Parts needed:
1 - Log Headboard
1 - Log Footboard (end with built-in ladder)
2 - Assembled Bunk rails (one right; one left)
1 - Bundle of 5 Slats
10 - 1 5/8” Wood Screws for slats
1 - Plywood for Upper Bunk (bottom bunky boards are optional)
8 - 1 5/8” Wood screws for Upper Bunk plywood
2 - Log Side Rails (81” Long for Single & Double Beds & 86” Long for King & Queen Beds)
16 - 6” Lag Screws and washers for Single/ Single, Double/ Double, Queen/ Queen beds
OR
12 - 6” Lag screws for Double/ Single, Queen/ Single beds
6 - 1 1/2” Diameter Log Bed Plugs (for holes to hide/cover lag screws)
5 - Support Rails (for Double/Doubles, Double/Queens, and Queen/Queen bunk beds ONLY)
see step 11 below
2 - Secondary bed rails (without notches) (for Double/Doubles, Single/Singles and Queen/Queen ONLY)
1 - T-25 Bit (Torx bit screwdriver)
King & Queen Beds Only
 • T-Support-(consistsof2approx7”x75”boardstobeassembled)
 • 8-4”T30screws
 • 1-T30driverbit(Torx)
CHECKING/CRACKING:
It’s normal for all cedar log furniture to develop some checks in the wood. Checking occurs as a log releases moisture across or
through the annual growth rings. It does not aect the structural integrity of the wood. All logs which contain the heart of the
tree will develop lengthwise cracks or checks. e check never goes deeper than the heart.
Cedar Bunk Bed Assembly Instructions
Tools Needed for Assembly:
15/16” Socket & Ratchet (or Impact Driver)
Cordless Drill with Phillips Head
Rubber Mallet if required
IMPORTANT! Please read and follow the Bunk Bed Safety instructions on the last page of this instruction packet.
is product is designed to provide the safety levels of this certication when the assembly instructions are properly followed.
Completing assembly as instructed will make beds safer.

FIRESIDELODGEFURNITURE.COM | 877-568-6188 2
READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING ASSEMBLY
(Note: Two people are required for assembly. One person should hold headboard, while other inserts railings.)
1. Remove all pieces from the pallet with a Phillips screw driver.
2. To remove the skis from the bed frame legs, use the T-25 bit included in the hardware kit.
Bed Rail
Mortises
Pictured is a Double/
Single Ladder Right

FIRESIDELODGEFURNITURE.COM | 877-568-6188 3
3. Bedrailshaveatenon(taperedendofthelog)oneachend.Insertoneend,ortenon,ofLogSideRailintothe
2 1/2” mortise (round hole cut into head and foot boards). e bed rails have right angles cut into them the full
length of the rail. e right angles on the bed rails have a long at-edge and a short at-edge.
4. Acorrectlyinstalledbedrailhasthelongat-edgefacingup.eslatsforthemattresswillsitonthisedge.
When rails are correctly installed, the short at-edge should be aligned vertically as seen below.
5. Insert one end of the Log Side Rails into 2 1/2” mortises (pre-drilled holes) on front side of headboard.
6. is step applies ONLY to Double/Single and Queen/Single bunk beds
a. ese beds come without secondary bed rails. e Bed Rail Mortises are located on the jut-out post.

FIRESIDELODGEFURNITURE.COM | 877-568-6188 4
7. is step applies ONLY to Single/Single, Double/Double, and Queen/Queen bunk beds
a. ese beds come with 2 secondary bed rails. ese secondary bed rails are not quartered out
(no right angle cut in). e mortises are located on the main post, above the bed rail mortises.
b. e secondary bed rails should be placed into mortises so the small end of the secondary rail is
directly above the large end of the bed rail.
8. Screwina6”lagscrew/washersfromthebacksideofheadboardintotheLogSideRailsabout3/4oftheway.
(Do not tighten completely at this time). Hint: Scraping the lag screw accross a bar of soap or wax will make it
easier to install the screw.
9. Insert the other end of Log Side Rails into 2 1/2” mortises of footboard. Screw the lag screw in about ¾ of the
way. (Do not tighten completely at this time).
10.IfyouhaveaKingorQueenSizeBed,assembletheT-Support(consistsofqty2approximately7”x75”boards
and 1 has a slot) – stand the other upright in the slot and screw together – approx height will be 8.25”. Lay
assembled T-Support on the oor in the center of the bed running from head to foot and centered between the
two side rails.
11.Lay all 5 slats onto wide at portion of the Log Side Rails. Secure the slats with the screws provided
(1 screw on each end is sucient.) Do not over-tighten the screws as this will cause the slats to split.

FIRESIDELODGEFURNITURE.COM | 877-568-6188 5
Important! For safety, the slats at the head and foot must be spaced so the gap to the headboard and to the
footboard is 3” or less. e remaining slats may be evenly spaced between the two end slats.
12. Insert Right Hand Assembled Bunk rail (as marked on rail) into upper mortises of headboard and footboard.
(All left and right rails are based upon standing at foot of bed and facing headboard). You may have to gently
tip either the headboard or footboard out slightly to get the rail assembly into the mortises.
13. THIS STEP Applies ONLY to Double/Doubles, Double/Queens, and Queen/Queen bunk beds.
a. After the right-hand rail assembly has been placed & tapped into mortises, you can place the 5 support
rails into the mortises of bottom quartered out rail of bunk assembly.
b. e at surfaces of the rails should be facing up and level.
c. With another person lift left bunk assembly up into lower mortises of left side of bunk – be sure to have
top rail spun out to the side of upper mortises. e second person will place tenons of support rails into
matching mortises of left hand bunk rail assembly.
d. Spin upper rail up and into mortises
14. RepeattheprocesswiththelefthandAssembledBunkrail.

FIRESIDELODGEFURNITURE.COM | 877-568-6188 6
15. Some tapping of support rails will be necessary to get the left assembly into mortises. Lift the Plywood over
the bunk rail (right or left side) and slip it into the top bunk mattress position (It may be necessary to slip
one assembled bunk rail out of the top holes to drop the plywood in). Important! For safety, the plywood
must be positioned so the gap to the headboard and to the footboard is 3” or less.
16. Usingthe8-15/8”Woodscrewsprovided,screwtheplywooddownontothebunkrailin4placesoneach
side.
17. Insert6”LagScrewsintoallbunkmortisesandlightlytighten.Besuretousewasherswitheachlagscrew.
18. Begin to tighten all Lag Screws securely. Starting from bottom bedrail, move from one to another in a rotation
until all 12 lag screws are securely tted. Note: It is normal to hear some popping or cracking as rails become
rmly seated. Please make sure that you tighten completely this will ensure that your bunk bed will be VERY
sturdy.
19. Position log bed plugs into each 1 1/2” mortise.
is will conceal the lag screw heads and complete
your assembly.
20. Enjoy your Log Bunk Bed for many, many years!!
031314
04/17

FIRESIDELODGEFURNITURE.COM | 877-568-6188 7
Size of Mattress and Foundation
is bed is designed to use a mattress:
 • Single: 741/2”x38”
 • Double: 741/2”x53”
 • Queen: 791/2”x60”
Topmattressmustnotexceed10”,3/4”foundationboardsupplied.Note:eremustbeatleast5”frommattress
sleeping surface to top edge of guardrail.
Replacement Parts
Replacement parts, including additional guardrails, may be obtained from place of purchase.
Safety Warnings
1. Follow the information on the warnings appearing on the upper bunk end structure and on the carton.
Do not remove warning label from bed.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood
of entrapment or falls.
 3. Surfaceofmattressmustbeatleast5inchesbelowtheupperedgeofguardrails.
 4. Donotallowchildrenunder6yearsofagetousetheupperbunk.
5. Periodically check and ensure that the guardrail, ladder, and other components are in their proper position,
free from damage, and that all connectors are tight.
6. Do not allow horseplay on or under the bed and always prohibit jumping on the bed.
 7. Alwaysustheladderforenteringandleavingtheupperbunk.
8. Do not use substitute parts. Contact manufacturer or dealer for replacement parts.
9. Use of a night light may provide added safety precaution for a child using the upper bunk.
10. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be
placed against the wall to prevent entrapment between the bed and the wall.
11. Always use guardrails on both the long sides of the upper bunk.
12. e use of water or sleep otation mattresses is prohibited.
 13. Keeptheseinstructionsforfuturereference.
 14. StrangulationHazard–Neverattachorhangitemstoanypartofthebunkbedthatarenotdesignedfor
use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
Cedar Bunk Bed Safety Instructions
