5T LOG SPLITTER USER'S MANUAL
3
TABLE OF CONTENTS
5T LOG SPLITTER
USER'S MANUAL
TABLE OF CONTENTS
1. GENERAL SAFETY INSTRUCTIONS.....................................................................................................4
2. SAFETY INSTRUCTIONS............................................................................................................................5
3. SAFETY WARNINGS & CAUTIONS.....................................................................................................8
4. APPLICATION CONDITIONS............................................................................................................. 10
5. ELECTRICAL REQUIREMENTS............................................................................................................ 10
6. SET UP AND PREPARATION FOR OPERATION ..........................................................................11
7. ASSEMBLY....................................................................................................................................................13
8. LOG SPLITTER OPERATION .................................................................................................................15
9. FREEING A JAMMED LOG..................................................................................................................16
10. REPLACING HYDRAULIC OIL ............................................................................................................17
11. TROUBLE SHOOTING .............................................................................................................................18
12. SPECIFICATIONS.......................................................................................................................................19
13. DISPOSAL.................................................................................................................................................... 20
14. DECLARATION OF CONFORMITY...................................................................................................21

EN 4
FZLS 1005H-E
GENERAL SAFETY INSTRUCTIONS
1. GENERAL SAFETY INSTRUCTIONS
Important safety notice
Carefully unpack the product and take care not to throw away any part of the packaging before you find all
the parts of the product.
Store the product in a dry place out of reach of children.
Read all warnings and instructions. Not following warnings or instructions may lead to injury by electrical
shock, a fire and/or serious injuries.
Packaging
The product is packed in a package that prevents damage during transport. This package is a resource and so
can be handed over for recycling.
Operating instructions
Before you start working with the power tool, read the following safety and usage instructions. Understand the
operating elements and the correct use of the power tool. Keep the user’s manual in a safe place where it can be
easily retrieved for future use. Save the original packaging, including the internal packing material, warranty card
and proof of purchase receipt, at least for the duration of the warranty. If you need to ship this power tool, pack it
in the original cardboard box to ensure maximum protection during shipping or transport (e.g. when moving or
when you need to send this power tool for repair to a service centre).
Note: If you hand over the power tool to somebody else, do so together with this user's manual.
Following the instructions in the included user's manual is a prerequisite for the proper use of the power tool.
The user's manual also contains operating, maintenance and repair instructions.
The manufacturer takes no responsibility for accidents or damages resulting from not
following the instructions in this manual.

EN
5T LOG SPLITTER USER'S MANUAL
5
SAFETY INSTRUCTIONS
2. SAFETY INSTRUCTIONS
ATTENTION!
Acquaint yourself with all warnings and safety instructions and with operation instructions for the power
tool.
ATTENTION!
Not adhering to warnings or safety instructions may result in injury by electrical shock, a fire and/or serious
injury.
ATTENTION!
Store all warnings and safety instructions in a practical location for future reference.
Note: The term "power tool" in all hereafter provided warnings is defined as an electric power tool powered
from the power grid (via a flexible power cord).
Safety in the work area
Keep the work area tidy and well illuminated. Untidiness and dark locations in the workplace are sources of
accidents.
Do not use the power tool in environments where there is a explosion hazard, where there are flammable
liquids, gases or dust. The power tool generates sparks which could ignite dust or vapours.
When using the power tool, prevent children and other persons access to the power tool. If you become
distracted, you may lose control over the power tool.
Safety when working with power tools
The plug on the flexible power cord must correspond to the power socket outlet. Never modify the plug in any
way. Never use any socket adapters with power tools that have a safety earth grounding connection. Plugs
that are not damaged by modifications and that correspond to the power socket will limit the danger of injury
by electrical shock.
Prevent your body from coming into contact with grounded objects, such as pipes, central heating radiators,
stoves and refrigerators. The risk of injury by electrical shock is greater when your body is connected to the
ground.
Do not expose the power tool to rain, dampness or wetness. The entry of water into the power tool increases
the danger of injury by electrical shock.
Do not use the flexible power cord for other purposes. Never carry or pull the power tool by its power cord or
pull the plug out of the socket by the power cord. Protect the power cord against heat, grease, sharp edges
and moving parts. Damaged or tangled power cords increase the danger of injury by electrical shock.
If the power tool is used outdoors, use an extension cord suitable for outdoor use. Using extension cords
designed for outdoor use limits the risk of injury by electrical shock.
If you will be using the power tool in a damp environment, use a residual current device (RCD) in the power
supply circuit. The use of a residual current device reduces the risk of injury by electrical shock.
Note: The "residual current device" (RCD) may be substituted for by the term "ground fault circuit
interrupter" (GFCI) or "earth leakage circuit breaker" (ELCB).

EN 6
FZLS 1005H-E
SAFETY INSTRUCTIONS
Safety of people
When working with the power tool, always stay alert, watch what you are doing and use common sense.
Do not use power tools if you are tired or under the influence of drugs, alcohol or medication. A moment of
carelessness when working with power tools may result in serious injury.
Use personal protective aids. Always use eye protection. Use protective aids, e.g. respirator, safety footwear
with anti-slip soles, hard head cover or hearing protection appropriately to the work conditions; they reduce
the risk of injury to persons.
Avoid accidentally starting up the power tool. Before connecting to a power source, before connecting the
battery, before storage or before carrying the power tool, make sure that the start/stop trigger is in the off
position. Carrying the power tool with a finger on the trigger or connecting the power tool’s plug with the
trigger engaged may cause an accident.
Remove all adjustment tools and spanners before turning on the power tool. An adjustment tool or spanner
left attached to a rotating part of the power tool may result in injury to persons.
Only work in locations that you can reach safely. Always maintain a stable stance and balance.
In this way you will have better control over the power tool in unexpected situations.
Dress in an appropriate manner. Do not wear loose clothing or jewellery. Make sure that your hair, clothing
and gloves are at a sufficient distance from moving parts. Loose clothing, jewellery and long hair may
become caught in the moving parts.
If there is equipment available for the extraction and collection of dust, make sure that such equipment is
connected and used correctly. The use of such equipment may limit the danger posed by the created dust.
Using power tools and their maintenance
Do not overload the power tool. Only use power tools that are appropriate for the work being performed.
Appropriate power tools for the given task will do the job better and more safely.
Do not use power tools that cannot be turned on and off with a switch. Any electric power tools that cannot
be controlled using a switch are dangerous and must be repaired.
Before adjusting the power tool, before replacing accessories or if you will not be using the power tool, pull
the power plug out of the power socket. These preventative safety measures limit the danger of accidentally
turning on the power tool.
When not used, store the power tool out of children’s reach and do not permit person not acquainted with
the power tool or these instructions to use the power tool. A power tool in the hands of inexperienced users is
dangerous.
Perform maintenance on the tool. Check the adjustment of moving parts and their movement, focus on
cracks, broken parts or any other circumstances that may threaten the proper operation of the power tool.
If the power tool is damaged, have it repaired before using it again. Many accidents are caused by
insufficiently maintained power tools.
Keep cutting power tools clean and sharp. Correctly maintained and sharpened cutting power tools are less
likely to get stuck on material or to jam and they are also easier to control.
Use power tools, accessories, working tools, etc. in accordance with these instructions and in such
a manner as prescribed for the specific power tool with respect to the given work conditions and the type
of work being carried out. Using power tools for tasks other than for which they are designed may lead to
dangerous situations.

EN
5T LOG SPLITTER USER'S MANUAL
7
SAFETY INSTRUCTIONS
Service
Have your power tool repaired by a qualified person that will use original spare parts. In this manner, the
same level of safety will be ensured as before the repair of the power tool.
Storage
only move or store the power tool with the protective cover attached
carefully clean and perform appropriate maintenance before storing the power tool
before transporting the power tool, secure it against oil leakage, damage or injury hazard

EN 8
FZLS 1005H-E
SAFETY WARNINGS & CAUTIONS
3. SAFETY WARNINGS & CAUTIONS
SAFETY WARNINGS & CAUTIONS SYMBOL AFFIXED
TO THE MACHINE
UNDERSTAND YOUR LOG SPLITTER
Read and understand the owner’s manual and labels affixed to the log splitter. Learn
its application and limitations as well as the specific potential hazards peculiar to it.
DRUGS, ALCOHOL AND MEDICATION
Do not operate the log splitter while under the influence of drugs, alcohol, or any
medication that could affect your ability to use it properly.
AVOID DANGEROUS CONDITIONS
Put the log splitter on a 60 - 75cm high, stable, flat, and level work bench where there
is plenty of room for handling, and help the operator stay alert. Bolt the log splitter to
the work surface if it tends to slip, walk, or slide.
Keep your work area clean and well lighted. Cluttered areas invite injuries.
Do not use the log splitter in wet or damp areas or expose it to rain.
Do not use it in areas where fumes from paint, solvents or flammable liquids pose
a potential hazard.
INSPECT YOUR LOG SPLITTER
Check your log splitter before turning it on. Keep guards in place and in working
order. Form a habit of checking to see that keys and adjusting wrenches are removed
from tool area before turning it on. Replace damaged, missing or failed parts before
using it.
DRESS PROPERLY
Do not wear loose clothing, gloves, neckties or jewelry (rings, wrist watches). They
can be caught in moving parts.
Protective electrically non conductive gloves and non-skid footwear are recom-
mended when working. Wear protective hair covering to contain long hair, preventing
it from get caught in machinery.
PROTECT YOUR EYES AND FACE
Any log splitter may throw foreign objects into the eyes. This can cause permanent
eye damage. Always wear safety goggles. Everyday eyeglasses have only impact
resistant lenses. They are not safety glasses.
Do not put the log splitter on the ground for operations. This is awkward operating
position that the operator has to bring his face close to the machine, and thus risks
being struck by wood chips or debris.
EXTENSION CORDS
Improper use of extension cords may cause inefficient operation of the log splitter
which can result in overheating. Be sure the extension cord is no longer than 10m
and its section is no less than 2.5mm2 to allow sufficient current flow to the motor.
Avoid use of free and inadequately insulated connections. Connections must be
made with protected material suitable for outdoor use.

EN
5T LOG SPLITTER USER'S MANUAL
9
SAFETY WARNINGS & CAUTIONS
AVOID ELECTRICAL SHOCK
Check that the electric circuit is adequately protected and that it corresponds with the
power, voltage and frequency of the motor. Check that there is a ground connection,
and a regulation differential switch upstream.
Ground the log splitter. Prevent body contact with grounded surfaces: pipes, radia-
tors, ranges, and refrigerator enclosures.
Never open the pushbutton box on the motor. Should this be necessary, contact
a qualified electrician.
Mark sure your fingers do not touch the plug’s metal prongs when plugging or
unplugging the log splitter.
KEEP VISITORS AND CHILDREN AWAY
The log splitter must be always operated by one person only. Other people should
keep a safe distance from the work area, especially when the log splitter is under
operations. Never use another people to help you with freeing jammed log.
INSPECT YOUR LOG
Make sure there are no nails or foreign objects in logs to be split. The ends of the logs
must be cut square. Branches must be cut of flush with the trunk.
DON’T OVERREACH
Floor must not be slippery.
Keep proper footing and balance at all times.
Never stand on log splitter. Serious injury could occur if the tool is tipped or if the
cutting tools is unintentionally contacted. Do not store anything above or near the log
splitter where anyone might stand on the tool to reach them.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Always pay full attention to the movement of the log pusher.
Do not attempt to load the log on until the log pusher has stopped.
Keep hands out of the way of all moving parts.
PROTECT YOUR HANDS
Keep you hands away from splits and cracks which open in the log; They may close
suddenly and crush or amputate your hands.
Do not remove jammed logs with you hands.
DON’T FORCE TOOL
It will do a better and safer job at its design rate. Never try to split logs larger than
those indicated in the specifications table. This could be dangerous and may dam-
age the machine.
Don’t use log splitter for a purpose for which it was not intended.
NEVER LEAVE TOOL RUNNING UNATTENDED
Don’t leave tool until it has come to a complete stop.
DISCONNECT POWER
Unplug when not in use, before making adjustments, changing parts, cleaning, or
working on the log splitter; Consult technical manual before servicing.

EN 10
FZLS 1005H-E
APPLICATION CONDITIONS | ELECTRICAL REQUIREMENTS
PROTECT THE ENVIRONMENT
Take used oil to an authorized collection point or follow the stipulations in the country
where the log splitter is used.
Do not discharge into drains, soil or water.
MAINTAIN YOUR LOG SPLITTER WITH CARE
Keep the log splitter clean for best and safest performance.
MAKE THE WORKSHOP CHILDPROOF
Lock the shop. Disconnect master switches. Store the log splitter away from children
and others not qualified to use it.
4. APPLICATION CONDITIONS
This log splitter is a home use model. It is designed for operating under ambient temperatures between +5oC and
40oC and for installation at altitudes no more than 1000m above M.S.L. The surrounding humidity should less
than 50% at 40oC. It can be stored or transported under ambient temperatures between -25oC and 55oC.
5. ELECTRICAL REQUIREMENTS
Connect the main leads to a standard 230V 10% (50Hz 1Hz) electrical supply which has protection devices
of under-voltage, over-voltage, over-current as well as a residual current device (RCD) which maximum residual
current rated at 0.03A. Be sure the extension cord is no longer than 10m and the diameter of each line is no less
than 2.5mm2to allow sufficient current flow to the motor.

EN
5T LOG SPLITTER USER'S MANUAL
11
SET UP AND PREPARATION FOR OPERATION
6. SET UP AND PREPARATION FOR
OPERATION
1. Bolt the Support Leg to the Log Splitter, lift the log splitter by the handles at both ends and place it on a 60 –
75cm high, stable, flat and level work surface.
2. Familiarize yourself with the controls and features of this log splitter in the illustrations.
1. Log Pusher
2. Work Table
3. Wedge
4. Lift Handle
5. Support Leg
6. Log Retaining Plates
7. Switch
8. Motor
9. Pushbutton Box
10. Wheels for Minor Moving ONLY.
11. Hydraulic Control Lever
12. Control Lever Guard
13. Bleed Screw
14. Oil Drain Bolt w/ Dipstick
15. Max Pressure Limiting Screw
Before operating the log splitter, the Bleed Screw should be loosened by some rotations
until air can go in and out of the oil tank smoothly.
Air flow thru the Bleed Screw hole should be detectable during the log splitter is under
operations.
Before moving the log splitter, make sure the Bleed Screw is tightened to avoid oil leak-
ing from this point.
FAILED TO LOOSEN THE BLEED SCREW WILL KEEP THE SEALED AIR IN HY-
DRAULIC SYSTEM BEING COMPRESSED AFTER BEING DECOMPRESSED.
SUCH CONTINUOUS AIR COMPRESSION AND DECOMPRESSION WILL
BLOW OUT THE SEALS OF THE HYDRAULIC SYSTEM AND CAUSE PERMANT
DAMAGE TO THE LOG SPLITTER.

EN 12
FZLS 1005H-E
SET UP AND PREPARATION FOR OPERATION
DO NOT ADJUST THE MAX PRESSURE LIMITING SCREW!
Max pressure was set before the log splitter ex work and the max pressure limiting screw
is sealed with glue to ensure the log splitter works under pressure no more than rating
splitting force. The setting was done by qualified mechanic with professional instru-
ments.
Unauthorized resetting will cause the hydraulic pump fail to output enough splitting pres-
sure or RESULT IN SERIOUS INJURY AS WELL AS DAMAGE TO THE MACHINE.
WIRING DIAGRAM PLUMBING DIAGRAM

EN
5T LOG SPLITTER USER'S MANUAL
13
ASSEMBLY
7. ASSEMBLY
Connect the log catcher supporting part , supporting leg and work table with screws.
Connect the whole cover with 13 pieces of outside hex bolt M5*10,spring washers ø5 and gaskets ø5.

EN 14
FZLS 1005H-E
ASSEMBLY
Connect the cover with machine by 2pieces of outside hex bolts M8*16,gasketø8 ,lock nut M8.
4pieces of outside hex bolts M6*12,gasket ø6,lock nut M6.
Then connect the log catcher with the cover by 2 pieces of outside hex bolts M6*12,gasket ø6,lock nut M6 and 2
pieces knobs and gasket ø6.
Adjust the height of wood catcher by 2 pieces knob M6.

EN
5T LOG SPLITTER USER'S MANUAL
15
LOG SPLITTER OPERATION
8. LOG SPLITTER OPERATION
This log splitter is equipped with “ZHB” control system
that requires to be operated by both hands of the user –
Left hand controls the hydraulic control lever while right
hand controls the pushbutton switch. The log splitter
will freeze upon absence of either hand. Only after both
hands release the controls, the log pusher starts to
return backward to the starting position.
Trigger type lock-out device is adopted to avoid ac-
cidental Hydraulic Control Lever pushdown. To operate
the Hydraulic Control Lever, draw the Trigger backward
with the index finger before push the Hydraulic Control
Lever forward.
Never force the log splitter for more than 5 seconds by keeping pressure on
it to split excessively hard wood.
After this time interval, the oil under pressure will be overheated and the machine could be damaged. For such
extremely hard log, rotate it by 90oto see whether it can be split in a different direction. In any case, if you are not
able to split the log, this means that its hardness exceeds the capacity of the machine and thus that log should
be discarded to protect the log splitter.
Always set logs firmly on the log retaining plates and work table.
Make sure logs will not twist, rock or slip while being split. Do
not force the blade by splitting the log on the upper part. This will
break the blade or damage the machine.
Break log in the direction of its growing grain. Do not place log across the log splitter for splitting. It may be
dangerous and may seriously damage the machine.
Do not attempt to split 2 pieces of logs at the same time. One of them may fly up and hit you.

EN 16
FZLS 1005H-E
FREEING A JAMMED LOG
9. FREEING A JAMMED LOG
Release both controls.
After the log pusher moves back and completely stops
at its starting position, insert a wedge wood under the
jammed log.
Start the log splitter to push the wedge wood to go
completely under the jammed one.
Repeat above procedure with sharper slope wedge
woods until the log is completely freed.
Do not try to knock the jammed log off. Knock-
ing about will damage the machine or may
launch the log and cause accident.

EN
5T LOG SPLITTER USER'S MANUAL
17
REPLACING HYDRAULIC OIL
10.REPLACING HYDRAULIC OIL
Replace the Hydraulic oil in the log splitter after every 150 hours of use. Take following steps to replace it.
Make sure all moving parts stops and the log splitter is
unplugged.
Unscrew Oil Drain Bolt with Dipstick to remove it.
Turn the log splitter on the Support Leg side over an 3.5 liters
capacity container to drain the hydraulic oil off.
Turn the log splitter on the the motor side.
Refill fresh hydraulic oil at the volume as per the hydraulic oil
capacity of a particular model indicated in above specifications
table.
Clean the surface of Dipstick on the Oil Drain Bolt and put it
back into the oil tank while keep the log splitter vertically.
Make sure the level of the refilled oil is just between 2 grooves
around the Dipstick.
Clean the Oil Drain Bolt before thread them back. Make sure
they are tightened to avoid leakage before place the log splitter
horizontally.
Periodically check oil level to ensure it is between 2 grooves around the Dipstick. Upon
Lower oil level, oil refilling is required.
ATTENTION!
Only use special hydraulic oil for log splitter (for example SHEPPACH HYDRAULIC OIL ISO VG 22, 5 l )
SHELL Tellus 22
MOBIL DTE 11
ARAL Vitam GF 22
BP Energol HLP-HM 22
SHARPENING WEDGE
After using the log splitters for some time, sharpen the wedge of the log splitter using a fine-toothed file and
smooth any burrs or crushed area along the cutting edge.

EN 18
FZLS 1005H-E
TROUBLE SHOOTING
11. TROUBLE SHOOTING
PROBLEM PROBABLE CAUSE REMEDY SUGGESTED
Motor Stops to
Start.
Overload Protection Device disengaged
to protect the log splitter from being
damaged.
Contact a qualified Electrician for opening
the Pushbutton Box to engage the Over-
load Protection Device inside.*
Fails to split logs. Log is improperly positioned. Refer to “Log Splitter Operation” section
for perfect log loading.
The sizes or hardness of the log exceeds
the capacity of the machine.
Reduce the log sizes before splitting it on
the log splitter.
Wedge cutting edge is blunt. Refer to “Sharpening Wedge“ section to
sharpen the cutting edge.
Oil leaks. Locate leak(s) and contact the dealer.
Unauthorized adjustment was made on
Max. Pressure Limiting Screw. Lower max
pressure rating was set.
Contact the dealer.
The log pusher
moves jerkily, taking
unfamiliar noise or
vibrating a lot.
Lack of hydraulic oil and excessive air in
the hydraulic system.
Check oil level for possible oil refilling.
Contact the dealer.
Oil leaks around
cylinder ram or
from other points.
Air sealed in hydraulic system while
operating.
Loosen Bleed Screw by 3 4 rotations
before operating the log splitter.
Bleed Screw is not tightened before mov-
ing the log splitter.
Tighten the Bleed Screw up before moving
the log splitter.
Oil Drain Bolt with Dipstick is not tight. Tighten the Oil Drain Bolt with Dipstick.
Hydraulic Control Valve Assembly and / or
seal(s) worn.
Contact the dealer.

EN
5T LOG SPLITTER USER'S MANUAL
19
SPECIFICATIONS
12.SPECIFICATIONS
Model Number FZLS 1005H-E
Motor 230V 50Hz 2000W IP54
Log Capacity Diameter 5 25cm
Length 52cm
Splitting Force 5t
Hydraulic Oil Capacity 3L
Overall Size
Length 1320mm
Width 405mm
Height 650mm
Weight 53Kg
The diameter of the log is indicative – a small log can be difficult to split when it has knobs or a particularly tough
fiber. On the other hand, it may not be difficult to split logs with regular fibers even if its diameter exceeds the max.
figure indicated above.

EN 20
FZLS 1005H-E
DISPOSAL
13. DISPOSAL
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your municipality.
The machine and its accessories are manufactured from various materials, e.g. metal and
plastic.
Take damaged parts to a recycling centre. Inquire at the relevant government department.
Changes in the text, design and technical specifications may be made without prior notice and we reserve
the right to make these changes.
