Foxconn 945G7AD User manual

Thismanualistheintellectualpropertyof Foxconn,Inc.Althoughthe
informationinthismanualmaybechangedormodifiedatanytime,
Foxconn doesnot obligateitself toinformtheuser of these changes.
Statement:
Alltrademarksarethepropertyoftheir respectiveowners.
Moreinformation:
If you want moreinformationaboutourproducts,pleasevisit Foxconn s
website: http://www.foxconnchannel.com
Thisproduct anditsaccessoriesareproducedafter13thAug.,2005and
complywiththe WEEE2002/96ECdirective.
Version:
Trademark:
User sManualV1.0for 945P7AD/945G7ADmotherboard.
Symboldescription:
Note: referstoimportantinformationthatcanhelpyoutousemotherboard
better.
Attention: indicates thatit maydamagehardwareorcause dataloss,
and tellsyou howtoavoidsuch problems.
Warning: means thatapotentialriskofpropertydamage or physical
injuryexists.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Declaration ofconformity
HONHAIPRECISIONINDUSTRYCOMPANYLTD
66,CHUNGSHAN RD.,TU-CHENGINDUSTRIALDISTRICT,
TAIPEI HSIEN,TAIWAN, R.O.C.
declaresthatthe product
Motherboard
945P7AD/945G7AD
isinconformitywith
(referencetothespecification under which conformityisdeclared in
accordance with89/336EEC-EMCDirective)
þEN55022:1998/A2:2003Limitsandmethodsofmeasurementsofradiodisturbance
characteristicsofinformationtechnologyequipment
þEN61000-3-2/:2000 Electromagneticcompatibility(EMC)
Part3: Limits
Section 2:Limitsforharmoniccurrent emissions
(equipmentinput current <=16Aperphase)
þEN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)
Part3: Limits
Section2:Limitsof voltagefluctuationsand flickerin low-voltage
supplysystems forequipmentwithratedcurrent<= 16A
þEN55024/A2:2003 Informationtechnologyequipment-Immunitycharacteristicslimits
andmethodsof measurement
Signature: Place/ Date: TAIPEI/2006
PrintedName: JamesLiangPosition/Title: AssistantPresident
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Declaration ofconformity
Trade Name: Foxconn
ModelName: 945P7AD/945G7AD
ResponsibleParty: PCE IndustryInc.
Address: 458 E.Lambert Rd.
Fullerton,CA92835
Telephone: [phone]
Facsimile: 714-738-8838
Equipment Classification: FCCClassBSubassembly
Type ofProduct: Motherboard
Manufacturer:HON HAIPRECISION INDUSTRY
COMPANYLTD
Address: 66,CHUNG SHANRD.,TU-CHENG
INDUSTRIALDISTRICT, TAIPEIHSIEN,
TAIWAN,R.O.C.
SupplementaryInformation:
ThisdevicecomplieswithPart15oftheFCC Rules. Operationissubjecttothefollow-
ingtwoconditions:(1) thisdevice maynotcauseharmfulinterference,and(2) this
devicemustacceptanyinterference received,includinginterferencethat maycause
undesiredoperation.
TestedtocomplywithFCC standards.
Signature: Date: 2006
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

ProductIntroduction
MainFeatures........................................................................................2
Layout......................................................................................................4
RearPanelPorts...................................................................................5
InstallationInstructions
CPU.........................................................................................................7
Memory..................................................................................................10
Power Supply........................................................................................11
OtherConnectors................................................................................12
ExpansionSlots...................................................................................18
Jumpers...............................................................................................19
BIOSDescription
Enter BIOSSetup.................................................................................22
Mainmenu............................................................................................22
StandardCMOSFeatures...................................................................24
FoxCentralControlUnit......................................................................26
Advanced BIOSFeatures....................................................................28
AdvancedChipsetFeatures...............................................................32
IntegratedPeripherals........................................................................34
SecurityChipFeatures........................................................................40
PowerManagementSetup.................................................................41
PnP/PCIConfigurations......................................................................44
PC HealthStatus.................................................................................45
LoadFail-SafeDefaults.....................................................................46
LoadOptimizedDefaults..................................................................46
SetSupervisor/UserPassword.........................................................46
Save &Exit Setup.................................................................................47
ExitWithout Saving..............................................................................47
TableofContents
Chapter 2 2
Chapter 3
3
Chapter 1
1
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

DriverCD Introduction
UtilityCDcontent.................................................................................49
InstallingDrivers..................................................................................50
InstallingUtilities.................................................................................50
DirectionsforBundledSoftware
FOXONE.................................................................................................51
FoxLiveUpdate....................................................................................58
TableofContents
4
4
Chapter
5
5Chapter
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

1.Attach the CPUand heatsinkusing silicageltoensurefullcontact.
2.Itissuggestedtoselecthigh-quality, certified fansinordertoavoid
damagetothemotherboardandCPU duehigh temperatures.
3.Neverturnon themachineiftheCPU fanisnot properlyinstalled.
4.EnsurethattheDC powersupplyisturnedoff beforeinserting or
removingexpansioncardsorotherperipherals,especiallywhen
youinsert orremoveamemorymodule.Failuretoswitchoff the DC
powersupplymayresultinseriousdamagetoyoursystemor
memorymodule.
Attention:
Wecannotguarantee thatyoursystemwill operatenormallywhile
over-clocked. Normaloperation dependson theover-clock capacity
ofyourdevice.
Attention:
Attention:
SinceBIOSprogramsareupgradedfromtimetotime,theBIOS
description inthismanualisjustforreference.Wedo notguarantee
thatthecontentofthismanualwillremainconsistentwiththeactual
BIOSversion atanygiventimeinthefuture.
Attention:
The pictures of objectsusedinthismanualarejustforyour reference.
Pleaserefertothe physicalmotherboard.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Thismanualissuitableformotherboardof945P7AD/
945G7AD.Eachmotherboardiscarefullydesigned forthePC
userwho wantsdiverse features.
-L withonboard10/100MLAN(Default isomitted.)
-K withonboardGigabit LAN
-6 with6-Channelaudio(Default isomitted.)
-8 with8-Channelaudio
-E with1394function
-S withSATAfunction
-2 withDDR2function
-RwithRAIDfunction
-HcomplywithRoHSdirectives
Youcanfind PPIDlabelonthemotherboard.It indicatesthe
functions thatthemotherboardhas.
Forexample:
The lettersontheblackmarkofthe PPIDlabel, it means the
motherboardsupports6-ChannelAudio(-6)(default), 1394
port (-E), onboard10/100MLAN (-L)(default), SATAfunction (-
S).
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter
Thankyouforbuying Foxconn s945P7AD/945G7ADseries
motherboard.Thisseriesofmotherboardisoneofournew
products,andofferssuperiorperformance,reliabilityand
quality,atareasonableprice.Thismotherboardadoptsthe
advancedIntel®945P/945G+ICH7/ICH7Rchipset, providing
usersacomputerplatformwithahigh integration-compatibil-
ity-performancepriceratio.
Thischapterincludes thefollowing information:
vMainFeatures
vLayout
vRear I/OPorts
1
1
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter1ProductIntroduction
2
MainFeatures
Size
·ATXformfactorof 12inchx9.6inch
Microprocessor
·SupportsIntel®CoreTM 2ExtremeEdition,CoreTM 2Duo,Pentium®D,Pentium®
4ExtremeEdition,Pentium®4,Celeron®DprocessorsinanLGA775
package
·SupportsFSB at533MHz /800MHz /1066 MHz
Chipset
·Intel®945P/945G(NorthBridge)+ICH7/ICH7R(SouthBridge)
SystemMemory
·Four240-pinDIMMslots
·SupportsDual-ChannelDDR2667/533/400
·Supportsup to4GBDDR2memory
USB2.0Ports
·Supportshotplug
·EightUSB2.0ports
·Supportswake-up fromS1and S3mode
·SupportsUSB 2.0protocolup to480Mbpstransmission rate
OnboardSerialATAII
·300MBpsdatatransferrate
·SupportsRAID0,RAID1, RAID10(onlyforICH7R)
·FourinternalSerial ATAII connectorsand oneexternalSerial ATAIIconnector
OnboardLAN (-K)
·One LANinterfacebuilt-inonboard
·Supports10/100/1000 Mbit/secEthernet
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

3
Chapter1ProductIntroduction
Onboard1394(-E)(optional)
·Support hotplug
·Withrateoftransmission at400 Mbps
·Canconnectwith2independent1394 unitssynchronouslyatmost
OnboardAudio(-6)(optional)
·AC 97 2.3Specification Compliant
·SupportsS/PDIFoutput
·OnboardLine-injack,Microphone-injack,Line-out jack
·Supports6-channelaudio(setting viasoftware)
OnboardAudio(-8)(optional)
·SupportsSPDIFoutput
·SupportsJack-Sensing function
·SupportsIntel®High Definition Audio
PCI Expressx16 Support
·Supports4GB/sec (8GB/sec concurrent) bandwidth
·Lowpowerconsumptionand powermanagementfeatures
OnboardGraphic(supported on 945Gonly)
·SupportsintergratedVGAdisplayfunction
Green Function
·SupportsACPI(AdvancedConfiguration andPowerInterface)
·SupportsS0(normal), S1(power on suspend), S3(suspendtoRAM),S4
(Suspend todisk-depends onOS),and S5(soft -off)
ExpansionSlots
·ThreePCIslots
·onePCIExpress x16 Graphicsslot
·twoPCIExpress x1slot
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter1ProductIntroduction
4
Layout
16. FrontUSBConnectors
17.BIOSTBLProtectJumper(optional)
18.TPMConnector
19.ChassisIntruderConnector
20.SYS_FAN1 Connector
21.COM2Connector
22.SATAIIConnector
23.24-pinATXPowerConnector:PWR2
24. FDDConnector
25. IrDAHeader
26.DDR2DIMMSlots
27.CPU_Fan Connector
28.North Bridge:Intel®945P/945GChipset
29.LGA775 CPUSocket
30.8-pinATX_12VPowerConnector:PWR1
1. PCIExpress x16Slots
2.1394aConnector(optional)
3. PCIExpress x1Slots
4.South Bridge: Intel®ICH7/ICH7RChipset
5. PCISlots
6.AUX-INConnector(optional)
7. CD_INConnector
8.Front AudioConnector
9.SPIDF_OUTConnector
10.SpeakerConnector
11.IDEConnector:PIDE
12.FrontPanelConnector
13.SPIConnector(optional)
14.J1Connector(optional)
15.ClearCMOSJumper
Note: The abovemotherboardlayout isprovided forreferenceonly,pleaserefer
tothe physicalmotherboard.
6
5 4 32 1
7
8
9
10
11
12
13
14
15
16 17 18 1920 21 22 23 24
25
26
27
28
30
29
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

5
Chapter1ProductIntroduction
RearI/OPorts
Thismotherboardprovides theportsas below:
USB2.0Port
LANPort(-K)ParallelPort
(Print Port)
PS/2Mouse
Port
PS/2Keyboard
Port
eSATAPort
rear
CEN/LFE
Microphone
Line-in
Line-out
Side
Line-in
(Rear)
Line-out
(Front)
Microphone
(CEN/LFE)
For-6models
For-8models
Line-injack,Line-outjack,Microphonejack (for-6models)
Whenusing a2-channelsound source,theLine-outjack isusedtoconnectto
speakerorheadphone;theLine-inport connectstoanexternalCDplayer,tape
playeror other audiodevice.TheMicrophonejack isusedtoconnecttothe
microphone.
Whenusing a6-channelsound source,connectthefrontspeakertothegreen
audiooutput;connecttherearspeakertotheblueaudiooutput;connectthe
centerspeaker/subwoofertotheredMicrophoneoutput.
Linein, Lineout,Microphone,Rear, LEF/CEN,Side Jacks(for-8models)
When usingan8-channelsoundsource, connectthe frontspeakertothe green
audiooutput;connect the rearsound speaker tothe blackaudiooutput;con-
nectthecenterspeaker/subwoofertothe orangeaudiooutput;connectthe side
soundspeakertothegreyaudiooutput.
1
2
56
7
1394Port
(optional)
4
8
VGAPort
(optional) Coaxial
S/PDIFout
Port
3
10
3
3
9
10
10
7
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter1ProductIntroduction
6
Thischapterintroduces thehardwareinstallationprocess,in-
cluding theinstallation ofthe CPU,memory,powersupply,
slots,andpinheaders,and themounting ofjumpers.Cau-
tion shouldbeexercisedduring theinstallation ofthese
modules.Please refertothemotherboardlayoutprior toany
installationandreadthecontentsinthischaptercarefully.
Thischapterincludes the following information:
vCPU
vMemory
vPowersupply
vOtherConnectors
vExpansionSlots
vJumpers
Chapter2
2
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
7
CPU
Thismotherboardsupportssingleprocessorincluding Intel®CoreTM 2Extreme
Edition,CoreTM 2Duo,Pentium®D,Pentium®4ExtremeEdition,Pentium®4,
Celeron®DprocessorsinanLGA775package withaFrontSideBus(FSB)of
1066/800/533MHz.
ForthedetailedCPU support listonthismotherboard,please visitthe
website: http://www.foxconnchannel.com
Installation ofCPU
Belowisthe CPU socketillustration. Followtheseprocedures toinstallaCPU.
Loadlever Load plate
Protectivecover
1.Use thumbandforefinger toholdthehookofthe loadlever andpullthe lever
downandaway fromsockettounlock it.Lift theload lever.
2.Pushdownthe rear tab withyourforefingertobringthefrontendofthe load
plateupslightly.Open the loadplatewiththumb.Becarefulnottotouch the
contacts.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
8
3.HoldCPUwiththumbandforefinger.Ensurefingersaligntosocket cutouts.
Match theCPUtrianglemarkertoPin1positionasshownbelow.Thealignment
key also providestheorientation directedfunction.Lower the CPUstraight down
withouttiltingorslidingtheCPU inthesocket.
4.Afterinstalling theCPU,removetheprotectivecoverfromload plate. The
protectivecoverisusedtoprotectthecontactsofthe socket. Donotdiscardthe
protective cover.Always replacethesocketcover if theCPUisremovedfromthe
socket.
AlignmentKey
SocketCutouts
Pin1position
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
9
Note:
Excessive temperatures willseverelydamage theCPU and
system.Therefore, you shouldinstall CPU coolingfanand make
surethatthe coolingfanworksnormallyatalltimesinorderto
preventoverheatinganddamagingtotheCPU.Pleaserefertoyour
CPU fanuserguidetoinstall itproperly.
5.Closetheloadplate,andslightlypushdownthe tongueside.
6.Lowertheleverand lock ittotheloadplate,thentheCPU islockedcompletely.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
10
Memory
Thismotherboardincludes four240-pinDIMMslots.SoYoumust installatleast
onememorybank toensurenormaloperation.
InstallationofDDR2Memory
1.ThereisonlyonegapnearthecenteroftheDIMMslot, and thememory
modulecan be fixedinonedirection only.Unlock aDIMM slotbypressing the
moduleclips outward.
2.AlignthememorymoduletotheDIMM slot,and insert the modulevertically
intotheDIMMslot.
3.Theplasticclipsatbothsides oftheDIMM slotwill lock automatically.
128Pins 112Pins
Forthe detailedmemorysupportliston thismotherboard,please visitthe
website: http://www.foxconnchannel.com
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
11
Power Supply
Thismotherboarduses anATX powersupply.Inordertoavoiddamaging any
devices,make surethat they havebeeninstalledproperlypriortoconnecting
thepowersupply.
24-pinATX powerconnector:PWR2
PWR2istheATXpower supplyconnector. Make
surethatthepowersupplycableandpinsare
properlyalignedwiththeconnectoron the
motherboard.Firmlyplugthepowersupplycable
intotheconnectorand makesureitissecure.
8-pinATX_12 VPowerConnector:PWR1
The 8-pinATX12Vpowersupplyconnectsto
PWR1andprovidespower totheCPU.
24-pinATXPowerConnector
8-pinATX_12 VPowerConnector
1
4
5
8
GND
12V
1
4
5
8
Connecta4-pin
powerplug here
Note:
Westronglyrecommend that youuse 8-pinATX
12Vpowersupply.Ifyou wanttouse4-pin
powersupply,connectthe4-pinpowercon-
nectoras shown.
+3.3V
+5V
GND
+3.3V
GND
PWROK
+3.3V
24
+5V
GND
+3.3V
GND
GND+5V
+5V
GND
PS-ON
-12V
12
GND
+5V
+ 5V_AUX
+12V
+12V
RSVD
GND
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
12
OtherConnectors
ThismotherboardincludesconnectorsforFDDdevices,IDEdevices,SerialATA
devices,USB devices, IRmodule,and others.
FDDConnector:FLOPPY
ThismotherboardincludesastandardFDDconnector,supporting360K,720K,
1.2M,1.44M,and2.88MFDDs.
IDEConnectors:PIDE
The PIDEconnectorsupportsUltraATA 100/66IDEharddiskdrives.
Connectthe cablesblueconnectortotheIDEconnector, thenconnect thegray
connector totheslavedevice (harddisk drive) and theblack connector tothe
UltraATAmasterdevice.Ifyou installtwoharddisks,you mustconfigurethe
seconddriveas aslavedevicebysetting itsjumper accordingly.Refertothehard
diskdocumentation for thejumper settings.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
13
FrontPanelConnector: FP1
Thismotherboardincludesoneconnectorforcon-
nectingthefrontpanelswitch and LED indicators.
HDDLEDConnector(HD-LED)
Theconnectorconnectstothecase sHDD indicator LED indicatingtheactivity
statusofharddisks.
ResetSwitch (RESET)
Attach theconnectortothe Resetswitchonthe frontpanelofthecase;the
systemwillrestartwhenthe switch ispressed.
Power LEDConnector(PWRLED)
Attachtheconnectortothe powerLEDonthefront panelof thecase. ThePower
LEDindicatesthe system sstatus.When thesystemisinS0status,theLEDis
on.Whenthe systemisinS1status, the LEDisblink;When thesystemisinS3,
S4,S5status,the LED isoff.
PowerSwitch Connector(PWRSW)
Attachtheconnectortothepower buttonof the case.Pushingthisswitchallows
thesystemtobeturnedon and off ratherthan using the powersupplybutton.
+-
+-
1
FP1
NCHD-LED RESET
PWRLED
PWRSW
Empty
AudioConnector: F_AUDIO(for-6models)
(optional)
Theaudiointerface providestwokinds of
audiooutputchoices:theFrontAudio,theRear
Audio.Theirpriorityissequencedfromhigh
tolow(FrontAudiotoRear Audio).Ifhead-
phonesareplugged intothe frontpanelof
thechassis(using theFrontAudio),thenthe
Line-out(RearAudio) on the rearpanelwill
notwork.If you don twanttousetheFront
Audio,pin5and 6,pin9and 10 mustbe
SHORT,and thenthesignalwillbe sentto
therearaudioport.
AUD_OUT-L
NA
MIC_IN
MIC_PWR
F_AUDIO
MIC_GND
+5VA
AUD_OUT-R AUD_RET-R
Empty
AUD_RET-L
1
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn
