Current audio Oc8 Troubleshooting guide

The dual purpose OC8 Indoor/Outdoor speaker is the perfect

choice for either main listening or sound reinforcement

applications. This ported bass reflex speaker supplies

serious sound.

The 8”graphite mica mineral impregnated polypropylene

woofer cone and butyl rubber surround are virtually

impervious to the weather and insects. It delivers shock and

awe. The 1”titanium tweeter presents clear crisp high

frequencies to complement the hard driving bass.

The OC8 can also be utilized as a stand alone subwoofer

with or without an equalizer. In this function the OC8 can be

employed to launch deep bass into the listening area further

enhancing the sound quality of your system.

This speaker color is offered is black. It can be painted to

match any décor. The speaker enclosure is a durable UV-

resistant material that allows for both indoor and outdoor

installations. The perforated powdered coated aluminum

alloy grill is long lasting, corrosion resistant and rust free.

Included in the package is a universal heavy gauge

mounting kit. The kit includes a rust proof serrated U bracket

and large easy to install positive locking knobs. The knobs

are attached to the matching serrated area on the zero

balanced point of the enclosure via threaded studs. This

allows the speaker to easily be positioned to place the sound

where you want it. Hand tightening the knobs will clamp the

speaker in place. The speaker may be mounted either

horizontally or vertically.

Electrical connection, up to 12 gauge wire, is made by gold

plated constant tension spring loaded terminals.

This speaker is also available in a 70 volt version with

various wattage taps and a ½” knock out terminal cover.

One Hardwood Tree is planted in the National Forest to

offset the Styrofoam packaging on each pair.

With our limited 5 year warranty you are assured years of

superior trouble free operation.

OC8 Indoor/Outdoor Speaker User’s Installation Guide

www.currentaudio.com

1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181

SPECIFICATIONS

OC8

Driver

8” Mica Filled Polypropylene

Tweeter, 1” (25.4mm) Dome

Titanium

Frequency Response

42Hz-20kHz

Power handling

5-150 Watts

SPL @ 1 Watt/1 meter

90db

Impedance 8 ohm Nominal

Fixed Crossovers

Height X Width X Depth

16.5"(419m) X 11"(279.4mm) X

10”(254mm)

Color

Black

Part Number 92038 OC8B Black

Manual URL www.currentaudio.com

Accessories Volume Control ZL25R, ZL50S

Specifications subject to change without notice. OC8 RPA 060210

8.0” 2-Way, Indoor/Outdoor

Dual Purpose, Full Range Loudspeaker

OC8B Top OC8B Back

Packaging and Enclosed Parts

Please inspect your pack for damaged or missing parts. Notify your supplier if any discrepancies occur.

The OC8 Cabinet Speakers are packaged one to a box and sold as each.

Each box includes (1) Speaker, (1) U Bracket, and (2) Knobs and (1) Hardwood Tree planted in the National Forest.

Specifications subject to change without notice.

Gold Plated Constant Tension Spring

Loaded Terminals

Red (+)

Black (-)

Install

1. Decide if you want standard two speaker stereo sound or one reinforcement subwoofer speaker sound. The OC8 can do either

2. Chose locations for your speakers. If using two separate speakers, keep in mind your “sweet stop” the area where you will spend most of your time.

3. Choose your wiring method: Wall Mount, PVC conduit or Direct Burial cable.14 or 12 gauge low voltage Malibu direct burial cable works fine and is

readily available.

4. Bury your conduit or wire 18”below grade to prevent damage by tillers or shovels when planting. Prewire before hardscape concrete.

5. Insure there is enough room to place the OC8to enable aiming and rotation.

6. Mount the U-Bracket first then attach the speakers with the (2) positive locking knobs. Aim the speaker then tighten the knobs to secure in place.

7. The knobs are a male ¼-20 thread that mate to the 1/4 -20 insert on the speaker. This accommodates other mounts and tamper proof screws.

8. Carefully identify Left and Right cables at both ends . For proper phasing identify the (+) and (-) on each cable.

9. Connect the amplifier Left wire to the to the White and Green wire Only on the designated LEFT OC8 speaker. Observe polarity.

10. Connect the amplifier Right wire to the to the White and Green wire Only on the designated RIGHT OC8 speaker. Observe polarity.

11. If using the OC8 as a Subwoofer chose an amplifier with enough power handling capabilities.

12. Before connecting the wires to the amplifier check the impedance with a multi-meter on the resistance scale. It should read about 6.5 ohms.

13. If multi-meter reading is OK then connect to amplifier.

14. If using a volume control I suggest placing it inside the house for easy control and to protect it from the elements.

Limited 5 Year Warranty

Current Audio, LLC speakers and accessories are warranted to be free from defects in materials and or workmanship to the original retail purchaser for a

period of 5 years provided the equipment was purchased and installed from a Current Audio, LLC Authorized Dealer.

In the event of defective materials and or workmanship, Current Audio, LLC will, without charge, repair or replace, at its option, the defective product. In

order to make claim under this Warranty and to obtain performance of any obligation under warranty, please contact Current Audio. Instructions will be given

on how to return the defective product to Current Audio. Returned products must be shipped prepaid. Proof of purchase must be provided with the product.

The Warranty does not apply to damage not resulting from defective materials and or workmanship while in the possession of the original consumer or due to

unreasonable use by the original consumer, which includes but not limited to improper installation, negligence, unauthorized repair or modification, aesthetic

deterioration from the environment. Products purchased by unauthorized sources will void the warranty and not be honored.

Current Audio, LLC is not liable for any incidental or consequential damages, so the above limitations or inclusion may not apply to you. This warranty gives
