INSTRUCTION MANUAL
™
DUAL HEAD
WEED BURNER

a
b
d
f
e
1
Flame King
#YSN1000K
TORCH COMPONENTS
a. Dual Large, wide nozzles
b. Arm support
c. Flame control knob
d. Handwheel tightener
e. Idle/boost control lever
f. Grip handle
g. Nozzle cooling stand
h. Dual Switch Piezo-powered ignitors
i. 16-ft hose
j. Assembly wrenches (included)
i
g
h
c
j
1. Remove torch from the box
2. Straighten out the dual head neck
3. Apply both wrenches as shown in the
graph to tighten and lock in place
(apply wrenches here)

2
Flame King
GAS ROOFING BURNER FOR LIQUID GAS
#YSN1000K
OPERATIONAL SAFETY
The torch has no temperature indicator. Careless handling of the tool may cause fire. Protect yourself and the
environment and observe applicable safety measures.
CAUTION!
1. Do not put the torch burner close to face and hands.
There is risk of burns.
2. The burner heats up very much during torch
operation. High temperature remains for some time
after the torch is switched off.
3. Do not put hot torch burner close to flammable
materials.
4. Before storing ensure that gas valve wheel is turned
off, hot torch must cool down.
5. Do not store the gas container in temperature
above 40°C (104ºF) or in direct sunlight.
6. Keep the torch beyond reach of children.
7. With this torch use propane, butane or propane and
butane mixed.
8. Protect the torch and rubber hose against oil, acids
and other chemical agents.
9. When operating the torch always use personal
protection measures: protective glasses and gloves.
10. Do not operate damaged torch or a torch with
damaged rubber hose.
11. Do not repair the torch by yourself, do not dismantle
parts of the torch.
12. Use the torch accordingly to the manual.
WARNING!
– Do not use brazed joints for elements that may be
subject to temperature above 130°C.
– Do not join parts used for lifting weights with brazed
joints.
CAUTION!
Ensure that flexible, rubber hose between
torch and gas container is in good technical
condition, connection is air-tight, and gas pressure does
not exceed the value on the rubber hose.
CAUTION!
Rubber hoses are equipped with left hand
thread connectors.
CAUTION!
All checks and repairs should be carried out by
the supplier’s service department or by service
site certified by the supplier. All checks and repairs must
be carried out only when rubber hose is disconnected
from the gas cylinder. Cut o gas supply before
disconnecting the hose!
CAUTION!
Do not pull the rubber hose to move or lift gas
container.
Check condition of rubber hose each time
before starting work. In case any damage is found
(accidental surface cut, signs of burns, bulge or
change of diameter) immediately replace the hose
with a new one.
Rubber hose also must be replaced not later than 5
years from its production date specified on the hose.

3
Flame King
TECHNICAL PARAMETERS
Flame temperature [°C] 1850
Gas consumption [g/h] 7800
Burner power [kW] 110
Number of burners 2
Burner diameter (mm) W = 50
Type of burner roofing
Hose length 5m
Additional equipment 50 cm gas supply stiff
connection
OPERATION AND USE
Starting the torch
– Release gas valve lever
– Turn gas valve of the torch towards (-) to turn it off.
– Connect gas hose to the torch and gas container.
– Open gas container valve to supply rubber hose with gas.
– Direct the torch nozzle forward.
– Press the gas valve lever against the handle
–Turn the torch gas valve by 2/3 of a turn in (+) direction (you should hear specific hissing of the gas coming out).
– Light up gas coming out of the burner.
Adjusting flame size and temperature
Gas valve wheel allows setting the flame size and temperature.
Turn the wheel in (-) direction to reduce the flame size and temperature. Turn the wheel in (+) direction to increase
the flame size and temperature.
Extinguishing the flame
– Release gas valve lever
–Turn the gas valve in (-) direction to extreme position.
– Cut off gas supply from the gas container when the flame is extinguished.
MAINTENANCE
Sometimes using contaminated gas that may
appear when the gas tank is almost empty causes
partial clogging of the nozzle. To clean the nozzle turn the
gas container valve off, disconnect rubber hose from the
gas container, disassemble the torch, clean the nozzle
thoroughly with petrol or similar liquid. You can also use
very thin wire to clear the nozzle. UNDER NO
CIRCUMSTANCES ALLOW THE NOZZLE OPENING TO
ENLARGE.
