Fisher SLIM-3010 User manual

INSTRUCTION MANUAL
SLIM3010

1
SAFETY INFORMATION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying this unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SAFETY CERTIFICATION
This unit is made and tested to meet exacting safety standards. It meets CSA and FCC requirements and
complies with safety performance standards of the U.S. Department of Health and Human Services.
CAUTION - USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
WARNING: TO AVOID THE HAZARDS OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR OTHER MOISTURE.
CAUTION: TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
Thank-you for choosing Fisher. This executive audio system includes a built-in CD player, AM/
FM stereo tuner, alarm clock, timer, motorized CD door, removable speakers and remote
control. The unit can be wall mounted in order to save desk or counter space.
++
INVISIBLELASER RADIATION
DONOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUME NTS
CLASS3A LASER PRODUCT
WARNING: Handling the cord on this product or cords associated with accessories sold with this product
will expose you to lead, a chemical known to the State or California to cause cancer, and birth defects or
other reproductive harm.
Wash hands after handling.
FCC information
For CD player section: This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between equipment and receiver.
- Connect the equipment to an outlet on a different circuit from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV tech.
FOR SAFE AND EFFICIENT OPERATION
- Do not damage the power cord.
- When not in use, disconnect the power cord from the outlet. Grasp the plug, not the cord, when
disconnecting the unit.
- If water should enter the unit, electrical shock or malfunction may result. Use in an area where there is low
humidity and little dust.
- Do not disassemble or alter the unit in any way.
- Do not use the unit in areas where extremes in temperature occur (below 40 F or exceeding 95 F), or
where it may be exposed to direct sunlight.
- Because of the CD player’s extremely low noise and wide dynamic range, there is a tendency to turn the
volume on the amplifier higher than necessary. Doing so may produce an excessively high output from the
amplifier, which can cause damage to your speakers. Please be careful in this regard.
- Sudden changes in the surrounding temperature can cause dew to form on the optical pickup lens inside
unit. Under this condition, the unit may be unable to operate properly. If this should occur, remove the disc
and allow the player to adjust to the surrounding temperature.
2
CLASS 1 LASER PRODUCT
PRODUIT DE LASER DE CLASSE 1. INVISIBLE LASER RADIATION
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 3A LASER PRODUCT
LASER APERTURE

3
Read Instructions - All the safety and operating instructions should be read before the
product is operated.
Retain Instructions - The safety and operating instructions should be retained for future
reference.
Heed Warnings - All warnings on the product and in the operating instructions should be
adhered to.
1.
2.
3.
Follow Instructions - All operating and use instructions should be followed.
Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Attachments - Do not use attachments not recommended by the product manufacturer as
they may cause hazards.
4.
5.
6.
Water and Moisture - Do not use this product near water - for example, near a bath tub,
wash bowl, kitchen sink, or laundry tub; in a wet basement, or near swimming pool, and the
like.
7.
Accessories - Do not place this product on an unstable cart, stand tripod, bracket, or
table. The product may fall, causing serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions and should use a mounting accessory recommended by the
manufacturer.
A product and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product and cart combination to overturn.
8.
9.
Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure
reliable operation of the product and to protect it from overheating, and these openings
must not be blocked or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product should not be placed in a
built-in installation such as a bookcase or rack unless proper ventilation is provided
according to manufacturer’s instructions.
Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instructions.
10.
11.
S3125A
PORTABLE CART WARNING
(symbol provided by RETAC)
4
Grounding or Polarization - This product may be equipped with a polarized alternating
current line plug (a plug having one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12.
14.
15.
Lightning - For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet. This will
prevent damage to the product due to lightning and power-line surges.
16.
Overloading - Do not overload wall outlet, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could result in
a fire or electric shock. Never spill liquid of any kind on the product.
Servicing - Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to qualified
service personnel.
Damage requiring Service - Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions,
adjust only those controls that are covered by the operating instructions as an
adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance.
17.
18.
Power-Cord Protection - Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed on or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point where they exit from the product.
13.

5
Replacement Parts - When replacement parts are required, be sure the service technician
uses replacement parts that have been specified by the manufacturer or that have the
same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
Safety Check - Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper operating
condition.
Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
Heat - The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.
Nonuse Periods - Unplug the product’s power cord when you will not use it for an
extended period.
19.
20.
21.
22.
23.
CONNECTIONS
AUDIO IN
Amplifier (for LINE IN)
AUDIO OUT
LINE (L)
LINE (R)
LINE (AUX) IN/OUT CONNECTIONS
Press the LINE (AUX) button (34) to select IN or OUT mode.
++
Active Subwoofer
SUBWOOFER CONNECTIONS
Connect the Active Subwoofer to the Subwoofer socket (45) at rear of main unit.
6
VCR (for LINE OUT)
VIDEO OUT
TV

LOCATION OF CONTROLS - UNIT
1
10
23
456789
11 12 13 14
16
18
22 23
26
27
24 25
30
31
32
33
34
21
7
2
35
36
37
38
39
49
48 51
50
53
54
28
29
43 42
41 40
15
19
20
++
47
46 45
44
52
LOCATION OF CONTROLS - UNIT (cont.)
Headphone Jack
CD Door
Detachable Three-Way Speaker (L)
CD Door OPEN/CLOSE Button
Open or close the CD door
VOLUME UP/DOWN Button
Adjust volume level
MOODLIGHT Button
Illuminates the CD compartment
Remote Sensor
LCD Display
SureWake LED Indicator
SureWake function on or off indicator
1.
2.
3.
4.
5.
6.
7.
8.
9.
BACKLIGHT Button
Selects display backlit on or off
CD SELECTION - Disc 3 Button
Selects disc 3
CD SELECTION - Disc 1 Button
Selects disc 1
CD SELECTION - Disc 2 Button
Selects disc 2
POWER STANDBY Indicator
Standby indicator is lit when system
switches off
10.
11.
12.
TUNER/BAND Button
To select AM or FM tuner (radio) modes
LINE Button
Activates operating mode LINE
MODE Button
Toggles the display contents
SUREWAKE Button
Turns on surewake function
FOLDER UP Button
Activates the MP3 album (Forward)
FOLDER DOWN Button
Activates the MP3 album (Backward)
STOP Button
To stop CD playback or clear CD
program
PLAY/PAUSE Button
To play or pause CD playback
14.
16.
21.
22.
24.
25.
26.
27.
13.
28.
29.
30.
8
MUTE Button
Mutes the sound
SLEEP Button
Press for sleep to music.
MEMORY Button
For tuner memory / CD program
SNOOZE Button
Switches off the unit for 9 minutes while
timer is on. The unit will then start again.
LINE IN/OUT Button
Selects Line IN or OUT mode
31.
32.
33.
34.
Detachable Three-Way Speaker (R)
LINE IN STEREO MINI Jack
LINE OUT RCA Jack (R/L)
TIMER Button
Activates the timer
23.
17.
18.
POWER ON/STANDBY Button
To power ON, standby light should be
switched off
15.
LINE Socket Cover
Opens line socket cover
19.
Pedestal20.
17

INSTALLATION (Unit)
INSTALLATION PEDESTAL
1
2
1. Carefully align the unit tabs onto the pedestal holder (1).
2. Push the unit backward until it clicks (2).
3
3
6
4
5
DISASSEMBLE PEDESTAL
1. Press down both side of safety lock ribs (3) then push forward slightly (4) at the same time.
2. Hold onto the unit (5) then push forward (6) again carefully to release the unit from the
pedestal.
10
LOCATION OF CONTROLS - UNIT (cont.)
SURROUND Button
Press to turn the surround sound ON or
OFF. The indicator lights while surround
is ON.
DYNAMICBASS Button
Press for a rich bass sound.
EQ Button
Selects FLAT, POP, ROCK, JAZZ and
DISCO sound effects
STEREO Button
Stereo / mono switching for FM stations
PRESET/REPEAT Button
-Retrieve preset radio stations (Forward)
-Repeats track / 1 disc / all discs for CD
mode
3 CD Changer Compartment
CD-TUNER-SKIP Button
-Manual tuning, station search (Forward)
-CD forward title selection, forward
search operation
42.
35.
36.
37.
38.
39.
40.
41.
CD-TUNER-SKIP Button
-Manual tuning, station search
(Backward)
-CD reverse title selection, reverse
search operation
MP3 MODE Button
Selects MP3 TITLE & ARTIST or ALBUM
AC Socket
Main power connection
NOTE:
If the system is connected to the power
voltage, part of the machine is in
operation due to the stand-by function. In
order to switch off the system completely,
pull out the power plug from the power
socket.
44.
43.
Wall Mounting Holder - Center unit
Used to mount the center unit on a wall
Wall mounting Holder - R-Speaker
Used to mount the R-speaker on a wall
Wall mounting Holder - L-Speaker
Used to mount the L-speaker on a wall
Reset Switch
If the system does not display
information, or the data appearing is
wrong, press the “RESET” switch with a
sharp object, e.g. needle or ballpoint pen.
The data must then be re-entered.
FM Antenna
Note - Do not connect to external antenna
Speaker Terminal
Battery Compartment
Batteries (3 x 1.5V “AA" size) for power
back-up of time and programmed radio
stations.
52.
48.
49.
50.
51.
9
Subwoofer Jack
To connect powered subwoofer (not
supplied)
DC 14V Jack
Connects to CAR/BOAT adapter
AM Antenna
AM antenna connection socket (connect
frame antenna included in this package)
45.
46.
47.
54.
53.

INSTALLATION (Speakers)
1
2
3
4
ASSEMBLE SPEAKERS
1. Carefully align the speaker studs with the holes on the side of the main unit (1).
2. Slide the speaker (2) downwards until it locks into place. Repeat for the remaining speaker.
To detach the speaker, pull up on the speaker (3) then release from the main unit (4).
11
To mount the center section on the wall:
Position the bracket (supplied) on the wall (as show below) where you want to hang the center unit. Drill
2 holes slightly undersized for a firm fit.
Secure the bracket on the wall using 2 dowels and 2 screws (supplied).
The mounting screws should be anchored into solid wall support, such as wood frame or concrete wall.
Mount the center unit onto the wall bracket.
Make sure the mounting tab on the center unit fits securely into the mounting slot on the wall bracket.
Screws and plastic dowels are also provided for speakers if they are to be wall-mounted away from the
center section.
INSTALLATION (Wall Mounting)
Installation options:
Wall mount
One or both speakers attached or detached
12

13
REMOTE CONTROL (Battery Installation)
1a
1b
2
3
Remove battery tray by pressing point
(1a) inside then sliding point (1b) area at
the same time.
Pull out the battery tray.
Install or replace the button type battery
“CR2032”.
Close the battery tray.
4
1.
2.
3
4
55 56 57 59 60 61
62
63 64
65 66
67 68
69
71 72
73 7475
86
77 78
58
LOCATION OF CONTROLS - REMOTE CONTROL
70
79 80
81 82
83
84
85
76
Note: Pull out insulation tag from the
button battery tray before operating the
remote control.
14
LOCATION OF CONTROLS - REMOTE CONTROL (Cont.)
TIMER Button
Activates/deactivates the timer
CD Door OPEN/CLOSE Button
Opens the door while the unit is on. Other
operating elements now become
accessible, and you can insert or remove
CDs.
MOOD LIGHT Button
Press to turn on soft lighting from the CD
door.
Remote Control Transmitter
EQ Button
Selects FLAT, POP, ROCK, JAZZ and
DISCO sound effects
POWER ON/STANDBY Button
Switches the system on or off
1 - 9, 0/+10 NUMERIC Buttons
Recalls TUNER preset stations / recalls
CD tracks
55.
56.
57.
58.
59.
60.
61.
62.
63.
64.
65.
66.
67.
68.
69.
73.
FOLDER Button
Selects MP3 album (reverse)
PLAY/PAUSE Button
To play CD, start CD playback / short
interruption of CD playback
MUTE Button
Mutes the sound
VOLUME (+) Button
Increases volume
CD / TUNER SKIP Button
-Manual tuning up to stations, station
search operation (Forward)
-CD forward title selection, forward
search operation
70.
71.
72.
74.
75.
76.
77.
MEM/PGM Button
For tuner memory / CD program
MP3 MODE Button
Selects title & artist or album in MP3
mode
REPEAT Button
Repeats 1 track / 1 disc / all discs in CD
mode
DISC-2 Button
Press to play CD tray-2
ST/MO / FOLDER Button
-Stereo/Mono switching for FM stations
-Selects MP3 album (Forward)
DISC-3 Button
Press to play CD tray-3
VOLUME (-) Button
Reduces volume
DYNAMICBASS Button
Press for a rich bass sound
SURROUND Button
Press to turn the surround sound ON
or OFF. The indicator lights while
surround is ON.
CD / TUNER SKIP Button
-Manual tuning down to stations,
station search operation (Backward)
-CD backward title selection,
backward search operation
TUNER / BAND Button
Activates TUNER mode and selects
the reception band
78. STOP Button
Interrupting the CD playback /
clearing the CD programme

LOCATION OF CONTROLS - REMOTE CONTROL (Cont.)
SLEEP Button
Press for sleep to music
CD selection - Disc 1 Button
Press to access disc 1
SNOOZE Button
Switches off the unit for 9 minutes while
timer is on. The unit will then start again.
MODE Button
Toggles the display contents
85.
79.
80.
81.
82.
INTRO Button
Plays 10 seconds of each CD track
RANDOM Button
CD play in random sequence
PRESET Button
Press to retrieve preset radio stations
(Forward)
LINE Button
Activates operating mode LINE
83.
84.
86.
15
POWER SUPPLY
AC power operation
Take the cord out and connect it.
BATTERY SUPPLY (For Tuner/Clock Memory Back-up)
+
-
+
-
NOTE:
This unit is equipped with a polarized plug. If you
have difficulty inserting the plug, turn it over and
reinsert it.
CAUTION:
TO PREVENT ELECTRICAL SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
Install batteries (not supplied).
Observe + and - signs.
Remember to replace the battery
compartment lid
3“AA” size batteries
CAUTION:
WHEN INSTALLING BATTERIES
To prevent leakage from the batteries, (leakage is
corrosive and can cause personal injury and
damage to the unit) observe the following
precautions:
The batteries must be installed correctly. Match
the polarities (+ and - signs) on the batteries, to
the polarities shown on the battery
compartment of the unit (see above).
Do not mix new batteries with old or used
batteries.
Only use batteries of the same type and brand.
If the unit will not be used for an extended
period of time, remove the batteries and store
them in a cool place.
Carefully follow the battery manufacturer’s
instructions for proper use and disposal.
DO NOT ALLOW YOUNG CHILDREN TO
HANDLE BATTERIES.
1.
2.
3.
4.
5.
6.
IMPORTANT NOTE:
SPENT OR DISCHARGED BATTERIES MUST BE
RECYCLED OR DISPOSED OF PROPERLY IN
COMPLIANCE WITH ALL APPLICABLE LAWS.
FOR DETAILED INFORMATION, CONTACT
YOUR LOCAL COUNTRY SOLID WASTE
AUTHORITY.
16
120V AC, 60 Hz
++
++
+
-

When the AC power is connected, the clock shows on the LCD display.
Press the POWER button to turn the unit 'ON'.
Note: The LCD display lights up.
You can now select your desired music source
by pressing one of the function buttons:
TUNER/BAND or CD PLAY/PAUSE or AUX.
To switch to POWER OFF, press the POWER
button.
POWER ON/OFF
The LCD display backlit goes off.
SETTING THE TIME
When the unit is first connected to AC power, the display shows "AM 12:00". To set the clock to the current
time proceed as follows:
OPERATING INSTRUCTIONS
17
With unit at off mode, press the MEM/PROG
button once, the hour digits begin to flash.
Press the SKIP Forward or Backward buttons to
adjust the hour. Be sure to set the hour
correctly for AM or PM.
Press the SKIP Forward or Backward buttons to
adjust the minute.
Press the MEM/PROG button again, the minute
digits begin to flash.
Press the MEM/PROG button once more, the
display stops flashing and the clock begins to
run.
1.
2.
3.
1.
2.
3.
4.
5.
Example : FM mode
NOTE: Please turn off the unit to standby mode before disconnecting main power supply from the unit.
MEMORY
MEMORY
MEMORY
POWER/STANDBY
POWER/STANDBY
TIMER ON/OFF SETTING
18
NOTE: The clock should be set before the Timer On/Off setting.
Press the SKIP forward or backward buttons to adjust
the hour. Be sure to set the hour correctly for AM or
PM.
Press the SKIP forward or backward buttons to adjust
the minute.
Press the MEMORY/PROGRAM button again, the
minute digits begin to flash.
Press the MEMORY button once more, the timer on
setting is finished.
3.
4.
5.
6.
Press the MEMORY/PROGRAM button once, the hour
digits begin to flash.
2.
With unit at off mode, press the TIMER button once, the
TIMER ON indicator begins to flash.
1.
Press the MODE button again, the TIMER OFF
indicator begins to flash.
Press the MEMORY button once, the hour digits begin
to flash.
Press the SKIP forward or backward buttons to adjust
the hour. Be sure to set the hour correctly for AM or
PM.
7.
8.
9.
Note: Timer “ON” indicator will stop flashing after about
3 seconds and then goes off.
Note: Timer function with Surewake starts the music
quietly and then increases the volume to room level to
make sure you awake (when SUREWAKE switch is set
at ON position).

SLEEP SETTING
Pressing the SLEEP button permits settings from 00
minutes to 120 minutes. When the desired time appears,
releasing your finger will set the time.
(Pressing "SLEEP" after the 120-minute position will cancel
the sleep timer)
Change of SLEEP
Press the MEMORY button again, the minute digits
begin to flash.
10.
Press the SKIP forward or backward buttons to adjust
the minute.
11.
Press the MEMORY button once more, the timer off
setting is finished.
12.
Note: Timer “OFF” indicator will stop flashing after
about 3 seconds and then goes off.
To cancel the timer on setting, press the TIMER button
until “TIMER” display goes off.
13.
SNOOZE FUNCTION
If the unit has switched itself on by means of the timer function, press the SNOOZE button to switch the unit
off for approximately 9 minutes. After this time, the unit switches itself on again. Then press the SNOOZE
button again for another 9 minutes, or switch the unit off with the POWER/STANDBY button.
00 10 20 30 40 50 60 90 120
19
BASIC OPERATION
Electronic volume control
Electronic volume control display
Press VOLUME UP or DOWN button to
adjust sound level, the volume level (MIN -
01 ~ 59 - MAX) will be shown in the LCD
display.
Holding down the button will result in
continuous increase or decrease of the
volume.
1.
2.
MUTING FUNCTION
If the MUTE button is pressed, the audio output will
be muted, and "MUTE" indicator will be displayed.
Press once more to cancel.
Cancel Muting
Switching the display
Pressing MODE button in the power Off mode
changes the setting as follows:
Clock Timer On
Setting Timer Off
Setting
Pressing CD/MODE button in the CD playing
mode changes the setting as follows:
Playing time Clock Timer On
Setting Timer Off
Setting
Pressing CD/MODE button in the tuner mode
changes the setting as follows:
Tuning display Clock Timer On
Setting Timer Off
Setting
20
Example : Muted FM mode
DYNAMICBASS Control
Press the DYNAMICBASS button to get a rich bass
sound.
Note: Display will recall the most recent setting
when you first press DYNAMICBASS button.
To cancel the DYNAMICBASS function, press once
more.
PRESET EQ FUNCTION
Press the EQ button repeatedly to cycle through the
preset EQ shown on the LCD display - FLAT, POP,
ROCK, JAZZ and DISCO.
SURROUND FUNCTION
Press the SURROUND button on remote control to
ON for full sound.

4.
Manual Tuning - Press and hold the SKIP
forward/backward buttons until the display
approaches your desired station. Then tap the
buttons repeatedly until the display shows the
exact frequency.
Auto tuning - Press the TUNING forward or
backward buttons momentarily and release.
The tuner will move up or down to the next
available station.
Press the POWER button to turn the system
'ON'.
1.
2. Press the TUNER/BAND button to select the
radio function.
3. Press the TUNER/BAND button repeatedly to
select AM or FM band.
1.
STORING PRESET STATIONS
The unit enables you to randomly preset 16 stations
for FM and 16 stations for AM band.
STEREO / MONO Function
Repeatedly pressing the button “ST / MO” switches between stereo and mono reception. The stereo
reception of a station in the FM band is indicated on the display.
In the case of stereo stations with a bad reception (noise infested reception) we recommend switching the
tuner to mono reception. Press the “ST / MO” button. In the display, the STEREO indicator disappears in
mono mode.
LISTENING TO THE RADIO
Example : FM mode
5. When finished listening, press the POWER/
STANDBY button to shut the system OFF.
Press the SKIP forward or backward buttons to
tune to the desired station.
2. Press the MEMORY button once.
4. Press the MEMORY button again. The station
is stored in channel 2.
Tune to the station you wish to store.
3. Press the PRESET/REPEAT button repeatedly
to set the desired preset station number.
5. To store other stations, repeat above steps.
RECALLING PRESET STATION
Press the PRESET/REPEAT button repeatedly
to select the desired station.
21
FM
BAND
PRESET/
REPEAT
Switch on the power and press the PLAY/
PAUSE button to select the CD mode.
IN PLAY MODE
PRESS ONCE PRESS TWICE IN STOP MODE PRESS ONCE
BACK TO THE
BEGINNING OF
THE CURRENT
TRACK
PREVIOUS
TRACK PREVIOUS TRACK
NEXT TRACK NEXT TRACK
Press and hold the SKIP button during playback.
:: FAST BACKWARD : FAST FORWARD
NOTE : During the search mode low level audio will be heard to assist in locating the
correct point in the track.
PLAYING COMPACT DISCS
If there is no CD inside, a "NO DISC" display
will appear.
When there is no disc
1.
2.
Loading a disc
Press the CD DOOR OPEN/CLOSE button to
open the CD door.
To load a disc to 3 CD changer, simply put the
disc onto the center spindle of the player and
then press CD DOOR OPEN/CLOSE button
again to close the CD door. After that, reading
TOC will start.
After reading TOC (1st Disc)
To play the disc
Press PLAY/PAUSE button to play the CD.
Playing disc 1 track 1
To pause the playing
Press PLAY/PAUSE button while the disc is
playing, the playing time will flash.
While paused
To stop the disc playing
Press STOP button.
Stop condition (TOC display)
Skip and Search Function
Press the SKIP forward or backward buttons momentarily.
Ensure that the disc is correctly mounted on the
spindle and locked in place.
22
1.
2.

To repeat a track or disc
Random play function
PROGRAMMED PLAYBACK
The CD player enables you to program up to 40 tracks in a sequence of your choice. First select CD stop
mode.
1. Press the MEMORY button on remote control
one time.
3. Press the MEMORY button again, then track 4
is stored.
2. Press the SKIP forward or backward buttons to
select the desired track to be programmed.
4. Continue to program, repeat steps 2 and 3.
Press PLAY/PAUSE button to play the program
tracks.
5.
23
Press REPEAT button on remote control:
Press once for one track repeat
Press RANDOM button on remote control in stop
condition to start random play. Press once again to
cancel the function.
Note: Random play can not operate while playing
programmed tracks.
Random playing start
Intro play function
In stop condition, press the INTRO button on
remote control. After that the first 10 seconds of
each song will be played.
If the INTRO button is pressed again, the CD will
change to normal playing mode.
Intro playing
Program input mode
Choose track 4
Note: If the program function has stopped with
MEMORY indicator displayed, press the PLAY/
PAUSE button, the program play will start.
Clear the program
In stop mode, press the STOP button once, the
MEMORY indicator will go off and the preset
programs will be cancelled.
Press twice to repeat all tracks
in playing disc Press three times to repeat tracks in all discs
With one further press, the repeat
mode is cancelled.
24
PLAYING MP3 DISC
Switch on the power and press the PLAY/
PAUSE button to select the CD mode.
After reading TOC
Press the FOLDER or buttons to
select desired album.
1.
2.
3.
4.
To repeat a track or Folder
Press the REPEAT Button on remote control
once, MP3 plays one track repeatedly and
“REPEAT” is displayed.
Press this button twice, MP3 plays all tracks
within the selected album repeatedly and
“REPEAT ALL” is displayed.
Press this button three times, MP3 plays all
tracks on the disc and REPEAT ALL DISC is
displayed.
To cancel repeat function, Press the REPEAT
button repeatedly until repeat function display
goes off.
1.
2.
3.
4.
Random play function
Press RANDOM button on remote control in stop
condition to start random play. Press once again to
cancel the function.
Random playing start
One track repeat
All track repeat
All disc repeat
Intro play function
In the stop condition, press the INTRO button on
remote control. The first 10 seconds of each song
will be played.
If the INTRO button is pressed again, normal
playing mode will resume.
Intro playing
Press the SKIP or buttons to
select desired track.
Press the PLAY/PAUSE button to play MP3.
Note: When an MP3 disc is playing, press and
hold the MP3 MODE button, and the track no.,
title and artist information will be shown
repeatedly in the display if disc information is
available.
To resume normal play display, press the
MP3 MODE button repeatedly until playing
time appears.

PROGRAMMED PLAYBACK
Press the MEMORY button on remote control
once.
Press the SKIP or buttons or
Numeric buttons on remote control to select
your desired track.
Press the MEMORY button again to store the
selected track. (for example, track 38 shown
below)
The MP3 player enables you to program up to 40 tracks in a sequence of your choice. First select CD stop
mode.
1.
2.
3.
4. Continue to program, repeating steps 1 to
3.
Press PLAY/PAUSE to play the
programed tracks.
5.
Note: If the program function has stopped
with MEMORY indicator displayed, press
the PLAY/PAUSE button, the program
play will start.
Clear the program
In the stop mode, press the STOP button once,
the MEMORY indicator will go off and the
preset programs will be cancelled.
25
CARE AND MAINTENANCE
26
CLEANING THE UNIT
Caution: never allow any water or other liquids to get inside the unit while cleaning.
COMPACT DISC CARE
Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to come in
contact with the shiny, unprinted side of the disc.
Do not attach adhesive tape, stickers etc., to the disc label.
Clean the disc periodically with soft, lint-free, dry cloth. Never use detergents or adhesive cleaners
to clean the disc. If necessary, use a CD cleaning kit.
If disc skips or gets stuck on a section of the disc, it is probably dirty or damaged (scratched).
When cleaning the disc, wipe in straight lines from the centre of the disc to the edge of the disc.
Never wipe in a circular motion.
To remove a disc from its storage case, press down on the centre of the case and lift the disc out,
holding it carefully by the edges.
Fingerprints and dust should be carefully wiped off the disc's recorded surface with a soft cloth.
Unlike conventional records. compact discs have no grooves to collect dust and microscopic debris,
so gently wiping with a soft cloth should remove most particles.
To prevent fire or shock hazard, disconnect your unit from the AC power source when cleaning.
The finish on the unit may be cleaned with a dust cloth and cared for as other furniture. Use caution
when cleaning and wiping the plastic parts.
If the cabinets become dusty, wipe them with a soft dry dust cloth. Do not use any wax or polish
sprays on the cabinets.
If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a soft cloth
slightly dampened with a mild soap and water solution. Never use abrasive cloths or polishes as
these will mar the finish of your unit.

27
Symptom Possible cause Solution
Noise or sound distorted on AM or
FM broadcasts. Station not tuned properly for AM
or FM Retune the AM or FM broadcast
station.
Volume at minimum Increase Volume.
FM: Line antenna is not extended.
Set FM MODE to FM STEREO
position.
TUNER Function button is not
pressed.
AM or FM, no sound.
FM MODE button is set to MONO
position.
Press TUNER function button.
FM STEREO indicator does not
light
AM: Unit is not positioned correctly. Rotate unit until best reception is
obtained.
TROUBLESHOOTING GUIDE
Should this unit exhibit a problem, check the following before seeking service.
Radio
Extend FM line antenna.
Compact Disc Player
CD Player will not play. CD Function button is not pressed. Press the CD Function button.
CD is not installed or installed
incorrectly. Insert CD with label side out.
CD skips while playing. Disc is dirty or scratched. Wipe disc with cloth or use
another disc.
Disc is inserted but CD player
skips over spot and will not play, Disc inserted upside down. Insert disc properly.
Disc is dirty. Clean disc.
Disc is non-standard. Use correct disc.
AC Power AC 120V, 60Hz
Power Output 10 W CH 10% THD
Dimension of:
Main Section 723(W) x 428(D) x
213(H)mm (Approx.)
Radio section Tuning : PLL with 32 Random
Preset Memory
Freq. Range : AM 530-1710KHz
FM : 87.5-108MHz
CD Section Vertical Front Loading CD
Speaker System Woofer: 5 1/4", 4 ohms
Tweeter: 2", 4 ohms
Remote Control 41 Keys, Battery size “CR2032”
(Battery included)
SPECIFICATIONS
28
OBLIGATIONS
In order to ogtain factory warranty service, call the toll-free number below. The unit must be packed in the original carton or
a well padded sturdy carton in order to avoid shipping damage.
Note: Do not return this unit to the retail store for service.
To obtain factory warranty service product operation or for problem resolution, call
Customer Information 1-800-421-6382
Weekdays 8:00 AM -5:00 PM Pacific Time
THIS WARRANTY IS VALID ONLY ON FISHER PRODUCTS PURCHASED AND USED IN THE UNITED STATES OF
AMERICA.
THIS WARRANTY APPLIES ONLY TO THE ORIGINAL RETAIL USER, AND DOES NOT APPLY TO PRODUCTS USED
FOR ANY INDUSTRIAL, PROFESSIONAL OR COMMERCIAL PURPOSE. THE ORIGINAL DATED BILL OF SALE OR
SALES SLIP MUST BE SUBMITTED AT THE TIME WARRANTY SERVICE IS REQUESTED.
Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO FISHER COMPANY (SFC) warrants this FISHER
product against defects in materials and workmanship for the periods of LABOR and PARTS specified below. SFC will
repair or replace (at its option) the product and any of its parts which fail to conform to this warranty with new or
reconditioned products or parts.
This warranty period commences on the date the product was first purchased at retail.
This warranty does not cover (A) the adjustment of customer-operated controls as explained in the appropriate model's
instruction manual, or (B) the repair of any product whose serial number has been altered, defaced or removed.
This warranty shall not apply to the cabinet or cosmetic parts, antenna, knobs, batteries or routine maintenance.
This warranty does not apply to uncrating, setup, installation, removal of the product for repair or reinstallation of the
product after repair.
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of SFC including,
but not limited to, any malfunction, defect or failure caused by or resulting from unauthorized service or parts, improper
maintenance, operation contrary to furnished instructions, shipping or transit accidents, modification or repair by the user,
abuse, misuse, neglect, accident, incorrect power line voltage, fire, flood or other Acts of God, or normal wear and tear.
The foregoing is in lieu of all other expressed warranties and SFC does not assume or authorize any party to assume for it
any other obligation or liability.
THE DURATION OF ANY WARRANTIES WHICH MAY BE IMPLIED BY LAW (INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS) IS LIMITED TO THE TERM OF THIS WARRANTY. IN NO EVENT SHALL SFC BE
LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF
THIS PRODUCT, OR FOR ANY DELAY IN THE PERFORMANCE OF ITS OBLIGATIONS UNDER THIS WARRANTY
DUE TO CAUSES BEYOND ITS CONTROL.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
For your protection in the event of theft or loss of this product, please fill in the information below for your own personal
records.
EXCLUSIONS
Model No.
Date of Purchase
Where Purchased Purchase Price
Serial No.
(Located on back or bottom side of unit)
LABOR PARTS
90 DAYS 90 DAYS
FISHER STUDIO STANDARD
MODEL SLIM-3010 LIMITED WARRANTY
