Fike Fcp-300 User manual

P/N LS10145-002FK-E:A • ECN 151526

Document LS10145-002FK-E

3/12/2021

Addressable Fire Alarm Control Panel

FCP-300/FCP-300ECS

Installation/Operation Manual

2FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Fire Alarm & Emergency Communication System Limitations

While a life safety system may lower insurance rates, it is not a substitute for life and property insurance!

An automatic fire alarm system—typically made up of smoke

detectors, heat detectors, manual pull stations, audible warning

devices, and a fire alarm control panel (FACP) with remote

notification capability—can provide early warning of a developing fire.

Such a system, however, does not assure protection against property

damage or loss of life resulting from a fire.

An emergency communication system—typically made up of an

automatic fire alarm system (as described above) and a life safety

communication system that may include an autonomous control unit

(ACU), local operating console (LOC), voice communication, and

other various interoperable communication methods—can broadcast

a mass notification message. Such a system, however, does not

assure protection against property damage or loss of life resulting

from a fire or life safety event.

The Manufacturer recommends that smoke and/or heat detectors be

located throughout a protected premises following the

recommendations of the current edition of the National Fire Protection

Association Standard 72 (NFPA72), manufacturer's

recommendations, State and local codes, and the recommendations

contained in the Guide for Proper Use of System Smoke Detectors,

which is made available at no charge to all installing dealers. This

document can be found at http://www.systemsensor.com/appguides/.

A study by the Federal Emergency ManagementAgency (an agency

of the United States government) indicated thatsmoke detectors may

not go off in as many as 35% of all fires. While fire alarm systems are

designed to provide early warning against fire, they do not guarantee

warning or protection against fire. A fire alarm system may not

provide timely or adequate warning, or simply may not function, for a

variety of reasons:

Smoke detectors may not sense fire where smoke cannot reach the

detectors such as in chimneys, in or behind walls, on roofs, or on the

other side of closed doors.Smoke detectors also may not sense a fire

on another level or floor of a building. A second-floor detector, for

example, may not sense a first-floor or basement fire.

Particles of combustion or “smoke” from a developing fire may not

reach the sensing chambers of smoke detectors because:

• Barriers such as closed or partially closed doors, walls, chimneys,

even wet or humid areas may inhibit particle or smoke flow.

• Smoke particles may become “cold,” stratify, and not reach the

ceiling or upper walls where detectors are located.

• Smoke particles may be blown away from detectors by air outlets,

such as air conditioning vents.

• Smoke particles may be drawn into air returns before reaching the

detector.

The amount of “smoke” present may be insufficient to alarm smoke

detectors. Smoke detectors are designed to alarm at various levels of

smoke density. If such density levels are not created by a developing

fire at the location of detectors, the detectors will not go into alarm.

Smoke detectors, even when working properly, have sensing

limitations. Detectors that have photoelectronic sensing chambers

tend to detect smoldering fires better than flaming fires, which have

little visible smoke. Detectors that have ionizing-type sensing

chambers tend to detect fast-flaming fires better than smoldering

fires. Because fires develop in different ways and are often

unpredictable in their growth, neither type of detector is necessarily

best and a given type of detector may not provide adequate warning

of a fire.

Smoke detectors cannot be expected to provide adequate warning of

fires caused by arson, children playing with matches (especially in

bedrooms), smoking in bed, and violent explosions (caused by

escaping gas, improper storage of flammable materials, etc.).

Heat detectors do not sense particles of combustion and alarm only

when heat on their sensors increases at a predetermined rate or

reaches a predetermined level. Rate-of-rise heat detectors may be

subject to reduced sensitivity over time. For this reason, the rate-of-

rise feature of each detector should be tested at least once per year

by a qualified fire protection specialist. Heat detectors are designed to

protect property, not life.

IMPORTANT! Smoke detectors must be installed in the same room

as the control panel and in rooms used by the system for the

connection of alarm transmission wiring, communications, signaling,

and/or power. If detectors are not so located, a developing fire may

damage the alarm system, compromising its ability to report a fire.

Audible warning devices such as bells, horns, strobes, speakers

and displays may not alert people if these devices are located on the

other side of closed or partly open doors or are located on another

floor of a building. Any warning device may fail to alert people with a

disability or those who have recently consumed drugs, alcohol, or

medication. Please note that:

• An emergency communication system may take priority over a fire

alarm system in the event of a life safety emergency.

• Voice messaging systems must be designed to meet intelligibility

requirements as defined by NFPA, local codes, andAuthorities

Having Jurisdiction (AHJ).

• Language and instructional requirements must be clearly dissemi-

nated on any local displays.

• Strobes can, under certain circumstances, cause seizures in peo-

ple with conditions such as epilepsy.

• Studies have shown that certain people, even when they hear a

fire alarm signal, do not respond to or comprehend the meaning of

the signal.Audible devices, such as horns and bells, can have dif-

ferent tonal patterns and frequencies. It is the property owner's

responsibility to conduct fire drills and other training exercises to

make people aware of fire alarm signals and instruct them on the

proper reaction to alarm signals.

• In rare instances, the sounding of a warning device can cause

temporary or permanent hearing loss.

A life safety system will not operate without any electrical power. If

AC power fails, the system will operate from standby batteriesonly for

a specified time and only if the batteries have been properly

maintained and replaced regularly.

Equipment used in the system may not be technically compatible

with the control panel. It is essential to use only equipment listed for

service with your control panel.

Alarm Signaling Communications:

•IP connections rely on available bandwidth, which could be lim-

ited if the network is shared by multiple users or if ISP policies

impose restrictions on the amount of data transmitted. Service

packages must be carefully chosen to ensure that alarm signals

will always have available bandwidth. Outages by the ISP for

maintenance and upgrades may also inhibit alarm signals. For

added protection, a backup cellular connection is recommended.

•Cellular connections rely on a strong signal. Signal strength can

be adversely affected by the network coverage of the cellular car-

rier, objects and structural barriers at the installation location. Uti-

lize a cellular carrier that has reliable network coverage where the

alarm system is installed. For added protection, utilize an external

antenna to boost the signal.

•Telephone lines needed to transmit alarm signals from a premise

to a central monitoring station may be out of service or temporarily

disabled. For added protection against telephone line failure,

backup alarm signaling connections are recommended.

The most common cause of life safety system malfunction is

inadequate maintenance. To keep the entire life safety system in

excellent working order, ongoing maintenance is required per the

manufacturer's recommendations, and UL and NFPA standards. At a

minimum, the requirements of NFPA 72 shall be followed.

Environments with large amounts of dust, dirt, or high air velocity

require more frequent maintenance. A maintenance agreement

should be arranged through the local manufacturer's representative.

Maintenance should be scheduled as required by National and/or

local fire codes and should be performed by authorized professional

life safety system installers only. Adequate written records of all

inspections should be kept. Limit-F-2020

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 3

Installation Precautions

Adherence to the following will aid in problem-free installation with long-term reliability:

WARNING - Several different sources of power can be con-

nected to the fire alarm control panel. Disconnect all sources of

power before servicing. Control unit and associated equipment may

be damaged by removing and/or inserting cards, modules, or inter-

connecting cables while the unit is energized. Do not attempt to

install, service, or operate this unit until manuals are read and under-

stood.

CAUTION - System Re-acceptance Test after Software Changes:

To ensure proper system operation, this product must be tested in

accordance with NFPA 72 after any programming operation or

change in site-specific software. Re-acceptance testing is required

after any change, addition or deletion of system components, or after

any modification, repair or adjustment to system hardware or wiring.

All components, circuits, system operations, or software functions

known to be affected by a change must be 100% tested. In addition,

to ensure that other operations are not inadvertently affected, at

least 10% of initiating devices that are not directly affected by the

change, up to a maximum of 50 devices, must also be tested and

proper system operation verified.

This system meets NFPA requirements for operation at 0-49º C/32-

120º F and at a relative humidity 93% ± 2% RH (non-condensing) at

32°C ± 2°C (90°F ± 3°F). However, the useful life of the system's

standby batteries and the electronic components may be adversely

affected by extreme temperature ranges and humidity. Therefore, it

is recommended that this system and its peripherals be installed in

an environment with a normal room temperature of 15-27º C/60-80º

Verify that wire sizes are adequate for all initiating and indicating

device loops. Most devices cannot tolerate more than a 10% I.R.

drop from the specified device voltage.

Like all solid state electronic devices, this system may operate

erratically or can be damaged when subjected to lightning induced

transients.Although no system is completely immune from lightning

transients and interference, proper grounding will reduce susceptibil-

ity. Overhead or outside aerial wiring is not recommended, due to an

increased susceptibility to nearby lightning strikes. Consult with the

Technical Services Department if any problems are anticipated or

encountered.

Disconnect AC power and batteries prior to removing or inserting

circuit boards. Failure to do so can damage circuits.

Remove all electronic assemblies prior to any drilling, filing, ream-

ing, or punching of the enclosure. When possible, make all cable

entries from the sides or rear. Before making modifications, verify

that they will not interfere with battery, transformer, or printed circuit

board location.

Do not tighten screw terminals more than 9 in-lbs. Over-tightening

may damage threads, resulting in reduced terminal contact pressure

and difficulty with screw terminal removal.

This system contains static-sensitive components. Always

ground yourself with a proper wrist strap before handling any circuits

so that static charges are removed from the body. Use static sup-

pressive packaging to protect electronic assemblies removed from

the unit.

Units with a touchscreen display should be cleaned with a dry,

clean, lint free/microfiber cloth. If additional cleaning is required,

apply a small amount of Isopropyl alcohol to the cloth and wipe

clean. Do not use detergents, solvents, or water for cleaning. Do not

spray liquid directly onto the display.

Follow the instructions in the installation, operating, and program-

ming manuals.These instructions must be followed to avoid damage

to the control panel and associated equipment. FACP operation and

reliability depend upon proper installation.

Precau-D2-11-2017

FCC Warning

WARNING: This equipment generates, uses, and can radi-

ate radio frequency energy and if not installed and used in

accordance with the instruction manual may cause interfer-

ence to radio communications. It has been tested and found

to comply with the limits for Class A computing devices pur-

suant to Subpart B of Part 15 of FCC Rules, which is

designed to provide reasonable protection against such

interference when devices are operated in a commercial

environment. Operation of this equipment in a residential

area is likely to cause interference, in which case the user

will be required to correct the interference at his or her own

expense.

Canadian Requirements

This digital apparatus does not exceed the ClassAlimits for

radiation noise emissions from digital apparatus set out in

the Radio Interference Regulations of the Canadian Depart-

ment of Communications.

Le present appareil numerique n'emet pas de bruits radio-

electriques depassant les limites applicables aux appareils

numeriques de la classeAprescrites dans le Reglement sur

le brouillage radioelectrique edicte par le ministere des

Communications du Canada.

eVance®, Flexput®, Honeywell®, JumpStart®, and SWIFT® are registered trademarks of Honeywell International Inc. Microsoft® and Windows® are registered

trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation.

4FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Software Downloads

In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent

upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we strongly

recommend that you download the most current version of software for each product prior to commissioning any system. Contact

Technical Support with any questions about software and the appropriate version for a specific application.

Documentation Feedback

Your feedback helps us keep our documentation up-to-date and accurate. If you have any comments or suggestions about our online

Help or printed manuals, you can email us.

Please include the following information:

• Product name and version number (if applicable)

• Printed manual or online Help

• Topic Title (for online Help)

• Page number (for printed manual)

• Brief description of content you think should be improved or corrected

• Your suggestion for how to correct/improve documentation

Send email messages to:

[email protected]

or call (800)979-3453, x21 in US or (816)229-3405 international

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 5

Table of Contents

Section 1: Introduction ................................................................................................................................................... 10

1.1: System Overview.............................................................................................................................................................................................10

1.1.1: Hardware Features ................................................................................................................................................................................10

1.1.2: Network System Hardware Features ....................................................................................................................................................10

1.1.3: Software Features .................................................................................................................................................................................10

1.1.4: FCP-300ECS Features ..........................................................................................................................................................................10

1.1.5: Terms Used in this Manual...................................................................................................................................................................11

1.2: Compatible Products........................................................................................................................................................................................11

Section 2: Agency Listings, Approvals, and Requirements........................................................................................ 13

2.1: Federal Communications Commission (FCC).................................................................................................................................................13

2.2: Underwriters Laboratories (UL) ......................................................................................................................................................................14

2.2.1: Requirements for All Installations........................................................................................................................................................14

2.2.2: Central Station Fire Alarm Systems Requirements..............................................................................................................................14

2.2.3: Local Protected Fire Alarm Systems Requirements.............................................................................................................................14

2.2.4: Remote Station Protected Fire Alarm Systems Requirements .............................................................................................................14

2.2.5: Requirements for the Installation of Carbon Monoxide (CO) Detection and Warning Equipment, NFPA 720..................................14

2.2.6: NFPA Requirements.............................................................................................................................................................................14

Section 3: Installation Requirements ............................................................................................................................ 16

3.1: Inventory..........................................................................................................................................................................................................16

3.2: Environmental Specifications ..........................................................................................................................................................................16

3.3: Software Downloads........................................................................................................................................................................................16

3.4: Electrical Specifications ..................................................................................................................................................................................16

3.5: Wiring Specifications.......................................................................................................................................................................................17

3.6: Board Assembly Diagram ...........................................................................................................................................................................19

3.7: Calculating Current Draw and Standby Battery ..............................................................................................................................................19

3.7.1: Current Draw Worksheet Requirements...............................................................................................................................................19

3.7.2: Current Draw Worksheet for FIK SLC Devices...................................................................................................................................20

3.7.3: Maximum Battery Standby Load..........................................................................................................................................................23

Section 4: Control Panel Installation ............................................................................................................................. 24

4.1: Mounting the Control Panel Cabinet ...............................................................................................................................................................24

4.1.1: Preventing Water Damage ....................................................................................................................................................................24

4.1.2: Removing the FCP-300/ECS Assembly from the Housing..................................................................................................................24

4.1.3: Ethernet Connection .............................................................................................................................................................................24

4.2: AC Connection.................................................................................................................................................................................................25

4.3: Battery Power ..................................................................................................................................................................................................25

4.3.1: RBB Accessory Cabinet .......................................................................................................................................................................26

4.4: SBUS Wiring ...................................................................................................................................................................................................27

4.4.1: Calculating Wiring Distance for SBUS Modules.................................................................................................................................27

4.4.2: Wiring Configurations ..........................................................................................................................................................................29

4.5: FIK-RA100 Remote Annunciator Installation.................................................................................................................................................30

4.5.1: Mounting the FIK-RA100 ....................................................................................................................................................................30

4.5.2: Connecting the FIK-RA100 to the Panel..............................................................................................................................................33

4.6: FIK-RA1000 Remote Annunciator Installation...............................................................................................................................................33

4.6.1: Mounting the FIK-RA1000 ..................................................................................................................................................................34

4.6.2: Connecting the FIK-RA1000 to the Panel............................................................................................................................................35

4.7: FIK-RA2000 Remote Annunciator Installation...............................................................................................................................................35

4.7.1: Mounting the FIK-RA2000 ..................................................................................................................................................................36

4.7.2: FIK-RA2000 Connection to the Panel..................................................................................................................................................38

4.8: FIK-6815 Installation.......................................................................................................................................................................................38

4.8.1: FIK-6815 Connection to the Panel .......................................................................................................................................................39

4.9: FIK-5824 Serial/Parallel Interface Module Installation ..................................................................................................................................39

4.9.1: Selecting FIK-5824 Options .................................................................................................................................................................40

4.10: FIK-5880 LED I/O Module ...........................................................................................................................................................................41

4.10.1: FIK-5880 Board Layout .....................................................................................................................................................................41

4.10.2: FIK-5880 Connection to Panel ...........................................................................................................................................................42

4.10.3: LED Wiring ........................................................................................................................................................................................42

4.10.4: Dry Contact Wiring ............................................................................................................................................................................43

4.11: FIK-5865-3/FIK-5865-4 LED Annunciator Installation................................................................................................................................43

6FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Table of Contents

4.11.1: FIK-5865 Connection to Panel ...........................................................................................................................................................44

4.11.2: FIK-5865 Mounting............................................................................................................................................................................44

4.12: Configuring SBUS Modules..........................................................................................................................................................................45

4.12.1: Assigning SBUS Module IDs.............................................................................................................................................................45

4.12.2: SBUS Bandwidth Considerations.......................................................................................................................................................46

4.13: Telephone Connection ...................................................................................................................................................................................46

4.14: Notification Appliance/Auxiliary Power Circuits .........................................................................................................................................46

4.14.1: Conventional Notification Appliance .................................................................................................................................................46

4.14.2: Auxiliary Power Installation...............................................................................................................................................................48

4.15: On-Board Relays (Conventional) ..................................................................................................................................................................49

4.15.1: Trouble Relay .....................................................................................................................................................................................49

4.15.2: Programmable Relays.........................................................................................................................................................................49

4.16: Remote Station Applications .........................................................................................................................................................................49

4.16.1: Keltron Model 3158 Installation.........................................................................................................................................................49

4.16.2: City Box Connection Using the 5220 Module ...................................................................................................................................50

4.17: Using the Addressable Relay Module for City Box Connection...................................................................................................................51

4.17.1: NFPA 72 Polarity Reversal ................................................................................................................................................................52

4.17.2: Transmitter Activated by Dry Contacts..............................................................................................................................................54

Section 5: Networking..................................................................................................................................................... 55

5.1: Network System Hardware Features ...............................................................................................................................................................55

5.1.1: Networked Sites....................................................................................................................................................................................55

5.1.2: Wiring Options/Requirements to Connect Networked Panels .............................................................................................................55

5.2: Network Wiring ...............................................................................................................................................................................................55

5.3: FIK-NIC Wiring Options .................................................................................................................................................................................56

5.3.1: Fiber Loop Modules .............................................................................................................................................................................56

5.3.2: FIK-NIC Installation.............................................................................................................................................................................58

5.4: Setting the Network ID for each Panel ............................................................................................................................................................60

Section 6: Network Management ................................................................................................................................... 61

6.1: Network Diagnostics .......................................................................................................................................................................................61

6.1.1: Ping Panel .............................................................................................................................................................................................61

6.1.2: Data Network Status .............................................................................................................................................................................61

6.1.3: Voice Network Status ...........................................................................................................................................................................61

6.2: Network Programming ....................................................................................................................................................................................61

6.2.1: Learn Network ......................................................................................................................................................................................61

6.2.2: Edit Network Names.............................................................................................................................................................................61

6.2.3: Edit Panel ID.........................................................................................................................................................................................61

6.2.4: Computer Access ..................................................................................................................................................................................62

6.2.5: Access Codes ........................................................................................................................................................................................62

6.2.6: Communicator Options.........................................................................................................................................................................63

6.3: Voice Options...................................................................................................................................................................................................65

6.3.1: Edit Timers ...........................................................................................................................................................................................65

6.3.2: Edit Voice Commands..........................................................................................................................................................................65

6.4: Sync Network Options.....................................................................................................................................................................................66

6.5: Network Management Quick Reference .........................................................................................................................................................67

Section 7: Fike and SWIFT SLC Device Installation..................................................................................................... 69

7.1: List of Fike SLC Devices ................................................................................................................................................................................69

7.2: SWIFT Wireless SLC Devices ........................................................................................................................................................................69

7.3: Maximum Number of SLC Devices ................................................................................................................................................................69

7.4: Wiring Requirements for SLC Devices ...........................................................................................................................................................69

7.4.1: Wire Sizing for FIK-6815.....................................................................................................................................................................70

7.4.2: Wiring Requirements for Fike Modules...............................................................................................................................................70

7.4.3: Wiring FIK-6815 in Style 6 & 7 (Class A) Configuration ...................................................................................................................71

7.5: Addressing the Fike SLC Devices ...................................................................................................................................................................72

7.6: Addressing SD Devices ...................................................................................................................................................................................72

7.6.1: SLC Devices with DIP Switches ..........................................................................................................................................................73

7.7: WIDP-WGI Wireless Gateway ........................................................................................................................................................................73

7.7.1: Power Connections for the Gateway ....................................................................................................................................................73

Section 8: Programming Overview ................................................................................................................................ 74

8.1: JumpStart® Auto-Programming ......................................................................................................................................................................74

8.1.1: Input Points...........................................................................................................................................................................................74

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 7

Table of Contents

8.1.2: Output Points ........................................................................................................................................................................................74

8.1.3: Running JumpStart Auto-Programming...............................................................................................................................................74

8.2: Mapping Overview ..........................................................................................................................................................................................75

8.2.1: Input Point Mapping .............................................................................................................................................................................75

8.2.2: Output Circuit Mapping........................................................................................................................................................................77

8.2.3: Event Mapping.....................................................................................................................................................................................77

8.2.4: Mapping LED Points ............................................................................................................................................................................81

8.2.5: Mapping LED Points for a Networked System ....................................................................................................................................82

8.3: Programming Using the HFSS Software Suite................................................................................................................................................82

8.4: Programming Using an Annunciator ...............................................................................................................................................................82

8.4.1: Entering / Exiting the Panel Programming...........................................................................................................................................82

8.4.2: Moving through the Menus ..................................................................................................................................................................83

8.4.3: Selecting Options and Entering Data....................................................................................................................................................83

8.5: Programming Menu Quick Reference .............................................................................................................................................................83

Section 9: Programming ................................................................................................................................................. 92

9.1: UL 864 / UL 2572 Programming Requirements..............................................................................................................................................92

9.2: Modules ...........................................................................................................................................................................................................92

9.2.1: Edit Modules.........................................................................................................................................................................................92

9.2.2: Adding a Module ..................................................................................................................................................................................93

9.2.3: Deleting a Module ................................................................................................................................................................................93

9.2.4: View Module List .................................................................................................................................................................................93

9.3: Zone .................................................................................................................................................................................................................93

9.3.1: Edit Zone ..............................................................................................................................................................................................94

9.3.2: View Zone Points .................................................................................................................................................................................96

9.4: Group ...............................................................................................................................................................................................................96

9.4.1: Edit Group ............................................................................................................................................................................................96

9.4.2: View Group Points ...............................................................................................................................................................................97

9.4.3: Edit OPG Template...............................................................................................................................................................................97

9.5: Point .................................................................................................................................................................................................................98

9.5.1: Point Programming For FIK-6815 Module ..........................................................................................................................................98

9.5.2: Point Programming for the Internal or the External Power Module (FIK-RPS1000)........................................................................100

9.5.3: Point Programming For FIK-5880 or 5865 Modules .........................................................................................................................101

9.5.4: Point Programming for FIK-5496 ......................................................................................................................................................102

9.5.5: Point Programming for FIK-AMP......................................................................................................................................................102

9.5.6: Point Programming for FIK-NVCM and FIK-RVM Modules...........................................................................................................103

9.6: System Options..............................................................................................................................................................................................105

9.6.1: Communication Options.....................................................................................................................................................................105

9.6.2: Daytime/Nighttime Sensitivity ...........................................................................................................................................................108

9.6.3: Holiday Days ......................................................................................................................................................................................108

9.6.4: Time Options ......................................................................................................................................................................................109

9.6.5: Miscellaneous Options........................................................................................................................................................................109

9.6.6: Daylight Saving Options.....................................................................................................................................................................110

9.6.7: Edit Banner .........................................................................................................................................................................................110

9.6.8: SLC Family.........................................................................................................................................................................................110

9.7: JumpStart® AutoProgramming ..................................................................................................................................................................... 111

9.8: Restore Defaults............................................................................................................................................................................................. 111

9.9: Voice Options................................................................................................................................................................................................. 111

9.9.1: FIK-NVCM Maintenance...................................................................................................................................................................111

9.9.2: Voice Settings.....................................................................................................................................................................................111

Section 10: System Operation...................................................................................................................................... 112

10.1: Default User and Installer Codes .................................................................................................................................................................112

10.2: Annunciator Description ..............................................................................................................................................................................112

10.2.1: LCD Display.....................................................................................................................................................................................112

10.2.2: Banner...............................................................................................................................................................................................112

10.2.3: Single Key Acknowledge .................................................................................................................................................................113

10.3: Menu System ...............................................................................................................................................................................................113

10.3.1: Main Menu Overview.......................................................................................................................................................................113

10.3.2: Using the Menus ...............................................................................................................................................................................113

10.4: Basic Operation ...........................................................................................................................................................................................113

10.4.1: Setting Time and Date ......................................................................................................................................................................113

10.4.2: Disable / Enable a Point....................................................................................................................................................................113

8FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Table of Contents

10.4.3: View Event History ..........................................................................................................................................................................114

10.4.4: Conduct a Fire Drill ..........................................................................................................................................................................114

10.4.5: Conduct an Indicator Test.................................................................................................................................................................114

10.4.6: Conduct a Walk Test ........................................................................................................................................................................115

10.4.7: Conduct a Communicator Test .........................................................................................................................................................115

10.4.8: Manual AlarmNet Registration.........................................................................................................................................................115

10.4.9: Silence Alarms or Troubles ..............................................................................................................................................................115

10.4.10: Reset Alarms...................................................................................................................................................................................115

10.4.11: Check Detector Sensitivity Through Point Status ..........................................................................................................................116

10.4.12: View Status of a Point ....................................................................................................................................................................116

10.4.13: View Alarms or Troubles ...............................................................................................................................................................116

10.4.14: System Information ........................................................................................................................................................................116

10.5: Event Priority..............................................................................................................................................................................................117

10.5.1: System Control .................................................................................................................................................................................117

10.5.2: System Override ...............................................................................................................................................................................117

10.5.3: Event Priority....................................................................................................................................................................................117

10.5.4: Priority Rules ....................................................................................................................................................................................118

10.5.5: Other Priority Considerations ...........................................................................................................................................................118

10.6: Operation Mode Behavior ...........................................................................................................................................................................118

10.6.1: Multi-Site Annunciator and Multi-Site User Access........................................................................................................................121

10.7: Releasing Operations ...................................................................................................................................................................................121

10.7.1: Single Interlock Zone Releasing.......................................................................................................................................................122

10.7.2: Double Interlock Zone Releasing .....................................................................................................................................................123

10.8: Smoke Alarm Verification ...........................................................................................................................................................................124

10.9: Function Keys .............................................................................................................................................................................................124

10.9.1: Recording an F-Key Macro ..............................................................................................................................................................124

10.9.2: Aborting an F-Key Macro Recording Session..................................................................................................................................124

10.9.3: Erasing an F-Key Macro...................................................................................................................................................................124

10.9.4: Using a Recorded F-Key Macro .......................................................................................................................................................124

10.9.5: F-Key Status Event ...........................................................................................................................................................................124

10.9.6: F-Key Map Inhibit ............................................................................................................................................................................124

Section 11: Emergency Communication System Operation ..................................................................................... 125

11.1: Overview......................................................................................................................................................................................................125

11.2: LOC Functionality .......................................................................................................................................................................................125

11.2.1: Keys and LEDs .................................................................................................................................................................................125

11.2.2: Gaining ECS Control........................................................................................................................................................................126

11.2.3: Manual ECS......................................................................................................................................................................................126

11.2.4: Microphone Mode ............................................................................................................................................................................127

11.2.5: Message Mode ..................................................................................................................................................................................127

11.2.6: Custom ECS Event ...........................................................................................................................................................................127

11.2.7: Passing ECS Control.........................................................................................................................................................................127

11.2.8: Exit ECS Control Menu....................................................................................................................................................................128

11.2.9: Relinquish ECS Control ...................................................................................................................................................................128

11.2.10: ECS Reset .......................................................................................................................................................................................128

11.3: ECS Super User ...........................................................................................................................................................................................128

11.4: ECS Point Functionality ..............................................................................................................................................................................128

11.4.1: ECS Point Activations ......................................................................................................................................................................128

11.4.2: FIK-NVCM & FIK-RVM Points......................................................................................................................................................129

11.5: Amplifier Programming...............................................................................................................................................................................129

11.5.1: Adding an Amplifier.........................................................................................................................................................................129

11.5.2: Editing an Amplifier .........................................................................................................................................................................129

11.6: LOC Programming.......................................................................................................................................................................................129

11.6.1: Adding an LOC.................................................................................................................................................................................129

11.6.2: Editing an LOC.................................................................................................................................................................................130

11.7: Using the Microphone..................................................................................................................................................................................130

11.7.1: Microphone Functionality ................................................................................................................................................................130

11.7.2: Custom ECS Event ...........................................................................................................................................................................130

11.7.3: Fire Page ...........................................................................................................................................................................................130

11.8: Recording Custom Messages.......................................................................................................................................................................131

11.8.1: Recording Messages 1-15 Using Aux Audio Input..........................................................................................................................132

11.8.2: Recording Messages 1-15 Using the Microphone............................................................................................................................133

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 9

Table of Contents

11.8.3: Erasing User Message.......................................................................................................................................................................134

11.8.4: Using HFSS Voice Message Load Software ....................................................................................................................................134

11.9: Network Paging ...........................................................................................................................................................................................135

Section 12: Reporting ................................................................................................................................................... 136

12.1: Receivers Compatible with the Control Panel.............................................................................................................................................136

12.2: SIA - FCP-300/ECS Panels PI Modifier Contact Reporting: ......................................................................................................................143

12.3: SIA – Panel Communicator: ........................................................................................................................................................................144

Section 13: Testing and Troubleshooting................................................................................................................... 145

13.1: Troubleshooting ...........................................................................................................................................................................................145

13.2: Event History ...............................................................................................................................................................................................146

13.3: Built-in Troubleshooting and Testing Tools ................................................................................................................................................146

13.3.1: SLC Device Locator .........................................................................................................................................................................146

13.3.2: SLC Multiple Device Locator ..........................................................................................................................................................146

13.3.3: I/O Point Control ..............................................................................................................................................................................147

13.3.4: Earth Fault Resistance ......................................................................................................................................................................147

Section 14: Installation Records .................................................................................................................................. 148

14.1: Detector and Module Point Record .............................................................................................................................................................148

14.2: Conventional Output Point Record..............................................................................................................................................................150

Appendix A: Compatible Devices ............................................................................................................................... 151

A.1: Notification Appliances ................................................................................................................................................................................151

A.1.1: Two Wire Detectors...........................................................................................................................................................................158

A.2: Four-Wire Smoke Detectors/Devices (UL Listed)........................................................................................................................................159

A.3: Door Holders (UL Listed).............................................................................................................................................................................161

A.4: Relays (UL Listed)........................................................................................................................................................................................161

A.5: Compatible 520Hz Signaling Speakers ........................................................................................................................................................162

A.6: Compatible 520Hz Low Frequency Bases....................................................................................................................................................162

Appendix B: Editing Text Using the Built-In Programmer......................................................................................... 163

B.1: Characters Used for Editing Text ..................................................................................................................................................................163

B.2: Example Name Edit ......................................................................................................................................................................................163

Appendix C: Expanded Receiver/Panel Relationship ................................................................................................ 164

Appendix D: Cadence Patterns .................................................................................................................................... 165

Appendix E: Panel Security.......................................................................................................................................... 166

10 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Section 1: Introduction

The Fike® Series, FCP-300 (red) and FCP-300ECS (red) panels are Analog Addressable Fire Alarm Control Panels (FACP), that com-

ply with the requirements of the UL 864 Standard.

The FCP-300ECS is an intelligent fire alarm control panel combined with an Emergency Communication System that meets the require-

ments for Mass Notification as described in UL 864 and UL 2572 Standards.

1.1 System Overview

The FCP-300 base System is an Addressable System with a built-in annunciator that can also be used to program the System.

If you have a question or encounter a problem not covered in this manual, contact Fike Customer Service listed below:

1.1.1 Hardware Features

• The basic FCP-300/ECS panel contains one built-in Signaling Line Circuit (SLC), which supports up to 159 Fike sensors and 159

Fike modules or devices. Additional SLC loops can be added to increase the overall point capacity.

• Additional FIK-6815 SLC expanders supports 159 Fike sensors and 159 Fike modules for a maximum of 300 points per FCP-

300/ECS control panel.

• 6.0A of the output power is available through 4 sets of terminals for notification appliance circuits or auxiliary applications.

Each circuit is power-limited per UL 864 and can source up to 3.0A (total output power for all 4 circuits must not exceed 6.0A).

The constant auxiliary power load must not exceed 3A for normal standby.

• Built-in dual phone line, digital alarm communicator/transmitter (DACT), IP or optional technologies.

• Reports events to the Central Station by point or by zone.

• UL Listed for pre-action and deluge Releasing Systems.

• Two general purpose Form C programmable relays.

• One Form C Trouble Relay.

• Can be used with up to 16 Models: FIK-RA100, FIK-RA1000R, FIK-2000 Remote Annunciators in any combination (sold

separately).

• Can be used with Models: FIK-5865-3, FIK-5865-4, and FIK-5880 in any combination for a total of eight devices on one control

panel. See Sections 4.11 and Section 4.12 for additional information on these models.

• Printing of the Event Log is available through the Model FIK-5824 Serial/Parallel Printer Interface Module.

• 250 software zones and 250 output groups.

• Add six Flexput® circuits with each FIK-RPS1000 power supply.

• Add four NAC circuits with each FIK-5496 NAC expander.

1.1.2 Network System Hardware Features

• The default network setup can contain up to 32- FCP-300 panels connected.

• Network support for up to 32 sites.

• Each building is referred to as a “site”.

• Panels can be interconnected using a Class B or Class A topology.

• To network panels together, use the FIK-NIC network card. Copper wire or fiber-optic cable panel connectivity can be used within

the same networked System.

• The network architecture provides true peer-to-peer capability allowing network survivability for all hardware that remains

operational in the event of partial System failure.

1.1.3 Software Features

• Advanced smoke detector features:

– Automatic drift compensation

– Automatic day/night sensitivity adjustment

– Maintenance alert region

– Point status complies with the calibrated smoke test requirements for NFPA 72

• “JumpStart®” feature for easy programming

• The non-volatile Event History stores 1000 events

• Offers a choice of output patterns available for notification outputs, including ANSI 3.41 temporal signal

• Built-in synchronization appliance support for AMSECO, Gentex®, System Sensor®, and Wheelock®

1.1.4 FCP-300ECS Features

• Can select Fike Series, ECS message as priority over fire alarm

• 15 recordable messages that can be mapped to eight Fike Series, ECS buttons

• Supports up to seven FIK-LOC’s

• Support for one FIK-NVCM

Phone: 800-979-FIKE (3453) or 816.229.3405

Website: www.fike.com

Address: Fike Corporation

704 SW 10th Street

Blue Springs, MO 64015

NOTE: The System can have a maximum of 16 Intelligent Power Modules, FIK-5496 or FIK-RPS1000, combined.

Compatible Products Introduction

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 11

• Programmable trigger inputs from an external source, such as a Monaco System, to either the FIK-NVCM, FIK-RVM,

FIK-5880 or any SLC input module.

• Fire alarm and Fike Series, ECS combined in one easy to program System

• Supports up to eight FIK-50W, FIK-125W, FIK-INT50W, or FIK-DUAL50W Addressable Amplifiers for a maximum of

1000 watts per System

• Support for dual channel and backup audio using the FIK-DUAL50W amplifier and FIK-50WBU back-up amplifier.

1.1.5 Terms Used in this Manual

The following terminology is used with the FCP-300/FCP-300ECS System:

1.2 Compatible Products

The chart below lists the products available from Honeywell for use with the FCP-300.

Term Description

SLC Signaling Line Circuit

Module The term module is used for all hardware devices except for the SLC addressable devices

and the notification appliances. This includes the FCP-300 panel itself.

Input Point An addressable sensing device, such as a smoke, a heat detector or a contact monitor

device.

Input Zone A protected area made up of input points.

Output Point (or Output Circuit) A notification point or circuit used for notification appliances. The relay circuits and auxiliary

power circuits are also considered output points.

Output Group (OPG) A group of output points. The operating characteristics are common to all output points in the

group.

Output (or “Cadence”) Pattern The pattern that the output will use. For example, Constant, March Code, ANSI 3.41. applies

to zones and special System events.

See “Cadence Patterns” on page 210 for additional information.

Mapping Mapping is the process of specifying which outputs are activated when certain events occur in

the System. Section 8.2 explains the mapping in detail.

Fike Series, ECS Emergency Communication System

Networking Up to 32 panels can be networked.

Network System Consist of any combination of 32 panels of these model numbers:

FCP-75, FCP-300, FCP-300ECS, FCP-2100 or FCP-2100ECS.

SWIFT Smart Wireless Integrated Fire Technology

Table 1.1 Terminology

Type of Device Model Description

FIKE Addressable SLC Devices See Section 7.1 for a list of compatible devices

SWIFT Wireless SLC Devices See Section 7.4 for a list of compatible devices

Other Modules

FIK-5824 Serial/Parallel

Printer Interface Module Allows a printer to be attached to the System for the on-site event logging.

Connect a maximum of four printers per System.

FIK-6815 SLC Expander Supports the System Sensor Devices (Fike) only.

Each FIK-6815 supports up to 159 Fike sensors and 159 Fike modules.

The maximum point count is 300 per panel.

FIK-RPS1000 (Rev F or higher)

Intelligent Power Supply Provides additional power, six Flexput®

circuits, and two Form C relays. FIK-RPS1000s and FIK-5496s can

be used in any combination, up to a

total of 16 on one SystemFIK-5496 (Rev F or above) NAC

Expander Add 4 Notification/Auxiliary power circuits

with each FIK-5496 Intelligent Power

Module

RA-2000 Remote LCD

Annunciator 4x 40 Remote LCD annunciator, can be used in any combination, up to a total of

16 devices on one panel.

FIK-RA100 Remote LCD

Annunciator 4 x 20 Remote LCD annunciator, can be used in any combination, up to a total

of 16 devices on one panel.

Other Modules

FIK-RA1000 and

FIK-RA1000R Remote LCD

Annunciator

4 x 20 Remote LCD annunciator, can be used in any combination, up to a total

of 16 devices on one panel.

FIK-RA100TR Trim Ring Kit Trim ring kits for surface mounting the FIK-RA1000 annunciator. 5860TR is red.

FIK-FIK-5865-3 and FIK-5865-4

LED Annunciator LED annunciator can display up to 30 LEDs

(15 red and 15 yellow). FIK-5865-4 has key

switches for silence and reset, and a

System trouble LED. FIK-5865-3, FIK-5865-4, and FIK-

5880 can be used in any

combination, up to a total of eight

devices on one panel.

FIK-5880 (Rev C or above) LED

I/O Module Driver for up to 40 LEDs. Interfaces with

customized annunciator boards. In addition

the FIK-5880 has eight generic switch input

points.

Table 1.2 FCP-300 Compatible Products

12 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Introduction Compatible Products

FIK-5883General PurposeRelay

Module Provides 10 Form C relays. Designed to be driven by the FIK-5880. Up to four,

FIK-5883s can be used with each FIK-5880 module.

FIK-NVCM Network Voice Control Module Refer to the Fike, ECS Series

Installation Manual P/N LS10262-

001FK-E for more information on

these accessories.

FIK-SW24 24 switch expander

FIK-50W 50 watt audio amplifier

FIK-125W 125 watt audio amplifier

FIK-CE4 Provides 4 additional audio circuits for the

FIK-50W or FIK-125W.

FIK-RVM Remote Voice Module

FIK-DUAL50W Dual Channel amplifier

FIK-50WBU Backup daughter card

FIK-INT50W 50 wall internal amplifier

FIK-LOC Local Operating Console Refer to LS10187-001FK-E

FIK-NIC Network Interface Card Refer to LS10172-001FK-E

Wireless

FIK-W-WGI Wireless Gateway

Refer to the SWIFT wireless

Installation Manual P/N LS10036-

FK-E for more information on these

accessories.

FIK-W-PHOTO Wireless Photoelectric Smoke Detector

with 4" base

FIK-W-ACCLIMATE Wireless Multi criteria photoelectric smoke

detector with thermal (135°F) with 4" base

FIK-W-HEAT-ROR Wireless Heat Rate of Rise Detector 135°

fixed with 4” base

FIK-W-HEAT Wireless Heat, 135° fixed Heat Detector

with 4” base

FIK-W-MONITOR Wireless Addressable Monitor module

FIK-W-RELAY Wireless Addressable Relay module

B210W 6" wireless base

FIK-W-WGI Wireless Gateway

Refer to the SWIFT wireless

Installation Manual P/N LS10036-

FK-E for more information on these

accessories.

FIK-W-PHOTO Wireless photo with 4" base

FIK-W-PHOTO-T Wireless Multi criteria photoelectric smoke

detector with thermal (135°F) with 4" base

FIK-HEAT-ROR Wireless heat, ROR/ 135° fixed with 4"

base

FIK-W-HEAT Wireless Heat, 135° fixed with 4" base

FIK-W-MONITOR Wireless monitor module

FIK-W-RELAY Wireless relay module

B210W 6" wireless base

Miscellaneous

HFSS Programming Tool For communication and panel programming with a Windows-based computer.

Enables remote viewing of detector status and event history.

7860 Telephone Cord RJ31X cord for connecting phone line to the FCP-300.

RBB Remote Battery Box for mounting backup batteries that are too large to fit into

the main control panel cabinet. Dimensions: 16" W x 10" H x 6" D (40.64 cm W x

25.4 cm H x 15.24 cm D).

Type of Device Model Description

Table 1.2 FCP-300 Compatible Products (Continued)

Federal Communications Commission (FCC) Agency Listings, Approvals, and Requirements

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 13

Section 2: Agency Listings, Approvals, and Requirements

2.1 Federal Communications Commission (FCC)

The following information must be provided to the Telephone Company before the FCP-300 can be connected to the phone

lines:

This equipment complies with Part 68 of the FCC Rules and the Requirements adopted by ACTA. On the inside cover of this

equipment is a label that contains, among other information, a product identifier. If requested, this information must be pro-

vided to the Telephone Company.

A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable

FCC Part 68 Rules and Requirements adopted by the ACTA. A compliant telephone cord (not provided) and modular jack

must be used with this product. It is designed to be used with a modular jack that is also compliant.

The REN (ringer equivalence number) provided on this document is used to determine the number of devices that may be con-

nected to the Public Switched Telephone Network. This number must not exceed 5.0. Since this product has an REN of 1.0A,

the number of devices is limited. The REN number is embedded in the FCC registration number as 10A.

If the FCP-300 or FCP-300ECS causes harm to the Telephone Network, the Telephone Company will notify you in advance

that the Service may be required to be temporarily discontinued. However, if advance notice is not practical, the Telephone

Company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC

if you believe it is necessary.

The Telephone Company may make changes in its facilities, equipment, operations or procedures that could affect the opera-

tion of the equipment. If this occurs, the Telephone Company will provide advance notice in order for you to make necessary

modifications to maintain uninterrupted service.

If a trouble event is experienced with the FCP-300 or FCP-300ECS, for repair or warranty information, please contact Fike

Customer Service at 800-979-3453 (Fike) or www.fike.com.

If the equipment is causing harm to the telephone network, the Telephone Company may request that you disconnect the FCP-

300 until the problem is resolved.

This product cannot be adjusted or repaired in the field. It must be returned to the factory for service.

This equipment is not designed for use with party line service. The connection to the party line service is subject to state tariffs.

You may contact the State Public Utility Commission, Public Service Commission or Corporation Commission for informa-

tion.

Since the FCP-300 or FCP-300ECS are commercial fire alarm panels, they must be connected upstream of all other equipment

using the phone lines. If you have questions about the installation, contact your Telephone Company or a qualified installer.

AManufacturer: Fike Corporation

BModel Number: FCP-300 and FCP-300ECS

CFCC registration number: US: HS9AL10A2100

Ringer equivalence: 1.0A

DType of jack: RJ31X

EFacility Interface Codes: Loop Start: 02LS2

FService Order Code: 9.0F

WARNING: This device has been verified to comply with FCC Rules Part 15. Operation is subject to the

following conditions: (1) This device may not cause radio interference, and (2) This device must accept any

interference received, including interference that may cause undesired operation.

CAUTION 1: To ensure proper operation, this equipment must be installed according to the enclosed installation

instructions. To verify that the equipment is operating properly and can successfully report an alarm, this equipment

must be tested immediately after installation, and periodically thereafter, according to the enclosed test

instructions.

CAUTION 2: In order for “Alarm Dialing Equipment” to be able to seize the phone line to report an alarm or other

event when other customer equipment (telephone, answering System, computer modem, etc.) connected to the

same line are in use, the “Alarm Dialing Equipment” must be connected to a properly installed RJ31X jack.

The RJ31X jack must be connected in series (sequentially) with, and ahead of, all other equipment attached to the

same phone line. The Series installation of an RJ31X jack is depicted in the figure below. If you have any questions

concerning these instructions, you should consult your Telephone Company or a qualified installer about installing

the necessary jack and alarm dialing equipment for you.

14 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Agency Listings, Approvals, and Requirements Underwriters Laboratories (UL)

2.2 Underwriters Laboratories (UL)

2.2.1 Requirements for All Installations

The general requirements are described in this section. When you install an individual device, refer to the specific section of

the manual for information on the additional requirements. The following subsections list specific requirements for each type

of installation (for example, Central Station Fire Alarm Systems, Local Protected Fire Alarm Systems, and so on). See Section

10.6 for information on the Releasing operation.

1. All field wiring must be installed in accordance with NFPA 70 National Electric Code.

2. Use the addressable smoke detectors specified in Section 7 of this manual and or conventional detectors listed in the

compatibility chart. (See Appendix A.)

3. Use UL listed notification appliances compatible with the FCP-300 that are listed in the Appendix A.

4. A full System checkout must be performed any time the panel is programmed.

Restricted Options:

• The loss of AC signal is defaulted to 3 hours. However, the System allows settings from 0 - 3 hours. For UL certified

installations, this number must be set from 1 to 3 hours.

• The System allows the use of non-latching spot type smoke detectors. This feature may not be used in commercial

applications, whereby a general alarm is sounded. It is intended for use with elevator recall, door holding applications,

and hotel/motel room applications.

• The System allows the Alarm Verification time to be set from 60 to 250 seconds. For UL certified installations, the setting

must be a minimum of 60 seconds.

• The System allows the Auto-resound time to be set to 24 or 4 hours. For UL certified installations that are using SWIFT®

devices, the value must be set to 4 hours.

• Call forwarding shall not be used.

• When two count is used, the detector spacing shall be cut in half. You shall not use the alarm verification feature, and no

delay shall be used.

• P.A.S(Positive Alarm Sequence) feature shall be used only with automatic detectors.

2.2.2 Central Station Fire Alarm Systems Requirements

1. Use both phone lines. Enable phone line monitors for both lines.

2. You must program a phone number and a test time so that the FCP-300/ECS shall automatically initiate and complete a

test signal transmission sequence to its associated receiver at least once every 6 hrs. The AC Loss Hours option must be

set from 1-3 hours.

3. If you use a wired Ethernet, you must program the corresponding Account/Subscriber ID and a test time, so that the

FACP shall automatically initiate a test signal transmission sequence to its associated receiver at least once every 6 hours.

2.2.3 Local Protected Fire Alarm Systems Requirements

At least one UL listed supervised notification appliance must be used.

2.2.4 Remote Station Protected Fire Alarm Systems Requirements

The minimum System requirements are as follows:

• One Fike Addressable Initiating Device

• The 5220, Keltron 3158 or the built-in Digital Alarm Communicator Transmitter (DACT)

• Do not exceed the current load restrictions shown in Section 3.7.5.

• The AC Loss Hours option must be set from 1-3 hours.

2.2.5 Requirements for the Installation of Carbon Monoxide (CO) Detection and Warning

Equipment, NFPA 720

When you use the Carbon Monoxide Detection, the System must be monitored by a Supervising Station.

2.2.6 NFPA Requirements

The following are the minimum configuration to comply with the NFPA requirements.

Model/Module Description Local Releasing Remote

Station Auxiliary Central

Station

Emergency

Signaling

FIK-6861BIA 4 x 40 display Y Y Y Y Y Y

FIK-6815 SLC Expander O O O O O O

FIK-NIC Network card O O O O O O

FIK-FML/ FIK-FSL Fiber module O O O O O O

7644 Pol Rev device N N Y N N N

5220 City tie, Pol. Rev Device N N Y Y N N

Keltron 3158 Rev Pol Module N N Y Y N N

Table 2.1 NFPA Requirements for the FCP-300

Underwriters Laboratories (UL) Agency Listings, Approvals, and Requirements

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 15

Y = YES, N = NO, O = OPTIONAL

1. When configured for the Emergency Relocation and the Evacuation Equipment, the System must meet the Local

configuration Model FCP-300) with a minimum of one amplifier (Model FIK-50W/FIK-125W or FIK-INT50W) .

Model/Module Description Local Releasing Remote

Station Auxiliary Central

Station

Emergency

Signaling

Table 2.1 NFPA Requirements for the FCP-300 (Continued)

Model/Module Description CS Local Auxiliary Remote

Station EVAC5Mass Notification

(In-Building)5

FIK-50W 50W Amp1OOO O Y YO

FIK-50WHV 50W Amp1OOO O Y Y

FIK-125W 125W amp1OOO O Y Y

FIK-125WHV 125W Amp1OOO O Y Y

FIK-INT50W Internal 50W1Amp OOO O Y Y

FIK-SW24 Switch annunciator O O O O O Y

FIK-CE4 Speaker expander mod3OOO O O O

FIK-6815 SLC Expander O O O O O O

FIK-NVCM Network Voice Card O O O O O O

FIK-NIC Network Card O O O O O O

FIK-FML / FIK-FSL Fiber Module O O O O O O

Y = YES, N = NO, O = OPTIONAL

1. A maximum of eight 50/125 WattsAmplifiers for a maximum of 1000 Watts per the Fike Series, ECS System.

2. A maximum of one Voice Control Module per the Fike Series, ECS System.

3. A maximum of one Speaker Expander Module per Model FIK-50W/FIK-125W.

4. A maximum of two Remote Microphone modules per the Fike Series, ECS System.

5. When the System is configured for the emergency relocation and evacuation equipment, the System must comply with the

Local configuration (i.e., Model FCP-300) with a minimum of one amplifier (i.e., Models: FIK-50W/FIK-125W, or

FIK-INT50W).

Table 2.2 NFPA Requirements for FCP-300ECS

16 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Section 3: Installation Requirements

This Section of the manual is intended to be used to help you plan your tasks to facilitate a smooth installation. Please read this section

thoroughly, especially if you are installing a FCP-300ECS panel for the first time.

3.1 Inventory

When an FCP-300ECS shipment is received, check that all the parts are included in the shipment. The shipment consists of one of each

of the following:

• main circuit board with the display

• backbox with the door

• plastic bag containing two keys, screws, cables, and ten 4.7k ohm end-of-line resistors

• manual

3.2 Environmental Specifications

It is important to protect the FCP-300 control panel from water. To prevent water damage, the following precaution should be FOL-

LOWED when you install the units:

• Mount the panel indoors in dry locations only.

• Do not mount the panel directly on exterior walls, especially masonry walls (condensation).

• Do not mount the panel directly on exterior walls below grade (condensation).

• Protect the panel from plumbing leaks.

• Protect the panel from splash caused by the sprinkler System inspection ports.

• Do not mount the panels in areas with humidity-generating equipment (such as, dryers, production machinery).

When you select a location to mount the FCP-300 control panel, the unit should be mounted where it will NOT be exposed to tempera-

tures outside the range of 0°C-49°C (32°F-120°F) or humidity not exceeding 93% non-condensing.

3.3 Software Downloads

In order to supply the latest features and functionality in the fire alarm and the life safety technology to our customers, we make frequent

upgrades to the embedded software in our products. To ensure that you install and program the latest features, we strongly recommend

that you download the most current version of software for each product prior to commissioning any System. Contact the Technical Sup-

port with any questions about software and the appropriate version for a specific application. Software updates can be found at

www.fike.com.

3.4 Electrical Specifications

Table 3.1 lists the terminal block on the FCP-300 as well as a description of each of the individual terminals and their respective electri-

cal rating.

Terminal No. Label Description Rating

Group Individual Voltage Current

Terminal Block 1 TELCO 1 RING Phone Line 1 Telco Ring

TIP Phone Line 1 Telco Tip

PHONE 1 RING Phone Line 1 Phone Ring

TIP Phone Line 1 Phone Tip

TELCO 2 RING Phone Line 2 Telco Ring

TIP Phone Line 2 Telco Tip

PHONE 2 RING Phone Line 2 Phone Ring

TIP Phone Line 2 Phone Tip

Terminal Block 2 SLC IN – Used for Class A installations 32 VDC 150 mA

SLC OUT – SLC terminals 32 VDC 150 mA

SLC PROG – Used for programming SLC

Detectors 32 VDC 150 mA

Terminal Block 3 SBUS Out B SBUS Communication 5 VDC 100 mA

+ SBUS Power 24 VDC 1.0 A

–

Terminal Block 4 BATTERY + To Positive battery terminal 24 VDC Up to 35 Ah (see Section

“Battery Power” on page 37

for details)

– To Negative battery terminal

Terminal Block 5 AC INPUT B AC input (hot) 120 VAC, 60 Hz 3.3 A

Earth Earth Ground N/A N/A

W AC input (neutral) 120 VAC, 60 Hz 3.3 A

Table 3.1 Terminal Descriptions and Electrical Specifications

Wiring Specifications Installation Requirements

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 17

3.5 Wiring Specifications

The induced noise (transfer of electrical energy from one wire to another wire) can interfere with the telephone communication

or cause false alarms. To avoid induced noise, follow these guidelines:

• Isolate the input wiring from the high current output and the power wiring. Do not pull one multi-conductor cable for the

entire panel. Instead, separate the wiring as follows:

• Do not pull the wires from the different groups through the same conduit. If you must run them together, do so for as short

a distance as possible, or use the shielded cable. Connect the shield to the earth ground at the panel. You must route the

high and the low voltages separately.

• Route the wiring around the inside perimeter of the cabinet. It should not cross the circuit board, where it could induce

noise into the sensitive microelectronics or pick-up unwanted RF noise from the high speed circuits. See Figure 3.1 for an

example.

• High frequency noise, such as that produced by the inductive reactance of a speaker or bell, can also be reduced by

running the wire through ferrite shield beads or by wrapping it around a ferrite toroid.

Terminal Block 6 TROUBLE NC Normally closed relay contact 24 VDC 2.5 A, resistive

COM Common terminal

NO Normally open relay contact

RELAY 1 NC Normally closed relay contact 24 VDC 2.5 A, resistive

COM Common terminal

NO Normally open relay contact

RELAY 2 NC Normally closed relay contact 24 VDC 2.5 A, resistive

COM Common terminal

NO Normally open relay contact

NAC1* – Notification Appliance

Circuit/Auxiliary power 24 VDC 3.0 Amp NAC or Aux power

NAC2* – Notification Appliance

Circuit/Auxiliary power 24 VDC 3.0 Amp NAC or Aux power

NAC3* – Notification Appliance

Circuit/Auxiliary power 24 VDC 3.0 Amp NAC or Aux power

NAC4* – Notification Appliance

Circuit/Auxiliary power 24 VDC 3.0 Amp NAC or Aux power

P8 EXT. Comm B input 0Ω

S+ 55 mA, 95 mA

S-

P7 Voice Network Used For FIK-NVCM 24 VDC 59 mA

P10 Data Network Used for FIK-NIC 24 VDC 21 mA

Note: * Regulated/special application when used for releasing.

Terminal No. Label Description Rating

Group Individual Voltage Current

Table 3.1 Terminal Descriptions and Electrical Specifications (Continued)

High voltage AC power terminal

SLC loops SLC In/Out Terminals

POTS reporting input/output Phone line circuits, Ring Tip Telco, Phone Terminals

Notification circuits I/01-I/04Terminals

SBUS SBUS In Terminals

Relay circuits Trouble, Relay 1, Relay 2 Terminals

Table 3.2 Wiring Specifications

18 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Installation Requirements Wiring Specifications

Figure 3.1 Wire Routing Example for FCP-300

Figure 3.2 Wire Routing the FCP-300/ECS Example

Relay Outputs

NAC/Aux Power

Outputs

SBUS Devices

Phone Lines

SLC IN/OUT

AC Power

Input

Note: 1/4” spacing must be

maintained between each

of these circuit types; as well

as between power-limited

and non-power-limited circuits.

SLC

Phone Lines

AC Power Input

SBUS

Devices

In/Out

Relay Outputs

NAC/Aux Power

Outputs

Battery Battery

Note: 1/4” spacing must be

maintained between each of

these circuit types, and

between the power-limited

and non-power-limited

circuits.

Board Assembly Diagram Installation Requirements

FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 19

3.6 Board Assembly Diagram

Figure 3.3 Model FCP-300 Assembly

Figure 3.3 shows the circuit board that attaches the FCP-300 assembly to the cabinet. If you need to remove the board assem-

bly for repair, remove the nine mounting screws (six on the main circuit board, and three on the heat-sink) which secure the

assembly in the cabinet. Then, lift the entire assembly out of the cabinet.

3.7 Calculating Current Draw and Standby Battery

Use this Section to determine the current draw and the standby battery needs if you use the FIK addressable devices

(Table 3.3).

3.7.1 Current Draw Worksheet Requirements

The following steps must be taken when you determine the FCP-300 current draw and the standby battery requirements.

1. Use the Current Draw Worksheet to determine the current draw and the standby battery requirements. Use Table 3.3 if

you install the FIK SLC Devices to determine the current draw. For the FCP-300, the worst case current draw is listed for

the panel, addressable devices, and all SBUS expanders. Fill-in the number of addressable devices that will be used in the

System and compute the current draw requirements for the alarm and standby. Record this information in the Current

Draw Worksheet on Line A.

2. Add up the current draw for all the auxiliary devices and record it in the table at Line B.

3. Add up the notification appliance loads and record it in the table at Line C.

4. For notification appliance circuits and auxiliary devices not mentioned in the manual, refer to the device manual for the

current ratings.

NAC / Aux

Power

Form C

Relays

Phone lines

SLC

AC Power

Input

SBUS Out

Connections

Battery

Connections

Form C

Trouble

Relay

SLC

PGM

Circuits

EXT COMM

Ethernet

USB

20 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021

Installation Requirements Calculating Current Draw and Standby Battery

5. Make sure that the total alarm current you calculated, including the current for the panel itself, does not exceed 6.0 A.

This is the maximum alarm current for the FCP-300 control panel. If the current is above 6.0 A you will need to use a

notification power expander(s) such as the Fike FIK-5496 NAC Expander, to distribute the power loads, so that the FCP-

300 or the power expanders do not exceed their power rating. Refer to the Current Draw Worksheets provided with the

FIK-5496 manual so you do not exceed their power requirements.

6. Alternatively, you may network additional FCP-300ECS’ to obtain additional power.

7. Complete the remaining instructions in the appropriate Current Draw Worksheet for determining the battery size

requirements.

3.7.2 Current Draw Worksheet for FIK SLC Devices

Use Table 3.3 to determine the current requirements during thalarm/battery standby operation when the SLC devices are

installed. TheFCP-300FACP supports up to a total of 300 SLC devices, consisting of any combination of Sensors and Mod-

ules.7

Device Number of

Devices Current per Device Standby

Current Alarm Current

For each device use this formula: This column X This column = Current per number of devices.

Fire Panel (Current draw from battery) 1 Standby: 190 mA 190 mA

Alarm: 250 mA 250 mA

Addressable SLC Detectors

FIK-2351 Standby/Al

arm:

.30 mA1

mA mA

FIK-2351T mA mA

FIK-2351R mA mA

FIK-5351 mA mA

FIK-5351H mA mA

FIK-5351R

FIK-2351 / IV Detector SLC Standby: 200µA mA

Alarm: 4.5mA mA

FIK-2351R / IV Detector SLC Standby: 200µA mA

Alarm: 4.5mA mA

FIK-2351T / IV Detector SLC Standby: 200µA mA

Alarm: 4.5mA mA

FIK-5351 / IV Detector SLC Standby: 200µA mA

Alarm: 4.5mA mA

FIK-5351R / IV Detector SLC Standby: 200µA mA

Alarm: 4.5mA mA

FIK-5351H / IV Detector SLC Standby: 200µA mA

Alarm: 4.5mA mA

Alarm: 8.5 mA mA

DNR3(non-Relay) None, included with FIK-2351R

DNR4(with Relay) None, included with FIK-2351R & FIK-M500R

FIK-FC351 SLC Standby: 30 mA mA

Alarm: 7.2 mA mA

Table 3.3 Current Draw Worksheet for Fike SLC Devices

Other manuals for FCP-300

This manual suits for next models

Table of contents

Other Fike Fire Alarm manuals

Fike

Fike 68-140 User manual

Fike

Fike CIE-A-200 User manual

Fike

Fike 313-0001 Sita Soundpoint User manual

Fike

Fike Quadnet User manual

Fike

Fike DUONET User manual

Fike

Fike Twinflex Hipoint User manual

Popular Fire Alarm manuals by other brands

Aritech

Aritech 1200C user manual

Panasonic

Panasonic EBL512 operating instructions

DSC

DSC WS4916 Series Installation and operating instructions

Pertronic

Pertronic SYSTEM SENSOR FAAST LT Series Installation and maintenance guide

Pittway

Pittway NOTIFIER LED-10N manual

LIFETONE

LIFETONE HLAC100 user manual

Siemens

Siemens CERBERUS AlgoRex Series Installation guidelines

Zeta

Zeta Premier M plus installation manual

LST

LST Vds 245402 Specifications

Notifier

Notifier UniNet 2000 AFP-300 NION instruction manual

Simplex

Simplex TFX-500M Operator's manual

Bosch

Bosch FAP-DO420 Operation guide

Zeta Alarm Systems

Zeta Alarm Systems SIMPLICITY MICRO instruction manual

Synaps

Synaps LF24W installation instructions

E2S

E2S GNExCP6B-PB instruction manual

Kentec Electronics

Kentec Electronics Taktis Vision Installation and operation manual

Notifier

Notifier UniNet 2000 Simplex 4010 NION Installation and operation manual

System Sensor

System Sensor PS12/24ADA Series Installation and maintenance instructions

Fike FCP-300 User manual

Popular Fire Alarm manuals by other brands
