Four Seasons Courtyard 243332 User manual






































FS Avellino 6PK Chair
TV. No: 243332
IMPORTANT:
1. Keep all children and pets away from assembly area. Children and pets should be supervised while product is being
assembled.
2. The assembled product should be located at least 6 feet (2 m) from any obstruction such as fence, garage, house,
overhanging branches, laundry lines or electrical wires.
3. This unit is heavy. Do not assemble this item alone. 2 people are recommended for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of
personal injury and damage to equipment. Please read all instructions before assembly and use.
6. For both outdoor and indoor use.
7. Check all bolts for tightness before and during usage.
8. Please check your state and local regulations prior to purchasing. Some jurisdictions may require permits for
installation and use of this product. Some special procedures may be valid in your area.
Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from
rusting. However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are
scratched. This is not a defect and thus not covered by the warranty. To minimize this condition, we recommend care
when assembling & handling the product to prevent scratching the paint. Should any scratching or damage occur, we
recommend immediate touch-up with rust inhibiting paint. Surface rust can also be easily removed with a very light
application of common cooking oil. If surface oxidation (rusting) occurs and if no measure is taken to prevent this, the
oxidation may start dripping on to deck or patio and caused damaging stains, which may be difficult to remove. This can
be prevented if the above-mentioned measures are taken to keep the product from oxidizing.



























Step1:Connectconnect bar(B)andleft/rightarm(A1/A2)withbots(AA),springwasher(DD)andflatwashers(EE).
Step2:Fixtheassembledarmstochairback(C)withbots(BB),springwasher(DD)andflatwashers(EE).
No. Description Qty
A1 Right arm 1
A2 Left arm 1
B Connect bar 1
C Chair back 1
D Swivel 1
E Leg 4
F Ring 1
AA Bolt M6*20 4
BB Bolt M6*35 16
CC Bolt M6*28 4
DD Spring Washer M6 24
EE Flat washer M6 36
FF Nut M6 12
GG Hex M6 1
HH Wrench M6 1
PartList




























Step3:Fixtheswivel(D)toassembledchairseatwithbots(CC),flatwashers(EE),springwasher(DD)andnuts(FF).
Step4:Fixthering(F)tolegs(E)withbots(BB),springwasher(DD)andflatwashers(EE).
Step5:Fixtheassemblychairbasetoassemblychairseatwithbots(BB),flatwashers(EE),springwasher(DD)andnuts(FF).
Step6:Turnoverthechair,nowyouchairisreadytouse.
