Instructions Manual
Electric Griddles
Model
EG548 / EG618

01
CAUTION
This equipment is designed and sold for commercial use only by personnel trained and ex-
perienced in its operation and is not sold for consumer use in and around the home nor use
directly be the general public in food service locations.
Before using your new equipment , read and understand all the instructions & labels associ-
ated with the unit prior to putting it into operation. Make sure all people associated with its
use understand the units operation & safety before they use the unit.
All shipping containers should be checked for freight damage both visible and concealed.
This unit has been tested and carefully packaged to insure delivery of your unit in perfect
condition. If equipment is received in damaged condition , either apparent or concealed, a
claim must be made with the delivering carrier.
Concealed damage or loss—If damage or loss is not apparent until after equipment is un-
packed, a request for inspection of concealed damage must be made with carrier within 15
days. Be certain to retain all contents plus external and internal packaging materials for in-
spection. The carrier will make an inspection and will supply claim forms.
INSTALLATION
The griddles are equipped for the voltage indicated on the nameplate mounted in the rear of
the machine.
WARNING
DO NOT OPERATE TO DIRECT CURRENT (DC)
The installation of the electric griddle should conform to the:
NATIONAL ELECTRIC CODE AND ALL LOCAL ELECTRICA CODES AND OR-
DINANCES AND THE LOCAL ELECTRIC COMPANY RULES AND REGULA-
TIONS.
For your protection we recommend that a qualified electrician install this griddle. He should
be familiar with electrical installations and all electric codes. Proper connections and power
supply are essential for efficient performance. The supply circuit should be properly fused
and equipped with a means of disconnecting , as required by local electrical code. THE
BODY OF THE GRIDDLE SHOULD BE GROUNDED

02
GENERAL OPERATIN G PROCEDURES
The Fleetwood by Skymsen griddles may be wired for operation in the field for 1 phase power
supplies by making line connections with the power cord located at the rear of the unit. Be
certain the unit is supplied with the proper voltage listed on the nameplate.
ELECTRICAL CONNECTION
Disconnect the unit from the power source before installing or removing any parts.
WARNING
BE SURE UNIT IS PROPERLY GROUNDED
CONNECT/PLUG UNIT INTO DEDICATED A.C. LINE ONLY SPECI-
FIED ON THE DATA PLATE OF THE UNIT.
LOCATING AND LEVELING UNIT
Do not install the unit closer than one inch from a side wall and /or closer than one inch from a
rear wall. Level unit by adjusting the four (4) feet which have an adjustment of 1” for accurate
leveling.
SEASONING THE GRIDDLE HEATING SURFACE
Prior to seasoning the griddle , remove protective coating from the griddle surface using a mild
detergent and water. Clean the griddle surface thoroughly. After the griddle has been cleaned, it
should be seasoned to prevent food from sticking. Before using and after each thorough scour-
ing , season the griddle heating surface in the following procedure.
1. Turn temperature control dials to 325 F (162c)
2. Using a clean cloth , spread a thin film of cooking oil over the griddle cooking surface. This
film should remain on the griddle surface for half an hour.
3. Remove the excess oil and wipe clean.
4. Apply another film of cooking oil over the hot cooking area for another half and hour and
again remove excess oil and wipe clean. The griddle surface should now be ready to use.
Even with careful seasoning, food may to some extent , stick to the griddle cooking surface un-
til the griddle is broken in.

03
TEMPERATURE CONTROL
The temperature controls are combination “ON/OFF” switchs and thermostats. Turning the dial
knob automatically maintains the selected heat range.
The Fleetwood by Skymsen griddles have multiple controls which can be operated at different
ranges.
COOKING
Set the thermostat dial knob at the temperature desired, After a short pre-heating period, the
thermostat will automatically maintain the selected temperature.
IDLING
During idle periods , save on operating cost by lowering temperature setting of thermostat to
About 200—250 F. The griddle will quickly return to cooking temperature once thermostat are
adjusted upward.
SIGNAL LITES
Each thermostat has its own signal lite which indicates when the unit ‘s control knob is not in
the off position.
GRIDDLE CARE
Technical Specification
It takes very little time and effort to keep the griddle attractive and performing at top efficiency.
If grease is permitted to accumulate, it will form a gummy cake and then carbonize into a hard
substance which is extremely difficult to remove. To prevent this condition, the following sug-
gestions for cleanliness should be followed.
1. After each use, scrape the griddle with a scraper or flexible spatula to remove excess grease
and food. A waste drawer is provided for the scrapings. If there is an accumulation of burned on
grease and food, the griddle should be thoroughly scoured and re seasoned. Use pumice or a
griddle stone while the griddle is warm. Do not use steel wool because of the danger of steel
slivers getting into food.
EG548
Voltage................................. 110 V
Power Rating........................ 1500 W
Height................................... 9 7/8 ”
Width.................................... 21 7/8 ”
Depth.................................... 18 5/8 ”
Net Weight............................ 55 lb
Shipping Weight................... 60 lb
Plug Configuration................ NEMA 5-15P
Cooking Surface................... 21” x 14 1/2” x 5/16”
EG618
Voltage................................. 220 V
Power Rating........................ 6000 W
Height................................... 12 3/4 ”
Width.................................... 24 1/2 ”
Depth.................................... 24 1/8 ”
Net Weight............................ 88 lb
Shipping Weight................... 95 lb
Amperage............................. 27.3 A
Cooking Surface................... 24” x 20” x 5/16”

04
General Safety Practices
The following safety instructions are addressed to both the operator of the
machine as well as the person in charge of maintenance.
The machine has to be delivered to the operator in perfect conditions of use by
the Distributor to the user. The user shall operate the machine only after being well
acquainted with the safety procedures described in the present manual. READ THIS
MANUAL WITH ATTENTION.
Basic Operation Practices
Dangerous parts
Some parts of the electric devices are connected to high voltage points.
These parts when touched may cause severe electrical shocks or even be fatal.
Never touch commands such as buttons, switches and knobs with wet hands, wet
clothes and/or shoes. By not following these instructions operator could be exposed to
severe electrical shocks or even to a fatal situation.
Warnings
The operator has to be well familiar with the position of ON/OFF Switch to make
sure the Switch is easy to be reached when necessary. Before any kind of maintenance,
physically remove plug from the socket.
Provide space for a comfortable operation thus avoiding accidents.
Water or oil spilled on the floor will turn it slippery and dangerous. Make sure the floor is
clean and dry.
Before giving any manual command (switch, buttons, turn keys or lever) be sure
the command is the correct one. Check this manual for further details if necessary.
Never use a manual command (switch, buttons, lever) unadvisedly.
If any work is to be made by two or more persons, coordination signs will have to be given
for each operation step. Every step of the operation shall be taken only if the sign has
been made and responded.
Advices
In case of power shortage, immediately turn the machine OFF.
Use recommended or equivalent lubricants, oils or greases.
Avoid mechanical shocks as they may cause failures or malfunction.
Avoid penetration of water, dirt or dust into mechanical or electrical components
of the machine.
DO NOT modify original characteristics of the machine.
DO NOT remove, tear off or maculate any labels stuck on the machine. If any
label has been removed or is no longer legible, contact your nearest dealer for
replacement.
IMPORTANT
If any item from the GENERAL SAFETY NOTIONS section is not applicable to
your product, please disregard it.

05
SAFETY PROCEDURES AND NOTES BEFORE SWITCHING ON
IMPORTANT
Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.
Be sure to be familiar with the instructions and that you have well understood all
information contained in this manual. If you have any question contact your
supervisor or your nearest Dealer.
Danger
An electric cable or electric wire with damaged jacket or bad insulation could
cause electrical shocks as well as electrical leak. Before use, check conditions of all
wires and cables.
Advices
Be sure ALL INSTRUCTIONS in this manual have been thoroughly understood.
Every function and operational procedure have to be very clear to the operator.
Contact your nearest Dealer for further questions.
Any manual command (switch, button or lever) shall be given only after being
sure it is the correct one.
Precautions
The electric cable has to be compatible with the power required by the machine.
Cables touching the floor or close to the machine need to be protected against short
circuits.
AFTER THE WORK ENDS
Cares
Always clean the machine, to do the cleaning SWITCH IT OFF, AND TAKE OUT
THE PLUG FROM THE ELECTRICITY SUPPLY SOCKET .
Never clean the machine BEFORE IT IS COMPLETELY STOPED.
Fit all the machine components in their due places, before switching it on again.
MAINTENANCE
Dangers
Any maintenance is dangerous if made with the machine switched on.
SWITCH IT OFF AND TAKE OUT THE PLUG FROM THE SOCKET, DURING ALL
THE MAINTENANCE OPERATION.
This product will be replaced or repaired under warranty, for a period of (1) year,
beginning from the date of purchase by the original purchaser/user (“End User”), or
eighteen (18) months from the da te of shipment from SKYFOOD’s ware house,
whichever expires first.
Accessories wil l be replaced or repaired under wa rranty, for a period of (30) days,
beginning from the date of purcha se by th e original purchaser/user (“End User”), or
eighteen (18) months from the date of shipment from SKYFOOD’s warehouse, whichever
expires first.
This warranty shall not take effect until a properly completed and executed WARRANTY
REGISTRATION form has been received by SKYFOOD EQUIPMENT, LLC, within thirty
(30) days from the date of purchase. The WARRANTY REGISTRATION is available either
in the Instruction Manual of every Product or at SKYFOOD’s website www.skyfood .us. The
End User must fill out the WARRANTY REGISTRATION form and send it to SKYFOOD
according to the instructions posted on the referred website. Failure to do so will VOID
the warranty.
No extended warranties for third party products. There are no other express
warranties or conditions other than the one offered by each manufacturer for
products sold by SKYFOOD, not under the FLEETWOOD by SKYMSEN and
SKYMSEN brand.
For questions or assistance, do not return the p roduct or accessories to the store, please
call Toll Free 1-800-503-7534, or visit the Customer Service section at www.skyfood.us.
For faster service please have th e items name, serial number, and proof of purchase for
the operator to assist you.
SKYFOOD reserve s the right to change the term s of its limited warranty at any time
without any prior notice. It also reserves the right to change the design and
specifications of its equipment or any related documentation at any time. The e nd
user is not entitled to upgrades or refunds resulting from these changes.
Updates
These Terms and Conditions were last updated on January 14th, 2014.

06
IMPORTANT
In any emergency situation, always take the plug out of its socket.
ADVICES
Electrical or mechanical maintenance shall be made by qualified persons.
The person in charge of the maintenance performances shall check the machine works
under TOTAL SAFETY CONDITIONS.
SKYFOOD EQUIPMENT LLC - SERVICE
For questions or assistance, call SKYFOOD EQUIP MENT Toll Free : 1-800-503-7534, or
visit the Customer Service section at www.skyfood.us.
SKYFOOD’S LIMITED WARRANTY
Unless otherwise specified,new FLEETWOOD by SKYMSEN and SKYMSEN products,
excluding accessories, sold by SKYFOOD EQUIPMENT, LLC. (“SKYFOOD”), for use only
in the continental United States (collectively, “Products” or singularly, “Prod uct”), a re
warranted to be free from defects in materials and workmanship for a period of one (1)
year from the date of purchase by the original purchaser/user (“End User”), or eighteen
(18) months from the date of shipment from SKYFOOD’s warehouse, whichever expires
first. Several new products and accessories may be warr anted for a p eri od o ther tha n o ne
(1) year whil e others may be subject to travel li mitations, as spe cified on the products
Instruction Manual. Proof of purchase must be presented; if not this wa rranty will be
VOID. No warranty is given or imp lie d to a subsequent transferee or any other third party.
This warranty is expressly conditional upon SKYFOOD being notified of any defects in
materials or workmanship with in five (5) days of its occurrence, wi thin the warranted time
period. If a notice of a claim under this warranty is timel y made by the End User,
SKYFO OD or a SKYFOOD’s designated service company (“Service Company”), will repair
or replace the Product, at SKYFOOD’s discretion, subject to the additional conditions
hereinafter described.
This warranty shall not apply if damage occurs from improper installation or maintenance
performed by an unauthorized service company (“Service Company”), wrong voltage, nor
to the extent that Products or parts have been used other than in conformance with
operating and maintenance instructions, subjected to misuse or a buse or dama ged by
accident, acts of God, a bnormal use, stress or any other matter unrelate d to SKYFOOD,
and beyond its reasonable control. This warranty does NOT cover servic e labor and
trave l to perform adjustments on products and/or accessories. In addition to wear and
tear of certain items, such as, but not limited to; glass parts, blades, stones, ch opp er
cutting knives, plates, slicing knives, cutting disc, gaskets, oil changes, sealing tape, heat
seal wires, worm gears, self-lubricating bushings, carbon brushes for electric motors, and
other parts exp endable by nature and that nee d to be replaced frequently. Electrical
components are subject to na tural wear and tear, and are NOT covered by this
warranty. THIS WARRANTY EXCLUDES ALL ORAL, STATUTORY, EXPRESS OR
IMPLIED WARRANTIES WHICH MAY BE APPLICABLE TO SKYFOOD, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE. Under no circumstances shall SKYFOOD be
liable for loss of use, revenue or profit or for incidental or consequential dama ges.
SKYFO OD shall un der no circumstances be liable for any loss, damage, concealed
damage, expense or d ela y of goods for any reason when said goods are in th e custod y,
possession or control of third parties selected by SKYFOOD to forward, e nter, clear,
transport, or ren der other services with respect to such goods. The sole and e xclusive
remedy for breach of any warranty is limited to the remedies provided in the paragraph
above.
All products held at non-comme rcial facilities or domiciles, mu st be taken or shipped,
shipping charges prepaid, either to SKYFOOD's facility or a SKYFOOD's designated
service company ("Service Company"). Products held at comme rcial facilities and weighing
