FW1179 User’s Manual
M4066-00 1 Seyeon Tech Co., Lt
FW1179 User’s Manual
(Product Guide)
Version 4.12(Rev. )
September 30, 2011
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

FW1179 User’s Manual
M4066-00 2 Seyeon Tech Co., Lt
FW1179 User’s Manual
Document Part Number: M4066-00
Document Version: 4.12(Rev.E)
Revise : September 30, 2011
About This Document
This ocument is prepare for users of FW1179 supplie by Seyeon Tech Co., Lt . It is assume that the
users are familiar with Microsoft Win ows operating systems an Web browsers such as Internet Explorer.
It is also assume that the users are well aware of how to install an use the network equipment such as
LAN, Hub, router, an having basic knowle ge of network terminologies. If you have any questions
regar ing network installations, please contact your network equipment ven or or network a ministrator
or Internet service provi ers.
For up ate contents, etaile features an other applications from Seyeon Tech, please refer to the user’s
manual in CD-ROM provi e with the pro uct you purchase , or visit Seyeon Tech’s Internet homepage at
http://www.flexwatch.com/.
Copyright Notice
Copyright © 2011 Seyeon Tech Co., Lt . All rights reserve .
No part of this ocument may be repro uce in any form or by any means without the prior written
permission of Seyeon Tech Co., Lt .
Disclaimer
Seyeon Tech Co., Lt . (Seyeon Tech) Makes no representations or warranties with respect to the contents
hereof. In a ition, information containe herein is subject to change without notice. Every precaution has
been taken in the preparation of this manual, nevertheless, Seyeon Tech assumes no responsibility for
errors or omissions or any amages resulting from the use of the information containe in this ocument.
Tra emarks
FlexWATCH
®
an FlexWATCH
®
Logo are tra emarks of Seyeon Tech Co., Lt .
Win ows an Internet Explorer are a tra emark of Microsoft Corporation.
All other tra emarks belong to their respective owners.
Technical Support
For technical support call, email, or visit our web site.
Telephone: [phone]
Email: [email protected]
Web site: http://www.flexwatch.com or http://www.seyeon.co.kr

FW1179 User’s Manual
M4066-00 3 Seyeon Tech Co., Lt
Contents
1. PRODUCT OVERVIEW ......................................................................................................................... 4
1.1. FW1179 .......................................................................................................................................................................... 4
1.2. K EY F EATURES ................................................................................................................................................................. 5
1.3. T ECHNICAL S PECIFICATION ........................................................................................................................................... 6
1.4. FW1179 P ACKING L IST ................................................................................................................................................ 8
2. HARDWARE DESCRIPTION ................................................................................................................ 9
2.1. M AIN B ODY V IEW .......................................................................................................................................................... 9
2.1. F ULL V IEW ...................................................................................................................................................................... 10
3. FW1179 INSTALLATION AND BASIC SETUP ................................................................................. 11
3.1. B EFORE I NSTALLATION ................................................................................................................................................. 11
3.2. F ACTORY D EFAULT S ETTINGS ..................................................................................................................................... 11
3.3. I NSTALLING FW1179 .................................................................................................................................................. 11

FW1179 User’s Manual
M4066-00 4 Seyeon Tech Co., Lt
1. Product Overview
1.1. FW1179
FlexWATCH® 1179 is a stand-alone device transmitting vdeo from built-in megapixel camera over
IP(Internet Protocol) network. There is one type of FW1179 model: MS.
It can transmit up to [email protected] over the existing network. You can monitor video of FW1179 through
web browser(ie. MS Internet Explorer), if FW1179 is connected to network. FW1179 supports video
compression both Motion-JPEG and H.264 simultaneously so that user can choose appropriate video
compression for the purpose. For both Motion-JPEG and H.264, FW1179 provides 6 levels of video quality.
FW1179 also supports both ONVIF and PSIA.
Picture 1 : FW1179

FW1179 User’s Manual
M4066-00 5 Seyeon Tech Co., Lt
1.2. Key Features
Standalone device with a built-in web server
10M/100M Auto-Sensing Ethernet
Configuring and controlling through Web browser
Max 30 fps transmission speed on TCP/IP network
Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264
Supports Dual Streaming in Motion JPEG and H.264
Support Dynamic IP network by IPCCTVDNS Server
Support Transparent Mode
Encryption function by user authentication
Image transmission function via FTP and Email
Support both ONVIF/PSIA

FW1179 User’s Manual
M4066-00 6 Seyeon Tech Co., Lt
1.3. Technical Specification
FW1179-MS
Hardware
32bit Embedded CPU
NAND Flash 128Mbytes / DDR2: 128Mbytes
Linux version 2.6.xx operating system
Battery backed up real-time clock
Image sensor
1/3” progressive scan MOS
Active pixels 1280H x 1024V, 1.31M
Effective pixels 1376H x 1070V, 1,47M
Pixel size: 3.75 (H) µm × 3.75 (V) µm
Color filter Bayer arrangement of primary colors: R, G, B
Bit number of internal ADC: 12 bits
Parallel output: 54 MHz, 12 bits
Output frame rate per second: 30fps
Full scan mode: 1.3 mega pixel output
Lens Auto IRIS & Vari-focal 3.6 - 16.0 mm F1.2
IR Illuminator 50pcs 850nm Infrared LEDs
30°IR Range, maximum 30m IR distance
Minimum illumination Color: 0.1 Lux (F1.0) B/W: 0.01 Lux (F1.0) (TDN)
0.02 Lux (F1.0) (without TDN)
Video related special
functions
Day & Night (ON/OFF)
AGC, AWB
Lense (MANUAL/DC)
Shutter (MANUAL/AUTO)
Vertical/Horizontal Flip
Frequency Control (50/60)
Brightness/Contrast/Sharpness Control
Video compression Motion JPEG
H.264
Video standards ONVIF
PSIA
Resolution 1.3M(1280x1024), HD(1280x720), VGA(640x352), CIF(320x176), QCIF(160x96)
Frame rate
(each channel) Motion JPEG: Up to 30 fps @ 1280H x 1024V (Other Stream at QCIF) H.264: Up to 30 fps @ 1280H x 1024V (Other Stream at QCIF)
Video Streaming Motion JPEG and H.264 Dual Streaming (Simultaneously)
Controllable frame rate and bandwidth
Image setting Compression levels: 6 (Motion-JPEG, H.264)
Color: color, black & white
LAN interface 10/100BaseT Ethernet auto sensing IEEE 802.3af Built-in POE (optional)
IEEE 802.11b/g Built-in wireless (optional)
Security features Multi user level protection for amera access
Advanced Service Up to 5.6M memory for Pre/Post alarm buffer E-Mail, FTP, IP notification, Alarm Notification to e-mail
CGI Call by event or schedule

FW1179 User’s Manual
M4066-00 7 Seyeon Tech Co., Lt
Built-in Motion detections Accuracy: 12x12=144 blocks
Motion Sensitivity : -100 ~ 100 : 100 is hypersensitive
Management Configurable by serial, web or telnet
Remote system update via telnet, FTP OR web browser
Developer support Provides HTTP CGI API
ActiveX control development kit
PWR Supply SMPS Input: 100~240VAC, AC 50/60Hz, 1.2A
Output : DC 12 Volt, 3A
PWR Consumption DC 12Volt Max 900mA at night
Operating Environment Temperature : 32°~ 122°F (0°~ 50°C)
Humidity : 20 ~ 80% RH(non-condensing)
Miscellaneous Freely downloadable NDVR Software Work with FW-Manager( NDVR S/W)
Dynamic IP support through IPCCTVDNS
Simultaneous users Live-cast for up to 16 clients
Installation, management
and maintenance Installation CD and web-based configuration Firmware upgrades over HTTP or FTP , firmware available at www.flexwatch.com
Video access from Web
browser Video access from Web browser
Minimum Web browsing
requirements
Pentium 4, 2 GHz, 2GB(RAM) or higher
Video Card: 256MB RAM, 1024x768 resolution or higher
100Mbps Network Adaptor or faster
Windows XP Pro or later
Internet Explorer 6.x or later
System integration support
Powerful API for software integration available at http://www.flexwatch.com, including
Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream,
embedded scripting and access to serial port peripherals over HTTP/TCP
User can be installed user program daemon for event notification or sending image
Embedded operating system: Linux 2.6
Supported protocols HTTP, RTP/RTSP, TCP/IP, FTP, Telnet, RARP, PPPoE, PAP, CHAP, DHCP, SMTP
client(e- mail), NTP
Applications
(not included) FlexWATCH Manager 16/32/128/256
Included Accessories Power supply 12 V DC / Power cord
CD (User’s Manual, installation wizard and etc)
Approvals
MIC
FCC : Class A
CE : Class A
RoHS
Dimensions (HxWxD) and
weight (1lbs = 454g) 92.8Ø x 235.8(L) x 125.8(H) (in mm) About 1.1kg without power supply
* All specifications are subject to change without prior notice.
Table 1 : FW1179 Data Sheet

FW1179 User’s Manual
M4066-00 8 Seyeon Tech Co., Lt
1.4. FW1179 Packing List
FW1179-MS 1ea
Power Supply Unit
(Power Cable & SMPS DC12V 1.0A Adapter) 1ea
CD (User’s Manual, installation wizard and etc) 1ea
Table 2 : FW1179 Packing List
Note: Please check all the listed items are included in your package. For any missing items,
please contact your local distributor.

FW1179 User’s Manual
M4066-00 9 Seyeon Tech Co., Lt
2. Hardware Description
2.1. Main Body View
Picture 2 : Front View
Name Description
A IR LED 50pcs 850nm Infrared LEDs.
B Lens Lens for board mount
C Sunshield Top covering Sunshield
Table 3 : FW1179 Main Body View
B
A
C

FW1179 User’s Manual
M4066-00 10 Seyeon Tech Co., Lt
2.1. Full View
Picture 3 : FW1179 Full View
Name Description
A Main body Mainbody
B Mounting Bracket Mounting bracket
C LAN LAN Connector.
D Power Conn. Power Connector.
Table 4 : FW1179 Full View
D
C
A
B

FW1179 User’s Manual
M4066-00 11 Seyeon Tech Co., Lt
3. FW1179 Installation and Basic Setup
3.1. Before Installation
 Read carefully User's Manual.
 Check User’s Network (IP Address, Network Mask and default gateway)
 Secure IP address for FW1179.
3.2. Factory Default Settings
The following table shows the factory default condition. Please refer to this when you need to change
the values on admin menu.
Factory Default
Admin ID root
Admin password root
IP address 10.20.30.40
Network mask 255.255.255.0
Gateway 10.20.30.1
Wireless LAN (Option) Disabled
Table 5 : Factory Default
Note: Factory default Admin ID and Password are all lower case letters. You can change the
password with Capital letters.
3.3. Installing FW1179
Following steps are the physical installation process for FW1179.
1. Fix the FW1179 in place
2. Connect the FW1179 to the Internet cable through the LAN port.
3. Connect the power supply of FW1179.
After that, you need to follow the steps below.
 Network Configuration: Refer to “IP Installer User’s Manual”
 Camera Configuration: Refer to “FlexWATCH Admin Menu User’s Manual”
 Service Configuration: Refer to “FlexWATCH Admin Menu User’s Manual”
