1.Overview
Figure 1 XLINK-50
XLINK-50 is a point-to-point data/video wireless transmitting system designed for industrial UAVs, ground robots and
other data communication applications, featuring 50km long transmission distance.
XLINK-50 integrates the technology of 4G, 5G, WIFI, and adopts OFDM technique and multi-path anti-interference
technology, which has the advantages of long distance transmission, low latency, strong diraction performance, and
big data bandwidth communications.
XLINK-50 needs to be used in pairs. The selection of antenna is determined by the scenarios that it is applied to. When
used on aircraft, the sky end is referred to as the Air Unit, whereas the ground end is called the Ground Unit.

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
3
2.Industry Application
XLINK-50 needs to be used in pairs. The selection of antenna is determined by the scenarios that it is applied to. When
used on aircraft, the sky end is referred to as the Air Unit, whereas the ground end is called the Ground Unit.
XLINK-50 is applicable to the following industry application scenarios:
1) For 50Km~70Km long-range drones, omnidirectional antennas or optional directional antennas and antenna tracker
can be used in this scenario;
2) For long range data communication of the ground (unmanned) vehicle, use an omnidirectional berglass antenna, and
the distance is 2Km~5Km;
Figure 2

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
4
3.Parameter
3.1. Functions

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
5
3.2.Performance
Xlink-50 supports a variety of communication code streams, which can be selected according to the needs of actual
mission. Xlink-50 supports two-way communication, the specic description is as follows:
(1)From the air end to the ground end, it supports the transmission of large bit stream data through the IP network port,
which can be used for video communication;
(2)From the air end to the ground end, an independent control channel is supported through the control interface, which
can be used for communication of control information;
(3)From the ground end to the air end, it supports small stream data transmission through the IP network port, which can
be used to form two-way communication with the data of the sky end IP network port;
(4)From the ground end to the air end, the control information is supported through the control interface, and the control
information sent by the air end can form two-way communication; berglass antenna, and the distance is 2Km~5Km;
The external interface of XLINK-50 is shown in Figure 3. For external interface denition and description, please refer
to Table 5.
4.Interface

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
6
Figure 3 Pin identication number

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
7

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
8
5.Mechanical characteristics
See Table 7 for mechanical characteristics, and Figure 4 for specic product dimensions and installation.

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
9
Figure 4 Dimensions

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
10
Installation Instructions
(1)M3*10GB/T818, 4PCS
(2)cross head screwdriver
(3)The depth of threaded hole should be reserved at east 5mm
(4)Torque requirement 6±0.5Kgf;
6.Quick Start
6.1 UI Conguration
XLINK-30 has dierent data rates, which needs to be congured as needed.
STEP 1 Power on XLINK-30, and link it with PC by Ethernet. Then congure IP Address as shown below:
IP Address 192.168.0.1
Subnet Mask 255.255.255.0
Step 2
Search 192.168.0.9 and enter on browser, next it will show a conguration interface as gure 6., Select the conguration
according to the actual transmission rate, and click "SUBMIT" after the conguration is complete Refer to Table 8 for
the parameter description on the conguration interface.
Step 3
Reboot to activate the congured value.
Step 4
You need to congure the same bandwidth/data rate value for air and ground unit to ensure a successful pairing between
them.

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
11
6.2.Pairing
In the point-to-point application scenario, after air unit and ground unit are powered on, the two modules need to
successfully establish a link before they can communicate. The following describes the link establishment process:
Step 1
After one unit powers on, the SYNC LED indicator turns green. About 30s later, it starts to blink, which means it is
pairing with the other unit.
Step 2
If two units are powered on and paired, the indicator stops blinking and keeps on.
Step 3
If the pairing is failed, the indicator blinks green, during which the unit is still searching until two devices are
successfully paired.
Possible causes of failed pairing:
1.One of the unit is powered o.
2.Beyond transmission distance
3.Strong signal interference

FOXTECHXLINK-50 Long Range Video/Data Wireless Transmitting System User Manual
12
Appendix -1
Figure 7 diagram of J30J socket pin denition
