installation and Setup
Please download drivers and utilities from http://home.eeti.com.tw/drivers_Win.html
3.1.1 Touch Utility - Mouse Mode Setting
1. Download drivers from http://home.eeti.com.tw/drivers_Win.html
2. Run Setup.exe
User’s Manual
14
3. It means finished that “beeps”when you touch the monitor.
