•If the drain hose is placed on the ground or if the standpipe or tub is less than 800mm
high, the washing machine will continuously drain while being filled (siphon).
•Regularly check that your standpipe or tub is free from lint or other obstructions, which
may affect how your machine works or may cause flooding.
Attaching drain hose to spigot
1. Guide drain hose through hose guide
2. Secure hose guide to back wall of cupboard using a screw. The
height of the drain hose should be between 500 – 800mm from
ground level.
3. Attach drain hose to spigot and secure using a hose clamp
ensuring the blanking insert is cleared from spigot.
4. Check for leaks.
• The drain hose should be checked from time to time and
replaced if any damage (eg wear, cuts, bulges, kinks, leaks, etc)
is found. Do not bend the drain hose sharply, as this may cause
it to split.
• In multi-story apartments or any upper floor, the machine should
be installed on a floor equipped with a drain.
• Draining must comply with local by-laws.
Electrical connection
1. This appliance must be connected to a 220V – 240V, 50Hz, sinusoidal, minimum 10A electrical supply.
2. Uncoil the power cord, remove and discard the plastic pin cover and plug into a wall socket.
3. Connect the appliance to an earthed outlet protected by a fuse of suitable capacity.
• Check the power cord for damage and make sure it is not squashed or twisted when installing the
washer.
• Always remove the power cord from a socket by the plug, not by the cord.
