Solid Body Elevator
SBE-1250
Operating Instructions
Original Operating Instructions
Solid Body Elevator SBE-1250, VES-SBE-1250
P/N Type Load Rating Range
691250-Z-BC SBE-1250 1250 5“ - 12.3/4“
691250-Z-VES-1 VES-1-SBE-1250 1250 5“ - 8.5/8“
691250-Z-VES-2 VES-2-SBE-1250 1250 8.3/4” - 9.5/8”
691250-Z-VES-3 VES-3-SBE-1250 1250 9.7/8” - 12.3/4”
Fig. 1: Illustration Example VES-SBE-1250

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
2
Revision history
Version Date Author Changes
00 2012-06 B+V OT, ROK Device changes added
01 2013-01 B+V OT, ROK PN changes added
02 2013- 02 B+V OT, ROK PN changes added
03 2015 -11 Forum B + V OT, ROK Company Name Change, Layout Change, Update
04 2018-07 Forum B + V OT, St.S Layout Change
Document Approval
Version Author Eng. Check Appoval Check
04 FORUM Handling Tools
St.S 07-2018
FORUM Handling Tools
as per revision 03
FORUM Handling Tools
as per revision 03
The copyright protection claimed includes all forms and
matters of copyrighted material and information now
allowed by statutory or judicial law or hereinafter granted.
All product names and product numbers mentioned in this
publication are trademarks of
FORUM ENERGY TECHNOLOGIES, INC.
Other company brands and product names may be
trademarks or registered trademarks of the respective
companies and are also acknowledged.
All data in this manual takes place using best knowledge. This peration maintenance manual is based on the latest
product information that was available at the time of printing. Depending on ongoing technical improvements (ISO
9001), FORUM Handling Tools reserves the right to make alterations to the design and specifications without notice.
The values specified in this manual represent the nominal value of a unit produced in series. The values in individual units
may have slight differences. Only with written consent from FORUM Handling Tools may the contents of this instruction
manual be passed on to third persons. Procedure descriptions and explanations are not to be passed on to third
persons.Copying or multiplying for internal use is permitted.We are grateful for suggestions and critique regarding this
documentation or the product itself.
[e-mail]

OperationMaintenanceManual
11-2015 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 3
DESCRIPTIONSAFETYTRANSPORT
COMISSIONING /
OPERATION
INSPECTION /
MAINTENANCE SERVICESTORAGEAPPENDIX
Table of contents
A. GENERAL 5
I Intended Use 5
II Improper Use 5
III potentIal mIsUse 6
IV Warranty and lIabIlIty 6
V oblIgatIons of the operatIng Company 7
VI User groUps 8
VII safety symbols 9
VIII personal proteCtIVe eqUIpment (ppe) 10
IX ConformIty 11
X ContaCt forUm handlIng tools WorldWIde 11
XI onlIne teChnICal doCUment aCCess 12
a. InformatIon vIa homepage 12
b. InformatIon vIa extranet 13
1 DESCRIPTION 8
1.1 general 8
1.2 maIn assembly sbe-1250 and Ves-sbe-1250 8
1.3 teChnICal data 8
1.4 maIn dImensIons 9
1.5 solId body eleVaVes-sbe-1250or bUshIng type (9) sIze Components 9
1.6 bore Codes 10
1.7 optIonal aCCesorIes 10
1.8 operatIonal enVIronment 11
1.9 eqUIpment markIngs 11
2 SAFETY 12
2.1 general safety preCaUtIons 12
2.2 safety preCaUtIons 12
2.2.1 WarnIng SIgnS 12
2.2.2 WarnIng and Safety SIgnS on SolId body elevator 13
2.3 safety preCaUtIons for proteCtIon agaInst remaInIng hazards 14
2.4 hUman error 15
2.5 organIzatIonal measUres 15
2.6 aCCIdents, fIre 15
3 TRANSPORT / SETUP 14
3.1 delIVery 14
3.1.1 Scope of delIvery 14
3.1.2 UnpackIng and dISpoSal of packIng materIal 14
3.1.3 IntermedIate Storage 14
3.2 transport 15
3.3 lIftIng arrangements 16
3.3.1 SolId body elevator lIftIng arrangement 16
3.3.2 lIftIng arrangement for bUShIng SegmentS 16
3.3.3 lIftIng arrangement for bUShIng SegmentS 16
3.3.4 lIftIng arrangement for bUShIng SegmentS 16
3.4 setUp 17
3.5 InstallatIon CheCklIst 18
4 OPERATIONS 20
4.1 operatIon 20
4.2 pICk Up apIpe 20
4.3 InstallatIons proCedUre sbe-1250 21
4.4 InstallatIons proCedUre Ves-sbe-1250 22
4.5 InstallatIons proCedUre lIftIng tool 24
5 SERVICE 26
5.1 malfUnCtIon 26
5.2 repaIr 26
5.2.1 repaIr by cUStomer 26
5.2.2 repaIr by manUfactUrer 26
5.2.3 SecUrIng ScreWS WIth nord lock WaSherS 26
5.3 draWIng, parts break doWn and spare parts 27
5.3.1 veS-1-Sbe-1250, veS-2-Sbe-1250, veS-2-Sbe-1250 28
5.3.2 Sbe-1250 29
5.3.3 bUShIng aSSembly 30
5.3.4 lIftIng aSSembly 31
5.3.5 lIftIng tool 32
5.4 spare parts 33
5.4.1 691250-rSp Spare partS lISt for Sbe-1250 (1 year operatIon) 33
5.4.2 691250-veS-rSp Spare partS lISt for veS-Sbe-1250 (1 year operatIon) 33

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
4
GENERAL
6 INSPECTION / MAINTENANCE 36
6.1 lUbrICatIon 37
6.2 CleanIng 37
6.3 InspeCtIons 38
6.3.1 InSpectIon folloWIng crItIcal loadS 38
6.3.2 InSpectIon folloWIng removal 38
6.4 InspeCtIon CategorIes 39
6.4.1 InSpectIon category I 39
6.4.2 InSpectIon category II 39
6.4.3 InSpectIon category III 39
6.4.4 InSpectIon category Iv 39
6.4.5 InSpectIon IntervalS Und InSpectIon taSkS - SolId body elevator 39
6.4.6 InSpectIon checklISt 40
6.5 mInImUm ear dImensIons 41
6.6 CrItICal areas 41
8 STORAGE / DISPOSAL 44
8.1 storage of the entIre eqUIpment 44
8.2 dIsposal 45
8 APPENDIX 48
a. sample of eC deClaratIon 49
b. thIrd party doCUments 50
I Safety data-Sheet 50
II componentS 51

OperationMaintenanceManual
11-2015 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 5
GENERAL
A. General
This operation manual (hereinafter called OMM) refers to
the Solid Body Elevator (hereinafter called SBE-1250 and
VES-SBE-1250) from FORUM Handling Tools for use on oil
drilling platforms and rigs.
This OMM covers several FORUM Handling Tools models
from the Solid Body Elevator Type Series.
When installed in potentially explosive atmospheres, the
instructions that follow the Ex symbol must be followed.
Personal injury and/or damages to the Solid Body Elevator
may occur, if these instructions are not followed.
This OMM is intended for the operator of the
Solid Body Elevator. It is intended to ensure safe operation
and must be read carefully and kept where it is accessible
for Solid Body Elevator users at all times.
This OMM contains all information on safe and proper
operation of the Solid Body Elevator. Observance of these
instructions is required for safe operation.
In addition, it is necessary to observe all applicable national
and local regulations [e.g. accident prevention regulations
and environmental regulations] as well as the company’s
own internal safety regulations.
For installation, maintenance and repair work and proper
training of the operating personnel, Forum recommends
requesting service from FORUM Handling Tools itself.
I Intended Use
The Solid Body Elevator is designed to be used vertically in
hanging Elevator-Links. The Solid Body Elevator handles 5”
to 12.3/4” square shoulder pipe strings with a weight up to
1250 ton. The load capacity of the Solid Body Elevator is
imited to 1250 tons. The load capacity is limited in vertical
direction only.
In addition to observing all instructions in this OMM,
intended use also includes observing all prescribed
assembly, disassembly, startup, operating, repair and
maintenance work at the specified intervals as well as all
safety precautions.
The operation of the Solid Body Elevator is allowed for the
intended use only. The FORUM Handling Tools SBE-1250 is
designed in accordance with the latest version of the API
8C.
INFO
The abbreviation tand the word tons, which
are used in this OMM, describe short tons. If the
metric ton is referred it will explicit be named in the
text or the abbreviation ton.
1 sh ton = 2000 lb = 907,19 kg
1 metric ton = 2204,62 lb = 1000 kg
II Improper Use
INFO
Improper use of the Solid Body Elevator releases
FORUM Handling Tools from any liability for
personal injury or property damage resulting
therefrom.
The Solid Body Elevator is intended exclusively for lifting
and holding the specified pipes. Always observe the
specifications („1.3 Technical Data“ on page 8).
The following is specifically prohibited:
- Holding pipe with diameter for which use is not
specified.
- Exceeding the load rating/limit of the
Solid Body Elevator.
- Any use of the Solid Body Elevator which is not
intended.
Moreover, operation of the SBE-1250 is prohibited under
the following conditions:
- When the Solid Body Elevator is used for applications
other than intended.
- When the Solid Body Elevator or parts thereof are
damaged or when additional equipment is not installed
properly.
- When protective or safety equipment is damaged,
unusable, improperly installed or not present.
- When the Solid Body Elevator is not operating properly.
- When humans or foreign objects are located in the
hazard area of the Solid Body Elevator.
- When conversions or modifications have been
performed without previous, written approval by
FORUM Handling Tools.
- When equipment not approved by
FORUM Handling Tools are used.
- When the prescribed maintenance intervals have been
exceeded.
- When replacement parts not approved by
FORUM Handling Tools are used.
- When repair or service work has been performed on
the Solid Body Elevator by companies not authorized by
FORUM Handling Tools.
Observe also the section „IV Warranty and Liability“.

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
6
GENERAL
III Potential Misuse
This OMM contains information and warnings on
procedures that address hazardous conditions and could
cause personal injury but cannot reflect all fashions
in which hazardous consequences may occur due
to service and/or operation. All personnel using the
Solid Body Elevator or service procedures contained within
this OMM must be completely satisfied that personal and/
or Solid Body Elevator safety will not be compromised.
Common methods of MISUSE include but are not
limited to:
1. Use without ALL warning and identification labels
present. This can cause operating personnel to
misunderstand the areas of the Solid Body Elevator
that can cause serious injury.
2. Use with insufficient and/or worn assemblies and
parts. This can cause failure causing a suspended
hazard which can result in serious injury or death.
3. Use of the Solid Body Elevator in methods not
intended. The Solid Body Elevator should be used
ONLY in the methods described in this OMM.
IV Warranty and Liability
Liability
The technical information, data and instructions for
operation contained in this OMM correspond to the status
at the time of print and are provided according to the
best of our knowledge in consideration of our previous
experience and know-how.
We reserve all rights to make technical modifications
within the scope of technical development of the
Solid Body Elevator treated in this OMM. Claims or
entitlements cannot be deduced or derived from
information, illustrations and /or descriptions in this OMM.
FORUM Handling Tools is liable for all warranty obligations
made within the scope of the contract for any faults or
omissions on our part, excluding further claims. Claims
for damages suffered are excluded regardless of the legal
grounds.
Translations are complete according to best knowledge.
We cannot assume any liability for translation errors, even
when the translation was performed at our order.
Only the original text is binding. The original text language
for FORUM Handling Tools documents and OMM is
English.
The descriptions and illustrations do not necessarily reflect
the scope of delivery or any parts orders. The drawings
and illustrations are not to scale.
Warranty
FORUM Handling Tools general terms of purchase and
delivery apply. Purchasers recognize these conditions on
the day the contract is signed, at the latest.
The terms and duration of FORUM Handling Tools
warranty are specified in the sales documents as well as
the order confirmation. These will be submitted to the
operating company as information at the time the contract
is signed, at the latest.
The manufacturer assumes no warranty whatsoever for
damage or interruptions in operation resulting from failure
to observe the operating instructions.
The OMM is to be supplemented by the operating
company with operating instructions based on existing
national regulations on accident and environmental
protection, including information on supervisory and
reporting obligations taking into consideration operating
peculiarities, e.g. in regard to work organization.
Warranty claims/complaints within the scope of the
guarantee and liability for personal injury and property
damage are excluded, when such result from any of the
following causes:
- Any use other than intended;
- Improper installation, operation, maintenance or repair;
- Operation with defective, improperly attached or non-
operational safety and/or protective equipment;
- Failure to observe the instructions in the operating
manual regarding safe conduct;
- Impermissible structural and/or functional
modifications;
- Use of replacement parts not approved by
FORUM Handling Tools;
- Normal wear or insufficient inspection of components
subject to wear;
- External effects or force majeure;
- Lubricating the Solid Body Elevator with lubricants other
than those recommended by FORUM Handling Tools.
Info
Any structural or functional modification
to the Solid Body Elevator by the operating
company requires previous written approval
by FORUM Handling Tools. Failure to obtain
such approval voids the warranty as well as
the declaration of conformity and releases
FORUM Handling Tools from any product
liability. Following modifications or installation of
optional equipment, all safety equipment must
be reinstalled and checked by the operator for
proper function.

OperationMaintenanceManual
11-2015 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 7
GENERAL
V Obligations of the Operating Company
Planning and Checking Safety Measures
The obligation of the operating company to due diligence
includes planning safety measures and supervising their
observance. All personnel performing work on and with
the Solid Body Elevator must be trained by the operating
company for the work performed on and with the
Solid Body Elevator All personnel must have read and
understood the OMM.
Minimizing Risk of Injury
The following principles apply to minimize the risk of
injury:
• Ensure that work on the Solid Body Elevator is
performed only by qualified personnel.
• The personnel must be authorized for such work by the
operating company.
• The personnel must wear the prescribed protective
equipment.
• Procedures, competencies and responsibilities must
be clearly defined and established in the area of the
Solid Body Elevator. Proper behavior in the event of a
malfunction must be clear for everyone. The personnel
must be given regular training.
• All WARNING signs and information on the
Solid Body Elevator must be complete and easily legible.
For this purpose WARNING signs and information are
to be cleaned regularly and replaced as required.
Trouble-free Operation
The following principles apply for trouble-free operation:
• Keep the complete OMM at the location where
the Solid Body Elevator is in operation where it is
easily accessible for everyone and in an easily legible
condition.
• Use the Solid Body Elevator exclusively for its intended
purpose.
• Use the Solid Body Elevator only when it is in a perfect
operating state.
• Before starting work, check to ensure that it is in a safe
operating state and functioning properly.
Requirements for Operator
Basic knowledge of safe handling and use of the
Solid Body Elevator includes knowledge of the general
safety precautions. Ensure that the Solid Body Elevator
is operated only in compliance with the general safety
precautions and other instructions in this OMM.
Training
The operating company is obligated to organize and hold
regular training to ensure that all personnel involved with
transporting, installing, operating and/or servicing the
Solid Body Elevator is familiar with the required procedures
and safety precautions.
Minimum Qualifications
All work on the Solid Body Elevator requires special
knowledge and qualifications on the part of the operating
personnel. All personnel working on Solid Body Elevator
must have the following qualifications:
- Personal suitability for the work performed.
- Suitable qualifications for the work performed.
- Familiarity with the safety equipment and its function.
- Familiarity with this operating manual – particularly the
safety precautions – and all sections relevant for the
work to be performed.
- Familiarity with the elementary instructions on
operating safety and accident prevention.
In general, all employees must have one of the following
minimum qualifications:
- Technical training for independent work on the
Solid Body Elevator.
- Sufficient qualifications for working on the
Solid Body Elevator under supervision and at the
instructions of a trained specialist.

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
8
GENERAL
VI User Groups
This OMM is subdivided into the following user groups:
Personnel Personnel
Operating personnel
Sufficiently trained in:
- Functional procedures on the SBE-1250.
- Operating procedures.
Knowledge:
- Competency and responsibility in regard to the work to be performed.
- Behavior in emergencies.
Service personnel
Basic knowledge of:
- Mechanics.
Authorizations (according to standards of safety engineering):
- Starting up SBE-1250.
- Grounding SBE-1250.
- Marking of SBE-1250.
- Basic knowledge of installation and operation of the SBE-1250.
Special Technical Knowledge
The following work should be performed only by specially trained personnel:
Work Performed Qualifications
Work on mechanical parts
Personnel qualified or trained in industrial mechanics; work is to be
performed only under supervision and on instructions of a person
qualified in accordance with generally accepted codes of practice in
industrial mechanics.

OperationMaintenanceManual
11-2015 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 9
GENERAL
VII Safety Symbols
The safety precautions in this OMM contain standardized
depictions and symbols. Four hazard classes are
distinguished depending on the probability of occurrence
and severity of the consequences. Selection of the
WARNING category depends on the probability of
occurrence and the possible extent of damage.
CAUTION
Indication of recognizable hazard for
humans or possible property damage.
Failure to observe can lead to
reversible injuries or property
damage!
The symbol as specified in ANSI Z535.6
emphasizes the cause.
Measures for avoiding are listed.
WARNING
Indication of recognizable hazard for
humans.
Failure to observe can lead to
irreversible injuries!
The symbol as specified in ANSI Z535.6
emphasizes the cause.
Measures for avoiding are listed.
DANGER
Indication of imminent hazard for
humans.
Failure to observe can lead to
irreversible or lethal injuries!
The symbol as specified in ANSI Z535.6
emphasizes the cause.
Measures for avoiding are listed.
Preliminary Safety Precautions
Safety precautions are given in the preceding form at the
beginning of complete sections or sections. They apply for
the entire section or the entire subsequent section.
Safety Precautions Relevant for Action
If a safety precaution applies only for one single action
or a short series of actions, it is integrated into the text
preceding the possible hazard point.
For example:
1. Attach hoisting gear to eye bolts in cover.
CAUTION of pinching/crushing hands! The cover can
fall shut when the retainer is not engaged. Never open the
cover by hand.
2. Open the cover with a crane and suitable hoisting
gear.
3. Unscrew the M10 bolts with a 17 mm box wrench.
4. ...
Instructions for Safe Procedure
Special work steps to ensure Safe Procedure are depicted
as follows (example):
Safe Procedure
1. Shut off Equipment.
2. Disconnect supply lines.
3. Attach Equipment to crane.
4. ...

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
10
GENERAL
Linguistic Conventions
This OMM uses terms and symbols intended to help you
find information more easily, perform work steps more
effectively and recognize dangerous situations more
quickly. These symbols and terms are explained below:
All important text sections are printed in bold face.
- Lists without any necessary sequence are marked with
a dash (-) at the left side of the column.
• Individual activities to be performed are indicated by a
dot (•) to the left of the column.
Relevant consequences of an action or work step are
marked with an arrow (») in the left margin.
Enumerations in a certain sequence (e.g. a series of work
steps) are indicated by sequential numbers (1, 2, 3,...) in the
left margin.
For example:
1. Unscrew nuts on machine feet.
2. Lift quipment
3. ...
For greater clarity the illustrations are located in the
right column with the text opposite or directly below
the associated text section. Larger illustrations extending
over the entire width of the page are located before
the explanatory text. The illustrations are provided with
captions in telegraph style.
Fig. 2: Illustration Example SBE-1250
INFO
Additional information and relationships requiring
special attention are distinguished in this manner.
VIII Personal Protective Equipment (PPE)
The following symbols located at appropriate points in
this OMM indicate that it is mandatory to wear personal
protective equipment:
WEAR PROTECTIVE GLOVES!
WEAR EYE PROTECTION!
WEAR SAFETY SHOES!
WEAR PROTECTIVE HELMET!
WEAR EAR PROTECTION!

OperationMaintenanceManual
11-2015 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 11
GENERAL
IX Conformity
The SBE-1250 satisfies all requirements in applicable
directives and standards. A sample of the EC Declaration
of Conformity is given in the appendix.
INFO
This OMM is a part of the technical
documentation for the Solid Body Elevator.
The EC Declaration of Conformity is delivered
together with the Solid Body Elevator. Keep these
instructions and the associated documents for
later use.
X Contact FORUM Handling Tools worldwide
In the event of problems that cannot be solved with the
aid of this OMM, please contact one of the following
addresses.
FORUM B + V Oil Tools GmbH FORUM Handling Tools
Hermann-Blohm-Straße 2
20457 Hamburg
Germany
Tel: + 49.40.37022.6855
Fax: + 49.40.37022.6899
1023 FORUM Drive
Broussard, LA 70518 USA
Tel: [phone]
Fax: [phone]
E-Mail: [e-mail]
web: www.f-e-t.com
www.blohmvoss-oiltools.com
FORUM ENERGY TECHNOLOGIES Drilling-Service-Standorte
Email: [e-mail]
Canada Mexico Scottland
Nr. 106, 3903 - 75 Ave
Leduc, Alberta T9E 0K3
Tel: + 1 780.980.0345
Fax: + 1 780.986.3278
Avenida Avante Monterrey N 300
Parque Industrialxico
Tel: + 52.81.8245.6800
Peregrine Road, Westhill
Aberdeenshire, AB32 6JL
Tel: + 44,1224.744000
United Arabic Emirates Singapore
Oilfields Supply Center
Building B-45
Jebel Ali Free Zone Dubai UAE
Tel: + 971.4.883.5266
No 51 Benoi Road #06-00
Liang Huat Industrial Complex
629908
Tel: + 65.6465.4850
Fax: + 65.6465.4851
Out of hours
+ 65.913.898.12

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
12
GENERAL
XI Online Technical Document access
a. Information via homepage
INFO
For further and actual information you can also
visit our homepage in the Internet.
A digital version of the OMM as well as the operation
instructions, safety- and update notes for other
FORUM Handling Tools products can be reached via
the blohmvoss-oiltools homepage. To join our Internet
Technical Documentation service with the latest updates
on new technical documentation in a free and easy way,
you must register to our service with your email-address
and name in the customer-login area qon
www.blohmvoss-oiltools.com.
Fig. 3: Illustration Service–Homepage
q

OperationMaintenanceManual
11-2015 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 13
GENERAL
b. Information via Extranet
INFO
For further and actual information you can also
visit our Extranet homepage .
A digital version of the OMM as well as the operation
instructions, safety – and update notes for other
FORUM Handling Tools products can be reached via the
Extranet. To join our Internet Technical Documentation
service with the latest updates on new technical
documentation in a free and easy way, you must register
to our service with your email-address and name in the
customer-login q area on
https://www.accessoiltools.com/fx/.
Fig. 4: Illustration Service–Extranet
q

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 11-2015
14
[This] page [is] intentionally left blank.

OperationMaintenanceManual
07-2018 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 7
DESCRIPTION
DESCRIPTION

1 DESCRIPTION
1.1 General
The Solid Body Elevator SBE is designed for handling riser
runnig tools with either fixed or detachable couplings. A
solid forged design with highest strength material allows
loads up to 1250 tons.
Features
• Pipe rage from 5" to 12.3/4".
• Other size upon request.
• SBE with fixed bore code.
• VES-SBE bushing system for RRT with detachable
couplings.
• Manufactured according to API 8C PSL2.
1.2 Main Assembly SBE-1250
and VES-SBE-1250
Fig. 5: SBE-1250 Fig. 6: VES-SBE-1250
Pos. Description Pos. Description
qBody wLink Block
eBushing Assembly
1.3 Technical Data
Type P/N Rated
Capacity Range Weight*** [lbs/kg] Link size Temperature working range
SBE-1250 691250-Z-BC** 1250 tons 5" - 12.3⁄4" 4012 / 1820 1000 - 1250 tons - 40° C to + 60° C
- 40° F to + 140° F
VES-1-SBE-1250* 691250-Z-VES-1 1250 tons 5" - 8.1⁄2" 3549 / 1610 1000 - 1250 tons - 40° C to + 60° C
- 40° F to + 140° F
VES-2-SBE-1250* 691250-Z-VES-2 1250 tons 8.3⁄4" - 9.5⁄8" 3417 / 1550 1000 - 1250 tons - 40° C to + 60° C
- 40° F to + 140° F
VES-3-SBE-1250* 691250-Z-VES-3 1250 tons 12.3⁄4" 3274 / 1485 1000 - 1250 tons - 40° C to + 60° C
- 40° F to + 140° F
*Variable Elevator System with interchangeable Bushing System.
** BC = Bore Code.
*** Weight without Bushings.
qq
w
e
w
OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 07-2018
8
DESCRIPTION

1.4 Main Dimensions
Fig. 7: SBE-1250 and VES-SBE-1250 Main Dimensions
Part number A
[mm/inch]
B
[mm/inch]
C
[mm/inch]
D
[mm/inch]
691250-Z-BC 600 / 23.62 750 / 29.53 1282 / 50.47 900 / 35.43
691250-Z-VES-1 600 / 23.62 750 / 29.53 1282 / 50.47 900 / 35.43
691250-Z-VES-2 600 / 23.62 750 / 29.53 1282 / 50.47 900 / 35.43
691250-Z-VES-3 600 / 23.62 750 / 29.53 1282 / 50.47 900 / 35.43
1.5 Solid Body Elevator Bushing Type (VES-SBE-1250) Size Components
Solid Body Elevator Size P/N
VES-1-SBE-1250
6.5/8"691253-1-531
7" 691253-1-530
8" 691253-1-532
8.1/2"691253-1-533
8.5/8"691253-1-534
VES-2-SBE-1250
8.3/4"691253-2-534
9.29" 691253-2-537
9.40" 691253-2-539
9.5/8"691253-2-538
VES-3-SBE-1250 12.3/4"691253-2-543
OperationMaintenanceManual
07-2018 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 9
DESCRIPTION

1.6 Bore codes
P/N Pipe Size O.D. Weight
[kg] [lbs]
691250-Z-223 5'' csg 1606 3541
691250-Z-224 5.1⁄2'' csg 1600 3527
691250-Z-225 5.3⁄4" csg 1597 3521
691250-Z-226 6" csg 1594 3514
691250-Z-227 6.1⁄4" csg 1591 3508
691250-Z-228 6.5⁄8" csg 1585 3494
691250-Z-229 7" csg 1578 3479
691250-Z-230 7.1⁄4" csg 1575 3472
691250-Z-231 7.5⁄8" csg 1567 3455
691250-Z-232 8" csg 1560 3439
691250-Z-233 8.1⁄4" csg 1555 3428
691250-Z-234 8.5⁄8" csg 1546 3408
691250-Z-235 9" csg 1537 3389
691250-Z-236 9.5⁄8" csg 1520 3351
691250-Z-237 10" csg 1509 3327
691250-Z-238 10.3⁄4" csg 1484 3272
691250-Z-239 11.3⁄4" csg 1447 3190
691250-Z-240 12" csg 1437 3168
691250-Z-241 12.3⁄4" csg 1404 3095
691250-Z-262 11.7⁄8'' csg 1442 3179
691250-Z-263 8.3⁄4'' csg 1544 3404
691250-Z-265 9.7⁄8'' csg 1513 3336
691250-Z-266 8.1⁄8'' csg 1557 3433
691250-Z-268 5.723'' csg 1599 3525
691250-Z-269 7.3⁄4'' csg 1565 3450
691250-Z-312 9.3/8'' csg 1528 3369
691250-Z-402 7.5⁄8'' & 7.3⁄4'' csg 1565 3450
691250-Z-409 10.3⁄8'' csg 1496 3298
691250-Z-412 11'' c sg 1476 3254
691250-Z-415 7.1⁄2'' csg 1564 3448
691250-Z-538 9.5⁄8" RRT 1520 3351
691250-Z-540 9.5⁄8” RRT 1520 3351
1.7 Optional Accesories
Lifting Tool PN 691260-BC
Lifting Tool for easy transport and storage of the
Solid Body Elevator.
Fig. 8: Lifting Tool
OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 07-2018
10
DESCRIPTION

1.8 Operational Environment
The Solid Body Elevator is designed and constructed for
use in the drilling industry on ships and platforms. The
Solid Body Elevator complies with the Machinery Directive
2006 / 42 / EC.
The Solid Body Elevator is approved for operation in
explosion hazard areas. For equipment containing any
hydraulic powered parts, the directive 2014 / 34 / EU
“Equipment and protective systems in potentially explosive
atmospheres” applies. The corresponding ATEX certificates
are present in the Data book.
The Classification according to CE
(with reference to the ATEX guideline) is as followed:
III 2G IIB T6, for manual tools
with
CE- marking (with reference to the ATEX guideline)
Marking of the equipment for the Ex- range
II Equipment Group (II)
2 Equipment Category
G For explosive mixtures of air and combustible gases,
mists or vapors (G)
IIB Categorie for Gases
T5 / T6 Temperature class
1.9 Equipment Markings
The markings are generally used for traceability and
provide general information about the component/
equipment. All markings are in compliance to the latest API
8C and at least include the following information:
General Markings according to API 8C
• API Stamp (API monogram, spec, license).
• Manufacturer’s specifications (FORUM logo).
• Production Date (Month / Year).
• Part number (marking P/N before the part number).
• Serial number (marking S/N before the serial number).
• Load Rating.
• Equipment weight.
• CE-ATEX marking ( II 2G IIB T5 / T6).
• Country of manufacture.
• The email address of the manufacturer is given on the
support sticker if service is required.
Fig. 9: Contact with Technical Support
Fig. 10: Position of Equipment Markings
OperationMaintenanceManual
07-2018 PN 691250-Z-BC-D - Revision: 04 Solid Body Elevator 11
DESCRIPTION

OperationMaintenanceManual
Solid Body Elevator PN 691250-Z-BC-D - Revision: 04 07-2018
12
[This] page [is] intentionally left blank.
