Fike Quadnet User manual

26-0855 Issue 3
Quadnet / Duonet Repeater Panel V3
(Suitable for Quadnet / Duonet repeater panels from V2.00)
Repeater Panel User Guide
(TO BE RETAINED BY USER)

Quadnet / Duonet Repeater Panel User Guide
2
Fike’s policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every
care has been taken to ensure that the contents of this document are correct at time of publication, Fike shall be under no liability
whatsoever in respect of such contents.
Due to the complexity and inherent importance of a life risk type system, training on this equipment is essential, and commissioning
should only be carried out by competent persons.
Fike cannot guarantee the operation of any equipment unless all documented instructions are complied with, without variation.
E&OE.
Fike equipment is protected by one or more of the following patent numbers: GB2426367, GB2370670, EP1158472, PT1035528T,
GB2346758, EP0917121, GB2329056, EP0980056, GB2325018, GB2305284, EP1174835, EP0856828, GB2327752, GB2313690

Quadnet / Duonet Repeater Panel User Guide
3
Contents
Introduction ............................................................................................................ 4
Purpose of the Guide .................................................................................. 4
Definitions.................................................................................................... 4
Understanding the Equipment .................................................................... 4
System Configuration.................................................................................. 5
What to do if……......................................................................................... 5
User Responsibilities............................................................................................. 6
Introduction.................................................................................................. 6
Routine Testing........................................................................................... 6
General Operation.................................................................................................. 7
Repeater Panel Front.................................................................................. 7
Normal......................................................................................................... 7
Fire Alarm Controls ..................................................................................... 8
System Controls.......................................................................................... 8
Access Levels and Codes........................................................................... 9
Fire Alarm.................................................................................................... 9
On Hearing the Alarm ................................................................................. 9
Accessing the Controls ............................................................................... 9
Silencing the Alarms ................................................................................... 9
Resetting the System.................................................................................. 10
Sounding the Alarms .................................................................................. 10
Silencing the Buzzer ................................................................................... 10
Exiting Access Level Two ........................................................................... 10
Troubleshooting .......................................................................................... 11
Advanced Operation.............................................................................................. 12
Access Level 1 (Normal)............................................................................. 12
Access Level 2A (User)............................................................................... 12
Access Level 2B (Supervisor)..................................................................... 13
LED Indication............................................................................................. 16
Log Book................................................................................................................. 18
Installation Details ................................................................................................. 24 (Back Page)

Quadnet / Duonet Repeater Panel User Guide
4
Introduction
Purpose of the Guide
This guide is provided to enable the person responsible for the fire alarm system (see Definitions) to
operate the system, undertake their responsibilities with regard to testing and maintenance of the
system, and to record events and service/maintenance visits.
This is a generic document and therefore refers to the system components in general terms only. The
details of the installed system should be recorded in the space provided within this guide, and for
further reference, the record drawings (if applicable) should be consulted.
The responsible person, and any other staff who may be required to operate the system in an
emergency, should read and understand the basic operating instructions before an emergency
situation occurs.
Definitions
Responsible person:
The person having control of the premises, whether as an occupier or otherwise, or any
person delegated by the person having control of the premises to be responsible for the fire
alarm system and the fire procedures.
Competent Person:
A person competent to perform a defined task:
Normally a competent person will be an employee of the manufacturer, installer, or servicing
contractor, or a member of the user’s staff who has received suitable training from the
manufacturer, supplier or installer.
Understanding the Equipment
What are Quadnet and Duonet?
Quadnet and Duonet are the names of two fire alarm control panels that use the associated
Sita200plus devices. The panels and devices together form the fire alarm system installed in the
premises.
With a Quadnet panel system, up to four addressable device loops may be connected to each control
panel. With a Duonet panel system, up to two addressable device loops may be connected to each
control panel. In either system. up to a maximum of 4 panels may be networked together. These can
be a mixture of control panels and repeater panels.
Advantages of the Quadnet / Duonet system are significantly reduced cabling costs, enhanced
flexibility and flexible expansion capacity if required.
What is Multipoint?
This is the name of the automatic detector used in the Quadnet / Duonet installation. The Multipoint is
a unique device, which provides several modes of detection & sensitivity options within a single
device, enabling it to be easily configured for the application. One detector can function as a smoke
detector or heat detector (or both), and with various levels of sensitivity to suit the environment.

Quadnet / Duonet Repeater Panel User Guide
5
The Multipoint detector may also incorporate an integral sounder and strobe for general alarm
annunciation or local warning as required and an automatic isolator to maintain maximum cable
integrity in the event of a cable fault.
System Configuration
The detectors and call points are arranged in zones to enable the location of a fire alarm to be
identified. The number of zones depends on the size and the layout of the premises, and is limited to
128 zones per control panel (there may be more than one). There should be a chart or drawing
provided with the system indicating the area and layout of the zones –ensure that you are familiar
with the zone layout so that appropriate action can be taken in the event of a fire alarm.
The Repeater Panel display may also give you a zone number, a device description, a device number
and a device type; indicating the exact location of the device which has operated.
The system may be interfaced with the building services, e.g., the air conditioning may be shut down
when the alarm sounds. Make sure that you know what happens when the fire alarm operates as this
can affect routine system testing.
The system is powered from the mains supply and incorporates a standby battery which automatically
maintains the system in operation for a time of at least 48 hours in the event of a mains supply failure.
Note: the following controls can be carried out on a Quadnet / Duonet Repeater Panel.
Silence Alarms
Reset System
Sound Alarms
Silence Buzzer
What to do if . . .
The fire alarm sounds;
CARRY OUT THE PRESCRIBED FIRE DRILL
When it is safe to do so silence the alarms and reset the system, having first established the cause of
the alarm (refer to Operation).
The panel buzzer sounds;
If the panel buzzer sounds without the alarm sounders operating it is likely to be a fault or other
abnormal condition.
Make a note of all illuminated LEDs and displayed messages, record the time that the condition
occurred (if known), and other events within the building, eg., power failure, contractors working, etc.,
(Refer to troubleshooting). Call the service company with as much information as possible.

Quadnet / Duonet Repeater Panel User Guide
6
User Responsibilities
Introduction
The responsible person is required under BS5839 to undertake certain tasks with respect to the
testing and maintenance of the fire alarm system. The responsible person should also ensure that
written procedures are in place for the actions to be taken by the occupants in a fire condition, and
that staff required to operate the system have received adequate training. In a small building the fire
procedures can be quite simple, but when larger premises are involved the fire procedures can
become more complex and may involve the appointment of fire wardens, reporting procedures,
various assembly points, etc.
The responsible person is also required to liaise with the building maintenance personnel to ensure
that their work does not impair or otherwise affect the operation of the fire alarm system, and to
ensure that a clear space is maintained in the vicinity of detectors, and call points remain unobstructed
and conspicuous.
Routine Testing
For details on routine testing see the Quadnet Control Panel User Guide or the Duonet Control Panel
User Guide.
Any defects should be recorded in the log book and reported to the responsible person. A certificate of
testing should also be completed and given to the responsible person.
Action by the user following a fault
When a fault is reported by the repeater panel, the user should note all illuminated LEDs and
messages displayed, and the circumstances at the time the fault occurred, and report to the servicing
company.
The service company will be able to advise if the system is still able to respond to a fire alarm or
whether extra vigilance should be observed until the fault is rectified. Faults should not be left
unreported.

Quadnet / Duonet Repeater Panel User Guide
7
General Operation
Repeater Panel Front
Normal: Controls Enabled LED off
At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the Controls Enabled
LED is switched off –see Fire Alarm Controls.
fire fault disabled test power
TURN KEY OR ENTER CODE FOR CONTROLS
DUONET
REPEATER
V3.00 Panel 01: PANEL 01
23/05/11 23:01 NORM
fire alarm controls –turn key to enable controls enable
controls
system indication
systemfault
.
silence
alarms
reset
system
sound
alarms
silence
buzzer
ENTER
>
<
/\
1 2 3
4 5 6
7 8 9
*
0 #
0_0 ABC DEF
GHI JKL MNO
PQRS T UV WXYZ
_
system controls
ESC
General Indication LEDs
Repeater Panel Information Window
Active Information Window
Prompt Window
Network Information Window
Zonal Indication LEDs
(not used on Repeater Panels prior to V3)
Fire Alarm Controls
System Indication LEDs
System Controls
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
zones
>
powerfault
earthfault
loop
sounder
fireoutput
zone
fault output
day
routineservice
techalarm
confirmation
lt
systemfault
systemfault
delay
alarms
buzzersilenced

Quadnet / Duonet Repeater Panel User Guide
8
Fire Alarm Controls
Note: The Menus on repeater panels are exactly the same as the menus on control panels.
Controls sent from repeater panels are limited but all controls will still appear in the menu structure in
the repeater panel.
The greyed out controls below are not relevant to repeater panels and therefore should not be used.
The main Fire Alarm Controls may be enabled by turning the key switch to the controls enabled
position, or by entering a valid Access code.
System Controls
User
Supervisor
A context-driven highlighted-selection menu system is used to navigate the menu system,
automatically prompting you with the relevant options for your Access Level and system status.
The menus may be navigated in one of two ways as required:
1. Use the UP / DOWN keys to move the highlighted selection and press ENTER to select the
chosen one.
2. Enter the desired option number and press ENTER to select it.
Press the Esc key to exit to the previous menu.
fire alarm controls –turn key to enable controls
silence
alarms
reset
system
sound
alarms
enable controls
silence
buzzer
1. Delay On/Off
2. Test Display
3. View Logs
4. Disable/Enable
5. Set Time & Date
6. Test Modes
7. Day/Night Mode
8. Find Device
*
enter
1
o_o
>
<
<
<
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
0
___
#
ESC
1. Delay Override
2. Test Display

Quadnet / Duonet Repeater Panel User Guide
9
Access Levels and Codes
The menu system is divided into four access levels in order to restrict access to those who require it.
For simple indication the status of the Controls Enabled light will show the level selected as follows;
Access Level
Description
Shift LED
Key Operation
Default Code
1 –NORM
Normal
OFF
YES
N/A
2A –USER
User
ON
YES
8737
2B –SUPR
Supervisor
SLOW FLASH
NO
7877
The fourth level (Engineer) is not shown above. Access to the menu system requires either the
operation of the enable controls key for access to Access Level 2A (User), or the correct entry of the
relevant code for access to all other levels, in order to protect against unauthorised access to the
system. The codes may be changed using the Quadnet / Duonet OSP software.
A valid access level code must be entered in order access any of the menus.
Menu examples shown below are for the V3 panel. Menus in some earlier panel versions may differ.
Fire Alarm
When the panel enters the fire state, the alarms will sound, the fire LEDs will illuminate, the panel
buzzer will pulse quickly and the display will show the location and type of alarm.
On Hearing the Alarm
The responsible person should have already prepared written procedures for the action to be taken in
the event of a fire alarm. When the alarm sounds these procedures should be implemented.
Accessing the Controls
The user controls are accessed from Access Level 2A (User), or Access Level 2B (Supervisor) which
is reached as follows:
1.
Turn the key,
Or:
Enter your Access Level 2 (User)
or Access Level 2B (Supervisor)
code, ie, # # # #
The ‘CONTROLS ENABLED’ light will light up
continuously, and USER is displayed in the top right
hand corner.
The panel buzzer will be heard on each key press,
and when successfully entered the ‘CONTROLS
ENABLED’ light will light up continuously, and USER
or SUPR is displayed in the top right hand corner.
You are now in Access Level 2A (User) or Access
Level 2B (Supervisor) and may proceed to silence
and reset the system.
Silencing the Alarms
When the fire procedures have been carried out and it is safe to silence the alarm, proceed as follows.
1.
Press ’SILENCE ALARMS’
The alarm sounders should silence, but the panel
buzzer and the fire indication lights should remain.

Quadnet / Duonet Repeater Panel User Guide
10
Resetting the System
Before attempting to reset the system, the cause of the alarm should be established.
1.
Press ’RESET SYSTEM’
The panel buzzer and the fire indication lights should
switch off.
However, if any alarm condition still exists, eg., a
manual call point requires resetting, then the panel
will revert to the fire state until the cause for the
alarm is removed.
Note: if the panel does not reset or a fault condition is displayed, call your maintenance engineer
immediately.
Sounding the Alarms
To sound the alarms at any time after they have been silenced, proceed as follows:
1.
Press ’SOUND ALARMS’
The alarm sounders will activate. The panel buzzer
and the fire indication lights will also switch on.
Silencing the Buzzer
To silence the panel buzzer press the [SILENCE BUZZER] button at access level two as above .
1.
Press ’SILENCE BUZZER’
The panel buzzer will be silenced.
Exiting Access Level 2A (User) or Access Level 2B (Supervisor)
In order to prevent unauthorised access to the system, return to Access Level 1 (Normal). However, if
left untouched the display will time out after a short while and return automatically to Access Level 1
(Normal).
1.
Turn the key OFF if it is turned on.
Or;
Press ‘ESC’ until the system
shows NORM in the top right hand
corner.
The ‘CONTROLS ENABLED’ light will switch off and
the controls are disabled.
NORM is displayed in the top right hand corner.

Quadnet / Duonet Repeater Panel User Guide
11
Troubleshooting
Problem
Possible Cause
Remedial Action
Unable to silence
alarms
Panel not in Access Level 2A (User)
or Access Level 2B (Supervisor)
Enter Access Level 2A (User) or Access
Level 2B (Supervisor) - see section on
operation.
Unable to reset system
Alarms not silenced
Silence alarms before attempting to reset
the system.
Panel not in Access Level 2 (User)
or Access Level 2B (Supervisor)
Enter Access Level 2 (User) or Access
Level 2B (Supervisor) - see section on
operation.
Alarm condition still present
Remove cause of alarm, eg. reset call point
element with key
Panel buzzer sounding,
FAULT LED lit
Fault or abnormal condition
Note all illuminated LEDs and displayed
messages.
Call engineer.
Panel buzzer sounding,
POWER FAULT LED
flashing, ‘Mains supply
failed’ displayed.
Mains supply failure
Wait until mains supply is restored –if
panel does not revert to normal operation
call engineer.
Panel buzzer sounding,
SYSTEM FAULT LED
lit
Repeater panel fault
Call engineer immediately.
Any other fault or
abnormal behaviour
Various
Note all illuminated LEDs and displayed
messages.
Call engineer.

Quadnet / Duonet Repeater Panel User Guide
12
Advanced Operation
Access Level 1 (Normal): Controls Enabled LED off
At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the Controls Enabled
LED is switched off.
A valid access level code must be entered or the key switch must be used in order access any of the
menus.
Access Level 2A (User): Controls Enabled LED off
At Access Level 2A (User), the main Fire Alarm Controls are enabled, and the following System
Controls are accessible:
Delay Override
The Delay Override function overrides any programmed delays.
Test Display
The Test Display function causes the panel LEDs to illuminate, and the LCD screen to
blacken, and the panel buzzer to sound in order to verify their correct operation.
Press the Esc key to exit to the previous menu.
1. Delay Override
2. Test Display

Quadnet / Duonet Repeater Panel User Guide
13
Access Level 2B (Supervisor): Controls Enabled LED flashing slowly
At Access Level 2B (Supervisor), the main Fire Alarm Controls are enabled, and the following
System Controls are accessible:
1. Delay On/Off
Not applicable.
.
2. Test Display
The Test Display function causes the panel LEDs to illuminate, the LCD screen to blacken
and the panel buzzer to sound in order to verify their correct operation.
3. View Logs 1. Current Warnings
The Active Warnings Log will display any current warnings. These are displayed in text format
and may be scrolled through by pressing the UP and DOWN keys.
1. Delay On / Off
2. Test Display
1. Current Warnings
3. By Device Type
4. By Loop No - Device No
1. All Events
2. By Event Type
1. User Action
2. Panel Event
3. Fire Event
4. Fault Event
1. Multipoint with sounder
2. Multipoint
5. By Date
2. Current Faults
3. Current Disablements
4. Current Tests
5. Event Logs
4. Disable / Enable
1. Detection Zone
2. Device
3. Sounders
4. Fire Outputs
5. Fault Outputs
5. Set Time & Date
6. Test Modes
7. Day / Night Mode
1. Silent Test
2. Local Audible Test
1. Override into Day Mode
2. Override into Night Mode
3. Endall Overrides
3. System Test
4. ViewDay / Night settings
8. Find Device

Quadnet / Duonet Repeater Panel User Guide
14
3. View Logs 2. Current Faults
The Active Faults Log will display any current faults. These are displayed in text format and
may be scrolled through by pressing the UP and DOWN keys.
3. View Logs 3. Current Disablements
The Active Disablement Log will display any current disablements. These are displayed in text
format and may be scrolled through by pressing the UP and DOWN keys.
3. View Logs 4. Current Tests
The Active Tests Log will display any current test modes. These are displayed in text format
and may be scrolled through by pressing the UP and DOWN keys.
3. View Logs 5. Event Logs
The Event Log stores 1000 local fire / fault events and 1000 network events which may be
displayed in entirety, or displayed by category. These are displayed in text format and may be
scrolled through by pressing the UP and DOWN keys.
4. Disable / Enable 1. Detection Zone
Not applicable.
.
4. Disable / Enable 2. Device
Not applicable.
.
4. Disable / Enable 3. Sounders
Not applicable.
.
4. Disable / Enable 4. Fire Outputs
Not applicable.
.
4. Disable / Enable 5. Fault Outputs
Not applicable.
.
4. Disable / Enable 6. Default to All Enabled
Not applicable.
.
5. Set Time and Date
This allows the time and date to be adjusted. These settings will need to be re-entered after
the complete removal of power, as the system will simply resume from the point that power
was removed.

Quadnet / Duonet Repeater Panel User Guide
15
6. Test Modes 1. Silent Test
Not applicable.
.
6. Test Modes 2. Local Audible Test
Not applicable.
.
6. Test Modes 3. System Test
Not applicable.
.
7. Day / Night Mode 1. Override into Day Mode
Not applicable.
.
7. Day / Night Mode 2. Override into Night Mode
Not applicable.
.
7. Day Night Mode 3. End all Overrides
Not applicable.
.
7. Day Night Mode 4. View Day / Night Setting
Not applicable.
.
Not applicable.
.
8. Find Device

Quadnet / Duonet Repeater Panel User Guide
16
LED Indication
The operation of the LED indications on the front of the panel is described below. As this is a repeater
panel, not all of the following indications are applicable.
Description
Colour
State
Reason
1.
FIRE
Red
Continuous
The repeater panel is in the fire state. Other
indicators will show the origin
2.
FAULT
Yellow
Continuous
The repeater panel is in the fault state. Other
indicators will show the origin
3.
DISABLED
Yellow
Continuous
This indicates that a disablement action is in place.
Enable all devices / actions to clear.
4.
TEST
Yellow
Continuous
This indicates that a test routine is in place. End all
tests to clear.
5.
POWER
Green
Continuous
This indicates that power is being supplied to the
repeater panel from either the 230V AC mains
supply, or the standby batteries.
6.
‘ZONE 1-128’
Red
Flashing
Continuous
A Manual Call Point in the zone indicated is in the
alarm state and sending an alarm signal to the panel.
A Detector in the zone indicated is in the alarm state
and sending an alarm signal to the panel.
7.
SYSTEM FAULT
Yellow
Continuous
The system Fault LED indicates the presence of a
processor or a checksum error. Power the system
down to clear, reprogram all settings and test the
system.
8.
POWER FAULT
Yellow
Flashing
Continuous
The mains supply has failed (check the fuse and the
230V AC supply on the PCB Ac terminals).
A battery supply / charger fault has been detected
(check the fuse and the battery voltages).
9.
EARTH FAULT
Yellow
Flashing
An earth fault has been detected where a path exists
from the circuit wiring to earth. Remove circuits one
at a time to discover which one, and then rectify.
10.
LOOP
Yellow
Flashing
Continuous
A fault condition is present on one or more
addressable device loops, or one or more
addressable devices.
A device or an action associated with the
addressable device loop has been disabled
11.
SOUNDER
Yellow
Flashing
Continuous
A fault condition is present on a monitored sounder
circuit or on the addressable device loop sounders.
A device or an action associated with the monitored
sounder circuits or an addressable sounders has
been disabled.
12.
FIRE OUTPUT
Yellow
Flashing
Continuous
A fault condition is present on a monitored Relay
circuit or on the addressable device loop outputs.
A device or an action associated with the monitored
relay circuits or an addressable output has been
disabled.
13.
ZONE
Yellow
Continuous
A device or zone, or an action associated with them
has been disabled.

Quadnet / Duonet Repeater Panel User Guide
17
14.
FAULT OUTPUT
Yellow
Flashing
Continuous
A monitored output programmed to operate as a Fire
Output is in the fault state.
A monitored output programmed to operate as a Fire
Output has been disabled.
15.
DAY
Yellow
Flashing
Continuous
The system Day / Night mode timing has been over
ridden, and forced into the less sensitive day mode.
The system has gone in the less sensitive day mode
as programmed.
16.
SERVICE
Yellow
Flashing
The pre programmed service interval has expired
and a routine maintenance check is due.
17.
TECHNICAL ALARM
Yellow
Flashing
A device programmed as Technical Alarm is in the
alarm state and sending a Technical Alarm signal to
the panel.
18.
ALARM CONFIRMATION
Yellow
Flashing
A smoke detector is in the alarm confirmation state,
awaiting confirmation or reset.
19.
DELAY
Yellow
Continuous
An action has been started which utilises a
programmed delay.
20.
ALARMS SILENCED
Yellow
Continuous
The alarm sounders have been silenced whilst
operating, and the system is awaiting a reset.
21.
BUZZER SILENCED
Yellow
Continuous
Flashing
The repeater panel buzzer has been silenced whilst
operating and will stay silenced until another fault or
relevant action occurs.
The repeater panel buzzer has been disabled at
Access Level 3 (Engineer), and will remain silent
until it is reinstated. However, the buzzer will still
operate in the fire alarm state.

Quadnet / Duonet Repeater Panel User Guide
18
LOG BOOK
Record all fire and fault events,
whether or not an engineer was
called
Event Log
Time
Zone/Device
Event
Action
Initials

Quadnet / Duonet Repeater Panel User Guide
19
Time
Zone/Device
Event
Action
Initials

Quadnet / Duonet Repeater Panel User Guide
20
Time
Zone/Device
Event
Action
Initials
