Flexzilla PRO FDRCF1150030 Service manual
Operating, Service and
Warranty Manual
ENERGY EFFICIENT REFRIGERATED AIR DRYERS
Flexzilla® designs and manufactures products for safe operaon. However, operators and maintenance persons are
responsible for maintaining safety. All safety precauons are included to provide a guideline for minimizing the
possibility of accidents and property damage while equipment is in operaon. Keep these instrucons for reference.
2006
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
2
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
Contents
1. Important Safety Notes - Please read ......................3
1.1 Transportation..............................................................3
1.2 Positioning............................................................3
1.3 Installation............................................................3
1.4 Before Operating ..................................................3
1.5 Qualified Service Personnel.................................3
1.6 Maintenance By The User....................................4
2. Introduction To The Dryer..........................................4
3. Operation....................................................................4
4. Electrical Controller...................................................7
4.1 Digi-Pro ................................................................7
4.2 ESD 3...................................................................8
5. Technical Specifications .........................................12
6. Diagrams ..................................................................12
6.1 Air Flow Diagrams ..............................................12
6.2 Electrical Diagrams ............................................14
7. ID Diagram Drawings...............................................16
General Arrangements ..............................................18
8. Exploded Diagrams .................................................18
9. Components Location.............................................22
10. Troubleshooting.......................................................23
11. Warranty ...................................................................26
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
3
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
3
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
1. IMPORTANT SAFETY NOTES
When operang the air dryer the operator must apply
safe working methods and observe all local safety
instrucons and relevant regulaons.
A) Prior to installaon, the dryer and the compressed
air system are to be depressurized and
disconnected from the electrical main supply.
B) The user is responsible for safe operang
condions. Parts and accessories must be replaced
if inspecon shows that safe operaon cannot be
assured.
C) Installaon, operaon, maintenance and repair
are only to be performed by authorized, trained
and skilled technicians.
D) The minimum and maximum values stated must
be followed, as well as all of the safety precauons
described in this manual.
E) If any statement in this manual does not comply
with the local code laws, the strongest standard is
to be applied.
1.1. Transportaon
A) Use care and cauon when transporng the dryer.
Avoid dropping and other physical abuse.
B) A forkli can be used to transport the dryers
provided the forks are long enough to support its
full width or length and cauon is used throughout
the move.
1.2. Posioning
A) The dryer must be installed horizontally. A
minimum of 20 in. clearance around the dryer is
necessary to allow good venlaon and easy
access for servicing.
B) The ambient temperature in the room should not
exceed 113°F and should not be below 39.2°F, also
taking the heat radiated by the dryer into account.
C) (40 wa for each liter/sec under ISO 7138-A
condion or 18 was for each SCFM under ISO
7183-B condion).
D) There should be no chemicals in the atmosphere
that will damage the copper source. (Ammonia
gas, etc.)
1.3 Installaon
In addion to the general mechanical construcon
procedures and local code regulaons, the following
instrucons need to be understood and followed:
1) Only authorized, trained and skilled technicians
should install the compressed air dryer.
2) Safety devices, protecng covers or insulaon in
the dryers are never to be dismantled or modied.
Each pressure vessel or accessory installed outside
the dryer with air above atmospheric pressure
must be ed with the required pressure relief
safety valves.
1.4 Before Operang
The following must be observed before operang the
air dryer:
A) Review all safety precauons.
B) The dryer connecon piping measurements must
be selected correctly. (See Technical Specicaons)
C) The dryer connecon piping must be adapted to
the operang pressure. (See Technical
Specicaons)
D) Never operate the dryer at pressure above the
maximum specied on the dryer label (See
Technical Specicaons)
E) The drains should be opened to atmosphere. If the
drains are connected to a pipe/hose, the diameter
of the pipe/hose should be large enough to
create no back pressure during draining. It is not
recommended to reduce the diameter of the pipe/
hose less than the port that is given at the
drain outlet of the unit. The pipe/hose should be
at atmospheric pressure at all me. Back pressure
in relevant pipe will result in permanent damage
on drain system and funcon of the lters and/or
dryers.
1.5 Qualied Service Technicians
A) Maintenance and repairs should only be
performed when the air dryer is shut down,
depressurized and when the main power switch
is turned o. Lock and tag out of the power supply
is recommended.
B) Only use the appropriate tools for maintenance
and repair.
C) Before dismantling a part under pressure,
disconnect the pressure sources and depressurize
the system.
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
4
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
D) Proceed carefully during maintenance and repair.
Prevent dirt from entering by covering parts and
orices with a clean cloth, paper or tape. A
receiver should never be welded or modied in
any way.
E) Never leave tools, loose parts or cleaning rags in or
on the air dryer.
F) Before pung the dryer into service, check the
sengs of the control and safety devices as well as
the pressure and temperature of the compressed
air circuit.
1.6 Maintenance By The User
A) Keep the dryer clean.
B) Regularly check the correct operaon of the
condensate drain water trap.
C) Ever six months, check and clean the drain strainer
by undoing the access screw and rinsing the lter
with tap water to remove the trapped dirt from
the inside.
D) For air cooled dryers, clean the air condenser as
soon as it’s dirty or clogged.
E) For oponal water-cooled condensers, use only
clean water and install a water lter if needed. Use
proper water treatment if calcium levels are high.
F) Check the trouble-shoong list in case of
maintenance problems.
G) Check operang pressures, temperatures and me
sengs aer maintenance. If operang and safety
devices funcon properly, the air dryer may be
used.
2. INTRODUCTION TO THE DRYER
A) Purpose of this dryer
1) This refrigerated compressed air dryer has been
designed to remove water vapor from the
industrial compressed air system.
2) This dryer has been designed for indoor operaon.
3) The minimum and maximum values stated must be
observed, as well as the safety precauons
described in this manual.
B) Dryer label
The following label is axed on the cabinet of the
refrigerant compressed air dryer.
C) Working details
1) Refrigerant circuit:
The refrigerant circuit can be divided into 3 parts:
A) Low pressure secon with an evaporator
(heat exchanger)
B) High-pressure secon including: Condenser, liquid
receiver (if installed) and the lter dryer.
C) Control circuit including: compressor, expansion
valve, by-pass valve (if installed), fan pressure
switch (if installed)
2) The refrigerant circuit operates as follows:
A) The compressor compresses gaseous refrigerant to
a high temperature.
B) The hot refrigerant condenses in the condenser.
Being liqueed it is stored in the liquid receiver
(if installed).
C) The liquid is taken out of the storage vessel and
Dryer Label Descripons:
Model #: Dryer Model No.
CFM: Cubic feet per minute
Serial #: Dryer Serial No.
Max. Refrigerant Pressure: Dryer maximum working pressure
Max. Air Pressure: Maximum air pressure
Max. Air Inlet Temp.: Maximum air inlet temperature
Min. Ambient Temp.: Minimum ambient temperature
Max. Ambient Temp.: Maximum ambient temperature
Min. Circuit Ampacity: Minimum circuit ampacity
Max. Protecve Device Rang: Maximum protecve device rang
Voltage: Main supply voltage
IP Rang: Protecon rang
Refrigerant 134a: Amount of refrigerant gas used
Weight: Dryer weight
Fan: Model of fan used
Compressor: Model of compressor used
Largest Motor: Model of dryer motor used
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
5
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
injected in the evaporator (heat exchanger) by an
expansion valve. This expansion valve is protected
by a lter, which removes parcles and humidity
that could be in the circuit.
D) The injected liquid lls in the refrigerant secon of
the air/refrigerant heat exchanger and evaporates
by taking out the humidity from the compressed
air. The gaseous refrigerant is sucked in the
compressor and the cycle carries on.
E) In order to keep the evaporaon pressure
steady, and the refrigerant temperature in the
heat exchanger, a by-pass valve is injecng hot
gaseous refrigerant in the circuit. On certain dryers,
an automac expansion valve regulates the
amount of refrigerant.
3) Compressed air circuit
A) The saturated hot compressed air ows into the
economizer where it is pre-cooled by the out
owing dry chilled air. In the cold operang
condions the air refrigerant secon connues
to cool down to dew point and enters the
separator where condensates are collected.
The outgoing chilled air is then warmed up in the
economizer by the hot incoming air. This eliminates
condensaon on dryer outlet air piping.
B) The condensates are collected aer centrifugal
separaon and drained out through the
automac trap.
C) As long as the compressed air temperature
does not drop below dew point, there will be no
condensaon in the air circuit.
Compressed Air Dryer Working Principle
4) Refrigerant compressor
Increases the pressure of temperature of refrigerant.
There are two types of compressors commonly used
according to refrigerant capacity on this applicaon:
- Piston type
- Scroll type
5) Condenser
Dissipates the heat provided by evaporator and
compressor. there are two types of condensers used
on the applicaon:
- Air Cooled Type (standard)
These condensers are designed to dissipate the heat
to the ambient air. The fans are used to force the air
ow through the cooling ns to enhance the heat
transfer.
- Water Cooled Type (oponal)
These condensers are designed to dissipate the heat
to a water ow. A shell and tube heat exchanger is
used for this purpose.
6) Refrigerant circuit protecon
A) Overload: The single phase refrigerant compressors
are equipped with an overload switch in case of
malfuncon, if overload switches automacally.
B) High Pressure Safety Overload Switch: Refrigerant
line is considered a pressure vessel. That is why it
is protected against bursts by the help of manually
reseng the switch. It is set to 362 psi for dryers
working with R134a refrigerant.
C) Filter dryer: A refrigerant circuit is a close circuit
and total water removal in the refrigerant circuit is
necessary in order to obtain correct operaon.
D) To avoid problems, the refrigerant circuit must be
vacuumed before loading the refrigerant.
E) Water-cooled dryers have a safety high-pressure
switch. In case of cooling water failure, the safety
switch stops the dryer. When the safety switch has
tripped out, it has to be manually reseled before
switching on the dryer.
7) Refrigerant circuit controls
A) Liquid refrigerant injecon: the liquid refrigerant
is released into the evaporator by a control valve.
This is a thermostac valve for maintaining a
constant overheang of the refrigerant in the
evaporator(s).
B) Constant evaporang pressure: In the dryers
equipped with a by-pass valve, the evaporang
pressure is kept constant by a controlled injecon
of hot gas from the high-pressure side into the low-
pressure secon of the circuit.
Compressed Dry
Air Outlet
Compressed
Wet Air Inlet
Refrigerant Gas High Pressure Line
Refrigerant Gas Low Pressure Line
A - Refrigerant Compressor
B - Condenser
C - Filter Dryer
D - Expansion Valve
E - Heat Exchanger
F - Hot Gas Bypass Valve
G - Drain
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
6
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
8) Condensate drain-trap assembly
Dismantling the drain is easy because it can be
isolated from the air circuit under pressure with a ball
valve. The drain has to be depressurized before being
dismantled.
9) Heat exchanger modular design
A) The dryers are equipped with a compact
This assembly has been specially designed to dry
compressed air and is made of:
1) An economizer which pre-cools the entering hot air
with the out owing cold air.
2) Air/refrigerant exchanger is cooling down the
compressed air.
3) A centrifugal separator concentrang all
condensates and requiring no maintenance.
10) Accessories
Temperature switch: Located inside the dryer, this
temperature switch is adjustable from 32°F up to 95°F.
Digital Controller – DigiPro: This device helps dryer
save energy when there is not any compressed air
ow in the dryer. This informaon can be reached:
Dew point value, periodic maintenance interval
display, status report, run me meter, temperature
unit selecon (°F or °C)
Digital Controller – ESD3: Energy Saving Device: (ESD)
This device helps dryer save energy when there
is not any compressed air ow in the dryer. This
informaon can be reached: Dew point value, periodic
maintenance interval display, status report, run me
meter, temperature unit selecon (°F or °C)
3. OPERATION
Control panels for FDRCF Series
The control panel of the dryer includes the following
elements:
IMPORTANT NOTES
The Dryer has two Compressed Air Filters inside.
It is beer to change lter element for the best
eciency when the alarm status is acve.
It is recommended to keep replacement lter
elements in your stock in order to replace them
when needed.
FDRCF range dryers have low pressure drop
according its competors.
Do not use FDRCF range dryers together with other
dryers which have higher pressure drop without
geng the conrmaon from our technical team.
Single Phase Digital Controller
FDRCF1150030 / FDRCF1150058 Digi-Pro
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
7
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
3.1. During Operaon
Regularly check the digital temperature controller
ESD3 or Digi-Pro on dryer.
3.2 Start up and shut-down
Warning: Avoid leaving the dryer o when
compressed air is sll owing through it.
3.3 Starng for the rst me or aer a
long stop
1) Set the rotary switch to “I” This preheats the dryer
and turns the drain system on. It is recommended
to leave the dryer power on permanently so the
crankcase heater runs connuously.
IMPORTANT NOTE
2) Aer a long stop of the dryer it is MANDATORY to
allow a preheang period of minimum 4 hours
before starng again, to avoid any compressed air
ow during preheang.
3) Follow the daily starng and shut down procedure.
3.4 Daily starng and shut-down
A) Push on the ON buon to start the dryer.
B) The start light or Dryer Acve will indicate that
the dryer is running.
C) To stop the dryer, rst stop the airow (either
shut-down the air compressor or close the inlet/
outlet or by-pass valve) When the air ow is
stopped, set the rotary switch on “ 0 “ Set it again
on “ I “ in order to keep the preheang on.
IMPORTANT NOTE
4) Avoid leaving the dryer stopped when compressed
air is sll owing through it.
5) To switch the already preheated dryer on again,
simply push the green start buon.
4) ELECTRICAL CONTROLLER
4.1 DIGI-PRO
4.1.1 Descripon
With the Digi-Pro series controllers, air dryers have
outstanding technology for both funconality and
performance, as well as appearance. The mul-
funconal display provides an accurate digital dew
point display as well as coded alarm monitoring of the
refrigerant dryer.
DIGITAL CONTROLLER ADVANTAGES
• Digital dew point monitoring
• Energy-saving mode display
• Periodic maintenance interval display
• Status report
• Run me meter
• Fahrenheit and Celsius selecon
4.1.2 Operaon
Using the Digi Pro controller as shown in the picture
below:
4.1.3 Menu Buons
PROGRAM
To modify the parameter, press
and release buon set. The
menu is used by service tech.
To disable the Key Lock: Press
and hold the SET for 4 seconds.
POWER
This buon is used for starng
and stopping the dryer. Press
and hold for 4 seconds to start
or stop.
MENU
These buons are used to
navigate between screens and
adjust values.
MANUAL DRAIN
This buon is used for manual
control of the drain output.
Press and hold for 4 seconds to
drain manually.
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
8
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
4.1.4 ALARM DISPLAY
Alarms / warnings are displayed on the digital
screen. That means the dryer is not working
under normal operang condions, which are outside
the range of set values.
Please contact service when an alarm/warning occurs.
Alarm
Code Alarm Descripon Reason for Alarm
tAL Low Temperature Alarm Refrigerant line temperature is
lower than specied set values.
tAH High Temperature Alarm Refrigerant line temperature is
higher than specied set values.
FIL Filter Change Alarm Filter element needs to be replaced.
SEr General Service Alarm General service me of the dryer.
HP High Pressure Alarm Refrigerant high line pressure is
higher than specied set values.
Pr1 Temperature Probe Alarm Temperature sensor is faulty.
tSH High Sucon Line Temp
Temperature of refrigerant sucon
line is higher than specied set
values.
4.1.5 MODE DISPLAY
DRYER ACTIVE MODE
This mark indicates that the
dryer is performed in acve
state and drying.
AUTOMATIC DRAIN MODE Shows if the drain system is
acvated.
ENERGY SAVING MODE Shows if the energy saving
mode is acvated.
CELSIUS UNIT MODE Indicates that Celsius
temperature unit is selected.
FAHRENHEIT UNIT MODE Indicates that Fahrenheit
temperature unit is selected.
COMPRESSOR STANDBY MODE This mode shows that the dryer
is ready for drying operaon.
SERVICE MODE This mode shows that the dryer
in the service me.
4.2 ESD 3
4.2.1 DESCRIPTION
E-687 is designed as a controller for refrigerant
type compressed air dryers. The controller has 8
temperature sensor inputs.
The controller has an RS-485 communicaon interface
that can be used for remotely monitoring channel
temperatures, set points, input and output status.
Modbus RTU protocol is used for communicaon.
The front panel of the controller contains a four line
20 character LCD display and buons that are used in
conguraon and manual control operaons.
The dimensions of the controller are 3.7 x 7.5 in.
(front panel) with a depth of 4.3 in..
The panel cutout should be 3.5 x 7.2 in..
The operang voltage of the controller is 20 - 60V AC
or 20 - 85V DC.
4.2.2 OPERATION
The front panel view of E-687 controller is shows in
the below gure. The front panel of the controller
contains a four line 20 character LCD display, 10
buons and 2 indicator LEDs.
The Front Panel View of E-687 Controller
buon is used to enable or disable the ECO
(economy) mode. Pressing this buon complements
the state of ECO, i.e. if it is enabled; disables, if it is
disabled; enables the ECO mode. The green LED on
the le side of the buon lights if the ECO mode is
enabled.
buon is used for manual control of the drain
output.
buon is used for alarm acknowledge. The dryer
is automacally stopped if an fault is detected. In that
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
9
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
case, the alarm output and the alarm indicator LED
(red) on the front panel become acvated. In order to
restart the dryer, alarm should be acknowledged and
“restart delay” period should be med out. Pressing
buon acknowledges the alarm and reenergizes the
alarm output and alarm LED.
The buons below the LCD display ( , , and
) are used in screen selecon and conguraon
operaons.
buon is used to change the temperature unit
from °C to °F or vice versa.
and buons are used for starng and stopping
the dryer. If the dryer is stopped manually, it cannot
be started before “restart delay” period is med out.
, , , , and buons are disabled
during conguraon operaons.
4.2.3 OPERATION SCREENS
4.2.3.1 The Normal Operaon Screen
When the controller is powered on, it displays the
type and a message, and then the restart delay mer
is set to 5 seconds. Aer 5 seconds, the normal
operaon screen is displayed as shown in below gure:
The exchanger temperature (Dew Point) and
operaon state of the dryer is displayed in this screen.
If there is a situaon which will prevent the operaon
of the dryer then the “READY” message in the last line
will become “DISABLED”. See below gure:
In order to start the dryer, the following condions
must be sased.
1. All the temperatures except the exchanger
temperature and condenser outlet temperature must
be between their low and high limits. The low pressure
line temperature can be ‘HIGH’.
2. Digital Input 3 (Compressor Fault) is not acvated.
3. Digital Input 4 (Compressor Overload) is not acvated.
4. Digital Input 5 (Fan Fault) is not acvated.
5. Digital Input 6 (Fan Overload) is not acvated.
6. Digital Input 7 (Phase Sequence Error) is not acvated.
7. Digital Input 8 (Remote Disable) is not acvated.
8. Digital Input 11 (High Pressure) is not acvated.
9. Digital Input 12 (Low Pressure) is not acvated.
If all the above condions are checked, the message
in the last line of the normal operaon screen will be
“READY” and the dryer can be started either pressing
buon on the front panel or acvang Digital Input 1
(Remote Start) or acvang Digital Input 13 (Remote
Control). When the dryer is started, the normal
operaon screen is displayed as shown in below gure:
In the beginning, Digital Output 1 (Compressor Motor),
Digital Output 2 (Drain Output) and Digital Output 3
(Dryer is Running) become acve. While in normal
operaon, the drain output is controlled according to the
congured “drain on” and “drain o” periods. “DRAIN
ON” message is displayed in the end of the last line while
the drain output is acve.
When the Digital Input 9 (Fan Motor is on) is acvated,
“FAN MOTOR IS ON” message is displayed in the second
line as shown in below gure:
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
10
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
Digital Input 14 (Water Pump is on) acvates “WATER
PUMP IS ON” message as shown in below gure:
When ECO mode is enabled and the exchanger
temperature is less than or equal to “ECO Start Set
point” and this condion is prevailed more than “ECO
Start Delay”, then, the compressor motor is stopped
and ECO operaon starts. During the ECO operaon the
appearance of the display is given in below gure. The
value at the end of the second row indicates the me in
seconds since beginning of the ECO operaon.
Pressing and keys simultaneously at this page
toggles the controller between automac and manual
mode. In manual mode, the dryer starts and stops
manually by using and buons. Unlike the
manual mode, automac mode enables the controller to
start and stop automacally at pre-programmed mes
on a daily basis.
When running in automac mode, current scheduling
informaon messages are also acvated in the second
line of the displays as show in below gure. “NOT
SCHEDULED” message is displayed when no schedule
exists. “START IN XXX” shows the me to the next
scheduled program in minutes and “STOP IN XXX”
message shows the me to the end of current running
program in minutes.
If the dryer is stopped manually by using buon, or
acvang Digital Input 2 (Remote Stop) or deacvang
Digital Input 13 (Remote Control), the normal operang
screen is displayed as shown in below gure. The
number at the end of the last line indicates the
remaining me in seconds from the restart delay. If this
number becomes zero and there is no anomaly, the
dryer can be restarted.
The rst line in the normal operaon screen (NO NAME)
is user congurable.
If the exchanger temperature sensor is broken, dew
point temperature will be displayed as 1000ºC.
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
11
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
4.2.4 The Info Screens
Various data related to the dryer
can be monitored by sequenally
pressing buon. Pressing
buon, changes the display screen.
While one screen is displayed,
pressing buon reverts to the
normal operaon screen. The ow
chart for monitoring the dryer data
is given in gure on right. In this
gure, screen numbers are shown
on the upper le of the screens.
Screen 1 is the normal operaon
screen. While this screen is
displayed, pressing buon
selects Screen 2. By successively
pressing buon, all the screens
can be accessed. Screens can also
be selected by and buons.
In Screen 2, Screen 3 and Screen
4, the sensor temperatures
are displayed. If the measured
temperatures are between their
low and high limits, only the
temperature value is displayed,
otherwise “LOW” or “HIGH”
message is added in the end of
the line. In case of sensor break,
only “SENSOR BREAK” message
is displayed.
In Screen 5 and 6 the states
of the compressor motor, fan
motor, the phase sequence,
remote disable and air pressure
are displayed. This data is
derived from the digital inputs.
The message in the rst line
of Screen 5 is determined
by Digital Input 3 and Digital
Input 4 (Compressor Fault and
Compressor Overload). The
gure on right shows the relaon
between digital inputs and the
message.
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
12
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
Screen 8 displays the last four events that caused the
dryer stopping automacally. The possible alternaves
for these messages are given below.
INLET AIR TEMP.LO
INLET AIR TEMP.HI
EXCH.TEMP.LO
EXCH.TEMP.HI
LO.PRES.L.TEMP.LO
LO.PRES.L.TEMP.HI
HI.PRES.L.TEMP.LO
HI.PRES.L.TEMP.HI
AMB.TEMP.LO
AMB.TEMP.HI
COMPRESSOR FAULT
COMP.OVERLOAD FAN
MOTOR FAULT FAN
MOT.OVERLOAD PHASE
SEQ.ERROR REMOTE
DISABLE PRESSURE
HIGH PRESSURE LOW
CONDENSER FAULT
Screen 9 displays the date and me.
Screen 10 displays the states of the digital inputs and
digital outputs. The leers ‘L’ and ‘H’ stands for ‘not
acvated’ and ‘acvated’ states respecvely.
The data in the rst line of Screen 10 (D.INPUT1), from
right to le corresponds to Digital Input 1 to 8.
The data in the second line of Screen 10 (D.INPUT2),
from right to le corresponds to Digital Input 9 to 16.
The data in the third line of Screen 10 (D.OUTPUT),
from right to le corresponds to Digital Output 1 to 8.
Screen 11 displays automac mode scheduling for the
day. Please see Secon 2.3.3 for scheduling for auto/
manual selecon.
4.3.4 Operaon Principles
In order to start the dryer, the following condions
must be sased.
1. All the temperatures except the exchanger
temperature and condenser outlet temperature
must be between their low and high limits. The low
pressure line temperature can be ‘HIGH’.
2. Digital Input 3 (Compressor Fault) is not acvated.
3. Digital Input 4 (Compressor Overload) is not
acvated.
4. Digital Input 5 (Fan Fault) is not acvated.
5. Digital Input 6 (Fan Overload) is not acvated.
6. Digital Input 7 (Phase Sequence Error) is not
acvated.
7. Digital Input 8 (Remote Disable) is not acvated.
8. Digital Input 11 (High Pressure) is not acvated.
9. Digital Input 12 (Low Pressure) is not acvated.
If all the above condions are sased, the dryer
can be started.
5. TECHNICAL SPECIFICATIONS
Model FDRCF1150030 FDRCF1150058
Capacity (scfm) 29 50
Pressure drop (psig) 2,8 1,6
Connecon Size 1/2” NPT 3/4” NPT
Amount of Refrigerant
(pounds) 0.7 1.2
Refrigerant gas R134a R134a
Noise Level (dB) <70 <70
FOR ALL MODELS
Nominal Working Pressure 100 psig
Maximum Working Pressure 230 psig
Maximum Ambient Tempature 122°F
Minimum Ambient Temperature 39°F
Maximum Inlet Temperature 140°F
6. DIAGRAMS
6.1 AIR FLOW DIAGRAMS
FDRCF1150030 / FDRCF1150058
POS. DESCRIPTION QTY
1 COMPRESSOR
2 FAN MOTOR
3 CONDENSER
4FAN SWITCH
5 HIGH PRESSURE SWITCH
6 LIQUID RECEIVER
7 FILTER DRYER
8 EXPANSION VALVE
9 BY-PASS VALVE
10 LIQUID SEPARATOR
11 LOW PRESSURE SWITCH
12 HEAT EXCHANGER
13 FILTER
14 MANUAL VALVE
15 SOLENOID VALVE
16 CHECK VALVE
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
13
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
6.1 AIR FLOW DIAGRAMS
FDRCF1150030 / FDRCF1150058
1
11
AIR OUTLET
2
11
8
AIR INLET
9
10
4
12
14
3
13
S
Drain
Outlet
14
6
7
5
IMPORTANT NOTICE:
- High Pressure Switch (Part No:5) is not used on FDRCF1150030.
S
M
M
S
REFRIGERANT GAS FLOW LINE
COMPRESSED AIR FLOW LINE
DRAIN FLOW LINE
PILOT FLOW LINE
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
14
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
6.2 ELECTRICAL DIAGRAMS
With Control & Power
“User must supply the protecve earth conductor of
the dryer. The conductor is to be connected to the
point on the conducng body of the dryer, specied
by a scker with the protecve earth symbol next
to it. The size of the protecve earth conductor
should be minimum the size of the power conductor,
minimum 16 mm² for power conductor size between
16 and 35 mm², minimum half the size of the
conductor if it is larger than 35 mm²."
Model FDRCF1150030 FDRCF1150058
Voltage/Phase/Hertz 115/1P/60 115/1P/60
INSTALLED POWER (kWa) 0.42 0.69
Nominal Current (Amp) 3.92 7.42
MCA (A) 5.11 9.20
TOTAL LRA (A) 22.48 33.70
Fuse (Amp) 6 10
~
EV3
SP
EV3: Controller
SP: Power supply
AL: Alarm contacts
A20: Drain supply
DR: Drain valve relay
A40-1: Start capacitor
K01: Compressor start relay
K02: Compressor motor contactor
K30: Alarm relay
S10: Fan pressure switch
S16: Filter service contact(optional)
M01: Compressor motor
M10: Fan motor
P: Compressor motor overload protector
PT: Temperature sensor (NTC)
HP indicates high pressure.
DR
K01
K30
1
3
10
11
12
2
4
5
2
3
4
12
4
4
PT
1
4
5
6
7
S16
AL
4
3
19
L
4
N
P
S10
1
4
10
A
20
P
K01
A40-1
MAXIMUM SET: %15
A/S
C/C P/R
M
l
~
FIELD INSTALLED
M
l~
M10
ELECTRICAL
SPECIFICATIONS
FAN MOTOR
UN 115V/1~/60Hz
M01
S01 MAIN PROTECTION AND DISCONNECTING MEANS
SHALL BE PROVIDED BY THE INSTALLER OF
RESIDUAL CURRENT AUTOMATIC CIRCUIT BREAKER
SUPPLY LINE VOLTAGE RATING - 600 VAC
COMPRESSOR
UN 115V/1~/60Hz
FDRCF1150030 RLA 3,7A 0,285kW
FDRCF1150030 RLA 0,35A 0,055kW
ELECTRICAL SUPPLY LINE
SINGLE PHASE + PROTECTION EARTH
CABLES SIZE
FDRCF1150030 3AWG14
9
6
7
H
6.2 ELECTRICAL DIAGRAMS
FDRCF1150030
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
15
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
6.2 ELECTRICAL DIAGRAMS
FDRCF1150058
~
SP
EV3
EV3: Controller
SP: Power supply
AL: Alarmcontacts
A20: Drain supply
DR: Drain valve relay
A40-1:Start capacitor
K01: Compressor start relay
K02: Compressor motor contactor
K30: Alarm relay
S10: Fan pressure switch
S11: High pressure switch
S16: Filter service contact (optional)
M01: Compressor motor
M10: Fan motor
P: Compressor motor overload protector
PT: Temperature sensor (NTC)
HP indicates high pressure
DR
K01
K30
1
2
3
4
5
10
11
12
2
3
4
12
11
4
4
S11
10
1
4
S16
PT
P
4
3
6
5
7
10
19
L
4
N
AL
P
S10
1
4
10
A20
P
K01
A40-1
A/S
C/C P/R
MAXIMUM SET: %15
M
l
~
M
l~
M10
FIELD INSTALLE
D
M01
ELECTRICAL
SPECIFICATIONS
COMPRESSOR
UN 115V/1~/60Hz
FDRCF1150058 RLA 6A 0,466kW
FAN MOTOR
UN 115V/1~/60Hz
FDRCF1150058 RLA 0,95A 0,110kW
S01 MAIN PROTECTION AND DISCONNECTING MEANS
SHALL BE PROVIDED BY THE INSTALLER OF
RESIDUAL CURRENT AUTOMATIC CIRCUIT BREAKER
SUPPLY LINE VOLTAGE RATING - 600 VAC
ELECTRICAL SUPPLY LINE
SINGLE PHASE + PROTECTION EARTH
CABLES SIZE
FDRCF1150058 3AWG14
H
9
6
7
H
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
16
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
7. ID DIAGRAM DRAWINGS &
GENERAL ARRANGEMENTS
7.1 ID DIAGRAM DRAWINGS
FDRCF1150030 / FDRCF1150058
17,795" (452mm)
`
0,078"
8,72" (221,5mm)
`
0,078"
AIR INLET
1/2" NPT
2,559" (65mm)
`
0,078"
AIR
OUTLET
1/2" NPT
2,834" (72,0mm)
`
0,078"
TOP VIEW
1,155" (29,35mm)
`
0,078"
DIGITAL CONTROLLER
CABLE
CONNECTION
FRONT VIEW
LEFT VIEW
BACK VIEW
DRAIN
0,492"
`
0,039"
1/4"
NPT
(12,5mm)
RIGHTVIEW
4,33"
`
0,039"
(110mm)
0,492"
`
0,039"
(12,5mm)
ISOMETRIC VIEW
427,00
`
1,0
BOTTOM VIEW
1,982"
`
0,039"
(50,35mm)
13,357"
`
0,039"
(339,29mm)
1,982"
`
0,039"
(50,35mm)
17,48" (444mm)
`
0,078"
3,937"
`
0,039"
(100mm)
22,303" (566,5mm)
`
0,078"
19,783" (502,5mm)
`
0,078"
17,322" (440mm)
`
0,078"
18,71" (475,25mm)
`
0,078"
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
17
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
7.2 ID DIAGRAM DRAWINGS
FDRCF1150030 / FDRCF1150058
18,62"(473mm)
TOP VIEW
3,17"(80,5mm)
5,10"(129,6mm)
3,23"(82mm)
FILTER CHANGE BUZZER
ON-OFF BUTTON
DEWPOINT
INDICATOR
AIR INLET
3/4" NPT
AIR OUTLET
3/4" NPT
CABLE CONNECTION
1,15"(29,3mm)
DRAIN
3,94"(100mm)
LEFT VIEW
FRONT VIEW
BACK VIEW
RIGHT VIEW
M8x4
ISOMETRIC VIEW
0,51"(13mm)
17,60"(447mm)
0,51"(13mm)
BOTTOM VIEW
2,03"(51,5m
m)
13,78"(350m
m)
2,03"(51,5m
m)
17,83"(453mm)
3,94"(100mm)
32,75"(831,8mm)
27,33"(694,1mm)
3,05"(77,5mm)
28,54"(725mm)
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
18
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
7.3 GENERAL ARRANGEMENTS
FDRCF1150030 / FDRCF1150058
8. FDRCF EXPLODED DIAGRAMS & SPARE PARTS LISTS
8.1 - ED & Spare Part List
FDRCF1150030
Model Element Type Length (inch) Width (inch) Height (inch) Weight (lbs)
FDRCF1150030 FILTERKIT011 17.48 17.79 22.30 72.00
FDRCF1150058 FILTERKIT012 17.83 18.62 32.76 116.60
ALL
MODELS
Superheat of
thermostac
expansion valve
Evaporang
pressure
Fan pressure
switch
Security high
pressure
switch
Security low
pressure
switch
Drain Timer
Refrigerant
temperature
switch
Water ow
valve (if water
condenser)
41.0°F - 50.0°F 29.7 psi 130.5 - 174 psi 162.5 psi 23.2 psi 5 min. - 5 sec. 113°F 159.5 psi
50
58
49
59
40
32
38
39
61
33
29
34
60
55
42
54
56
10
36
61
57
31
28
11
35
15
18
35
62
63
37
41
44
45
16
19
30
12
6
18
17
15
26
25
52
13
14
44
43
24
23
27
53
63
21
1
22
45
46
48
50
8
9
2
47
3
7
4
5
51
6
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
19
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
8.1 - ED & Spare Part List FDRCF1150030
PART LIST
DWG
SIZE ITEM
NO. PART NO. DESCRIPTION REV QT Y.
1 MK30E-CAB CABINET BASE 1
2 MK30E-CON CONDENSER 1
3 M-FAN-0075 FAN BLADE 1
4M-GRL-0075 FAN GRILL 1
5 M-FMT-0075-115-1-60 FAN MOTOR 1
6 MK260E-BLT630 BOLT M6x30mm 8
7 MK110E-NT4 NUT M4 4
8 MK110E-BLT414 BOLT M4x14mm 1
9 MK110E-WHR20 WASHER 20x4,3x1,5 1
10 MK30E-EXC HEAT EXCHANGER 1
11 MK30E-IHE INSULATION OF HEAT
EXCHANGER 1
12 MK260E-RCD 1/2" RECORD 1
13 M-DBV-0200 DRAIN BALL VALVE 1
14 MK150E-RDC REDUCTION 3/8"
- 1/4" 1
15 MK170E-CHV CHECK VALVE 2
16 MK170E-T1/4 1 / 4" T CONNECTOR 1
17 MK170E-NIP1/4 1 / 4" NIPPLE 2
18 MK150E-FIT6 1 / 4" - 6mm
FITTINGS 3
19 M-SLV-0150-115 SOLENOID VALVE 1
20 N/A N/A -
21 M-CMP-0035-115-1-60 COMPRESSOR 1
22 MK40E-CEC COMPRESSOR
ELECTRICAL BOX
COVER 1
23 M-CSR-0035-115-1-60 COMPRESSOR START
RELAY 1
24 M-COP-0035-115-1-60 COMPRESSOR
OVERLOAD
PROTECTOR 1
25 M-CSC-0035-115-1-60 COMPRESSOR START
CAPACITOR 1
26 MK30E-WSR18 WASHER 18x7x1mm 4
27 MK30E-NT6 NUT M6 4
28 MK30E-ELK-Y COMPRESSED AIR
FILTER KIT (Y) 1
29 MK30E-ELK-X COMPRESSED AIR
FILTER KIT (X) 1
30 MK170E-EWF 90* 1 / 4" - 6mm
ELBOW 1
31 MK30E-CPG COUPLING CLAMP 4
PART LIST
DWG
SIZE ITEM
NO. PART NO. DESCRIPTION REV QT Y.
32 MK30E-CNK-NPT CONNECTION CIT 2
33 MK30E-ORG O-RING 4
34 MK30E-EXS HEAT EXCHANGER
SUPPORT STEEL 1
35 MK260E-RDC REDUCTION 1 / 2"
- 1 / 4" 1
36 MK90E-GFD GASKET FOR DRAIN 1
37 MK30E-FIE-X COMPRESSED AIR
FILTER ELEMENT (X) 1
38 MK30E-FIE-Y COMPRESSED AIR
FILTER ELEMENT (Y) 1
39 MK30E-CRT CABINET REAR TOP 1
40 MK30E-CAI CABINET INSIDE 1
41 MK35E-FTT-T TEE FITTING 1
42 MK60E-BLT48 BOLT M4x8 8
43 MK260E-STC SETTING THE
CONNECTION 1
44 M-BYV-0100 EXPANSION VALVE 1
45 M-DRI-0200 DRYER-DEHYDRATOR 1
46 M-FNS-0200 FAN ON/OFF SWITCH 1
47 MK260E-PCP PLASTIC CONTROL
PANEL 1
48 MK130E-DPI-115 DIGITAL
CONTROLLER 1
49 M-STU-6000 CABINET STUD AND
NUT 8
50 MK90E-BLT412 BOLT M4x12 18
51 MK30E-COP CONTROLLER PANEL 1
52 MK260E-CG11 CABLE GLAND PG11 1
53 MK260E-RNT8 RIVET NUT M8 4
54 MK30E-CLT CABINET LEFT 1
55 MK30E-CBR CABINET RIGHT 1
56 M-CHN-6000 CABINET HANDLE
(NEW) 2
57 MK30E-CSG CABINET STRIPPING 2
58 MK30E-CAT CABINET TOP 1
59 M-FAS-6000 CABINET FASTENER 8
60 MK90E-CSP CABLE STRAP 3
61 MK90E-RVT3,5 RIVET Ø3,5 25
62 MK130E-PWC POWER CABLE 1
63 MK60E-RTA2 ROTOLOCK
ADAPTOR2 2
Flexzilla Pro Energy Ecient Refrigerated Air Dryers
20
Scan or go to www.exzilla.com/air-dryer-warranty-registration
Warranty only valid by following conditions expressed in the Warranty Statement section of this Air Dryer Manual.
YOU MUST
REGISTER TO
ACTIVATE
WARRANTY
8.1 - ED & Spare Part List
FDRCF1150058
39
59
42
40
56
10
51
38
33
57
60
41
54
37
31
36
35
53
58
44
55
32
50
46
43
40
67
24
25
62
20
A
A
30
29
21
67
45
64
28
43
27
63
18
26
19
65
23
61
22
13
16
11
17
14
15
1
12
52
3
4
48
10
2
5
8
9
49
7
47
6
This manual suits for next models
1
Table of contents
