FosPower FOSSP-2369 User manual
Waterproof True Wireless Stereo Bluetooth Speaker
Disclaimer Statement:
FosPower shall not be liable to you or anyone else for any loss, injury, hearing damage for any damage relating to this
product. FosPower is not liable for any damage or destruction to consumer electronics devices or other personal property
that are contained inside or outside the FosPower product, including, without limitation, laptops, cellular phones, or other
handheld devices, or any loss of data contained in the foregoing devices.
Thank you for purchasing this FosPower product. For optimum performance and safety, please read these instructions
carefully before connecting, operating or using this product. Please keep this for future reference.
FosPower Waterproof True Wireless Stereo Bluetooth Speaker is a portable speaker that produces great sound out of a little
package. This device can be used indoor and outdoor. It is also waterproof, allowing you to use it while swimming, bathing,
and more.
Package Includes:
1x Bluetooth Speaker
1x Micro-USB Cable
1x Metal Carabiner
1X Quick Start Guide
Specications:
Bluetooth Version V4.2
Rated Power
Waterproof Rating
Battery Capacity
Power Supply
Frequency Response
Receiving Range
Driver Unit
Charging Port
5W(RMS)
IPX7
900mAh L-ion
DC 5V/1A
115Hz-15KH
≤30M
4Ω5W/53mm
Micro-USB
Play Time Up to 10 Hours
Charge Time 3 Hours
Product Diagram:
Microphone
LED Indicator
Volume Up/
Next Song
Play/Pause
Pick Up/Hang Up Call
Volume Down
Previous Song
On/O/Pair
Buttons/Controls:
(Please note, it is recommended to fully close
back panel ap for waterproof eectiveness)
Back Panel
Micro SD Card Slot
Charging Port
Power On/O
1. Press and hold On/O button to power on/o
the speaker.
Bluetooth Pairing
1. Turn on speaker (LED will ash blue)
2. Go to Bluetooth settings on your device
3. Locate device FOSSP-2369 and select to pair
4. When pairing is successful you will hear a sound and
the LED will stay solid blue
Pairing two FOSSP-2369 speakers together (TWS mode)
1. Disconnect Bluetooth speaker from device and power speakers o
2. Power on both speakers and double click the On/O button
3. The two speakers will begin to search for each other and should pair
automatically under the TWS mode.
4. While in TWS Mode, you can use commands on either speaker to toggle
functionality for both.
5. To disable TWS Mode, double click the On/O button.
“-“ Button
1. Press once to turn volume down (one level of 16-level volume)
2. Press and hold for 1 second to play previous song
“+” Button
1. Press one to turn volume up (one level of 16-level volume)
2. Press and hold for 1 second to play next song
Play/Pause Button
1. Press once
a. Play/Pause music
b. Connect to incoming phone call
c. Hang up phone call
d. Press twice to redial previous phone number
2. Press and hold
a. While in play mode: press and hold for two seconds to reset factory default and clear pairing settings.
b. While on a phone call: press and hold to reject incoming call
NOTE: Compatible with Amazon Alexa and Google Home Bluetooth functionality.
Charging Port:
1. It is recommended to turn o speaker before charging.
(SAFETY GUIDELINES: Charging while in use could potentially reduce the battery life, cause the battery to charge at a slower
rate, and cause the device to heat up.)
2. Connect the micro USB side of the supplied cable into the charging port, and the USB side into any USB charger.
3. LED light will change to RED when charging, when the speaker is fully charged the LED will turn o automatically.
Micro SD Card Slot:
1. Supports up to 64GB TF card, and WMA/WAV/MP3 formats
2. Place micro SD card into slot, audio les will begin playing automatically.
CAUTION!
The Federal Communications Commission warns the user that changes or modications to the unit not expressly approved
by the party responsible for compliance could void the user’s authority to operate the equipment.
Follow Us On Social Media
www.fospower.com
support@fospower.com
© 2018 FosPower Inc. All rights reserved.
Limited Lifetime Warranty
This FosPower product includes a limited lifetime warranty. Please
visit our FosPower website for more details.
Recycling the Product
FCC Information
To dispose this product, please follow the recycling process regulated in your area.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
DO NOT RETURN THE PRODUCT
There are good days and there are bad days. It is our BAD if the product is
not working, or if you are not happy with it. PLEASE GIVE US A CHANCE
and WE WILL MAKE IT RIGHT.
Contact us:
(651) 389-4432
support@FosPower.com
