DAPAudio EDGE EUA-1 User manual

EDGE EUA-1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: D1486
USER MANUAL
ENGLISH
V2

1
EDGE EUA-1
Product code: D1486
Preface
Thank you for purchasing this DAP product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Installation and operation of the device
●Intended and non-intended use of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2022 DAP. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
EDGE EUA-1
Product code: D1486
Table of contents
1. Introduction..........................................................................................................................................................3
Before Using the Product ..................................................................................................................................3
Intended Use .......................................................................................................................................................3
Text Conventions ................................................................................................................................................3
Symbols and Signal Words................................................................................................................................4
2. Safety ....................................................................................................................................................................4
Warnings and Safety Instructions ....................................................................................................................4
Requirements for the User.................................................................................................................................5
3. Description of the Device ...................................................................................................................................6
Overview..............................................................................................................................................................6
Product Specifications ......................................................................................................................................6
3.3. Accessories..........................................................................................................................................................7
Dimensions...........................................................................................................................................................7
4. Installation ............................................................................................................................................................8
Ambient Conditions ...........................................................................................................................................8
Mounting..............................................................................................................................................................8
5. Setup .....................................................................................................................................................................9
Safety Instructions for Operation.....................................................................................................................9
Compatibility of the Device.............................................................................................................................9
Setting the Gain Boost.......................................................................................................................................9
Connecting the Device ..................................................................................................................................10
6. Troubleshooting .................................................................................................................................................11
7. Maintenance .....................................................................................................................................................11
Preventive Maintenance................................................................................................................................11
Basic Cleaning Instructions ...................................................................................................................11
Corrective Maintenance................................................................................................................................11
8. Deinstallation, Transportation and Storage ....................................................................................................12
9. Disposal ..............................................................................................................................................................12
10. Approval.............................................................................................................................................................12

3
EDGE EUA-1
Product code: D1486
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
●DAP EDGE EUA-1
●2 x BNC antenna cable (3 m)
●User manual
Fig. 01
Intended Use
This device is intended for use as an unidirectional antenna. It is suitable for indoor use. It is not suitable for
households. Any incorrect use may lead to hazardous situations and result in injuries and material
damage.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Text Conventions
Throughout the user manual the following text conventions are used:
●References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “press the power switch (03)”
●0–255: Defines a range of values
●Notes: Note: (in bold lettering) is followed by useful information or tips

4
EDGE EUA-1
Product code: D1486
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Provides important information about the disposal of this product.
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
●Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
Attention
General safety
●Do not shake the device. Avoid brute force when installing or operating the device.
●If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it
on immediately. Let the device reach room temperature before switching it on, otherwise it may be
damaged by the formed condensation.

5
EDGE EUA-1
Product code: D1486
Attention
This device shall be used only for the purposes it is designed for.
This device is intended for use as an unidirectional antenna. It is suitable for indoor use. It is not suitable for
households. Any incorrect use may lead to hazardous situations and result in injuries and material
damage.
This device does not contain user-serviceable parts. Unauthorized modifications to the device will render
the warranty void. Such modifications may result in injuries and material damage.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Maintenance and installation may be carried by ordinary
persons. Service shall be carried out only by instructed or skilled persons. Contact your Highlite
International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the service of this product, so that they can
identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the service of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

6
EDGE EUA-1
Product code: D1486
3. Description of the Device
The DAP EDGE EUA-1 is a set of 2 unidirectional antennas. The device is designed to be used with the DAP
EDGE receivers but it is also suitable for other receivers that operate in the frequency range of 470–980
MHz.
Overview
01) Antenna
02) 5/8” mounting thread (with a 3/8” adapter)
03) Gain boost switch (0 dB/10 dB)
04) BNC connector OUT
05) Gain boost indicator
Fig. 02
Product Specifications
Model:
DAP EDGE EUA-1
Features:
Wireless audio frequency:
470–980 MHz
Antennas:
RF antenna output:
1 x BNC connector OUT
RF receiver antenna output voltage:
15 V
RF gaining:
6 dBi
RF gaining (range):
0–10 dB
Polar pattern:
Super Cardioid
Thread:
5/8” (with a 3/8” adapter)
Physical:
Dimensions:
305 x 26 x 270 mm (L x W x H)
Weight (1 x antenna + 1 x cable):
0,6 kg
Construction:
Housing:
Aluminum
Color:
Black
IP rating:
IP20
Thermal:
Max. ambient temperature ta:
From -10 °C to 50 °C

7
EDGE EUA-1
Product code: D1486
3.3. Accessories
The device is delivered without the receiver. The receiver is available in each of the following 4 sets:
●D1475B (EDGE EHS-1, 1-channel wireless handheld system)
●D1476B (EDGE EBS-1, 1-channel wireless bodypack system)
●D1479B (EDGE EHS-2, 2-channel wireless handheld system)
●D1480B (EDGE EBS-2, 2-channel wireless bodypack system)
The device is delivered without the antenna distributor. There is 1 antenna distributor available for this
device:
●D1485 (EDGE ED-1, antenna distributor)
You can additionally purchase the following accessories:
●D1477B (EDGE EHM-1, handheld condenser microphone)
●D1478B (EDGE EBT-1, bodypack)
Dimensions
Fig. 03

8
EDGE EUA-1
Product code: D1486
4. Installation
Ambient Conditions
●The device can be used indoors.
●The maximum ambient temperature ta= 50 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 50 °C.
Mounting
The device can be mounted on a microphone stand.
●Make sure that the device is safely mounted on the microphone stand.
●Do not use microphone stands that are not recommended in this user manual. Use of the device
with other stands may result in instability causing injury.
Install the device on a microphone stand with the 5/8” mounting thread (02).
Fig. 04

9
EDGE EUA-1
Product code: D1486
5. Setup
Safety Instructions for Operation
Attention
This device must be used only for the purposes it is designed for.
This device is intended for use as an unidirectional antenna. It is suitable for indoor use. It is not suitable for
households.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Compatibility of the Device
This device can be connected:
●to the EDGE ED-1 antenna distributor,
●to the EDGE receivers or,
●to other receivers that operate in the frequency range of 470–980 MHz.
Setting the Gain Boost
Move the gain boost switch (03) to select 0 or 10 dB. The gain boost indicator (05) lights up.

10
EDGE EUA-1
Product code: D1486
Connecting the Device
Use the supplied antenna cables to connect the BNC connector OUT (04) to the antenna input
connector of the antenna distributor (or of the receiver).
The antennas receive the signal from the transmitter(s) and send it to the antenna distributor. The
antenna distributor sends the signal to each connected receiver.
The receivers, transmitters and the antenna distributor are not supplied with the device. See 3.3.
Accessories on page 7.
Fig. 05

11
EDGE EUA-1
Product code: D1486
6. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in
injuries and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the
solution is not described in the table.
Problem
Probable cause(s)
Solution
The device does not
function at all
No power to the device
●Make sure that the device is
connected to the antenna distributor
or to the receiver
Bursts of noise or other
audible signals
present
Sources of interference are present
●Identify potential sources of
interference (other RF-sources) and turn
them off
●Set the gain boost switch (03) to 0 dB
●Move the device to another place until
the sound quality is good
7. Maintenance
Preventive Maintenance
Attention
Before use, examine the device visually for any defects.
Basic Cleaning Instructions
To clean the device, follow the steps below:
Disconnect the device from the antenna distributor/ receiver.
Clean the device with a soft, lint-free cloth.
Attention
●Do not immerse the device in liquid.
●Do not use alcohol or solvents.
Corrective Maintenance
The device does not contain user-serviceable parts. Do not open the device and do not modify the
device.
Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for
more information.

12
EDGE EUA-1
Product code: D1486
8. Deinstallation, Transportation and Storage
●Use the original packaging to transport the device, if possible.
●Clean the device before storing. Follow the cleaning instructions in chapter 7.1.1. Basic Cleaning
Instructions on page 11.
●Store the device in the original packaging, if possible.
9. Disposal
Correct disposal of this product
Waste Electrical and Electronic Equipment
This symbol on the product, its packaging or documents indicates that the product
shall not be treated as household waste. Dispose of this product by handing it to the
respective collection point for recycling of electrical and electronic equipment. This
is to avoid environmental damage or personal injury due to uncontrolled waste
disposal. For more detailed information about recycling of this product contact the
local authorities or the authorized dealer.
10. Approval
Hereby, Highlite International declares that the device EDGE EUA-1, product code D1486, is in
compliance with Directive 2014/53/EU (RED –Radio Equipment Directive).
The full text of the EU declaration of conformity is available at the respective product page on the
website of Highlite International (www.highlite.com).
The DAP EDGE EUA-1 is a Class 2 wireless audio device (Commission Decision 2000/299/EC).
Frequency: 470–980 MHz
BE
BG
CZ
DK
DE
EE
IE
EL
ES
FR
HR
IT
CY
LV
LT
LU
HU
MT
NL
AT
PL
PT
RO
Sl
SK
FI
SE
Exclusion of liability
The frequency ranges available for radio transmitters differ per country and region. Consult the
respective national and/or regional authority as licensing or specific restrictions may apply for the use of
the device. We do not take any responsibility in case the device cannot operate or cannot be used in
your country/region or if it requires additional licensing. Before using the device, check the allowed
frequencies in your country or region.

13
EDGE EUA-1
Product code: D1486

14
EDGE EUA-1
Product code: D1486

©2022 DAP
