Forest garden LOG STORE User manual

LOG STORE
1762
1234
1097mm
912mm
DRILL
REQUIRED TOOLS : (NOT SUPPLIED)
Thank you for choosing this product manufactured by the UK's largest manufacturer of timber garden products. In order to gain the most benefit from it, please note the following:
- Exercise particular care and follow instructions.
- This product is pressure treatedto ensure longevity of all components and to protect against rot. This may leave a colour difference as on some parts as that will even out as the
moisturte content stabilises. For extra protection from the elements we recommend that you treat your structure using a wood preservative treatment. Apply in accordance with the
manufacturers instructions.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance and this may affect the remedies you are
entitled to. If the product is not constructed in accordance with the instructions, or is altered in anyway (eg painted), the manufacturer cannot be held liable for any resulting damage
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- Important Note : Do not lean or stand on roof during assembly this is not a load bearing.
- If there are any technical queries with the product, please contact our customer help line on 0333 7777 089 between the hours of 8.30 am and 5.00 pm Monday to Friday.
MUST PRE DRILL
Issue 0116
LOGSTOREFP FIXING PACK
8
TAPE MEASURE
POZI DRIVE SCREWDRIVER
1
JE
Place the left hand side on
to the floor short side as
shown and secure using
2x50mm screws, screwing
into the batten
underneath.
Repeat this step with the
right hand side.
22
30mm
24
137161762PTR (Large Board) Qty 6
LSRHS
(Log Store Right Hand Side)
ELSROOF (Economy Log Store)
ELSLHS
(Economy Log Store
Left Hand Side)
ELSFLR
(Economy Log Store Floor)
50mm
LSFLR
(Log Store Floor)
LSROOF (Log Store Roof)
137160912PTR (Board) Qty 5
1155
1234
IMPORTANT, RETAIN FOR FUTURE REFERENCE :READ CAREFULLY
LSLHS
(Log Store Left Hand Side)
ELSRHS
(Economy Log Store
Right Hand Side)
LGLSROOF (Large Log Store)
137161155PTR (Board) Qty 6
LGLSFLR
(Large Log Store Floor)
LOGSTOREFP
For LGLOGSTORE
For LOGSTORE

Once the sides are fixed to the floor
attach the boards so that they are in
line with the boards on the left and
right hand side and secure using
two 30mm screws at each end as
shown
2
3
Place the log store roof on top of
the structure so that the overhang is
at the front.
Fix in place using 2x50mm screws
for each side, screwing into the
batten underneath.
Forest Garden plc.
Unit 288 Hartlebury Trading Estate
Hartlebury
Worcestershire
Dy10 4JB
E-mail: [email protected]
www.forestgarden.co.uk
