Freespirit Recreation High Country Premium Series User manual
- 1 -
HIGH COUNTRY
PREMIUM SERIES
55”/63”/80”
INSTRUCTION MANUAL
HIGH COUNTRY 80”
IS PICTURED
- 2 -
DEAR FREESPIRIT FAMILY,
As a family owned and operated business, it is our hope that as you get out
there and use the Freespirit products, you feel like a part of our extended
family and also feel like we are all out there exploring this great planet
together.
Our goal at Freespirit Recreation has always been to
re-invent the roof top tent from the ground up.
We work hard to create the best designs using the best products that allow for
a fast and easy set-up. We want you spending more time
exploring and enjoying life.
You have asked us to be innovative, to provide the best quality, to provide
great customer service, and to keep creating products that
Elevate Your Adventure so stay in touch with us!
Follow us on social media and on our website, www.gofsr.com.
Have questions for us?
Reach out, we are here to help!
sales@gofsr.com
Oh, and because we have to put this in here…
PLEASE REVIEW THIS INSTRUCTION MANUAL BEFORE USING
YOUR ROOF TOP TENT.
From the Freespirit family to you, THANK YOU for your purchase.
We hope that it really will Elevate Your Adventure!
Renee Tewes: President and Team Leader, Customer Service
Tanner Tewes, Team Leader: Sales and Product Innovation
Kristine Sewell, Team Leader: Marketing
Ben Tewes, Team Leader: Sales and Product Innovation
- 3 -
TABLE OF CONTENTS:
PRODUCT OVERVIEW (PAGE 4)
PRODUCT SPECIFICATIONS (PAGE 4-6)
PRODUCT FRAME (PAGE 6)
INSTALLING YOUR ROOFTOP TENT (PAGE 7-9)
SETTING UP YOUR ROOFTOP TENT (PAGE 9-10)
TAKING DOWN YOUR ROOFTOP TENT (PAGE 11)
GENERAL MAINTENANCE, IMPORTANT NOTES, TROUBLESHOOTING
(PAGE 12)
INCLUDED TOOLS (PAGE 13)
- 4 -
PRODUCT OVERVIEW:
The High Country Premium Series Rooftop Tents are designed to maximize
space for people and gear when opened but also have a minimal footprint
when closed and stored. It is known as our “fold out” rooftop tent because
using the built-in telescopic ladder you can set it up in seconds by folding it
out from the closed position. The High Country Series Rooftop Tents can easily
be installed and set-up with 2 people.
It is available currently in three sizes: 55”, 63”, and 80”. The 55” size is
roughly the size of a full size mattress. The 63” is roughly the size of a queen
size mattress. And the 80” is roughly the size of a king size mattress. The 80”
is also the ONLY High Country Series Rooftop tent that uses stabilizer poles to
the ground for extra support.
PRODUCT SPECIFICATIONS:
1. The entire frame uses aluminum alloy and the joints are made of strong
nylon.
2. There is a double layer of silver coating treatment for the outer tent
material to offer better heat insulation and to make it water resistant.
3. 3" foam mattress provides comfortable sleep experience.
4. Telescopic aluminum alloy ladder is removable and supports weight up to
350 lb.
- 5 -
HIGH COUNTRY 55” PREMIUM PRODUCT SPECIFICATIONS:
55" Premium
Dimensions
55"L X98"W X47"H
Exterior Closed
Dimensions
60"L X52"W X14"H
Weight
154 lbs
Sleeping Capacity
2-3 people
Weight Capacity
750 lbs
Tri-Layer Body
3 Layers of 150D Poly-Oxford with 60g/M2 Poly-fil
Rainfly 210D Rip-Stop Poly-Oxford with Silver Coating and
3,000mm Polyurethane Coating
Mattress
1.5″High Density Foam
Flooring
2″EPE foam
Frame
Extruded Aluminum Alloy
HIGH COUNTRY 63” PREMIUM PRODUCT SPECIFICATIONS:
63" Premium
Dimensions
63"L
X98"W X47"H
Exterior Closed
Dimensions
68"L
X52"W X14"H
Weight
162 lbs
Sleeping Capacity
3-4 people
Weight Capacity
750 lbs
Tri-Layer Body
3 Layers of 150D Poly-Oxford with 60g/M2 Poly-fil
Rainfly
210D Rip
-Stop Poly-Oxford with Silver Coating and
3,000mm Polyurethane Coating
Mattress
1.5″High Density Foam
Flooring
2″EPE foam
Frame
Extruded Aluminum Alloy
- 6 -
U Shaped Poles
Front Door/
Telescopic Pole
Telescoping Ladder
HIGH COUNTRY 80” PREMIUM PRODUCT SPECIFICATIONS:
80" Premium
Dimensions
80"L
X98"W X 50"H
Exterior Closed
Dimensions
85"L
X52"W X14"H
Weight
182 lbs
Sleeping Capacity
3-5 people
Weight Capacity
750 lbs
Tri-Layer Body
3 Layers of 150D Poly-Oxford with 60g/M2 Poly-fil
Rainfly
210D Rip
-Stop Poly-Oxford with Silver Coating and
3,000mm Polyurethane Coating
Mattress
1.5″High Density Foam
Flooring
2″EPE foam
Frame
Extruded Aluminum Alloy
PRODUCT FRAME:
- 7 -
INSTALLING YOUR HIGH COUNTRY PREMIUM SERIES
ROOF TOP TENT ON YOUR ROOF RACK:
IMPORTANT NOTE:
We recommend that any of the High Country Premium Series Rooftop Tents be
installed on a separate roof rack on top of your vehicle, one that can handle
over 200lbs of dynamic load. We do offer some roof racks on our website or
you can purchase them from several companies including Rhino Rack,
Yakima, Thule, Dee-Zee, etc. If you have any questions on which roof rack will
work for your specific vehicle, please reach out to the roof rack company
directly.
The distance between the High Country Premium Series Rooftop Tents and the
roof rack should not exceed more than 1.5”.
INSTALLATION STEPS:
1. Please make sure that your roof rack
is correctly fitted and installed to your
vehicle before installing the rooftop tent.
2. Lift the rooftop tent onto the roof rack
on top of the vehicle.
3. Adjust the rooftop tent so that it is
centered on the roof of the vehicle. If the
vehicle has a rear door ensure it can be
opened and closed.
4. Slide the M8x5O bolt into the rails
from both sides ensuring you have
positioned 8 in total (see picture 1), then
replace the plastic end caps of your roof
racks (see picture 2).
- 8 -
Rack
Rail
U-Shape
Stator
Picture #1 Picture #2
U-Shape Stator: Plastic Nut (8 Total):
M8x50 Bolts (8 total):
- 9 -
M8 Flat Washer & M8 Arc Washer: Plastic End Cap or Cover for
Rail on Roof Rack:
SETTING UP YOUR HIGH COUNTRY PREMIUM SERIES
ROOFTOP TENT:
1. From the top of the rooftop tent, pull the
telescoping ladder out completely.
2. Use the ladder as a lever to press down and fold
out the rooftop tent so that it is open.
3. Put the ladder to the
ground and adjust the
ladder length
- 10 -
You High Country Premium Series Rooftop Tent is set-up and ready….
it’s time to Elevate Your Adventure!
4. Take out the adjustable support poles (for use
with the High Country 80" ONLY) and insert the
pin into the plastic clip
5. Adjust the pole length to the floor and rotate the
two parts of poles up and down to lock the pole.
6. Stand on the ladder,
pull out the telescopic
pole of the rainfly and
lock the pole in place
on the sides with the
button pins.
- 11 -
TAKING DOWN THE HIGH COUNTRY PREMIUM SERIES
ROOFTOP TENT:
1. If using the High Country 80”,
remove support poles.
2. Press down two telescopic pole of
the rainfly and lift the ladder to fold
the roof top tent closed.
3. Press the ladder's
unlocking device to
shorten the ladder and
store it on top of the
rooftop tent.
4. You can use the red
rubber strip to tie the rear
side of roof tent. Cover the
tent with the PVC cover
on top of the tent and
buckle the straps down
before driving.
- 12 -
GENERAL MAINTENANCE:
1. Before you pack up the tent, please make sure the fabric is dry.
2. Keep the rail of the base clean and dry.
3. Leave windows partially open when opening and closing.
4. Please make sure you don’t leave your tent on top of your car for long
periods of time in extreme weather conditions, prolonged rain or
extreme sun/heat.
IMPORTANT NOTES:
1. When packing away the tent, ensure there is no other objects in the
tent (like sleeping bag, pillow).
2. Don't put heavy objects on the tent when the tent is closed to avoid
damaging the frame.
3. Clean and wipe the tent with wet rag instead of machine washing or
hand washing (cover of the mattress is washable).
4. Check the connecting points of the tent to the car rack; ensure all
points are properly locked.
5. Please don't jump when inside the tent because the uneven force
could damage the tent.
6. Always keep the tent closed when you are driving.
7. In extremely windy weather conditions, please do not open the tent.
8. If there is abnormal noise when setting up or folding down the tent,
please check the rail and all connection joints right away.
TROUBLESHOOTING TIPS (IF NEEDED):
If the tent stops working, check the following:
1. Check if the screw of Aluminum pole is loose
2. Check if the fabric is dragged into the stretcher pole
3. Check if the rail of base is broken
