Multiple group of airbags in seat, which can wrap up buttock and thigh, realizing alternative air squeezing massage on different parts, eliminating tiredness quickly.

准备工作

131478

910

自动复位菜单零重力OK自动开/关加热

③Take out the left and right armrest from the carton box, catch the two sides of the armrest and take out slowly. (The armrest is placed upside down in the box); Put the armrest on the table or ground in flat (pay attention to prevent scratches), catch the two sides from the front of armrest and take it slowly.

Left shoulder massage device(Inside with “L” MARKS)

④Take our the left and right shoulder massage devices from the carton box, catch the two sides of the shoulder massage devices and take out slowly, then put it on the table or ground in flat(pay attention to prevent scratches).

②③Right shoulder massage device(Inside with “R”MARKS)

1112

Step 4. How to assemble the left and right armrest.

①Unscrew the M6 on the seat frame with cross screwdriver.②Press the button on the fixed hole which inside the back of armrest,insert fixed hole into the fixed bolt of side backrest.③Insert the square tube into the inside piece of the seat frame. ④Slightly move the armrest to make the front and back panel match bolt hole on the seat metal frame,screw M6 on the hole.⑤Connect the air hose from seat frame with the hose joint on the armrest firmly.⑥Joint LED wire on the armrest with the LED wire on the seat.During installation,please make sure don't squeeze the air hose and LED wire.Disassemble armrest: Disassemble the shoulder device and seat side airbags at first, disconnect the LED wire and air hose between the seat frame and armrest,Then unscrew the four bolts on the seat frame.Lift up the front of the armrest,make the square tube of armrest move out from the plate of seat frame,then press the button on the fixed hole which at inside of the rear of armrest,pull the rear of armrest at the same time,move the fixed bolts on the side of backrest away from the fixed hole,then it finished to disassemble the armrest.

▲

Side pieces of seat meal frame

Fixed holeButtonFixed panel Square tube Air hoseLED wire ①②③BoltsFixed bolt⑤Purple air hose

⑥

Four bolts in the four corners ④

Step 5. Install left and right shoulder massage device ▲

When assemble the left and right shoulder massage device,please note,left shoulder massage device assemble on the left side of backrest, right shoulder massage device assemble on the side of backrest.①Two hands to grab the shoulder massage device to make the inside parts close to the side of backrest,connect the wire of loud speaker and air tube from shoulder massage device with the connector from the side of backrest.②Make the four axle holes on the armrest align to the four axles on the backrest,put strength to insert the axle to the axle hole,make close to the shoulder and back.③Turn the shoulder massage device downward,until it can't be moved,then it was fixed well.④Pull the shoulder bag leather zipper, open shoulder bag holster, gasbag fixed plate mounting holes on the bottom board and enchase nut at the top of the armrest after alignment;⑤Using M6X30 screw insertion on the screw hole, screw tightly by a cross screwdriver, then pull the shoulder holster zipper;⑥Repeat the above steps to install another shoulder massage device.Disassemble shoulder massage device: Unzip the shoulder airbags,screwing out the screws inside the air bag;Turn the shoulder parts upwards,move the axle away from the axle hole,then disconnect the wire of loudspeaker and airtube.

Right shoulder massage device

Left shoulder massage device

Right side of backrest

Left side of backrest

Connector for wire of loudspeaker and air tube①②

Four axles

Four axle holes

①②Zipper for shoulder airbags

Cross screwdriver screwing in bolt

⑤Bolt③LED wire

1314

▲

1516

1718

菜单3DAutomatic massage: after press “menu”button the cursor stop on auto massage program menu item by default.press the “Ok”button,there are optional automatic massage methods,also contain five special automatic massage modes.White-collarShopaholicBack YogaAthlete modeCare of agedUpper BodyWaist&Back3D:ZeroPartial3D+3D-

1920

Heating: In menu mode, choose heating by navigation key, heating symbol on the screen will be highlighted, and on or off two kinds of choice on the waist and leg.Full BodyUpper BodyArms&SeatLegs&Feet

Air: After press MENU button ,choose “air pressure” through navigation key ,Press “OK” button ,there are two kinds of air pressure related function :Position and Intensity ;choose the corresponding function ,then press “OK” to enter next menu and choose required function.

3D:Zero
