Franklin BRELLA-TEK 91505Z User manual

ITEM NUMBER: 91505Z
Made In China
Franklin Sports Inc.
Stoughton, MA 02072
For replacement parts:
Visit: www.franklinsports.com/91505Z
Email: [email protected]
Call: 1-800-225-8649
NOTE: PRINT FRONT TO BACK
UMBRELLA
BRELLA-TEK™ AUTOMATIC
NOTESTEP 4 - ADJUSTING THE CANOPY
This umbrella has two
flex points that allows
you to adjust the angle
of the umbrella. Simply
hold and bend to the
desired position.
CARE & STORAGE:
Make sure the BRELLA-TEK™ umbrella is dry and clean before packing and storing.
Use mild detergent to spot clean the umbrella.
UPPER FLEX POINT LOWER FLEX POINT
PINCH HAZARD! KEEP HANDS CLEAR.
CAUTION:

PARTS LIST
ITEM#: 2 ITEM#: 1
91505Z
For replacement parts:
Visit: www.franklinsports.com/91505Z
Email: [email protected]
Call: 1-800-225-8649
For replacement parts:
Visit: www.franklinsports.com/91505Z
Email: [email protected]
Call: 1-800-225-8649
3
ASSEMBLY INSTRUCTIONS
NOTESTEP 3 - ADJUSTING BASE HINGE
The umbrella can be
adjusted forward or
back by pressing the
button on the base
clamp. Press and
rotate to the desired
position and release.
The umbrella will lock
to the closest
setting.
91505Z
x1
Umbrella
1
Rep. Part: N/A
QTY
x1
Case
2
Rep. Part: N/A
QTY
PARTS NOTESTEP 2 - ATTACHING THE CLAMP
The BRELLA-TEK™
umbrella will attach to
either a round or
square surface up to
1.5in (3.8cm) diameter;
such as chairs, tables,
etc. Prior to attaching,
fully open the clamp by
twisting the adjustment
knob counter
clockwise.
Attach the clamp to the
desired location and
tighten by twisting
clockwise. Make sure
the area is clean and
dry to ensure a secure
fit.
Once attached open
the umbrella.
1 x1
PARTS NOTE
Remove umbrella from
case. Release the self
stick strap.
Open the SIDELINE
SUNBLOCKER™ by
pressing the automatic
button, releasing
umbrella until fully
extended.
1 x1
1
GENERAL NOTES
Read all the set up and usage instructions before use. If the instructions are not followed correctly,
injury or damage to the product may result.
Always inspect equipment for worn or damage before each use. If defects are found please do
not use.
Review your product to ensure all components are received. Please contact customer service if
you are missing anything.
STEP 1 - OPENING UMBRELLA
