Ferimex ISM Antennas User manual

Instructions for Assembling ISM Antennas
List of Parts:
1) Receiver, with plastic case and cable
2) Metal tube
3) Metal tube holder
4) Antenna rid
5) Elevation holder
6) Shark (2 pieces)
7) Screw: self-cuttin for fastenin to plastic
receiver
8) Bolt, M8x45 (2 pieces)
9) Bolt, M8x100 (4 pieces)
10) Bolt, M6x10 (3 pieces)
11) Nut, M8 (6 pieces)
12) Nut, M6 (2 pieces)
13) Split Washer, M8 bi (6 pieces)
14) Washer, M8 bi (6 pieces)
15) Split Washer, M6 small (2 pieces)
16) Washer, M6 small (2 pieces)
Fasten the metal tube holder (3) to the
antenna rid (4) in the followin manner:
Insert the two bolts (10) throu h the holes
in the front of the antenna rid so that they
pass throu h the holes in the metal tube
holder. Onto the bolts stickin out the back
of the metal tube holder, put a washer (16),
split washer (15), and fasten with the nut
(12).
Put the cable of the receiver (1) throu h the
end of the metal tube (2) which has
a small hole, and make the cable o out the
other end of the metal tube. Orient the
plastic receiver so that you can see the small
hole in the plastic receiver throu h the
small hole in the metal tube. Fasten throu h
the hole with the self-cuttin screw (7).
9
13
1
2
4
8
6
5
10
7
3
Obr. 1
Obr. 2
Obr. 3
11
11
12 13
14
14
15
16
310
1
2
4
16 15 12
7

www.ferimex.com
Put the cable (1) throu h the front of the
antenna rid and out the back of the metal
tube holder (3), but do not put the metal
tube (2) into the metal tube holder yet.
Fasten the elevation holder (5) to the metal
tube holder (3) usin two bolts (8), addin
the washer (14), split washer (13), and the
nut (11). Then insert the metal tube into the
metal tube holder (3) all the way until it hits
the bolt (8). The focal len th will then be
correct.
IMPORTANT:
The flat side of the plastic receiver must be
oriented parallel to the ribs of the antenna
rid. The antenna will NOT function if the
receiver is oriented 90 de rees from the
metal ribs!
In the hole in the metal tube holder (3) put
a bolt (10) and ti hten, so that the metal
tube/receiver combination is fixed and
cannot move.
Put the four bolts (9) throu h the holes in
the elevation holder (5), and then add
onto the bolts the two sharks (6), the four
washers (14), four split washers (13),
and the four nuts (11). This assembly is for
mountin onto poles or consoles.
Obr. 4
Obr. 5
Obr. 6
1
8
5
3
10
9
6
9
3
2
14 13 11
5
14 13 11
