Foscam S41/SPC User manual

1
User
User Manual Manual
Spotlight Camera
Model: S41/SPC
V1.2

2
Table of Contents
1 Overview............................................................................................................................................................................. 3
1.1 Key Features...........................................................................................................................................................3
1.2 Read before Use.................................................................................................................................................... 3
1.3 Packing Contents................................................................................................................................................... 3
1.4 Physical Description.............................................................................................................................................. 4
1.5 SD Card Management...........................................................................................................................................4
1.6 Add Device: Connection via the Foscam App................................................................................................... 5
1.7 Installation............................................................................................................................................................... 5
1.8 Waterproof Lid Installation Guide........................................................................................................................ 6
2 Default Parameters........................................................................................................................................................... 7
3 Specification....................................................................................................................................................................... 7

3
1 Overview
1.1 Key Features
4MP QHD Waterproof IP Camera
H.264+/H.264 video Compression
Supports Human detection&PIR detection
Supports maximum 110dB alarm siren
Compatible with free Foscam Video Management Software
Compatible with free Foscam iOS and Android APP
Support 2.4GHz&5GHz dual-band WiFi
Built-in 2pcs white LED and 2pcs IR LED, has excellent night vision image
Supports WDR(Wide-Dynamic Range)
Supports 256GB Micro SD Card storage(External)
Night Vision Range up to 10m(33 feet)
P2P Feature for Easy Remote Access
Supports image snapshot
Supports dual-stream
Supports remote viewing & record from anywhere anytime
Multi-level users management with password protection
Supports multiple network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
Supports Alexa
Supports Google Assistant
1.2 Read before Use
Please first verify that all contents received are complete according to the Package Contents listed below.
Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup
Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly
as intended.
1.3 Packing Contents
● Camera× 1
● Ethernet Cable× 1
● Quick Setup Guide × 1
● Expansion Screws× 1
● Waterproof Lid × 1
● Surveillance sign× 1
● Power Adapter × 1

4
1.4 Physical Description
Microphone: Built-in Microphone.
Lens: Fixed focus lens.
Spotlight：See full-color images at night with the spotlight on.
LED Indicator：Infrared LED for night vision.
Passive Infrared motion sensor：The Passive Infrared motion sensor is electronic devices which are used in
some security alarm systems to detect motion of an infrared emitting source, usually a human body.
Reset: Press and hold on the reset button for 10 seconds. Releasing the reset button, the password will back
to the factory default administrator password.
Micro SD Card slot: Supports up to 256GB SD card for storing the video.
Speaker: Built-in speaker
Power: AC wiring interface.
LAN:10/100M adaptive Ethernet interface. Through this interface, IP camera can be connected with various
network devices, such as hub, router, etc.
1.5 SD Card Management
This camera supports Micro SD Card.
When you plug in the SD card during the camera work process, please reboot the camera again, or else the
SD card might not work well.
On Foscam app go to the SettingsDevice StatusDevice Status page, you can see the SD card status.

5
1.6 Add Device: Connection via the Foscam App
Scan the QR code below to download and install the Foscam APP.
Please refer to the Quick Setup Guide.
1.7 Installation
Please refer to the Quick Setup Guide.
Point the camera at the desired location and use the screws provided to mount it.
For the best product experience, we suggested installation height of Spotlight camera: 2.2m (7.22 feet),
camera downward tilt angle 30°.
Please Note:
Ensure that rain or water will not reach the connector ports at the end of the pig tail wiring. These connectors
are not weather-resistant.

6
1.8 Waterproof Lid Installation Guide
When mounting your camera outdoors, you are suggested to install the waterproof lid for it. You may follow the
steps for installation.
1. Thread the Ethernet cable through the top cover and then the waterproof connector.
2. Put the rubber seal ring around the Ethernet cable between the top cover and the waterproof connector.
Note: The rubber seal ring provided has been cut. If not, you may manually cut it.
3. Put on the rubber O-ring to the Ethernet port of the camera and plug the Ethernet cable into the Ethernet
port.
4. Align the waterproof connector with the Ethernet port, then twist it clockwise to tighten the two parts.
5. Push the rubber seal ring into the waterproof connector, then screw the top cover and lock it into position
firmly to finish installation.

7
2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
3 Specification
ITEMS
S41/SPC
Spotlight
White LED
The irradiation distance of white light can reach 10m
Color Temperature
6500K
Image Sensor
Sensor Type
High Definition Color CMOS Sensor
Display Resolution
4.0Megapixels(2560*1440)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f.2.8mm; F2.4
Angle of view
Diagonal: 116°, Horizontal: 100°, Vertical: 55°
Video
Image Compression
H.264+/H.264
Image Frame Rate
Max 25fps (4MP)
Resolution
2K(2560*1440) 25fps,1080P(1920x1080) 25fps,720P(1280 x 720)
Flip Image
Flip and mirror
Night Mode
Manual and automatic modes,when the white light is on, the night vision
image is colored
Night Visibility
10m
Audio
Input/Output
Build-in mic and speaker,support full duplex 2-way Audio
Audio Compression
AAC
Siren
Support maximum 110dB alarm siren
PIR
PIR Detection
Built-in 1PCS PIR sensor, detection Angle up to 90°
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b/g/n/ac
Wireless Security
WPA, WPA2
Remote Access
P2P
Wifi configuration Mode
Support scan QR code , sound wave to add camera
Network Protocol
IP, TCP, UDP, SMTP, FTP, RTSP
System
Requirements
Operating System
Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android
(Foscam app), iOS (Foscam app)
Other Features
Light Control
Manual switch or alarm linkage
Motion Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Sound Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected

8
Human Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
PIR Detection
Built in 1pcs PIR Sensor,Supports sensitivity and range adjustment
Privacy Block
Yes
WDR
Improve image clarity in complex scenario
Zoom
6X digital zoom function
Storage
Support max. 256GB Micro SD card, local and FTP storage,Foscam
cloud storage
Cloud
Support cloud storage
LED
Indicator LED
Blue&Red
Power
Power Supply
DC12V/1A
Power Consumption
12Watts (Max.)
Physical
Dimension(LxWxH)
170(L)x75(φ)mm
Net Weight
290g
Environment
Waterproof
IP66
Operating Temperature
-20°C~ 60°C (-4°F ~ 140°F)
Operating Humidity
20% ~ 85% non-condensing
Storage Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
CE, FCC, RoHS,WEEE
For other parts, please refer to the “FOSCAM Camera User Manual”
