HAMPTON BAY DY9127-C User manual

THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this chaise lounge. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item #1001 857 601
Model #DY9127-C
USE AND CARE GUIDE
WOODBURY CHAISE LOUNGE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. – 6 p.m. EST, Saturday
HAMPTONBAY.COM
1-855-HD-HAMPTON
DY9127-C-R
DY9127-C-B
1001 857 574
1001 857 603

2
Table of Contents
Table of Contents..........................................................2
Warranty.........................................................................2
What is Covered .......................................................................2
What is Not Covered ................................................................2
Pre-assembly.................................................................3
Planning Assembly...................................................................3
Hardware Included...................................................................3
Package Contents ....................................................................4
Assembly ....................................................................... 5
Care and Cleaning ........................................................ 6
Warranty
THIS IS A RESIDENTIAL WARRANTY ONLY AND THIS WARRANTY DOES NOT APPLY TO
COMMERCIAL USE
WHAT IS NOT COVERED
It remains the customer's responsibility for freight and packaging charges to and from our service center.
This warranty does not cover commercial use, hardware, acts of nature, re, freezing, and abusive use.
In addition, purchased parts are not covered under this warranty. We reserve the right to make substitutions
with similar merchandise, if the model in question is no longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
YTNARRAWDETIMILCIRBAFDNAEVAEWNISERRAEY2/YTNARRAWDETIMILEMARFRAEY5
WHAT IS COVERED
for two years.

MOC.YABNOTPMAH3
.ecnatsissarehtrufrofNOTPMAH-DH-558-1tcatnocesaelP
Pre-assembly
PLANNING ASSEMBLY
Please read this entire instruction manual prior to assembly.
Identify all parts packed in the carton against the parts list. Remove all protective
materials and place the parts on a non-abrasive surface to avoid scratching.
HARDWARE INCLUDED
NOTE: Tools not shown to actual size.
_AA _BB _CC _EE
Part Description Quantity
AA M6x55mm Hex bolt 10
BB M6x45mm Hex bolt 4
CC 14
DD 14
NOTE: More than one person may be required
to complete the assembly of this product.
M6 Washer
M6x15mm Plastic spacer
M6 Hex bolt cap
EE 14
_DD
M6 Allen wrench
FF 1
_FF

4
Pre-assembly
CHAISE LOUNGE PACKAGE CONTENTS
Part Description Quantity
1Back frameA
1Left armB
1Right armC
1Seat panelD
A
B
C
D
E
F
1Back panel
E
1 Cushion F

MOC.YABNOTPMAH5
.ecnatsissarehtrufrofNOTPMAH-DH-558-1tcatnocesaelP
Assembly
1Attaching the left and right arm 2Attaching the back frame
□Attach the left arm (B) and the right arm (C) to the seat panel
(D) with the M6x55mm hex bolts (AA), washers (CC), and plastic
□Tighten all bolts and cover with bolt caps (DD).
NOTE: Please ensure all M6 hex bolts are assembled
correctly and use the M6 allen wrench (FF) to tighten.
□Attach the back frame (A) to the seat panel (D) with the M6x55mm
□Tighten all bolts with the M6 allen wrench (FF) and attach bolt caps
(DD).
□The chaise is now ready for use.
spacers (EE).
and front panel
□Attach the back panel (E) to the seat panel (D) with the M6x45
mm hex bolts (BB), washers (CC), and plastic spacers (EE).
hex bolts (AA), washers (CC), and plastic spacers (EE).
□Put the cushion (F) onto the chaise body.
DD
BB
CC EE
E
B
C
D
A
DD
AA CC EE
F
DD
AA
CC EE

6
Care and Cleaning
□Do not allow water to build up in the frames. This will cause corrosion and possible freezing damage in cold climates.
□Use a mild soap and water for normal cleaning. Do not use janitorial or alcohol based cleaners. Some cleaners may be marked as
natural, but some ingredients may cause discoloration or have an adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Treat frames with a liquid wax for maximum protection against UV rays and/or salty, damp air.

Retain this manual for future use.
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. – 6 p.m. EST, Saturday
HAMPTONBAY.COM
1-855-HD-HAMPTON
