Fisher Scientific 11100100H User manual

Isotemp Hotplates, Stirrers and
Stirring Hotplates
OPERATION MANUAL
AND PARTS LIST
Catalog # Type Top Plate Size and Material Voltage
11100100H Hotplate 10x10 Ceramic 120
11100100S Stirrer 10x10 Ceramic 120
11100100SH Stirring Hotplate 10x10 Ceramic 120
1110016H Hotplate 4x4 Ceramic 120
1110016S Stirrer 4x4 Ceramic 120
1110016SH Stirring Hotplate 4x4 Ceramic 120
1110049H Hotplate 7x7 Ceramic 120
1110049S Stirrer 7x7 Ceramic 120
1110049SH Stirring Hotplate 7x7 Ceramic 120
1120049H Hotplate 7x7 Aluminum 120
1120049S Stirrer 7x7 Aluminum 120
1120049SH Stirring Hotplate 7x7 Aluminum 120
1110116H Hotplate 4x4 Ceramic 100
1110149H Hotplate 7x7 Ceramic 100
1110149S Stirrer 7x7 Ceramic 100
1110149SH Stirring Hotplate 7x7 Ceramic 100
1120149S Stirrer 7x7 Aluminum 100
1120149SH Stirring Hotplate 7x7 Aluminum 100
11101100H Hotplate 10x10 Ceramic 100
11101100S Stirrer 10x10 Ceramic 100
11101100SH Stirring Hotplate 10x10 Ceramic 100
1110216H Hotplate 4x4 Ceramic 230
1110216S Stirrer 4x4 Ceramic 230
1110216SH Stirring Hotplate 4x4 Ceramic 230
1110249H Hotplate 7x7 Ceramic 230
1110249S Stirrer 7x7 Ceramic 230
1110249SH Stirring Hotplate 7x7 Ceramic 230
1120249H Hotplate 7x7 Aluminum 230
1120249S Stirrer 7x7 Aluminum 230
1120249SH Stirring Hotplate 7x7 Aluminum 230
11102100H Hotplate 10x10 Ceramic 230
11102100S Stirrer 10x10 Ceramic 230
11102100SH Stirring Hotplate 10x10 Ceramic 230
LT1892X1 • 12/28/09

Safety Information ..............................................................................................................................................3
Warnings ......................................................................................................................................................3
Specifications ......................................................................................................................................................5
Heating Specifications ..................................................................................................................................6
Stirring Speed Specifications ........................................................................................................................6
Environmental Conditions ............................................................................................................................7
Declaration of Conformity....................................................................................................................................7
Unpacking and Installation ..................................................................................................................................8
eneral Usage ..............................................................................................................................................8
Unpacking ....................................................................................................................................................8
Installation ....................................................................................................................................................8
Operation ............................................................................................................................................................9
Setting the Stirring Speed ............................................................................................................................9
Setting the Temperature................................................................................................................................9
Heating Metal Vessels and Sand Baths........................................................................................................9
Maintenance and Troubleshooting ....................................................................................................................10
eneral Cleaning Instructions ....................................................................................................................10
Error Codes ................................................................................................................................................10
Replacement Parts ............................................................................................................................................11
Accessories ......................................................................................................................................................11
Warranty ............................................................................................................................................................12
2
Table of Contents

Your Fisher Isotemp Hotplate, Stirrers or Stirring
Hotplate has been designed with function, reliability,
and safety in mind. It is your responsibility to install it in
conformance with local electrical codes. For safe oper-
ation, please pay attention to the alert signals through-
out the manual.
Warning: These products should be used only under
the operating conditions specified in the Operating
Manual. Always use safe laboratory practices and do
not leave the hotplate in operation while unattended as
product funcionality or laboratory practice failures could
occur that might lead to uncontrolled or excessive
heating of the top surface. Safety procedures (includ-
ing, but not limited to, unplugging when not in use) and
response plans should be put in place to address the
worst case possibility. If an over-temperature failure
occurs, the top surface temperature could rise to the
maximum temperature (300-540°C depending on your
model’s specification) and remain at that temperature
indefinitely. Under these conditions, the material being
heated on the surface of the hotplate could reach lev-
els in excess of the maximum temperature.
This manual contains important operating and safety
information. The user must carefully read and under-
stand the contents of this manual prior to the use of
this equipment.
Warnings
To avoid electrical shock, always:
1. Use a properly grounded electrical outlet of
correct voltage and current handling capacity.
2. Disconnect from the power supply prior to
maintenance and servicing.
To avoid personal injury:
1. Do not use in the presence of flammable or
combustible materials — fire or explosion
may result. This device contains components
which may ignite such materials. Not rated
for use in hazardous atmospheres.
2. Use caution when heating volatile materials;
3
Safety Information
Warning
Warnings alert you to a possibility of
personal injury.
Alert Signals
Note
If the equipment is used in a manner
not specified by the manufacturer the
protection provided by the equipment
may be impaired.

top surface and element can reach the “Flash
Point Temperature” of many chemicals. These
stirring hotplates are not explosion proof. Fire or
explosion may result. Unit contains components
which may ignite such materials.
3. Keep top surface clean. Use a non-abrasive
cleaner. Alkali spills, hydrofluoric acid spills or
phosphoric acid spills may damage top and lead
to thermal failure. Unplug unit and remove spills
promptly. Do not immerse unit for cleaning.
4. Replace the top immediately if damaged by
etching, scratching or chipping. A damaged top
can break in use.
5. Do not use metal foil on hotplate which may
block air flow. Overheating will result.
6. Check and tighten the removable cord periodi-
cally making sure it is secure. If loosened, the
cord could become hot and/or spark and be a
potential fire hazard. If cord appears damaged,
replace immediately.
7. Do not remove or modify grounded power plug.
Use only properly grounded outlets to avoid
shock hazard.
8. Use appropriate hand and eye protection when
handling hazardous chemicals.
9. ross weight of items placed on top of stirring
hotplates should not exceed 35 lbs. (15.9 kg.)
on the 10” x 10” models, 25 lbs. (11.3 kg) on the
7” x 7” models, and 15 lbs. (6.8 kg.) on the 4” x
4” models.
10. The top plate of the unit can remain hot for
some time after use. A “CAUTION - HOT TOP”
light will remain on until top plate temperature
cools to below 50°C.
11. Note that the exterior housing will be hot during
and for a period of time after use.
12. Refer servicing to qualified personnel.
4
SAFET INFORMATION

5
Specifications
#
golataC lacirtcelE
)esahP/.qerF/sttaW/spmA/stloV(
erutarepmeT
*egnaR
egnaRdeepS
)mpr(
etalPpoT
yticapaC
H001001111/06/0141/7.11/021C°004-5A/N.sbl53/ksalfL6
S001001111/06/02/73.0/021A/Nmpr0021-06.sbl53/ksalfL6
HS001001111/06/0441/21/021C°004-5mpr0021-06.sbl53/ksalfL6
H61001111/06/583/2.3/021C°045-5A/N.sbl51/ksalfL1
S61001111/06/02/73.0/021A/Nmpr0021-06.sbl51/ksalfL1
HS61001111/06/593/3.3/021C°045-5mpr0021-06.sbl51/ksalfL1
H94001111/06/0601/8.8/021C°045-5A/N.sbl52/ksalfL4
S94001111/06/02/730./021A/Nmpr0021-06.sbl52/ksalfL4
HS94001111/06/0701/9.8/021C°045-5mpr0021-06.sbl52/ksalfL4
H94002111/06/066/5.5/021C°003-5A/N.sbl52/ksalfL4
S94002111/06/53/5.0/021A/Nmpr0021-06.sbl52/ksalfL4
HS94002111/06/086/7.5/021C°003-5mpr0021-06.sbl52/ksalfL4
H61101111/06-05/583/8.3/001C°045-5A/N.sbl51/ksalfL1
H94101111/06-05/0701/7.01/001C°045-5A/N.sbl52/ksalfL4
S94101111/06-05/52/74.0/001A/Nmpr0021-06.sbl52/ksalfL4
HS94101111/06-05/5901/0.11/001C°045-5mpr0021-06.sbl52/ksalfL4
S94102111/06-05/53/6.0/001A/Nmpr0021-06.sbl52/ksalfL4
HS94102111/06-05/086/8.6/001C°003-5mpr0021-06.sbl52/ksalfL4
H001101111/06-05/5211/2.11/001C°004-5A/N.sbl53/ksalfL6
S001101111/06-05/52/74.0/001A/Nmpr0021-06.sbl53/ksalfL6
HS001101111/06-05/0511/5.11/001C°004-5mpr0021-06.sbl53/ksalfL6
H61201111/06-05/024/7.1/032C°045-5A/N.sbl51/ksalfL1
S61201111/06-05/02/71.0/032A/Nmpr0021-06.sbl51/ksalfL1
HS61201111/06-05/044/8.1/032C°045-5mpr0021-06.sbl51/ksalfL1
H94201111/06-05/0511/8.4/032C°045-5A/N.sbl52/ksalfL4
S94201111/06-05/02/71.0/032A/Nmpr0021-06.sbl52/ksalfL4
HS94201111/06-05/0711/9.4/032C°045-5mpr0021-06.sbl52/ksalfL4
H94202111/06-05/096/9.2/032C°003-5A/N.sbl52/ksalfL4
S94202111/06-05/53/3.0/032A/Nmpr0021-06.sbl52/ksalfL4
HS94202111/06-05/027/0.3/032C°003-5mpr0021-06.sbl52/ksalfL4
H001201111/06-05/0351/4.6/032C°004-5A/N.sbl53/ksalfL6
S001201111/06-05/02/71.0/032A/Nmpr0021-06.sbl53/ksalfL6
HS001201111/06-05/0551/5.6/032C°004-5mpr0021-06.sbl53/ksalfL6
* This stirrin hotplate does not cool. The minimum temperature is 5°C if used in a cold room.

6
Specifications
Heating Specifications
Top Plate Surface - Solid Ceramic
Temperature range
All 4" x 4" and 7" x 7" models: 41°F to 1004°F (5°C* - 540°C)
All 10" x 10" models: 41°F to 752°F (5°C - 400°C)
Heat-up time to maximum temperature (unloaded top plate). 8 minutes
Temperature stability at the center of the top plate surface (@ 100°C). ± 2.0°C
Accuracy of the temperature display vs the actual average temperature of a ± 5.0°C
2” diameter of settingarea at the center of the top plate (setpoint 100°C).
(Top plate temperature was verified with an infrared camera mounted approx.
26" above the center of the top plate surface; temperature accuracy at the
edges of the top plate may vary from the stated accuracy.)
Stirring Speed Specifications
Speed Range 60 to 1200 RPM
(Maximum speed is dependent on the viscosity of the solution)
Speed Dial Position Estimated Stirring Speed
2 60 rpm
4 125 rpm
6 350 rpm
8 700 rpm
10 1100 rpm
12 1200 rpm
Stability of the stirring speed setpoint (600 ml of water in a 1000 ml glass flask) ± 5.0%
Top Plate Size Max Recommended Flask Size Max Weight on Top Plate
4" x 4" 1 liter 15 lbs
7" x 7" 4 liters 25 lbs
10" x 10" 6 liters 35 lbs
* This stirrin hot plate does not cool. The minimum temperature is 5°C if used in a cold room.

7
Environmental Conditions
Operating: 17°C to 27°C; 20% to 80% relative humidity, non-condensing. Installation category II
(overvoltage) in accordance with IEC 664. Pollution degree 2 in accordance with IEC 664.
Altitude Limit: 2,000 meters.
Storage: -25°C to 65°C
10% to 85% relative humidity
Declaration of Conformity
(for 230 volt)
We hereby declare under our sole responsibility that this product conforms with the technical requirements of
the following standards:
EMC: EN 61000-3-2 Limits for harmonic current emissions
EN 61000-3-3 Limits for voltage fluctuations and flicker
EN 61326-1 Electrical equipment for measurement, control, and laboratory use;
Part l: eneral Requirements
Safety: EN 61010-1 Safety requirements for electrical equipment for measurement,
control, and laboratory use; Part I: eneral Requirements
EN 61010-2-010 Part II: Particular requirements for laboratory equipment for the
heating of materials (Hotplates and Stirring Hotplates)
EN 61010-2-051 Part II: Particular requirements for laboratory equipment for mixing
and stirring (Stirrers and Stirring Hotplates)
per the provisions of the Electroma netic Compatibility Directive 2004/108/EC, and per the provisions of the
Low Volta e Directive 2006/95/EC.
The authorized representative located within the European Community is:
Thermo Fisher Scientific
Electrothermal House
Unit 12A
Purdeys Industrial Estate
Purdeys Way
Rochford, Essex, SS4 1ND
United Kingdom
Tel: [phone]
Copies of the Declaration of Conformity are available upon request.
SPECIFICATIONS

eneral Usage
Do not use this product for anything other than its intend-
ed usage.
Unpacking
Remove your Isotemp hotplate, stirrer or stirring hotplate
from the carton. Inspect to ensure that the unit has not
been damaged during shipment. If the unit appears to
have sustained shipping damage contact Fisher Scientific
at 866-984-3766.
The followin items are included in the shipment:
Isotemp Hotplate, Stirrer or Stirring Hotplate
Cord
Stir Bar (Stirring models only)
Adapter (100V models only)
Knob
Operator’s Manual
Installation
Set the unit on a flat stable surface at least 12" away from
combustible materials, and plug the cordset into a proper-
ly grounded electrical outlet of correct voltage and current
handling capacity.
8
Unpacking and Installation
Warning
Use a properly grounded electrical
outlet of correct voltage and current
handling capacity.

9
Setting the Stirring Speed
To set the speed, turn the STIR knob to the desired
setting. Turn the knob clockwise to increase the speed
or counter-clockwise to decrease the speed. To discon-
tinue stirring, turn knob counter-clockwise to OFF.
Setting the Temperature
To set the temperature, turn the HEAT knob to the
desired setting. Turn the knob clockwise to increase
the temperature or counter-clockwise to decrease the
temperature. To discontinue heating, turn knob count-
er-clockwise to OFF.
The temperature will display in °C. When choosing a
setpoint, the display will indicate the setpoint for 5 sec-
onds, after which the display will flash until the desired
setpoint is reached.
The “CAUTION - HOT TOP” indicator illuminates when
the plate reaches 50°C. When the heating is turned off,
the indicator will continue to flash until the plate tem-
perature drops below 50°C.
Heating Metal Vessels and
Sand Baths
Metal vessels and sand baths may be heated safely
without the danger of the ceramic top breaking. Use
the lowest temperature setting possible for applications
to limit thermal stress to the ceramic top. Using a
metal vessel or sand bath may reduce the life of the
stirring hotplate.
Operation
Warning
Use caution when heating volatile
materials; top surface and element
can reach the “Flash Point
Temperature” of many chemicals.
These hotplates and stirring hotplates
are not explosion proof. Fire or explo-
sion may result. Unit contains compo-
nents which may ignite such materials.
Use appropriate hand and eye protec-
tion when handling hazardous chemi-
cals.
“Caution: Hot Top. Avoid Contact.” The
top plate of the unit can remain hot for
some time after use. A “CAUTION -
HOT TOP” light will remain on until top
plate temperature cools to below
50°C.

10
eneral Cleaning Instructions
Wipe exterior surfaces with lightly dampened cloth containing mild soap solution.
Error Codes - Hotplates and Stirring Hotplates only
The following errors should not be addressed by the user. If any of the errors appear, contact Fisher
Scientific Technical Service at 866-984-3766.
Displayed Message Intended to Detect Cause Solution
E01 Thermocouple Thermocouple not connected. Replace element
Call Tech. Service out of range. assembly (attached to
thermocouple).
Thermocouple open circuit.
E02 Excessive heat-up time. Thermocouple short circuit. Remove short.
Call Tech. Service
Failure of element. Replace element
assembly (attached to
thermocouple).
Failure of element circuit. Replace Element.
Replace Control Board.
E11 Alternating current Failure to detect alternating Replace Control Board.
Call Tech. Service measurement failure. current.
E12 Motor system failure. Locked rotor condition. Free locked rotor.
Call Tech. Service
Failure of motor. Replace motor.
Failure of motor circuit. Replace Control Board.
Failure of motor sensor. Replace motor sensor.
Notes:
Errors E01 and E02 are heatin errors. Heatin functions will be locked out. Stirrin functionality is unaffect-
ed.
Errors E11 and E12 are stirrin errors. Stirrin functions will be locked out. Heatin functionality is unaffected.
Maintenance and Troubleshooting

11
Accessories
Part No. Description
10-666-10 Q Support Rod - 12”
14-666-10BQ Support Rod - 18”
14-666-10CQ Support Rod - 24”
Replacement Parts
Please refer to the Specification Plate for the complete model number, serial number, and series number
when requesting service, replacement parts or in any correspondence concerning this unit.
All parts listed herein may be ordered from Fisher Scientific by calling 866-984-3766
4x4 Ceramic 7x7 Ceramic 7x7 Aluminum 10x10 Ceramic
Part No. Part No. Part No. Part No. Description
261575 261575 261575 261575 PC Board Fuse - 220-240V
PCX118 PCX118 PC1895X1 PC1886X1 Control Board - 100V, 120V (SHP)
PCX119 PCX119 PC1895X2 PC1886x2 Control Board - 220-240V (SHP)
PC1887X1 PC1887X1 PC1893X1 PC1884X1 Control Board - 100V, 120V (HP)
PC1887X2 PC1887X2 PC1893X2 PC1884X2 Control Board - 220-240V (HP)
PC1888X1 PC1888X1 PC1888X1 PC1885X1 Control Board - 100V, 120V (S)
PC1888X2 PC1888X2 PC1888X2 PC1885X2 Control Board - 220-240V (S)
266058 266058 266058 266058 PC Board Fuse - 100V, 120V
PCX113 PCX113 PCX113 PCX113 Display Board
PC1363X3 PC1363X3 PC1363X3 PC1363X3 Speed/Heat Adjustment Board (2)
KBX111 KBX111 KBX111 KBX111 Knob (2)
CRX106 CRX106 CRX106 CRX106 Cord Set - 100V, 120V
CRX104 CRX104 CRX104 CRX104 Cord Set - 220-240V
KBX78 KBX78 KBX78 KBX78 Knob
ZSX122A ZSX65A ZSX65A ZSX65A Stir Bar
MT1313X3 MT1313X3 MT1313X3 MT1316X3 Motor - 120V, 100V
MT1313X4 MT1313X4 MT1313X4 MT1316X4 Motor - 220-240V
ELX41 ELX44 ELX77 ELX47 Heating Element - 120V - w/thermocouple
ELX42 ELX45 ELX78 ELX48 Heating Element - 100V - w/thermocouple
ELX43 ELX46 ELX79 ELX49 Heating Element - 220-240V - w/thermocouple
540-0033 710-0117 CT1420X1 719-0073 Ceramic or Aluminum Top
EL1310X1 EL1313X1 EL1895X1 EL1316X1 Hot Plate Top Assembly - 120V
EL1310X2 EL1313X2 EL1895X2 EL1316X2 Hot Plate Top Assembly - 100V
EL1310X3 EL1313X3 EL1895X3 EL1316X3 Hot Plate Top Assembly - 220-240V
---- ----- TC1895X1 ----- Thermocouple

12
Laboratory instruments and equipment manufactured by Fisher Scientific Company L.L.C. – Laboratory
Equipment Division (hereinafter called “the Company”) are warranted only as stated below.
Subject to the exceptions and upon the conditions specified below, the Company agrees, at its election, to
correct by repair, by replacement, or by credit to the purchaser, any defect of materials or workmanship which
develops within one year (13 months for refrigerator and freezer products) from the date of purchase by the
original purchaser by the Company or by an authorized dealer of the Company provided that investigation or
factory inspection by the Company discloses that such defect developed under normal and proper use
The exceptions and conditions mentioned above are the following:
a. The Company makes no warranty concerning components or accessories not manufactured by it,
such as tubes, batteries, etc. However, in the event of the failure of any component or accessory not
manufactured by the Company, the Company will give reasonable assistance to the purchaser in
obtaining from the respective manufacturer whatever adjustment is reasonable in the light of the
manufacturer’s own warranty.
b. The Company shall be released from all obligations under its warranty in the event repairs or
modifications are made by persons other than its own service personnel or authorized dealer
personnel unless such repairs by others are made with the written consent of the Company.
c. THE COMPAN MAKES NO WARRANT OF MERCHANTABILIT , FITNESS FOR AN
PARTICULAR PURPOSE, OR AN OTHER WARRANT , EXPRESS OR IMPLIED, EITHER IN
FACT OF B OPERATION OF LAW,…STATUTOR OR OTHERWISE.
d. The above warranty and the above obligations to repair, replace, or credit are complete and
exclusive and the Company expressly disclaims liability for lost profits or for special, indirect,
incidental, consequential, or exemplary damages of any nature whether attributable to contract,
warranty, negligence, strict liability, or otherwise even if the Company has been advised of the
possibility of such damages.
e. Representations and warranties made by any person, including dealers and representatives of the
Company, which are inconsistent or in conflict with the foregoing warranty shall not be binding upon
the Company unless reduced to writing and signed by an officer of the Company.
Warranty
For the name of the authorized Thermo Scientific product dealer nearest you or any additional information,
contact us:
308 Ridgefield Court, Ashville, NC, 28806 USA
Phone: [phone]
Fax: [phone]
Web: www.thermo.com
