Flintec FT-112 User manual

FT-112(D) Panel
Weighing Terminal
Technical Manual

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 1of 170
Table of Contents:
1Safety Instructions...................................................................5
2Declaration of Conformity........................................................6
3Introduction .............................................................................7
Overview.............................................................................................................................................7
Specifications......................................................................................................................................7
The Front View and Key Functions...................................................................................................12
3.3.1 Display ..............................................................................................................................................12
3.3.2 Key Pad ............................................................................................................................................13
Passwords ........................................................................................................................................15
3.4.1 Keylock .............................................................................................................................................15
3.4.2 Passwords ........................................................................................................................................15
4Installation.............................................................................16
Recommendations............................................................................................................................16
4.1.1 Environment......................................................................................................................................16
4.1.2 Cabling..............................................................................................................................................16
4.1.3 Electrical Connection........................................................................................................................16
4.1.4 Location of the Peripheral Connections............................................................................................17
Cleaning............................................................................................................................................17
Disposal ............................................................................................................................................17
Housing.............................................................................................................................................18
Mechanical Installation......................................................................................................................18
Electrical Connections ......................................................................................................................19
4.6.1 Analogue Load Cell Connection (Only FT-112 Panel) .....................................................................19
4.6.2 Digital Load Cell Connection (Only FT-112D)..................................................................................20
4.6.3 RS232C Serial Port...........................................................................................................................21
4.6.4 RS485 Serial Port.............................................................................................................................22
4.6.5 RS422 Serial Port.............................................................................................................................23
4.6.6 Ethernet TCP/IP................................................................................................................................24
4.6.7 Profibus PB.......................................................................................................................................25
4.6.8 Profinet..............................................................................................................................................25
4.6.9 CANopen ..........................................................................................................................................26
4.6.10 EtherNET/IP......................................................................................................................................27
4.6.11 EtherCAT ..........................................................................................................................................28
4.6.12 CC-Link.............................................................................................................................................28
4.6.13 Powerlink ..........................................................................................................................................29
4.6.14 CC-Link IE.........................................................................................................................................29
4.6.15 USB Port...........................................................................................................................................30
4.6.16 Installation of Alibi SD card...............................................................................................................30
4.6.17 Installation of SD Card......................................................................................................................31
4.6.18 Digital Inputs .....................................................................................................................................31
4.6.19 Digital Outputs: .................................................................................................................................31
4.6.20 Analogue Output Connection............................................................................................................32
4.6.21 Power Source Connection and Grounding.......................................................................................32
5FT-112(D) Functions.............................................................33
Basic Functions.................................................................................................................................33
Advanced Functions .........................................................................................................................35
Alibi Memory.....................................................................................................................................38
6Programming and Calibration ...............................................41
Entering to the Programming and Calibration...................................................................................41
Quick Access to frequently Used Parameter Blocks........................................................................42
Exit from Programming.....................................................................................................................42
Programming and Parameters..........................................................................................................43
Calibration.........................................................................................................................................70
6.5.1 Linearity Correction...........................................................................................................................70

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 2of 170
6.5.2 Zero and Span Adjustments .............................................................................................................71
6.5.3 eCal Electronic Calibration ..............................................................................................................72
6.5.4 Gravity adjustment............................................................................................................................73
6.5.5 Calibration coefficients......................................................................................................................73
7Digital Load Cell (DLC) .........................................................74
Addressing Digital Load cells............................................................................................................74
8Identifications ........................................................................76
9SmartAPP..............................................................................78
10 Standard Applications ...........................................................79
Classifying.........................................................................................................................................79
10.1.1 Product Limit values at Classifying...................................................................................................80
10.1.2 Start and Stop the Classifying ..........................................................................................................81
10.1.3 SmartAPP at Classifying...................................................................................................................81
Checkweighing..................................................................................................................................82
10.2.1 Product Limit values at Checkweighing............................................................................................83
10.2.2 Start and Stop the Checkweighing ...................................................................................................84
10.2.3 SmartAPP at Checkweighing............................................................................................................84
Filling.................................................................................................................................................85
10.3.1 Product Entries at Filling...................................................................................................................86
10.3.2 Start and Stop the filling....................................................................................................................87
10.3.3 SmartAPP at filling............................................................................................................................87
Peak Hold .........................................................................................................................................88
10.4.1 Product entries..................................................................................................................................88
10.4.2 Start and Stop the peak hold ............................................................................................................90
10.4.3 SmartAPP at peak hold.....................................................................................................................90
10.4.4 Digital inputs and outputs .................................................................................................................90
Totalization........................................................................................................................................91
11 Digital inputs and outputs......................................................93
Basic Weighing .................................................................................................................................93
Application Weighing ........................................................................................................................94
Digital inputs .....................................................................................................................................95
Digital outputs ...................................................................................................................................96
12 Serial Data Outputs.............................................................106
Continuous Data Output .................................................................................................................106
12.1.1 Continuous Data Formats...............................................................................................................107
Fast Continuous Data Output .........................................................................................................110
Print Mode.......................................................................................................................................110
EPL Format.....................................................................................................................................111
BSI Data Structure for Dialog with PC and PLC.............................................................................112
12.5.1BSI-Base Commands ....................................................................................................................115
13 Optional Communication.....................................................118
Analogue Output.............................................................................................................................118
Modbus RTU and TCP/IP...............................................................................................................119
13.2.1 Modbus Data Structure...................................................................................................................120
Ethernet TCP/IP..............................................................................................................................127
13.3.1 Ethernet Parameters.......................................................................................................................127
Profibus DP.....................................................................................................................................128
14.1.1 Data Format....................................................................................................................................128
14.1.2 GSD Configuration..........................................................................................................................129
14.1.3 Profibus DP Data Structure ............................................................................................................129
Profinet............................................................................................................................................130
14.2.1 Data Format....................................................................................................................................131
14.2.2 Profinet Parameters........................................................................................................................131
14.2.3 GSDML Configuration.....................................................................................................................131

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 3of 170
14.2.4 Profinet Data Structure ...................................................................................................................132
CANopen.........................................................................................................................................133
14.3.1 Data Format....................................................................................................................................133
14.3.2 EDS Configuration..........................................................................................................................134
14.3.3 CANopen Data Structure................................................................................................................134
EtherNet/IP .....................................................................................................................................135
14.4.1 Data Format....................................................................................................................................136
14.4.2 EtherNet/IP Parameters..................................................................................................................136
14.4.3 EDS Configuration..........................................................................................................................136
14.4.4 EtherNet/IP Data Structure.............................................................................................................137
EtherCAT ........................................................................................................................................138
14.5.1 Data Format....................................................................................................................................139
14.5.2 ESI Configuration............................................................................................................................139
14.5.3 EtherCAT Data Structure................................................................................................................139
CC-Link...........................................................................................................................................140
14.6.1 Data Format....................................................................................................................................140
14.6.2 CC-Link Configuration.....................................................................................................................140
14.6.3 CC-Link Data Structure...................................................................................................................141
Powerlink.........................................................................................................................................142
14.7.1 Data Format....................................................................................................................................143
14.7.2 XDD Configuration..........................................................................................................................143
14.7.3 Powerlink Data Structure................................................................................................................143
CC-Link IE Field..............................................................................................................................144
14.8.1 Data Format....................................................................................................................................144
14.8.2 CC-Link IE Configuration................................................................................................................144
14.8.3 CC-Link IE Data Structure ..............................................................................................................145
15 Appendix 1: Data Structure Profibus, Profinet, EtherNET/IP,
EtherCAT, CC-Link, Powerlink, CC-Link IE..................................146
16 Appendix 2: Data Structure - CANopen..............................155
17 Sealing of Approved Scale..................................................165
18 Trouble Shooting.................................................................166

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 4of 170
RIGHTS AND LIABILITIES
All rights reserved.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or
by any means, mechanical, photocopying, recording, or otherwise, without the prior written permission of
FLINTEC GmbH.
No patent liability is assumed with respect to the use of the information contained herein. While every
precaution has been taken in the preparation of this book, FLINTEC GmbH assumes no responsibility for
errors or omissions. Neither is any liability assumed for damages resulting from the use of the information
contained herein.
The information herein is believed to be both accurate and reliable. FLINTEC GmbH, however, would be
obliged to be informed if any errors occur. FLINTEC GmbH cannot accept any liability for direct or indirect
damages resulting from the use of this manual.
FLINTEC GmbH reserves the right to revise this manual and alter its content without notification at any
time.
Neither FLINTEC GmbH nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident,
misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product,
or failure to strictly comply with FLINTEC GmbH operating and maintenance instructions.
FLINTEC GmbH shall not be liable against any damages or problems arising from the use of any options
or any consumable products other than those designated as Original FLINTEC GmbH Products.
NOTICE: The contents of this manual are subject to change without notice.
Copyright © 2016 by FLINTEC GmbH; 74925 Meckesheim, Bemannsbruch 9, Germany

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 5of 170
1 SAFETY INSTRUCTIONS
CAUTION! READ THIS MANUAL BEFORE OPERATING OR SERVICING THIS
EQUIPMENT. FOLLOW THESE INSTRUCTIONS CAREFULLY. SAVE THIS MANUAL
FOR FUTURE REFERENCE. DO NOT ALLOW UNTRAINED PERSONNEL TO
OPERATE, CLEAN, INSPECT, MAINTAIN, SERVICE, OR TAMPER WITH THIS
EQUIPMENT. ALWAYS DISCONNECT THIS EQUIPMENT FROM THE POWER
SOURCE BEFORE CLEANING OR PERFORMING MAINTENANCE. CALL FLINTEC
ENGINEERING FOR PARTS, INFORMATION, AND SERVICE.
WARNING! ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS EQUIPMENT.
EXERCISE CARE WHEN MAKING CHECKS, TESTS AND ADJUSTMENTS THAT MUST
BE MADE WITH POWER ON. FAILING TO OBSERVE THESE PRECAUTIONS CAN
RESULT IN BODILY HARM.
WARNING! FOR CONTINUED PROTECTION AGAINST SHOCK HAZARD CONNECT
TO PROPERLY GROUNDED OUTLET ONLY. DO NOT REMOVE THE GROUND
PRONG.
WARNING! DISCONNECT ALL POWER TO THIS UNIT BEFORE REMOVING ANY
CONNECTION, OPENING THE ENCLOSURE OR SERVICING.
WARNING! BEFORE CONNECTING/DISCONNECTING ANY INTERNAL ELECTRONIC
COMPONENTS OR INTERCONNECTING WIRING BETWEEN ELECTRONIC
EQUIPMENT ALWAYS REMOVE POWER AND WAIT AT LEAST THIRTY (30)
SECONDS BEFORE ANY CONNECTIONS OR DISCONNECTIONS ARE MADE.
FAILURE TO OBSERVE THESE PRECAUTIONS COULD RESULT IN DAMAGE TO OR
DESTRUCTION OF THE EQUIPMENT OR BODILY HARM.
CAUTION! OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC SENSITIVE
DEVICES.

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 6of 170
2 DECLARATION OF CONFORMITY
EU-Konformitätserklärung
EU-Declaration of Conformity
Monat/Jahr: month/year:
07/2019
Hersteller: Manufacturer:
Flintec GmbH
Anschrift: Address:
Bemannsbruch 9
D-74909Meckesheim
Deutschland/Germany
Produktbezeichnung:Product name:
Nr. der Bauartzulassung:
No oft the EC type-examination certificate:
Nichtselbsttätige Waage (NSW)
Non-automatic Weighing Instrument (NAWI)
FT-11x / FT 11x panel Wägeterminal / Weighing
Terminal
No. 0200-NAWI-04810, FORCE Certification
Das bezeichnete Produkt stimmt mit folgenden Vorschriften der Europäischen Richtlinien überein:
This product confirms with the following regulations of the Directives of the European Community
Richtlinie 2014/35/EU Niederspannungs-Richtlinie
Richtlinie 2014/30/EU EMV
Richtlinie 2011/65/EU RoHS
Richtlinie 2014/31/EU Nichtselbsttätige Waagen
Directive2014/35/EULowVoltageDirective
Directive2014/30/EUElectromagneticcompatibility
Directive2011/65/EURoHS
Dircetive2014/31/EUNon-AutomaticWeighing
Die Absicherung aller produktspezifischen
Qualitätsmerkmale erfolgt auf Basis eines
zertifizierten Qualitätsmanagement-Systems nach
DIN ISO 9001.
All product-related features are assured by a quality
system in accordance with ISO 9001.
FolgendeNormenwerdenzumNachweisderÜbereinstimmungmitdenRichtlinieneingehalten:
Asaproofofconformitywiththedirectivesfollowingstandardsarefulfilled:
EN 60950-1:2008
EN 61326-1:2013
EN 50581:2012
EN 45501:2015
DieseErklärungbescheinigtdieÜbereinstimmung
mitdengenanntenRichtlinien,beinhaltetjedoch
keineZusicherungvonEigenschaften.
Thisdeclarationcertifies theconformitywiththelisted
directives,butitisno promiseofcharacteristics.

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 7of 170
3 INTRODUCTION
Overview
FT-112(D) Panel weighing indicator is economic and powerful state-of-the-art indicator for industrial weighing
applications like basic weighing, checkweighing, classifying, peak holding, labelling, filling and totalization etc.
This compact instrument provides flexible solutions besides its high-speed weighing and interfacing features.
The weighing indicator has two identification data memory each has 500 items record size, 500 items record
size specific tare memory and 500 items set memory which has 6 set values for each item.
Digital inputs and outputs of the instrument can be programmed as a Remote IO on the fieldbus. This feature
gives advantage to eliminate additional PLC in the cabinet for only having remote IO’s.
The scales equipped with FT-112(D) Panel weighing indicator can be used in all kind of industrial areas up
harsh to wet and hygienic environments with its fast and efficient cleaning that was designed and built
according to the international guidelines.
Specifications
Analogue Load cell (only FT-112)
A/D converter type
24-bit Delta-Sigma ratio metric with integral analog and digital filters
Conversion rate
Up to 1600 measurement values per second
Input sensitivity
0.4 μV/e approved; 0.05 μV/d non approved.
Analog input range
-5 mV to +19 mV
Internal resolution
up to 16 000 000
Excitation
5 VDC max. 150 mA
Number of load cells
Up to 8 load cells 350 Ω or 25 load cells 1100 Ω.
Connection
4- or 6-wire technique.
Cable length: maximum 1000 m/mm² for 6-wire connection
Digital load cell (only FT-112D)
Interface
RS 485
Interface baud rate
Up to 57600
Connection
4 wire. Up to 500 meters.
Number of load cell
Up to 24 digital load cells.
Internal resolution
200 000 counts
Excitation
12 VDC, max. 1.3 A
Scale
Range
Single range, up to 3 x multi intervals, up to 3 x multi ranges.
Display resolution
FT-112 Panel Approval, up to 10 000 division at usage in trade, according to
EN45501 and OIML R76.
Up to 300 000 division at industrial usage.
FT-112D Panel Maximum 20 000. Should be limited by 10% of the maximum
count of the digital load cell for accurate measurement.
Calibration and Functions
Calibration
Calibration with test weights,
eCal electronic calibration without test weights,
Temporary zero calibration,
Zero adjustment, Gain adjustment,
Coefficient entry.
Digital filter
5 steps programmable adaptive filter

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 8of 170
RS 422
Baud rate
1200 to 57600 programmable
Data
Length 7 or 8 bits; parity even, odd or none
Stations
Up to10 stations
Ethernet TCP/IP
Transmission rate
10 / 100 Mbit/s, Full duplex
TCP/IP settings
Manual IP assign over Indface2x PC Software or by keys in programming mode.
Connection method
Server or Client
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45.
Isolation
Galvanically isolated bus electronics
Response speed
Up to 4 ms response delay after read/write commands
USB
Connection
Standard USB Micro-B cable
Response speed
Min. 4 ms response delay after read/write commands
Digital Inputs and Outputs (optional)
Digital Inputs
Optoisolated 4 digital input, 12 to 28 VDC, 10mA.
Any input(s) can be used as a Remote input of your PLC over BSI or Modbus.
Digital Outputs
5 free relay contact, 250 VAC or 30 VDC, 0.2A
Any output(s) can be used as a Remote output of your PLC over BSI or Modbus.
Analogue Output (opional)
Voltage output
0-5 VDC, 0-10 VDC
Current output
4-20mA, 0-20mA
Resolution
60 000 steps
Dynamic filter
Programmable dynamic filter
Weighing functions
Taring, zeroing, auto zero tracking, motion detection, auto zero at power up, tare
status saves at power off, increased resolution, automatic tare and clear,
temporary gross indication, unit change.
Standard applications
Labelling with barcode, checkweighing, classifying, basic filling, peak holding,
totalization, livestock weighing and free setpoints, functional outputs,
Remote IO of PLC or HMI, fieldbus interface.
Memory
Application memories
ID1, ID2, Limit values for weighing of items / setpoint memory and preset tare
memory.
Each memory size is 500 item records.
Alibi memory (optional)
99 999 records
Communication
Connectable with
PC, PLC, Printer, Remote display, EPL printer etc.
RS 232
Isolation
Galvanically isolated.
Baud rate
1200 to 57600 programmable
Data
Length 7 or 8 bits; parity even, odd or none
RS 485
Isolation
Galvanically isolated.
Baud rate
1200 to 57600 programmable
Data
Length 7 or 8 bits; parity even, odd or none
Stations
Up to 31 stations

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 9of 170
Max. cable length
300 meters
Max. load resistance
(current output)
500 Ω
Minimum load resistance
(voltage output)
10 kΩ
Profibus DPV1 (optional)
Data rate
Up to 12000 kbit/s with automatic baud rate detection
GSD file
Generic GSD-file provided
Topology
Depending on physical media
RS-485: segmented line topology without stubs
Installations
Shielded twisted pair cable
Line length depending on physical media and transmission speed
Max. Stations
up to 126 stations per network
Isolation
Galvanically isolated bus electronics
Response speed
Min. 4 ms response delay after read/write commands
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
Profinet (optional)
Data rate
100 Mbit/s, full duplex
GSDML file
Generic GSDML-file provided
TCP/IP settings
DHCP or manual IP are assigned over Indface2x PC Software or by keys in
programming mode. Device identity customization
Topology
Line, Bus, Star or Tree topology depending on physical media
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45
connectors.
Web client
Available
Isolation
Galvanically isolated bus electronics
Response speed
Min. 4 ms response delay after read/write commands
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
CANopen (optional)
Data rate
10 kbit/s –1 Mbit/s (selectable) kbit/s
EDS file
Generic EDS-file provided
Topology
Line with Trunkline, Dropline structure and Termination at both Ends
Line length depending on baud rate 25 –500 meters.
Installation
2 wire shielded twisted pair cable
Alternatively, 4 wire with 24 Volt power over the bus
Max. Stations
Up to 127 stations per network
Isolation
Galvanically isolated bus electronics
Response speed
Min. 4 ms response delay after read/write commands
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 10 of 170
EtherNet/IP (optional)
Data rate
10 Mbit/s or 100 Mbit/s, full duplex
EDS file
Generic EDS-file provided
DLR (Device Level Ring)
Available
TCP/IP settings
DHCP or manual IP assign over Indface2x PC Software or by keys in
programming mode. Device identity customization
Topology
Line, Bus, Star or Tree topology depending on physical media
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45
connectors.
Web client
Available
Isolation
Galvanically isolated bus electronics
Response speed
Up to 4 ms. response delay after read/write commands.
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
EtherCAT (optional)
Data rate
100 Mbit/s, full duplex
ESI file
Generic ESI-file provided
Topology
Line, Tree, Star or Daisy-chain topology depending on physical media
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45
connectors.
Isolation
Galvanically isolated bus electronics
Response speed
Up to 4 ms. response delay after read/write commands.
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
CC-Link (optional)
Data rate
156 kbit/s –10 Mbit/s (selectable)
Topology
Line with Trunkline, Branch structure and Termination at both Ends.
Installation
3 wires shielded twisted pair cable.
Max. Stations
Up to 64 stations per network
Isolation
Galvanically isolated bus electronics
Response speed
Up to 4 ms. response delay after read/write commands
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
Powerlink (optional)
Compatibility
Supports Ethernet POWERLINK V2.0 Communication Profile Specification
version 1.2.0
Data rate
100 Mbit/s, half duplex
XDD file
XDD-file provided
Ring redundancy
Available

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 11 of 170
Topology
100% free choice of star, tree, ring or daisy chain
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45
connectors.
Isolation
Galvanically isolated bus electronics
Response speed
Min. 4 ms response delay after read/write commands
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
CC-Link IE Field (optional)
Data rate
1 Gbit/s Baud Rate
CSP+ file
Generic CSP+ file provided
Topology
Line, Star, Line/Star mixture or Ring topology depending on physical media
Installation
IEEE802.3 1000Base-T cable, ANSI/TIA/EIA-568-B (Category 5e) compliant 4-
pair, balanced-type shield cable, Double-shield type is recommended.
Max. number of
networks
Up to 239
Number of connected
nodes per network
Master station = 1, Slave station = 120
Isolation
Galvanically isolated bus electronics
Response speed
Up to 4 ms. response delay after read/write commands.
Remote IO
Digital inputs and outputs of the instrument can be programmed independently as
a Remote IO’s of PLC to control them over fieldbus.
Power Consumption
FT-112
Panel
12 –28 VDC 250 mA + max. 500 mA for fieldbus interfacing
FT-112 (D)
Panel
12 –28 VDC 150 mA + max. 500 mA for fieldbus interfacing
+ load cell currents.
Environment and Enclosure:
Operation temp. range
Approved scales -10 °C to +40 °C
Industrial usage -15 °C to +55 °C
Humidity
80% RH max, non-condensing
Enclosure
Stainless steel front panel and rear panel, aluminum body.
Protection
Front panel IP67
Panel cut size
186 x 92 mm
(7.32 x 3.62”)
Sizes ( W x H x D )
205 x 108 x
112,5mm
(8.07 x 4.25 x 4.43”)
Weight
1,4 kg
(3,07 lb)
Packing sizes
(W x H x D)
273 x 190 x 153 mm
(10,75 x 7,48 x 6,02”)
Weight Packed
2,5 kg
(5,51 lb)

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 12 of 170
The Front View and Key Functions
Figure 3.1 –Front view of FT-112(D) Panel
3.3.1 Display
The bright and wide-angle LCD display of the FT-112(D) Panel instruments is shown below.
The meanings of the announcement symbols on the display:
1
6-digit 22 mm height big weighing display with sign
2
16-digit 8 mm height alphanumeric information display
3
High resolution digit separator.
4
Announces the indicated value is the net weight.
5
Announces the indicated value is the gross weight.
6
Bar graph
1
3
4
5
6
2
7
8
9
10
11
12
13
14
15

FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 13 of 170
7
Indicates the range of the scale at multi range and multi interval
operations.
8
g, kg, t, lb, klb, N, kN units are located on the right of the display.
9
Announces the activated inputs and outputs.
10
Announces the instrument is at repair status or call service.
11
Announces the weight value is in the center of zero range.
12
Announces the weighing is not stable. After stabilization of the
weighing, this symbol disappears.
13
Announces the scale is preset tared after entering the specified tare
value.
14
Announces the keys are locked.
15
ms
