SupaWarm SDHM5 User manual

Dehumidifier
245 Watt
INSTRU
C
TION MANUAL
717907 SDHM5 245w Dehumidifier IM 1_

Power Button
Filter Net
Front Panel
Water Tank
Handle
Back Housing
Continuous Water Out Hole
Power Cord
Images are for visual purposes only, actual product may differ from the image shown.
ATTENTION! This appliance is designed for domestic use only.
DO NOT use for industrial purposes.
717907 SDHM5 245w Dehumidifier IM 2_

(CE) N 842
/
2006
R290 is a type of fluorinated greenhouse gas covered by the
Kyoto Protocol.
Global Warming Potential (GWP): 3
*at room temperature of 30°C, 80% humidity
•
Water tank capacity: 2.2 litres
•
Working temperature range: 5°C - 32°C
•
Dehumidification capacity
"
: 10 litres / day (max)
•
Weight: 9kg
•
Refrigerment type: R290/35g
•
Unit dimensions: 280mm(W) x 240mm(D) x 456mm(H)
WARNING! This appliance must be earthed.
Ensure that the voltage indicated on the identification plate
corresponds with the mains voltage.
•
220-240V ~ 50Hz, 200-245W
Product Code: SDHM5
RATING
717907 SDHM5 245w Dehumidifier IM 3_

At the end of its working life, the product
must not be disposed of as urban waste. It
must be taken to a special local authority
differentiated waste collection centre or to
a dealer providing this service. Disposing
of a household appliance separately avoids
possible negative consequences for the
environment and health, avoiding
inappropriate disposal enables the
constituent materials to be recovered to
obtain significant savings in energy and
resources. As a reminder of the need to
dispose of household appliances
separately, the product is marked with a
crossed-out wheeled dustbin.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF
THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002
/
96
/
EC.
717907 SDHM5 245w Dehumidifier IM 4_

Only connect the appliance to a mains supply of the same
voltage specified on the rating plate.
The product is for household use only.
Use the appliance only for the mentioned purpose, namely
as a dehumidifier for domestic use.
DO NOT use for any other
application as this could be dangerous. The manufacturer is not
responsible for any eventual damages caused by improper or
faulty use.
F O R Y O UR O W N S A F E T Y !
PLEASE READ AND FOLLOW THESE INSTRUCTIONS FOR THE
USE OF YOUR DEHUMIDIFIER TO ENSURE THE HEALTH AND
SAFETY OF YOURSELF AND OTHERS WHO MAY BE AFFECTED.
717907 SDHM5 245w Dehumidifier IM 5_

717907 SDHM5 245w Dehumidifier IM 6_

717907 SDHM5 245w Dehumidifier IM 7_
Controls the level of dehumidification required as apercentage
Choose between dehumidification (DH) or ventilation (FA)
Use to set the desired operation time in 1 hour increments
Humidity:
Dehumidification:
Timer:
This dehumidifier has three functions;

717907 SDHM5 245w Dehumidifier IM 8_
Please keep the power cable away from any doors to avoid damage
to the cable.
Please keep children away from the dehumidifier. Make sure the appliance is
attended by a responsible adult if children are near the appliance.
Warning
QUICK START GUIDE
1.Connect the power supply of the dehumidifier.
2. Press “STAND-BY” to turn the appliance ON.
a.
N o
t
i c e : Please ensure the water tank has been installed correctly. The full
indicator light (orange light) will display if incorrectly installed or if the tank is full.
b. The appliance should now begin to operate.
3. Continuously press "TIMER" to select the desired time
N o
t
e : Timing can be set from 0-12 hours cycle
4.Press "DEHUMIDIFICATION", select dehumidification (DH) or ventilation (FA);
Note: in ventilation mode (FA) you can't set humidity.
Press "HUMIDITY" to set desired level of dehumidification (% of humidity in room)
The setting range is 30% - 80%, or forced operation (CO)
5.Press “STAND-BY” again to turn the appliance OFF.
The dehumidifier should now stop running.
6.TANK FULL indication:
The compressor will
stop running,but the fan will continue to run.

717907 SDHM5 245w Dehumidifier IM 9_
The recommended operating temperature range for this unit is
5°C - 32°C.
The unit cannot be placed on a surface which is soft or not flat to
avoid the unit causing noise, vibration and water leakage when
operating.
When using the dehumidifier, keeping the doors and window to
the room closed will improve the efficiency of the appliance.
Ensure the water tank is in place, or if required connect the
appropriate tube onto the continuous water out hole.
•
Ensuring the power button is set to off, connect the appliance
to a suitable power socket.
•
Once connected, switch on the dehumidifier using the
stand-by button.
•
To switch off the appliance press the stand-by button again.
To empty the water tank, switch off and disconnect from the
main supply, then remove the tank carefully sliding it out the
back of the unit. Then ensure the tank is properly seated back
into position once emptied.
lf the product shuts down, please wait at least 3 minutes before
restarting the unit to prevent damaging the compressor. When
the dehumidifier is in operation, the working compressor may
cause the unit to heat up slightly. This may alter the room
temperature.

717907 SDHM5 245w Dehumidifier IM 10_

717907 SDHM5 245w Dehumidifier IM 11_

717907 SDHM5 245w Dehumidifier IM 12_

717907 SDHM5 245w Dehumidifier IM 13_

717907 SDHM5 245w Dehumidifier IM 14_
DECLARATION OF CONFORMITY
We, the importer:
Munro Importers Ltd
First Floor, Unit 1 The Quadrangle The Drift, Nacton Road,
Ipswich, Suffolk, IP3 9OR
Declare that the product:
Product code: 717907 SDHM5
Product description: SupaWarm 245w Dehumidifier
Is in conformity with the relevant statutory instruments and their amendments:
And is manufactured in accordance with the following Standard or standardized documents:
All documentation is held on file and is available, on request, for review.
Authorized Signatory:
Date: 18.04.2023
Name: Dominic Richardson
Position: Product Coordinator
Year of Manufacture: 2023
MUNRO IMPORTERS LTD
Declara�on of Conformity
In accordance with Government Guidance
EMC Direc�ve 2014/30/EU and The Electromagne�c Compa�bility Regula�ons 2016
Low Voltage Direc�ve 2014/35/EU and The Electrical Equipment (Safety) Regula�ons 2016
Direc�ve 2011/65/EU on the Restric�on of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment (RoHS) with its Amendments (EU) 2015/863
EN 55014-1:2017/A11:2020, EN 55014-2:2015, EN IEC 61000-3-2:2019, EN 61000-3-3:2013/A1:2019
EN 60335-2-40:2003 + A11:2004 + A12:2005 + A1:2006 + A2:2009 + A13:2012, EN 60335-1:2012 + AC:2014 + A11:2014 +
A13:2017 + A1:2019 + A14:2019 + A2:2019, EN 62233:2008, AfPS GS 2019:01 PAK
EN 62321-1:2013, EN 62321-2:2014, EN 62321-3-1:2014, EN 62321-4, EN 62321-5:2014, EN 62321-7-1:2015 and EN
62321-7-2;2017, EN 62321-6:2015, EN 62321-8:2017
