Forest LEAN-TO KIT User manual

207mm
2
Making British gardens great
LEAN-TO KIT INSTRUCTIONS
ISSUE: 0219
FIXING PACK CODE: LTKMFP
Tape Measure
We recommend using the following tools (NOT SUPPLIED):
Pozidrive
Screwdriver
Drill & 2mm
Drill Bit
Spirit Level
5 x 70mm Screws
QTY: 12
FIXING PACK CONTAINS:
PLEASE KEEP PLASTIC BAGS AND SMALL
PARTS AWAY FROM CHILDREN
It’s vital that you build your new lean-to addition on level ground in your
desired location.
4 x 50mm Screws
QTY: 10
Missing Something?
Call our aftersales team on
0333 777 7089
Need more information?
Call our technical team on
0333 321 3142
Visit our website for spare
instructions and more
information
www.forestgarden.co.uk
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
IMPORTANT
Assembly requires 2+ adults.
REMINDER
Always pre-drill before screwing.
Felt Tacks
QTY: 46
1 3
4 x 40mm Screws
QTY: 6
BACK
FRONT
4
64LTKM
FRONT
BACK
AB
75LTKM
FRONT
BACK
1086mm
AB
A
86LTKM
BACK
1205.5mm
FRONT
AB
A
SECTION LAYOUT (UNDERNEATH)
Using the measurement provided and mark,
pre-drill and screw through the brace into the
post. Ensure the brace is ush to the one face/
edge as shown above. Use the section layout to
determine the correct brace directions before
screwing.
A B
Apply the roof. Ensure the posts
are in contact with the faces/
edges of the internal roof battens.
Screw through the roof battens
into the posts and braces as
shown above.
Screw the lean-to to your shed, using all the screws
provided to keep secure. Ensure the roof external roof
battens on the lean-to are in contact with the shed
external roof battens. Ensure the roof batterns are
ush to the shed roof battens.
Screw the fascias to the lean-to. Ensure it is ush with
the sheds fascias. Screw through the fascias into the
roof battens behind.
The 6x4 lean-to will only have 2 posts/braces
provided.
The 7x5 lean-to will have a central post
and brace. Use the central roof batten to
screw it into place. Use the measurement
provided to put it on the correct side of
the roof batten.
The 8x6 lean-to will have a central
post and brace. Use the central roof
batten to screw it into place. Use the
measurement provided to put it on
the correct side of the roof batten.
ABKEY
Determines which side the brace will be
screwed onto the post.
Part Code Description No.
38120770PAII63PT Fascia (38 x 12 x 770mm) 2
45450500AII32PT Brace (45 x 45 x 500mm) 1
64LTKRF Assembled Roof 2
75751318AI63PT Post (75 x 75 x 1318mm) 2
FELT26BL
Felt 1
Part Code Description No.
38120770PAII63PT Fascia (38 x 12 x 770mm) 2
45450500AII32PT Brace (45 x 45 x 500mm) 3
75751318AI63PT Post (75 x 75 x 1318mm) 3
75LTKRF Assembled Roof 1
FELT26BL
Felt 1
Part Code Description No.
45450500AII32PT Brace (45 x 45 x 500mm) 3
59120770PAII63PT Fascia (59 x 12 x 770mm) 2
75751318AI63PT Post (75 x 75 x 1318mm) 3
86LTKRF Assembled Roof 1
FELT26BL
Felt 1
6' x 4' Lean-To Kit (64LTKM)
7' x 5' Lean-To Kit (75LTKM)
8' x 6' Lean-To Kit (86LTKM)
CHECK YOU HAVE ALL YOUR PARTS.
(The parts do not have codes on them. They are listed above should you need
to order one.)
TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
