Firefly DVR603 User manual

1
firefly
SONY 12 Mega pixels HD DV
WiFi
SONY 12M COMS
Ver 2.3

2
Contents
Features ：.......................................................................................................................3
OLED Status Screen........................................................................................................4
Button Functions...............................................................................................................6
Menu Description:............................................................................................................ 6
Wi-Fi Remote:................................................................................................................... 8
Time update:........................................................................................................................9
Battery Charging:..............................................................................................................9
Transferring Files:.............................................................................................................9

3
Features ：
1
3
4
6
7
8
9
10
2
5
11
1.OK Button
2.Camera Status LED
3.OLED Status Screen
4.Power/Mode Button
5.Working/Charging Status Light
6.HDMI Port
7. USB/AV Port
8.Down Button
9.Up Button
10.TF Card Slot
11.Battery Door

4
OLED Status Screen
Note: Please use C10 TF Card and format it in FAT32 before use.
1
2
3
4
5
6
7
1.Modes: Video/Photo
2.Date
3.Resolution
4.Counter
5.WDR Status
6.FOV Level
7.Battery Status。

5
Performance and Specifications:
Photo resolution
12M
AV output format
USB Port
PAL/NTSC
（fit for gopro gimbals)
HDMI Output
YES
Kind of TF card
supported
Class 10
Maximum size of TF
card supported
64G
Wi-Fi
YES
Specifications
Camera size
59×41×21 MM
（fit for gopro gimbals)
Weight
70g
Battery Capacity (Battery
is removable,
exchangeable with
battery of gopro3/3+)
1600mAH
Battery life
2 hours
Time to complete
charging
2-3 hours
Compressed format
H264
Video/photo format
*.MOV / *.JPG
Optical Parameter
Diaphragm
F/2.8 ，7 glasses
Angle
Horizontal 105 degree
Diagonal 140 degree
Electric Parameter
Working Voltage
5V
current
800mA
Working Modes
Video
Time-lapse video
Time-lapse photo
11 Burst Photo

6
Button Functions
Name
Functions
描述 Descriptions
Power/Mode
Button
Turn on/off
camera; select
modes
Press once, camera on; press for 3
seconds, camera off/ press to select photo
or video mode.
OK Button
start/stop
recording
UP Button
move upwards
Enter menu setting/move upwards/Press for
3 sec, WIFI ON
DOWN Button
Move downwards
Enter menu setting/move downwards
Menu Description:
Video resolution: select from 1080P@30fps and 720p@60fps,etc。
Time-lapse video: to start/stop time-lapse video at 0.5 or 3 second
intervals.
Cycle recording: If cycle recording mode is selected, the video will be cut
into 5-minute segments. The earliest files will be covered when the TF
card is full.
USB Power Up Auto-record: If this function on, it will automatically start
recording when connected to external power source via USB.
WDR (Wide Dynamic Range): WDR function is suggested to be used in
cloudy/dark environment. It might cause overexposure in sunny days.
Photo resolution: 12M / 8M / 5M
Burst photo: capture 11 photos in 1 second.

7
Continuous photo: This option allows you to capture photos continuously
every 3 /10/30second. Note: Continuous photo mode has more priority
than burst photo mode.
ISO adjustment: AUTO/100/400/1600.ISO of photos can be adjusted. At
night, the lower ISO you select, the better image effect you get.
Sharpness adjustment: 3 options: High, Medium and Low. Low
sharpness is suggested at night.
Color adjustment: 2 options: standard and vivid.
Time stamping: this option allows you to stamp the time on the photos or
videos.
TV output mode: PAL / NTSC
HDMI output: HDMI mode is turned off in default.
Wi-Fi remote: the camera’s built-in Wi-Fi allows you to connect to the
smart phone/tablet via the Firefly App. You can view the photos and
videos taken by the camera on your smart phone/tablet; you can also use
your smart phone/tablet to control the camera to capture photos or record
videos.
USB Auto power-off: the power will be automatically turned off in 30

8
seconds after the USB power supply is cut.
Angle adjustment: 3 options: Large / Medium / Small. Small angle can
reduce image distortion.
TF card formatting:After power on, if the format of TF card does not fit the
system, you will see a tip “please format card” and please use this
function then.
Factory default settings: you can use this function to resume all factory
default settings.
System version: enter to see the system version of the camera.
Wi-Fi Remote:
You can use a Smart phone/tablet to view or take photos and videos via Wi-Fi
connection.
1. Download and install FIREFLY app from
the app store
on your smart phone/tablet,or scan the QR
code for
iOS: Android:
2. Turn camera’s Wi-Fi on.
3. In your smart phone’s or tablet’s Wi-Fi network settings, connect to the

9
camera’s Wi-Fi network named “FIREFLY_xxxx”, enter the password. Default
password is “12345678”.
4. Open the FIREFLY app on your smart phone/tablet. You will now be able to
control the camera with your smart phone/tablet plus view, playback and
share selected content.
Time update:
When connected to the Wi-Fi, time will be updated automatically.
Battery Charging:
Connect the camera to a computer or phone charger using the included USB
cable. Use 1A charger ,and turn off the camera when charging will increase the
charging rate. The Charging Status Light it will turn OFF when the battery is fully
charged.
Transferring Files:
1. Connect the camera to a computer via the included USB cable, and then turn on
the camera.
2. Double click “My Computer” and locate “Removable Disk”. Enter “Removable Disk”
and you will find all photo and video files in DVfolder.
