fire's edge 100A-M User manual

Fire's Edge
Fire Pit or Fire Pit Insert
Model 100A-M (Manual Operation)
OWNER’S MANUAL /
OPERATING AND MAINTENANCE INSTRUCTIONS
This manual should remain with the homeowner or parties responsible for operation.
(Rev C)
For your safety:
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
near unit.
3. If odor continues, immediately
call your gas supplier
For your safety:
Do not store or use any gasoline or
other flammable vapors and / or
liquids in the vicinity of this or any
other appliance.

2
Table of Contents
Gas Requirements Page 3
Installation Page 3
Operation Page 4
Maintenance Page 5

3
1.0 Gas Requirements:
1.1 Gas type: Natural Propane
1.2 Gas Pressure: 7” wc 11”wc
1.4 Gas flow: 1 Burner System: 125,000 Btu/hr
Note: Check with your gas supplier to verify gas flows and pressures available at the location
of your installation. In many cases utility companies will install larger meters at no charge to
accommodate larger flows.
2.0 Installation
Warning: This unit is for outdoor use only
2.1
2.2
2.3
2.4
2.5
2.6
2.7
Do not install near any combustibles such as wood structures, fuels, clothing, fabrics
or dry vegetation.
Installation shall be performed by a licensed contractor. All aspects of installation
must conform to local codes, or in the absence of codes, with National Fuel Gas Code
ANZI Z223.1.
An approved gas valve or keyed valve shall be installed upstream of the unit and
located in an accessible area that is within 5ft from the Fire's Edge Unit.
Maintain good piping practice by keeping pipe length and elbows to a minimum to
eliminate unnecessary pressure drops. (Do not use any flexible gas line)
Install the Fire's Edge Fire Pit (48”Tacora/42”- 60”Terra
Nova/42”Sumaco/40”-50”Amiata/45”Grand Curacoa)as shown in Fig. 1. or Fig. 2.
48”Tacora and 45”Grand Curacoa and 42” Sumaco require a Fire's Edge Mounting
Bracket to be installed. The Mounting Bracket secures bowl and allows for cooling air
and water drainage.
Fig.3 and Fig. 4 illustrate requirements for Fire Pits with Manual Burner Inserts.

4
(Fire Pit with External Key/Ball Gas Valve)
Fig. 1
(Fire Pit with Internal Key Valve)
Fig. 2

5
(Fire Pit Insert-Natural Gas)
Fig. 3
(Fire Pit Insert-Propane Gas)
Fig. 4
Important: Do not use Fire Glass with propane installations.!!
CAUTION!! Lava Rock is an accepted medium for fire features. However, pieces may
pop or explode when exposed to heat or when wet and exposed to heat.
Use caution when in immediate area.

6
3.0 Operation
Warning: This unit is for outdoor use only
For your safety:
3.1 If you smell gas, shut off gas valve immediately.
3.1 Extinguish any open flame.
3.3 If odor continues, immediately call your gas supplier.
3.4 Do not store or use gasoline or other flammable vapors and / or liquids in the
vicinity of this appliance.
3.5 Do not leave flame on while unsupervised.
3.6 Do not operate in windy or rainy conditions.
3.7 Unit should be operated only by a responsible adult.
3.8 When in use, an open flame is present, therefore, use with extreme care and at
your own risk.
3.9 Before any inspection of the unit, always turn off gas and make sure the unit is
3.10 cool.
If you experience problems with this unit, call a licensed heating
professional. All work on this unit shall be performed by a licensed
heating professional.
Caution! Before you turn on the Fire's Edge System, make sure that it is clear of
people, animals or any objects that are combustible.
3.12
3.13
3.14
3.13
With the gas valve in the closed position, check the Fire's Edge Unit for any
gas smell or indication of a gas leak. If you smell gas or see evidence of a gas
leak, do not operate the Unit. Immediately call your utility gas supplier to
inspect the unit.
If there is no evidence of a gas leak, crack open the gas valve and immediately
light the burner with an approved lighting device.
The height of the flame can be adjusted by opening or closing the ball valve or
keyed valve.
To turn the Unit “OFF”, close the gas valve to the fully closed position.

7
4.0 Maintenance
4.1 Periodically clean the Burner Assembly with a wet cloth or cleaning solution to
remove carbon build-up. Frequency of the cleaning will depend on usage.
4.2 Periodically inspect the underside of the Burner Assembly for any signs of
excessive temperatures.
4.3 Check that all gas connections are tight.
Note: If any problems are present, consult a licensed heating
specialist or call Fire's Edge.
Fire's Edge
1 year Limited Residential Warranty-6 Months Commercial
Fire's Edge will replace, at its expense, any unit, which in normal use, has proven
to be defective in workmanship or material, provided that the customer returns the
product prepaid to Fire's Edge with proof of product within one year

8
