FISIOTECH ANDROMEDA User manual

Rev.05 09/2020
USE AND MAINTENANCE MANUAL
ANDROMEDA
ANDROMEDA LARGE COUCH
SIMPLE SERIES
ANDROMEDA COUCH MODELS
Description
Code
Andromeda with foot pedal
112131
Andromeda LARGE with foot pedal
112141

2 of 16
Table of contents
INTRODUCTION p. 3
SAFETY p. 4
WARNINGS –WARRANTY –
PACKAGING –UNPACKING p. 5
PRODUCT LABEL AND SYMBOLS p. 6
TECHNICAL SPECIFICATIONS p. 7
TECHNICAL SPECIFICATIONS OF THE POWER GRID p. 8
WARNINGS p. 9
HOW TO USE THE COUCH p. 10-11
PROBLEMS, CAUSES AND SOLUTIONS p. 12
MAINTENANCE p. 13
CLEANING p. 14
SPARE PARTS –OPTIONAL ACCESSORIES p. 15
INSPECTION RECORD SHEET p. 16

3 of 16
The purpose of this manual is to provide users and operators with the necessary information to use the couch
properly, autonomously, and safely.
This manual contains information on the technical features, operation, maintenance, spare parts and security
of the couch.
This manual must always be carried with the equipment and stored with care so that the readability is not
compromised.
In case of transfer of use to a third party, this manual must be transferred as well, along with the other
documents, as provided by Council Directive 93/42/EEC.
Intended use
The ANDROMEDA / ANDROMEDA LARGE couch is a professional couch used by rehabilitation and
physiotherapy professionals.
Manufacturer’s details
FISIOTECH SRL
Operating headquarters: Via Toniolo, 44/E-F
31028 VAZZOLA (TV) - Italy
Tel. [phone]
Fax [phone]
[email protected]
Area of use
The medical devices described in this manual comply with the Directive 93/42/EEC as modified by Annex VII
to Directive 2007/47/EC. Area of use: outpatient care carried out under medical supervision in hospital or in
another medical centre where the medical electrical equipment are used for the treatment, diagnosis and
monitoring of sick patients, people who have sustained injuries and people with disabilities.
Storing
In case of storing, the following environmental conditions must be ensured: relative humidity 10% ÷ 90 % -
temperature -10°C ÷ +50°C –Clean place.
WARNING! Thoroughly read the manual before use.
FISIOTECH SRL refuses any responsibility and is not liable in case any
damage to peopleand/or goods caused by the improper use of the couch,
by negligent or not-qualified staff or by non compliance with these
instructions occurs.

4 of 16
WARNING! Do not use the couch:
Beyond its declared maximum safe working load.
On unstable floors or near inclined floors, steps, etc.
If it has been tampered with or modified.
In a potentiallyexplosive atmosphere where a fire hazard or corrosion mayoccur, or exposed
to the weather.
With an inappropriate configuration or if you suspect it may harm the patient.
WARNING!
Do not touch the moving areas of components and/or controls, which are specifically labelled.
When not supervised, leave the couch on its lower position and horizontal.
Special attention or the use of safety devices (e.g. cot sides) is advised when the couch is
used by the elderly or by those with reduced balance.
WARNING! ELECTRICAL PARTS
Only connect to electrical systems complying with the law.
Do not pull the power cord to unplug the device.
Do not pour liquids on the device.
Always unplug the device before working on any electrical part or before moving the device.
Do not damage the cables; avoid crushing the cables; do not unplug by pulling the cable, pull
the plug instead, etc.
Always check the power cord. In case it needs to be replaced, please refer to the vendor.
Unplug the power cord if the device will not be used for a long period of time. Doing so
increases the lifespan of the device and limits the already low energy consumption.
In case of breakdown or malfunctioning, unplug the device.
The warranty is void in case of misuse, negligence, if power is supplied at a different voltage
or if non-authorized personnel attempts repairing the device.
Do not cut the plug of the couch in case it is not compatible with the power socket. The
temporary use of an adapter until the problem is solved is advised. If the plug is cut, the
warranty is void.
Do not open the motor/actuator, the foot pedal and/or the hand control, or the warranty is
void. If the couch does not work, even though it is plugged in, please contact the vendor.

5 of 16
Foot pedals are not designed to support the weight of a person. Do not step on the foot pedals or on
the all round foot bar switch.
Do not use the lift mechanism constantly. Please follow the instructions at page 8: TECHNICAL
SPECIFICATIONS OF THE POWER GRID.
Expanded rubber and plastic components of the device may catch fire if exposed to open flames.
The couch may be moved thorugh the retractable castors only when unloaded.
Therapy lamps may damage the upholstery.
Corrosive and/or abrasive cleaning agents may damage the upholstery.
We recommend using a couch paper sheet between the patient and the antibacterial and fungicide
leatherette and to replace it at the end of the treatment/examination.
The ANDROMEDA / ANDROMEDA LARGE couch warranty covers only the manufacturing defects for 24
months starting from the date of delivery. The warranty does not cover: consumables and items of normal wear
–such as upholstery, foot pedals/hand controls, power cables and bearings –, breakdowns caused by any
impact and/or fall, wrong or improper use, use by non qualified personnel. The warranty is automatically void
if the seal of warranty has been damaged or altered. The warranty is void if the device has been tempered
with. Warranty repairs are carried out at our operational headquarters and prior authorization. The products to
be repaired under warranty must be shipped to the manufacturer freight prepaid and with the original
packaging. A copy of the invoice and of the transport document has to be sent along with a written request in
order for the products to be repaired.
The packaging consists of a cardboard box, with a lid and a bottom. The box is closed with iron
staples and placed on a pallet especially designed for this kind of box. The box is secured to the
pallet with plastic straps.
WARNING! The couch is heavy (about 90 kg) and, above all, bulky.
Dimensions of the packaging: length 195 cm –width 72 or 85 cm –height 70 cm. The couch
has to be handled extremely carefully. The unloading must be carried outwith the appropriate
equipment (e.g. forklift) or by at least 3/4 people.
This symbol on a product means that it should not
be thrown with regular waste, but disposed of
following the laws on recycling/disposal in force in
your country/region.
After placing the pallet containing the couch on a suitable surface cut the plastic straps securing the
pallet to the couch and closing the box.
WARNING! Be careful not to cut your hands while handling cutters, scissors or other
cutting items. The use of rounded edge scissors is advised to avoid harming your hands and
the upholstery of the couch. Save packaging for a possible return to the manufacturer.
Dispose of plastic straps, cardboard, and bubble wrap as recycling material.

6 of 16
Manufacturer
Product Code
Serial Number
Date of manufacture
Max working load
Warning
Temperature limit
Humidity limitation
Keep away from sunlight and heat sources
Keep away from rain
Read the instructions
This symbol on a product means that it should not
be thrown with regular waste, but disposed of
following the laws on recycling/disposal in force in
your country/region.

7 of 16
Adjustable height between 47 and 80 cm. Electric elevation with foot pedal.
Headrest angle +60° / –20° with gas spring.
Breathing hole and bung.
Dimensions cm 190 X 65 or 80 X 47/80.
Maximum static working load 200 kg, evenly distributed.
Under bed clearance 17 cm.
Lateral offset 32 cm.
Power supply 230V 50Hz.
Powder-coated steel frame.
4 cm-thick polyurethane foam fireproof padding. Density: 30 kg/m³.
Fireproof leatherette upholstery.
THE BASE OF THE ANDROMEDA / ANDROMEDA LARGE COUCH IS
SPECIFICALLY DESIGNED SO THAT THE PATIENT HOIST CAN BE
PLACED UNDER THE COUCH.

8 of 16
Class II 230V 50Hz power cord.
Low voltage 24V direct current motor.
Low voltage 24V foot switch/hand control.
Automatic limit switch.
With resettable thermal fuse.
WARNING! Please note that the actuator/motor should be ran
intermittently: max 2 minutes on/18 minutes off.

9 of 16
WARNING
The professional should be very careful:
1. Not to place his and/or the patient’s hands and/or feet in the areas highlighted by the
symbols below in order so avoid pinching/crushing.
2. Not to sit on the headrest.
3. Not to sit or concentrate load on the extremities of the couch (head-/backrest –footrest).
WARNING! The professional should never leave the patient
unattended to prevent falls. The manufacturer is not liable for any
damage to people and/or goods caused by negligent and/or not-qualified
personnel.

10 of 16
HOW TO USE THE COUCH
WARNING! The castors are designed to move the couch only. The
couch should not be used to move people and/or goods.
The height adjustment between 47 and
80 cm is carried out through the foot
pedal.
L1 lever
The headrest can be adjusted
through a gas spring operated with
a specific lever. In order to adjust
the inclination, pull the lever (L1)
and set the desired position; when
the desired position has been
reached, release the lever (L1).
Push the pedal all the way through
in order to use the castors. Pull the
pedal in order to lift the castors.
PEDAL

11 of 16
PAPER ROLL HOLDER
Raising the cot sides: Lift both cot
sides simultaneously and fasten
them.
Lowering the cot sides: Lower both
sides simultaneously.
COTSIDES
The paper roll holder is placed
under the footrest.

12 of 16
PROBLEM
CAUSES
SOLUTIONS
The actuator/motor
does not work
The plug is not plugged in
properly or the power is
out.
Plug the device to a power socket
abiding by the technical
specifications of the power grid
listed on p. 8.
The actuator/motor
does not work
Major problem (e.g. blown
fuse or broken control box)
Please refer to the vendor.
The actuator makes
screeching noises
There is dust on the stem.
Dust the stem with a non-abrasive
rag. Sometimes lightly oil the stem
(with liquid paraffin or cooking oil).
The headrest gas spring
does not work
The gas spring is empty.
The gas has leaked.
Please refer to the vendor in order
for the gas spring to be replaced.

13 of 16
Maintenance must be carried out by a specialist, an electrician or someone who is familiar with the
content of this manual.
Check the safety conditions of the device after any incident such as falls, violent impacts, spilling of
liquids, etc. and any time you deem it necessary.
WARNING!
- Unplug the device before maintenance.
- In case of safety hazard, the device must be unplugged and is not to be used until safety is
restored.
- Actuators, control boxes, foot pedals/switches or hand controls will be completely replaced if
broken. Do not open or tamper with the above-mentioned components or the warranty will be
void and the manufacturer will not be liable for any damage.
MAINTENANCE
WHAT TO DO
Electrical parts
No maintenance needs to be carried out on the actuator,
apart from what was mentioned under “Troubleshooting”.
Check the conditions of the foot pedal and power cord
every 3 months. If the cables are worn and/or frayed they
need to be replaced.
Check whether the couch makes unusual noises or
vibrates when it is moving every 6 months. Any noise or
vibration may be a sign of malfunction of the actuator
and/or mechanisms.
Complete the maintenance activating the couch with the
maximum safe working load.
Mechanical parts
Check the tightening of screws and bolts, the play of
bearing and pins, the absence of structural damages and
warpage every 3 months or after heavy usage.
Check the control cables, gas springs and sheats.

14 of 16
The use of disinfectants is advised in order to disinfect hands and other parts of the body that came
into contact with the patient or other surfaces.
WARNING! Unplug the couch before cleaning the electrical parts.
Cleaning the upholstery:
Clean with a damp soft cloth with a neutral detergent solution, rinse with clean water.
WARNING!
Do not use solvents, bleaches, synthetic detergents or polishing sprays.
Avoid direct sunlight on the upholstery in order to avoid early ageing.
Excessive rubbing may cause the early ageing of the device. Thoroughly verify that this
operation is carried out correctly.
Light colours should not come into contact with fabrics and clothes which have been treated
with unbound dye or not properly dyed in order to avoid colour spots and stains which may
not be removed.
Sanitation
Spray the surface with a 0.5% peroxide-based solution and rinse thoroughly. FREQUENCY: Daily
up to 6/8 per day
WARNING! Using detergents with additives and/or alcohol tends to increase the wear and
tear process and the ageing of the surface.
Cleaning the powder coated steel:
Gently dust with a dry or at most a lightly damp non-abrasive cloth.
WARNING!
1. Aggressive products may damage the frame and the upholstery.
2. Check whether all the components are completely dry before using the device after cleaning.

15 of 16
CODE
DESCRIPTION
MOAT000006
Motor / actuator
MOCT000002
Control Box
MOLT000001
Power supply
MOPT000001
Foot pedal for actuator/motor with cord
GAP4000001
Headrest gas spring
GAS0000005
Wires for headrest gas spring kit
GAS0000012
Mechanism to unlock all gas springs
MIM1121301
Complete padding for ANDROMEDA couch
MIM1121401
Complete padding for ANDROMEDA LARGE couch
CODE
DESCRIPTION
120010
Paper roll holder for electrical couches
120060
60cm-wide, 65mt-long double-ply paper roll
122010
Four castors
120030
Folding cot sides
120040
Terry towel couch cover for 65cm-wide couches
120050
Terry towel couch cover for 80cm-wide couches
OUR COLOURS
Metal frame
Textured RAL 9001 cream
Upholstery
Beige, yellow, orange, burgundy, green, blue, grey, and black

16 of 16
INSPECTION RECORD SHEET
DEVICE MODEL / CODE:
………………………………………
INSTALLATION DATE
………………………
SERIAL No.
…………………….
Inspection
Date
Maintenance
Name of the inspector
Signature
