Forward KBLT0011 User manual

Issue 1 - 16/07/20
Smart Desk
Product Refs-KBLT0011/KBLT0012/KBLT0013/KBLT0014
Assembly Instrucons
Imported By: Forward Industries, 33401. U.S.A

110lbs.
1

Desk top Qty 1 Underframe Qty 1
2
(KBLT0011/KBLT0012: 47.2*23.6*0.48")
(KBLT0013/KBLT0014: 47.2*23.6*0.24")
Feet Qty 2
(23.2*2.7")
Power Adaptor Qty 1
(122")
(45.2*26.7*3.2")

M6 Screw Qty 8 (M6*0.63")
3M Cable Clip Qty 2
(0.69*2.56”)
M8 Screw Qty 8 (M8*0.79") Allen Key 5*5 Qty 1
(0.2*0.2*3.15”)
If you have questions regarding the operation of your purchase, or in the unlikely event
you need to return the unit because it is faulty or is no longer wanted, please contact our
product returns department at [email protected], or 561-465-0030,
Option 0.
Address: Forward Industries, 105 South Narcissus Avenue Suite 412, West Palm Beach,
FL 33401
3

Assemble underframe
to top using
fixings .
Underside
Shown upside down
4
STEP 1
5x5 Qty 1
M8 Screw Qty 8
Assemble feet to
legs using fixings .
Note: Ensure the longer
secons of the feet are
located at the front as
shown.
STEP 2
Front
Back
5x5 Qty 1
M6 Screw Qty 8

5
Connect the Cables
STEP 3
Adaptor
Control Box
Adaptor
Power
Control Box
Fixed
Route cables through cable tidy clip .
Cable Clip

6
With help, carefully
turn the desk over into
it’s final locaon and
connect to a power
source.
STEP 4

Use the or keys to set the desired standing posion height.
Press memory keys and hold for 3 seconds.
The standing posion height will now be pre-set.
To select the preset standing posion height in the future, press memory keys and release. The desk top will adjust
to the pre-set height.
Height Adjustment/Controls
Key buon
7
LED Screen
UP/DOWN Keys
Memory Keys USB Charging Port
Type C Charging Port
Child Lock
To raise the desk height, press and hold the key for 1.2 seconds and release, it will rise automacally. Press it again
unl the desired height is reached. The screen will show "top" when the desktop reaches its highest point.
To lower the desk height, press and hold the key for 1.2 seconds and release, it will go down automacally. Press it
again unl the desired height is reached. The screen will show "bot" when the desktop reaches its lowest point.
Short press the key or key, to make small adjustments to the height.
Up and DOWN Funcon
The desk has two USB and one type-C ports. They can supply power to other electronic devices. Each port provides
output power 18W. While the desktop is moving, there will be no output power.
USB & Type C Charging
Press “Lock” keys to achieve the child lock funcon, so as to avoid accidentally touch and guarantee the safety of
children; The child lock buon is switchable, screen will show”Loc” when the desk is locked.
Child Lock
Press the “up” and “down” keys simultaneously to change sensivity level. When the screen show”A-0”, it means the
an-collision is off; “A-1” means an-collision sensivity is in level 1; “A-2” means an-collision sensivity is in level
2; “A-3” means an-collision sensivity is in level 3, Level 3 is the most sensive.
An-Collision
Standing:
Programme Preset Height (Standing/Seated)
Use the or keys to set the desired seang posion height.
Press memory keys and hold for 3 seconds.
The seang posion height will now be pre-set.
To select the preset seated posion height in the future, press memory keys and release. The desk top will adjust
to the pre-set height.
Seated:

FCC Statement
This device complies with Part 15 of the FCC Rules. Operaon is subject to the following two condions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operaon.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in a parcular installaon. If this
equipment does cause harmful interference to radio or television recepon, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
▪ Reorient or relocate the receiving antenna.
▪ Increase the separaon between the equipment and receiver.
▪ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
▪ Consult the dealer or an experienced radio/TV technician for help
8
If you have a wireless charging compable device, please put the phone on the wireless charging indicator and check
if the phone is successfully connected to the charging funcon. If not, move the mobile phone near the logo unl the
connecon is successful.
Some phone cases may inhibit the wireless charging funcon or it’s efficiency. It may be necessary to remove the
phone case if difficules are experienced.
Wireless charging will only work with wireless charging compable mobile devices.
Wireless Charging logo
Wireless Charging Function

Important Information
1. Power supply: AC100V-240V, 50/60Hz
2. Service Environment: 0-104°F
3. Unplug the power plug before cleaning, wipe the dust on surface with damp cloth when cleaning. Be careful
not to let water drops into the internal parts, or loose the connector.
4. Check carefully to ensure correct and complete assembly before using.
5. Be familiar with all funcons and program sengs of the product before first use.
6. Don’t allow children to play near the desk as their behavior is unpredictable. The manufacturer is not responsible
for loss, injury, or damage due to those improper acon.
7. The slight noise caused by the internal mechanism or brake system of the structure, will not have any effect on the
use of the equipment.
8. Do not use corrosive or abrasive materials are near the equipment. Please ensure that the cleaner used will not
pollute the environment.
9
a.Reset: Press the 3 and 4 keys simultaneously, the RST reset indicaon will appear. Connue to press the “▼” down
keys unl the liing table lowers to the lowest posion and rebounds to rise to a stop. The display shows the lowest
height “bot”, release “▼” down keys, the reset is over and the table can be used normally.
b.when the table doesn’t work and LED shows” E01” or “E02”, pls retry 18mins later.
c.If the “▼” buon doesn’t work, pls check the cable connecon and then cut off the power for at least 10seconds.
Reconnect the power and press “▼” keys to start and reset process when it shows the “RST”
d.If the above doesn’t resolve the problem, please contact our aer sales team.
Troubleshooting
The following ps will help you detected and eliminate the comman faults and errors. If the fault you met is not listed
below, please contact our aer sales team. Only the manufacturer can invesgate or resolve faults or errors not listed
below.
Fault phenomenon Method Fault phenomenon Method
No response while long pressing
down arrow aer connected with
a power supply
1.Check if all the cables be connected well
2.Contact your supplier or dealer
No response while pressing up
arrow/ down arrow aer
connected with a power supply
1.Check if all the cables be connected well
2.Contact your supplier or dealer
Rising in a low speed
1.Check if overloaded, max loading: 110lbs;
2.Contact your supplier or dealer
The motor not move as instructed 1. Contact your supplier or dealer
1.Reposion
2.Contact your supplier or dealer
Go down but not go up
Downward sliding
2.Contact your supplier or dealer
1.Check if overloaded, max loading: 110lbs;
Frequently Reposion
Overwork
（Duty cycle:Max 2min on/18min OFF）
2.Contact your supplier or dealer
1.Check if overloaded, max loading: 110lbs;
1.Restart aer suspend for 18mins while connecng
with power;
2.Contact your supplier or dealer;
1. Press "M"and "3" together for 3 seconds ormore,
aer hearing connuous beeping for twice,it will
restore factory sengs
Not enough up&down height
2.Contact your supplier or dealer

This marking indicates that this product should not be disposed with other household
wastes. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
To return your used device, please use the return and collecon systems or contact the
retailer where the product was purchased. They can take this product for environmental
safe recycling.
If you have quesons regarding the operaon of your purchase, or in the unlikely event you need to return the
unit because it is faulty or is no longer wanted, please contact our product returns department at
[e-mail], or 561-465-0030, Opon 0.
Address: Forward Industries, 105 South Narcissus Avenue Suite 412, West Palm Beach, FL 33401
9. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilies or lack of experience and knowledge, only aer they have been given supervision or instrucon
concerning use of the appliance in a safe way and understand the hazards involved. Children should not play with the
appliance.
10. Cleaning and user maintenance should not be aempted by children without supervision.
11. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified
person in order to avoid a hazard.
12. Please make sure there is no hazard sources in your operang environment. e.g., do not lier the tools around.
Always be careful to treat the packaging materials in order to avoid any possible danger, e.g. plasc bag may lead to
choking hazard to children.
13. We recommend you keep the original package of the equipment if necessary in case of the future use in
transportaon.
10
