freightliner Sprinter 2020 User manual

Your Operating Instructions
Vehicle document wallet in thevehicle
Here you can find information on operation, service work and the guarantee for
your vehicle in printed form.
É9075842506oËÍ
9075842506
Order no. T907 0202 13 Part no. 907 584 25 06 Edition B-2020
Sprinter
Operating Instructions
Sprinter Operating Instructions

Publication details
Internet
Further information about Freightliner Sprinter
vehicles and about Mercedes-Benz AG can be
found on thefollowing websites:
https://www.mbusa.com (USA only)
https://www.freightlinersprinterusa.com
Documentation team
©Daimler VANS USA, LLC
©Mercedes-Benz AG: not to be reprinted, transla‐
ted or otherwise reproduced, in whole or in part,
without written permission from Mercedes-
Benz AG.
Vehicle manufacturer
Mercedes-Benz AG
Mercedesstraße 120
70372 Stuttgart
Germany
Vehicle dealer
Daimler VANS USA, LLC
One Mercedes-Benz Drive
Sandy Springs, GA 30328
https://www.mbusa.com (USA only)
https://www.freightlinersprinterusa.com
Customer Assistance Center:
1-877-762-8267
Daimler VANS USA, LLC is a Daimler Company.
Co-driver airbag warning
Example
&WARNING Risk of injury or fatal injuries
if the front-passenger airbag is enabled
If the front-passenger front airbag is enabled,
achild on the front-passenger seat may be
struck by the front-passenger airbag during
an accident.
NEVER use a rearward-facing child restraint
system on a seat with an ENABLED FRONT
AIRBAG, DEATH or SERIOUS INJURY to the
CHILD can occur.
Observe thechapter "Children in thevehicle".
As at 06.09.19

Welcome to theworld of Freightliner
Sprinter
Beforeyou firstdrive off, read these Operating
Instructionscarefullyand familiarize yourself with
your vehicle. Foryour ownsafetyand alonger
vehicle life, followthe instructions and warning
notices in these Operating Instructions. Disre‐
garding them mayresult in damagetothe vehicle
or environment or in personal injury.
Vehicle damagecaused by failuretoobserve the
instructions is notcovered by theNew Vehicle
Limited Warranty.
The standardequipmentand productdescription
of your vehicle mayvaryand depends on thefol‐
lowing factors:
RModel
ROrder
RNational version
RAvailability
Freightliner Sprinter reservesthe right to intro‐
duce changes in:
RDesign
REquipment
RTechnicalfeatures
Therefore, thedescription maydifferfromyour
vehicle in some cases.
The following documentsare integralparts of the
vehicle:
RPrinted Operating Instructions
RMaintenance Booklet
REquipment-dependent supplements
Alwayskeep these documentsinthe vehicle. If
yousell thevehicle, alwayspass all documents
on to thenew owner.
DaimlerVANS USA, LLC
ADaimler Company
9075842506
9075842506

Symbols ..................................................... 4
At aglance ................................................. 6
Cockpit ........................................................ 6
Overheadcontrol panel............................... 8
Door control panel..................................... 13
Emergencies and breakdowns ................... 15
Generalnotes .......................................... 17
Environmental protection ........................... 17
Freightliner Sprinter Genuine Parts............ 17
Notesabout attachments, add-on
equipment, installationsand conver‐
sions .......................................................... 18
Operating Instructions ...............................19
Service and vehicle operation .................... 19
Operating safety........................................20
Declarations of conformity ........................ 21
Diagnostics connection .............................22
Notesonchanges to theengine output ..... 22
Qualified specialistworkshop .................... 22
Vehicle registration ................................... 22
Correct useofthe vehicle .........................23
Multi Purpose Vehicle ................................ 23
Information on problems withyour
vehicle .......................................................23
Reportingsafetydefects ............................ 23
Limited Warranty....................................... 24
QR codes forrescue card.......................... 24
Datastorage ..............................................24
Copyright ...................................................26
Occupant safety ...................................... 28
Restraint system ........................................28
Seatbelts .................................................. 29
Airbags...................................................... 32
Safely transporting children in the
vehicle .......................................................33
Notesonpetsinthe vehicle ......................42
Opening and closing ............................... 43
SmartKey ................................................... 43
Doors........................................................ 46
Sliding door............................................... 48
Electric sliding door................................... 49
Rear-enddoors..........................................52
Partition sliding door .................................53
Electricalstep............................................ 54
Sidewindow.............................................. 55
Anti-theftprotection ..................................58
Seats and stowage .................................. 61
Correct driver's seatposition ..................... 61
Seats ......................................................... 61
Adjusting thesteering wheel ..................... 73
Stowageareas ...........................................74
Bottle holder .............................................. 75
Cup holder .................................................75
Ashtray and cigarette lighter ...................... 76
Sockets ..................................................... 77
Wirelesslycharging themobile phone
and coupling withthe exterior antenna ..... 79
Installing or removing thefloor mats ......... 80
Light and vision ....................................... 81
Exteriorlighting ......................................... 81
Adjusting theinterior lighting .................... 84
Changingbulbs .......................................... 87
Windshield wipers ..................................... 92
Mirrors ....................................................... 94
Using sun visors........................................95
Climatecontrol ....................................... 96
Overviewofclimatecontrol systems ......... 96
Operating climatecontrol systems ............ 98
Operating air vents .................................. 101
Auxiliary heating ...................................... 102
Operating cargo compartment ventila‐
tion.......................................................... 105
Drivingand parking .............................. 106
Driving .....................................................106
Batterymainswitch................................. 117
Automatic transmission ........................... 119
All-wheeldrive .........................................121
DSR (DownhillSpeed Regulation) ............ 123
Electroniclevelcontrol ............................ 125
Refueling .................................................130
Parking .................................................... 137
Driving and driving safety systems ..........142
Work mode ..............................................164
Trailer operation ...................................... 164
Instrument Displayand on-board
computer ............................................... 171
OverviewofInstrument Display............... 171
Overviewofthe buttons on thesteer‐
ing wheel .................................................172
Operating theon-boardcomputer ........... 172
Overviewofthe displays on themulti‐
function display....................................... 173
Setting theinstrument lighting ................. 174
2Contents

Menus and submenus .............................. 174
MercedesPRO ....................................... 179
Information aboutMercedes PRO
(Mercedes me) ........................................ 179
Information aboutMercedes PROcon‐
nect (Mercedes me connect) ................... 179
Callingthe Freightliner Sprinter Cus‐
tomer Center using themultimedia
system ..................................................... 179
Making acall via theoverhead control
panel .......................................................180
Informationonthe breakdown assis‐
tance callvia theoverhead control
panel .......................................................180
Giving permission fordatatransfer ......... 180
Transferred dataduring aservice call ...... 180
Multimedia system ............................... 182
Overviewand operation ........................... 182
System settings ....................................... 188
Vehicle information ..................................190
Telephone................................................191
Media ...................................................... 198
Radio .......................................................202
Sound ...................................................... 203
Transporting .......................................... 204
Notesonloading guidelines ...................204
Load distribution ..................................... 205
Securing loads ......................................... 205
Carrier systems ....................................... 207
Using theinterior roof carrier system ...... 208
Placing aload on thewheel arch ............. 210
Maintenanceand care ........................... 211
ASSYSTPLUSservice intervaldisplay......211
Engine compartment ................................ 211
Cleaning and care....................................219
Breakdown assistance ......................... 225
Emergency .............................................. 225
Emergency Call System ........................... 225
Flat tire....................................................227
Battery.................................................... 227
Towing or tow-starting............................. 233
Electrical fuses........................................ 237
Vehicle tool kit ......................................... 238
Hydraulic jack......................................... 239
Wheels and tires ................................... 241
Information on noise or unusual driving
characteristics......................................... 241
Notesonregularly inspecting wheels
and tires ...................................................241
Information on driving withsummer
tires ......................................................... 241
Information on M+S tires .........................242
Notesonsnowchains .............................242
Tire pressure........................................... 243
Loading thevehicle ................................. 250
Tire labeling .............................................252
Informationondefinitions (tires and
loading) ................................................... 256
Changing awheel ....................................257
Spare wheel ............................................ 265
Technical data ....................................... 270
Information on technicaldata.................. 270
On-boardelectronics ...............................270
Vehicle identification plate, vehicle
identification number (VIN) and engine
number ....................................................271
Operating fluids and capacities ...............273
Vehicle data............................................. 281
Trailer hitch ............................................. 282
Lashing points and carrier systems ......... 286
Displaymessages and warning and
indicator lamps ..................................... 288
Displaymessages .................................... 288
Indicator and warning lamps ...................308
Index ....................................................... 319
Contents 3

In these Operating Instructions, youwill find the
following symbols:
&DANGER Dangerdue to notobserving
thewarning notices
Warning notices draw your attention to haz‐
ards that mayendanger your healthorlife, or
thehealthorlifeofothers.
#Observe thewarning notices.
+ENVIRONMENTAL NOTE Environmental
damagedue to failuretoobserve environ‐
mental notes
Environmental notesinclude information on
environmentally responsible behavior or envi‐
ronmentally responsible disposal.
#Observe environmentalnotes.
*NOTE Damage to property due to failure
to observe notesonmaterial damage
Notesonmaterial damageinformyou of risks
whichmay lead to your vehicle being dam‐
aged.
#Observe notesonmaterial damage.
%These symbols indicateuseful instructions or
further information that could be helpful to
you.
XInstructions
(Q
page)
Further information on atopic
Display Displayinthe multifunction display/
media display
+Highestmenu leveltobeselected in
themultimedia system
*Corresponding submenus to be selec‐
tedinthe multimedia system
*Indicates acause
4Symbols

1Combination switch
Turn signals →82
High beam →82
Windshield wipers →92
Rear window wiper →92
2Steering wheel buttons →172
3DIRECT SELECTlever →119
4Inside rearviewmirror →95
5Overheadcontrol panel →84
6DIN slot,e.g. formounting a
tachograph or thetimer forthe
stationaryheater
7Sun screen →95
8Co-driver's powerwindow
switch
→57
9Centrallocking →46
AStowagecompartment cover →239
BCo-driver's stowagecompart‐
mentortachograph housing
CCup holders →75
DClimatecontrol system →96
EMBUX multimedia system dis‐
play
→182
FMBUX multimedia system con‐
trol elements
→184
G12 Vsocket →77
H230 Vsocket
IOpens and closes theelectric
sliding door
→49
JHazardwarning lamps →82
KVehicles withKEYLESSSTART:
keyslot
→107
LUSB port →74
MStart/stop button →107
NRight-hand switch panel
Activates/deactivatesall-wheel
drive
→122
Engages/disengages LOW
RANGE
→123
Activates/deactivatesDSR →124
Raises/lowers thevehicle level →126
Activates/deactivatespower
take-off
Activates/deactivatesworking
speed control (ADR)
→164
Activates/deactivatescargo
compartment ventilation
→105
Activates/deactivatesthe
rotating beacon
OSteering wheel gearshiftpad‐
dles
→121
6At aglance–Cockpit

POpens thehood →211
QLeft-hand switchpanel
Sets theworking speed (ADR) →164
RLight switch
Headlamprangeadjuster
SAdjusts driver'sseat →63
TSeatheating →73
Centrallocking →46
UDriver's powerwindowswitch →57
At aglance–Cockpit 7

Version 1ofthe overhead controlpanel
1Sun visors →95
2Breakdown assistance callbut‐
ton(Mercedes PROconnect)
3ÌActivates/deactivates
interior protection
→60
Activates/deactivatesthe bus
interior lighting
4pSwitches theleft-hand
reading light on/off
5|Switches automatic light
controlon/off
6cSwitches thefront inte‐
rior lighting on/off
7wSwitches therear interior
lighting on/off
8pSwitches theright-hand
reading light on/off
9ËSwitches thetow-away
alarmon/off
→59
AEyeglasses compartment →75
BGSOS emergency callsys‐
tem
CATAindicatorlamp
8At aglance–Overhead control panel

Version 2ofthe overhead controlpanel
1Sun visors →95
2pSwitches theleft-hand
reading light on/off
3|Switches automatic light
controlon/off
4cSwitches thefront inte‐
rior lighting on/off
5wSwitches therear interior
lighting on/off
6pSwitches theright-hand
reading light on/off
At aglance–Overhead control panel 9

Version 3ofthe overhead controlpanel
1Sun visors →95
2|Switches automatic light
controlon/off
3cSwitches thefront inte‐
rior lighting on/off
→60
4wSwitches therear interior
lighting on/off
10 At aglance–Overhead control panel

Version 4ofthe overhead controlpanel
1Sun visors →95
2Switches theinterior lighting
on/off
At aglance–Overhead control panel 11

Overhead control panel forvehicles withbus equipment
1Sun visors →95
2FBreakdown assistance
callbutton
3Switches thebus func‐
tion on/off
→86
4pSwitches thereading
light on/off, left
5|Switches automatic light
controlon/off
→86
6cSwitches thefront inte‐
rior lighting on/off
7wSwitches therear interior
lighting on/off
→86
8pSwitches thereading
light on/off, right
9Switches reading lightsinthe
passenger compartment
on/off
→86
AEyeglasses compartment →75
12 At aglance–Overhead control panel

Door control panel in vehicles withelectricallyadjustable seats
1To adjustthe outside mirrors →94
2To activate/deactivatethe cen‐
trallocking system
→47
3To switchseat heating on/off →73
4To adjustthe front seats elec‐
tronically
→64
5To operatethe memoryfunc‐
tion
→66
6To open adoor →46
7To open/close theright-hand
side window
→55
8To open/close theleft-hand
side window
→55
At aglance–Doorcontrol panel 13

Door control panel vehicles without electricallyadjustable seats
1To adjustthe outside mirrors →94
2To activate/deactivatethe cen‐
trallocking system
→47
3To switchseat heating on/off →73
4To open adoor →46
5To open/close theright-hand
side window
→55
6To open/close theleft-hand
side window
→55
14 At aglance–Door control panel

1Checkingand topping up oper‐
ating fluids
→273
Startingassistance →228
2Buttons forthe SOS emergency
call system and roadside assis‐
tance
→226
3Warning lamp →225
Safetyvest →225
First-aidkit (soft sided) →225
4Vehicles withrear-wheel drive:
hydraulic jackand tire-change
tool kit
→239
5Hazardwarning lights →82
6QR code foraccessing theres‐
cue card
→24
7To disconnect thestarter bat‐
tery
→231
8Fuel filler flap withinstruction
labels fortirepressure,fuel
type and QR code foraccess‐
ing therescue card
→130
9Flattire →227
At aglance–Emergencies andbreakdowns 15

ASpare wheel (example) →265
16 At aglance–Emergenciesand breakdowns

Environmental protection
+ENVIRONMENTAL NOTE Environmental
damagedue to operating conditions and
personal driving style
The pollutant emission of thevehicle is
directlyrelated to thevehicle's operation.
Operateyour vehicle in an environmentally
responsible manner to help protect theenvi‐
ronment. Please observe thefollowing recom‐
mendations on operating conditions and per‐
sonaldriving style.
Operating conditions:
#Makesurethat thetirepressures are
alwayscorrect.
#Do nottransportany unnecessary
weight (e.g. aroof rack whichisnolon‐
gerrequired).
#Observe theservice intervals.
Aregularly serviced vehicle will contrib‐
utetoenvironmentalprotection.
#Alwayshave maintenance work carried
out at aqualified specialistworkshop.
Personal driving style:
#Do notdepress theacceleratorpedal
when startingthe engine.
#Do notwarmupthe engine while sta‐
tionary.
#Drivecarefully and maintainasufficient
distance to other vehicles.
#Avoid frequent, sudden acceleration and
braking.
#Shiftgearsingood timeand use each
gear onlyuptoÔof its maximum
engine speed.
#Switchoff theengine when in stationary
trafficfor aprolonged time.
#Driveinafuel-efficient manner. Pay
attention to theECO displayfor afuel-
efficient driving style.
Environmental issues and recommendations
It is recommended to re-useand recycle substan‐
ces instead of immediatelydisposingofthem.
The relevant environmental guidelinesand regula‐
tions serve to protect theenvironmentand
should be followedcarefully.
Freightliner Sprinter Genuine Parts
+ENVIRONMENTAL NOTE Environmental
damagecaused by notusing recycled
reconditionedcomponents
Mercedes-Benz AG offers recycled recondi‐
tionedcomponents and partswiththe same
quality as newparts.The same entitlement
from theLimited Warrantyisvalid as fornew
parts.
#Recycled reconditionedcomponents
and partsfromMercedes-Benz AG.
*NOTE The effectivenessofthe restraint
systems can be impaired by installing
accessoryparts, performing repairsor
welding operations
Airbags, Emergency Tensioning Devicesas
well as control unitsand sensorsfor the
restraint systems can be installed in thefol‐
lowing areas of thevehicle:
RDoor frames
RRoof frames
RDoors
RDoor pillars
RDoor sills
RSeats
RCockpit
RInstrument cluster
RCenter console
#Do notinstall anyaccessories suchas
audio systems in these areas.
#Do notperform repairsorwelding oper‐
ations.
#Have accessory parts installed at a
qualified specialistworkshop.
If youuse parts,tires, wheelsorsafety-relevant
accessories whichhavenot been approvedby
Freightliner Sprinter ,the operating safetyofthe
vehicle maybejeopardized. Safety-relevant sys‐
tems, e.g. thebrake system, maymalfunction.
Onlyuse Freightliner Sprinter Genuine Partsor
parts of equal quality.Use onlytires, wheels and
accessories that areapprovedfor your vehicle
model.
Freightliner Sprinter testsgenuine parts, conver‐
sion parts and accessoryparts that have been
approvedfor your vehicle model forreliability,
General notes 17

safetyand suitability. Despiteongoing market
research,weare unable to assessother parts.
We thereforeacceptnoresponsibility forthe use
of suchparts in Freightliner Sprinter vehicles,
eveniftheyhavebeen officially approvedorinde‐
pendentlyapproved by atesting center.
In some other countries, certain parts areonly
officially approvedfor installation or modification
if they comply with legal requirements. All
Freightliner Sprinter Genuine Partssatisfy these
requirements. Makesurethat all parts aresuita‐
ble foryour vehicle.
Alwaysspecify thevehicle identification number
(VIN) and theengine number when ordering
Freightliner Sprinter Genuine Parts
(/page271).
Notesabout attachments, add-on equip‐
ment, installations and conversions
Forsafetyreasons, have add-on equipmentpro‐
ducedand installed in accordancewiththe valid
Freightliner Sprinter body/equipment mounting
directives. These body/equipment mounting
directives ensurethat thechassisand add-on
equipmentformone unit and that thegreatest
possible levelofoperational and driving safetyis
achieved.
Both vehicle manufacturersand body manufac‐
turersmustalwaysensurethat theproducts they
manufacturecome intocirculation onlyinasafe
stateand do notpose anyriskstopeople. Other‐
wise, theremay be consequences under civil,
criminal or public law. All manufacturersare
responsible forthe products that they have man‐
ufactured. Manufacturersofattachments, add-on
equipment, installationsand conversions must
guarantee compliancewithDirective
2001/95/ECongeneral product safety.
Freightliner Sprinter recommends thefollowing
procedurefor safetyreasons:
RDo notmakeany other changes to thevehi‐
cle.
RObtain approval from thedealer named on
theinside title pageinthe event of deviations
from theapprovedbody/equipment mounting
directives.
Acceptance testsperformed by public test bodies
or officialapprovals do notrule out safetyrisks.
Observe theinformation about Freightliner
Sprinter Genuine Parts(/page17).
%Youcan obtain further information at aquali‐
fied specialistworkshop.
&WARNING Risk of accident and injuryin
theevent of incorrect conversions or
changes to thevehicle
Conversions or changes to thevehicle can
impair thefunction of systems or compo‐
nents.
As aresult, they maynolonger function as
intended and/or endanger theoperating
safetyofthe vehicle.
#Alwayshave conversions or changes to
thevehicle made at aqualified work‐
shop.
If youintend to makechanges to your vehicle,
Freightliner Sprinter urgentlyrecommends con‐
tacting thedealer,who will giveyou all theinfor‐
mation youneed. Theremay be achargefor this
service.
If body manufacturersand dealersmakemodifi‐
cations that affect thefinalinspection of the
engine, vehicle or equipment, they mustaccept
sole responsibility forthe vehicle. This also
appliestomarking and documenting thevehicle
parts affected by thechanges that they make.
Youare responsible forcertifying and providing
evidencethat thefollowing conditionsare met:
RThe vehicle complies withall relevant stand‐
ards and regulations that areaffected by the
modification.
RThe modified vehicle still meets thevehicle
safetystandards and emission regulations.
RThe modification does notimpair thesafetyof
thevehicle.
Freightliner is notresponsiblefor thefinalinspec‐
tion, product liability or warrantyclaimsresulting
from modification. This applies forthe following
points:
Rthemodified components or systems
Rtheresultant violationofemission regulations
or vehicle safetystandards
Rall consequences resulting from themodified,
less safeorevenfaulty vehicle
Freightliner accepts no responsibility as final
manufacturer or forthe resultant product liability.
Even seemingly minor changes to thevehicle,
suchasattaching aradiator grill in winter,are not
18 Generalnotes
