Assembly Instructions for Zennor Table
(2019 Design –Double Extension)
Parts Included
Item
Quantity
Tabletop (including fold away section)
1
Leg brace including parasol hole
1
Legs
2
50mm Bolts (for spreader bar)*
4
30mm Bolts (for table-top)*
4
Metal Parasol Ring and Cover
1
Allen key
1
Screws
4
If you discover any of the stated parts are missing or damaged, please contact Field & Hawken
customer support immediately for it to be rectified and replacements provided if required.
*Please note that you may receive a 2020 design which uses the same size bolts for spreader bar and
connecting the legs to the table-top. The assembly instructions remain the same.
Tools Required
Allen Key
1
Recommended Persons for Assembly
It is recommended that at least 2 people assemble this table.
Assembly Instructions
1. Lay the tabletop face down on some padding or protective material.
2. Assemble the leg components and spreader bar by matching the small numbered stickered
joints (E.g. A1 to A1, A2 to A2, etc.). Use the 50mm bolts to secure the spreader bar in place
and tighten using an allen key.
3. Insert the assembled leg structure into the tabletop matching any small numbered stickered
joints again. The tenon joint from the top of the legs goes inside the mortice joint in the
tabletop so that the 3 holes are aligned for the bolts to go through. Use the 30mm bolts to
secure the legs in place to the tabletop and tighten using an allen key.
4. Turn the table over and tighten any loose bolts. Do not overtighten
5. Place the metal ring and cover in the parasol hole.
6. Enjoy
7. The screws that are provided are intended to be used in the future should there be any
movement in the joints after acclimatisation of the table to the outside environment. If
required, insert the screws into the predrilled holes in the leg braces between the legs and
screw into the tabletop. It is recommended that light pressure is applied in the direction of
the arrows in the picture to ensure a tight contact when screwing in. Screw in one side first,
followed by the next.

Should you have any questions or concerns then please contact us.
Phone: [phone], Email: [e-mail]
Thank you for your purchase
Table with Extension Closed and Open
Screws
Screws
30mm
bolts
50mm bolts
30mm
bolts
