Frico Thermozone PA3500 User manual

PA3500/4200
.... 27
SE .... 33 EN
Original instructions
.... 38
NO .... 44 DE .... 51 ES
.... 57
FR .... 64 IT .... 71 NL .... 78 PL .... 84 RU
.... 90
FI

PA3500/4200
2
Introduktionssidorna består huvudsakligen av bilder. För översättning av de
engelska texter som används, se respektive språksidor.
SE
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the respective language pages.
EN
Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de
engelske tekstene, se de respektive språksidene.
NO
Les pages de présentation contiennent principalement des images. Pour la
traduction des textes en anglais, consultez la page correspondante à la langue
souhaitée.
FR
Die Einleitungsseiten bestehen hauptsächlich aus Bildern. Für die Übersetzung
der verwendetenTexte in englischer Sprache, siehe die entsprechenden
Sprachseiten.
DE
Las páginas introductorias contienen básicamente imágenes. Consulte la
traducción de los textos en inglés que las acompañan en las páginas del
idioma correspondiente.
ES
De inleidende pagina's bevatten hoofdzakelijk afbeeldingen. Voor een vertaling
van de gebruikte Engelse teksten, zie de pagina's van de resp. taal.
NL
Le pagine introduttive contengono prevalentemente immagini. Per le
traduzioni dei testi scritti in inglese, vedere le pagine nelle diverse lingue.
IT
Początkowe strony zawierają głównie rysunki. Tłumaczenie wykorzystanych
tekstów angielskich znajduje się na odpowiednich stronach językowych.
PL
RU Страницы в начале Инструкции состоят в основном из рисунков, схем и
таблиц. Перевод встречающегося там текста приведен в разделе RU.
Esittelysivut koostuvat lähinnä kuvista. Suvuilla olevien enlanninkielisten
sanojen käännökset löytyvät ko. kielisivuilta.
FI

PA3500/4200
3
PA3500
525
L
270 36
43
40
127
1, 1,5 m: 4 x M8
2 m: 6 x M8
2,5 m: 8 x M8
205 92
364
A
L
[mm] A [mm]
PA3510 1039 40
PA3515 1549 40
PA3520 2039 40
PA3525 2549 39
DN20 (3/4"),
outside thread
SIRe
PA 2 m; 2,5 m
L1
[mm] L2 [mm]
PA3515 1572 1515
PA3520 2062 2004
PA3525 2572 2515
270 36 525
L1
L2
23
40

PA3500/4200
4
611
L
295 36
40
127
A
43 235 102
404
1, 1,5 m:4 M8
2 m: 6 M8
2,5 m: 8 M8
PA4200
DN20 (3/4"), outside thread
SIRe
PA 2 m; 2,5 m
L
[mm] A [mm]
PA4210 1039 40
PA4215 1549 40
PA4220 2039 40
PA4225 2549 39
295 36 611
40
23
L2
L1
L1
[mm] L2 [mm]
PA4215 1572 1515
PA4220 2062 2004
PA4225 2572 2515

PA3500/4200
5
2
1
Fig. 1A: Open the unit by raising the front panel.
The front is blocked in open position with the
front hatch hook.
Fig. 2: Control card SIRe is integrated in the air
curtain at delivery.
SIRe
Fig. 1B: When the front has been removed it it
important to be sure it is firmly seated in the front
locks again.
min 100
Fig. 3: Minimum distance.
BA
Filling the water coil
Fig. 4
A B
C D

PA3500/4200
6
AB
A
127L
B
127875875
AB
127770745745
Fig. 5: M8-holes for mounting.
L
[mm]
PA3510 750
PA4210 750
PA3515 1260
PA4215 1260
A
[mm] B [mm]
PA3500 205 92
PA4200 235 102
PA3510/PA3515/PA4210/PA4215
PA3520/PA4220
PA3525/PA4225

PA3500/4200
7
Fig. 6: See separate manual for PA34WB.
PA3500/4200 + PA34WB
20 mm
A
B
C
D
E
F
PA34WB
79
19
120
11
40
40 40
Type Quantity
included
Length Fig. E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
PA34WB15 PA3510/15, PA4210/15 2 pcs 400 mm Fig. 6 87 505 68 673 91 18 49 320 82
PA34WB20 PA3520, PA4220 3 pcs 400 mm Fig. 6 87 505 69 673 91 19 49 320 83
PA34WB30 PA3525, PA4225 4 pcs 400 mm Fig. 6 87 505 70 673 91 20 49 320 84

PA3500/4200
8
Fig. 7: PA34TR + PA34CB + PA34VD.
See separate manual for PA34TR.
Fig.8: PA34WS + PA34CB
See separate manual for PA34WS.
Fig. 9: See separate manual for PA3JK / PA4JK.
PA3JK
PA4JK
PA34WS
(PA34CB)
PA34TR
(PA34VD)
PA34CB
Type Quantity
included
Length E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
PA34CB15 PA3510/15, PA4210/15 4 pcs 87 505 71 673 91 21 49 320 59
PA34CB20 PA3520, PA4220 6 pcs 87 505 72 673 91 22 49 320 60
PA34CB30 PA3525, PA4225 8 pcs 87 505 73 673 91 23 49 320 61
PA34WS15 PA3510/15, PA4210/15 4 pcs 3 m 87 505 37 673 90 97 49 322 05
PA34WS20 PA3520, PA4220 6 pcs 3 m 87 505 38 673 90 98 49 322 06
PA34WS30 PA3525, PA4225 8 pcs 3 m 87 505 39 673 90 99 49 322 07
PA34TR15 PA3510/15, PA4210/15 4 pcs 1 m 87 505 32 673 90 94
PA34TR20 PA3520, PA4220 6 pcs 1 m 87 505 34 673 90 95
PA34TR30 PA3525, PA4225 8 pcs 1 m 87 505 35 673 90 96
PA34VD15 PA3510/15, PA4210/15 4 pcs 87 505 74 673 91 24
PA34VD20 PA3520, PA4220 6 pcs 87 505 75 673 91 25 49 320 96
PA34VD30 PA3525, PA4225 8 pcs 87 505 76 673 91 26 49 320 97
Type E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
PA3JK PA3500 87 515 22 673 11 96 54 300 07
PA4JK PA4200 87 515 23 673 11 97 54 300 08
Accessories

PA3500/4200
9
Fig. 10: See separate manual for
PA3XT / PA4XT.
Accessories
See separate manual for PA3DW/
PA4DW.
Type Dimensions E-nr
(SE)
RSK-nr
(SE)
PA3DW10 PA3510 87x382x1006 mm 87 505 77 673 91 27
PA3DW15 PA3515 87x382x1516 mm 87 505 78 673 91 28
PA3DW20 PA3520 87x382x2006 mm 87 505 79 673 91 29
PA3DW25 PA3525 87x382x2516 mm 87 505 80 673 91 30
PA4DW10 PA4210 87x424x1006 mm 87 505 81 673 91 31
PA4DW15 PA425 87x424x1516 mm 87 505 82 673 91 32
PA4DW20 PA4220 87x424x2006 mm 87 505 83 673 91 33
PA4DW25 PA4225 87x424x2516 mm 87 505 84 673 91 34
Type Length E-nr
(SE)
RSK-nr
(SE)
PA3XT10 PA3510 130-200 mm 87 505 42 673 91 00
PA3XT15 PA3515 130-200 mm 87 505 43 673 91 01
PA3XT20 PA3520 130-200 mm 87 505 44 673 91 02
PA3XT25 PA3525 130-200 mm 87 505 45 673 91 03
PA4XT10 PA4210 130-200 mm 87 505 46 673 91 04
PA4XT15 PA4215 130-200 mm 87 505 47 673 91 05
PA4XT20 PA4220 130-200 mm 87 505 48 673 91 06
PA4XT25 PA4225 130-200 mm 87 505 49 673 91 07
PA3510, PA4210: 2 pcs
PA3515, PA4215: 2 pcs
PA3520, PA4220: 3 pcs
PA3525, PA4225: 4 pcs
See separate manual for PA3DC /
PA4DC.
Type Length E-nr
(SE)
RSK-nr
(SE)
PA3DCS PA3500 200-300 mm 87 505 60 673 91 08
PA3DCM PA3500 300-500 mm 87 505 61 673 91 09
PA3DCL PA3500 500-900 mm 87 505 62 673 91 10
PA3DXT PA3500 420 mm 87 505 63 673 91 11
PA4DCS PA4200 200-300 mm 87 505 64 673 91 12
PA4DCM PA4200 300-500 mm 87 505 65 673 91 13
PA4DCL PA4200 500-900 mm 87 505 66 673 91 14
PA4DXT PA4200 420 mm 87 505 67 673 91 15
PA3DW
PA4DW
PA3DC
PA4DC

PA3500/4200
10
Accessories
Note!The air curtain
must be secured in
the wall or ceiling.
Fig. 11: See separate manual for PA3JK /
PA4JK.
PA3VDW
PA4VDW
PA3JK
PA4JK

PA3500/4200
11
AXP300PA3VDW
PA4VDW
PA3JK
PA4JK
Type E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
NRF-nr
(NO)
PA3JK PA3500 87 515 22 673 11 96 54 300 07 85 023 71
PA4JK PA4200 87 515 23 673 11 97 54 300 08 85 023 72
PA3VDW15 PA3515 87 515 16 673 20 83 54 300 01
PA3VDW20 PA3520 87 515 17 673 20 84 54 300 02
PA3VDW25 PA3525 87 515 18 673 20 85 54 300 03
PA4VDW15 PA 4215 87 515 19 673 20 86 54 300 04
PA4VDW20 PA 4220 87 515 20 673 20 87 54 300 05
PA4VDW25 PA 4225 87 515 21 673 20 88 54 300 05
PA3HE PA3500
PA4HE PA4200
PA3HEVDW PA3500
PA4HEVDW PA4200
AXP300 PA3500/4200 87 514 87 672 69 77
Accessories
Type Length RSK-nr
(SE)
PA34EF10 PA3510W, PA4210W 673 20 95
PA34EF15 PA3515W, PA425W 673 20 96
PA34EF20 PA3520W, PA4220W 673 20 97
PA34EF25 PA3525W, PA4225W 673 20 98
DTV200S PA3500/4200W 673 91 16
FHDN20 PA3500/4200W 350 mm 673 91 17
FHDN2010 PA3500/4200W 1000 mm 670 45 65
See separate manual for
FHDN20.
See separate manual for
PA34EF.
DTV200S
PA3HE(VDW)
PA4HE(VDW)

PA3500/4200
12
Type E-nr
(SE)
RSK-nr
(SE)
EL-nr
(NO)
NRF-nr
(NO)
Dimensions Length
SIReBN
87 506 57 673 19 43 54 090 04 85 025 82
SIReACY
87 506 61 673 21 00 54 090 08 85 025 85
SIReAAY
87 506 62 673 24 06 54 090 09 85 025 86
SIReRTX
87 510 12
673 09 22
54 910 01 85 022 94
70x33x23 mm
SIReUR
87 510 11
673 09 21
49 325 00 85 022 93
114x70x50 mm
SIReWTA
673 09 69
SIReCJ4
87 510 33 673 09 70 54 910 02
SIReCJ6
87 510 34 673 09 71
85 025 24
SIReCC603
87 510 13
673 09 23
54 329 01 85 022 95
3 m
SIReCC605
87 510 14
673 09 24
54 329 02 85 022 96
5 m
SIReCC610
87 510 15
673 09 25
54 329 03 85 022 97
10 m
SIReCC615
87 510 16
673 09 26
54 329 04 85 022 98
15 m
SIReCC640
87 510 45
673 18 79 40 m
SIReCC403
87 510 17
673 09 27
54 329 05 85 022 99
3 m
SIReCC405
87 510 18
673 09 28
54 329 06 85 023 01
5 m
SIReCC410
87 510 19
673 09 29
54 329 07 85 023 02
10 m
SIReCC415
87 510 20
673 09 30
54 329 08 85 023 03
15 m
Accessories
C
SIReBN SIReACY
SIReAAY
SIReRTX SIReUR SIReWTA SIReCCSIReCJ4/SIReCJ6
SDM24 ST23024
VKF
VLP
Type RSK-nr
(SE)
NRF-nr
(NO)
Connection
VLSP15LF
670 45 35
DN15
VLSP15NF
670 45 36
85 026 36 DN15
VLSP20
670 45 37
85 026 37 DN20
VLSP25
670 45 38
85 026 38 DN25
VLSP32
670 45 39
85 026 39 DN32
VLP15LF
670 45 30
67 309 47 DN15
VLP15NF
670 45 31
85 026 31 DN15
VLP20
670 45 32
85 026 32 DN20
VLP25
670 45 33
85 026 33 DN25
VLP32
670 45 34
85 026 34 DN32
VOT15 673 61 93 85 024 05 DN15
VOT20 673 61 94 85 024 06 DN20
VOT25 673 61 95 85 024 07 DN25
VMT15 DN15
VMT20 DN20
VMT25 DN25
SD230 BPV10
VKF
VLSP
VOT
SD230
TRVS
VMT
TRVS SDM24 ST23024

PA3500/4200
13
PA3500 A
PA4200 A
SIReB1
Actuator
230V~
Transformer
230V
200V
170V
145V
120V 100V
N
Black
Blue
White
White
Supply
230V~
C2 C1 ROOM
Internal
sensor
Motor
protection
230V~
Transformer
230V
200V
170V
145V
120V 100V
N
Yellow Orange Red Brown Black Green Blue
PA4210A
°C°C°C
PA4215A
°C°C°C°C
PA4225A PA4220A
PA3515A PA3510A
PA3525A PA3520A

PA3500/4200
14
PA3500 E
PA4200 E
PA3510E PA4210E PA3520E/3525E
PA4220E/4225E
PA3510E/3515E PA4210E/4215E
400V3~
SIReB1
400V3~
Actuator
230V~
Transformer
230V
200V
170V
145V
120V 100V
N
Black Black
Grey
Blue Blue
White
White
C2 C1 ROOM
Internal
sensor
Motor
protection
°C°C°C
Transformer
230V
200V
170V
145V
120V 100V
N
Yellow Orange Red Brown Black Green Blue
N N
PA3515E PA4215E
°C°C°C°C
PA3525E PA4225E
PA3520E PA4220E
230V~

PA3500/4200
15
PA3500 W
PA4200 W
SIReB1
230V~
Actuator
230V~
Transformer
230V
200V
170V
145V
120V 100V
N
Black
Blue
White
White
Supply
230V~
C2 C1 ROOM
Internal
sensor
Motor
protection
Transformer
230V
200V
170V
145V
120V 100V
N
Yellow Orange Red Brown Black Green Blue
PA3510W PA4210W
°C°C°C
PA3515W PA4215W
°C°C°C°C
PA3225W PA4225W
PA3520W PA4220W

PA3500/4200
16
PA4215E/4220E/422 PA4210E PA 4210E/4215E
230V3~
SIReB1
Actuator
230V~
Transformer
230V
200V
170V
145V
120V
100V
N
Black
Black
Grey
Blue
Blue
White
White
C2 C1 ROOM
Internal
sensor
Motor
protection
°C°C°C°C
Transformer
230V
200V
170V
145V
120V
100V
N
Yellow
Orange
Red
Brown
Black
Green
Blue
N N
PA 4220E/4225E
230V3~
230V~
PA3500 E 230V3~
PA4200 E 230V3~
Type Output
step
[kW]
Airflow*1
[m3/h]
∆t*3
[°C]
Sound
level*2
[dB(A)]
Motor
[W]
Voltage
motor
[V]
Amp.
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
PA4210E12D 3,9/7,8/12 950/2400 38/15 46/66 920 230V~ 4,0 230V3~/30 1039 50
PA4215E18D 6,0/12/18 1300/3500 42/16 47/67 1260 230V~ 5,5 230V3~/45 1549 71
PA4220E24D 7,8/15/23 1900/4800 37/14 48/68 1840 230V~ 8,0 230V3~/60 2039 94
PA4225E30D 9,9/20/30 2300/5900 39/15 49/69 2140 230V~ 9,3 230V3~/75 2549 11 3
Type Output
step
[kW]
Airflow*1
[m3/h]
∆t*3
[°C]
Sound
level*2
[dB(A)]
Motor
[W]
Voltage
motor
[V]
Amp.
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
PA3510E08D 2,7/5,4/8,1 900/2000 27/12 41/61 580 230V~ 2,6 230V3~/20,3 1039 44
PA3515E12D 3,9/7,8/12 1400/3100 26/12 42/62 880 230V~ 3,9 230V3~/29,3 1549 63
PA3520E16D 5,4/11/16 1750/4000 28/12 43/63 11 3 0 230V~ 5,0 230V3~/40,5 2039 80
PA3525E20D 6,6/13/20 2400/5250 25/11,5 44/64 1500 230V~ 6,5 230V3~/49,5 2549 104
Protection class for units with electrical heating: IP20.
CE compliant.
*1) Lowest/highest airflow of totally 5 fan steps.
*2) Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area: 200 m².
*3) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.

PA3500/4200
17
SIReB Basic
PA3500/4200 A
PA3500/4200 E
Wiring diagrams for SIReAC Competent, see manual for SIRe.
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
SIReCC6XX (max 50 m)
SIReCC6XX
(max 50 m)
SIReCC6XX
(max 50 m)
SIReUB1
SIReRTX
(optional)
L=2m
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReB1/B2/B1EC

PA3500/4200
18
SIReB Basic
PA3500/4200 W
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
SIReCC6XX (max 50 m)
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReCC6XX
(max 50 m)
SIReCC6XX
(max 50 m)
SIReUB1
SIReRTX
(optional)
SD230
SD230
SD230
L=1,5m
L=2m
Wiring diagrams for SIReAC Competent and SIReAA Advanced, see manuals for SIRe.

PA3500/4200
19
3Electrical heat - PA3500 E
2Water heat - PA3500 WL
1Ambient, no heat - PA3500 A
Technical specifications PA3500
2Water heat - PA3500 WH
2Water heat - PA3500 WLL
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
*1) Lowest/highest airflow of totally 5 fan steps.
*2) Sound power (LWA) measurements according to ISO 27327-2: 2014, Installation type E.
*3) Sound pressure (LpA). Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent
absorption area: 200 m². At lowest/highest airflow.
*4) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*5) Applicable at water temperature 60/40 °C, air temperature, in +18 °C.
*6) Applicable at water temperature 80/60 °C, air temperature, in +18 °C.
*7) Applicable at water temperature 40/30 °C, air temperature, in +18 °C.
Type Output
[kW]
Airflow*1
[m3/h]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA3510A 0 900/2000 78 41/61 580 230V~ 2,6 1039 36
PA3515A 0 1400/3100 79 42/62 880 230V~ 3,9 1549 50
PA3520A 0 1750/4000 79 43/63 11 3 0 230V~ 5,0 2039 65
PA3525A 0 2400/5250 80 44/64 1500 230V~ 6,5 2549 79
Type Output
step
[kW]
Airflow*1
[m3/h]
∆t*4
[°C]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
PA3510E08 2,7/5,4/8,1 900/2000 27/12 78 41/61 580 2,6 400V3~/11,7 1039 44
PA3515E12 3,9/7,8/12 1400/3100 26/12 79 42/62 880 3,9 400V3~/16,9 1549 63
PA3520E16 5,4/11/16 1750/4000 28/12 80 43/63 11 3 0 5,0 400V3~/23,4 2039 80
PA3525E20 6,6/13/20 2400/5250 25/11,5 81 44/64 1500 6,5 400V3~/28,6 2549 104
Type Output*5
[kW]
Airflow*1
[m3/h]
∆t*4,5
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA3510WL 12 950/1900 23/19 1,5 76 43/60 540 2,35 1039 43
PA3515WL 19 1350/2900 25/20 2,4 77 44/61 770 3,4 1549 60
PA3520WL 26 1800/3900 25/20 3,3 78 45/62 970 4,3 2039 75
PA3525WL 35 2300/5100 25/20 4,2 79 46/63 1310 5,7 2549 95
Type Output*6
[kW]
Airflow*1
[m3/h]
∆t*4,6
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA3510WH 10 950/1900 21/16 1,0 76 43/60 540 2,35 1039 42
PA3515WH 16 1350/2900 22/17 1,6 77 44/61 770 3,4 1549 58
PA3520WH 23 1800/3900 23/17 2,2 78 45/62 970 4,3 2039 73
PA3525WH 29 2300/5100 23/17 2,9 79 46/63 1310 5,7 2549 92
Type Output*7
[kW]
Airflow*1
[m3/h]
∆t*4,7
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA3510WLL 7, 6 900/1850 14/12 2,0 75 43/60 460 2,0 1039 44
PA3515WLL 11 1300/2750 14/12 4,1 76 44/61 740 3,25 1549 63
PA3520WLL 16 1700/3700 15/13 5,6 77 45/62 920 4,0 2039 78
PA3525WLL 21 2250/4900 15/13 8,3 78 46/63 1280 5,6 2549 100
Voltage motor: 230V~

PA3500/4200
20
3Electrical heat - PA4200 E
2Water heat - PA4200 WL
1Ambient, no heat - PA4200 A
Technical specifications PA4200
2Water heat - PA4200 WH
2Water heat - PA4200 WLL
Type Output
[kW]
Airflow*1
[m3/h]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210A 0 950/2400 82 46/66 920 230V~ 4,0 1039 43
PA4215A 0 1300/3500 83 47/67 1260 230V~ 5,5 1549 56
PA4220A 0 1900/4800 84 48/68 1840 230V~ 8,0 2039 75
PA4225A 0 2300/5900 85 49/69 2140 230V~ 9,3 2549 91
Type Output
step
[kW]
Airflow*1
[m3/h]
∆t*4
[°C]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
PA4210E12 3,9/7,8/12 950/2400 38/15 82 46/66 920 4,0 400V3~/16,9 1039 50
PA4215E18 6,0/12/18 1300/3500 42/16 83 47/67 1260 5,5 400V3~/26,0 1549 71
PA4220E24 7,8/15/23 1900/4800 37/14 84 48/68 1840 8,0 400V3~/33,8 2039 94
PA4225E30 9,9/20/30 2300/5900 39/15 85 49/69 2140 9,3 400V3~/42,9 2549 11 3
Type Output*5
[kW]
Airflow*1
[m3/h]
∆t*4,5
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210WL 16 1050/2600 25/18 1,9 80 44/64 920 4,0 1039 50
PA4215WL 25 1600/3800 25/19 3,0 81 45/65 1330 5,8 1549 67
PA4220WL 35 2200/5300 25/19 4,1 82 46/66 1930 8,4 2039 90
PA4225WL 44 2800/6400 26/20 5,2 83 47/67 2280 9,9 2549 109
Type Output*6
[kW]
Airflow*1
[m3/h]
∆t*4,6
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210WH 14 1050/2600 22/16 1,3 80 44/64 920 4,0 1039 49
PA4215WH 21 1600/3800 22/16 2,0 81 45/65 1330 5,8 1549 65
PA4220WH 30 2200/5300 23/17 2,7 82 46/66 1930 8,4 2039 87
PA4225WH 36 2800/6400 22/16 3,8 83 47/67 2280 9,9 2549 105
Type Output*7
[kW]
Airflow*1
[m3/h]
∆t*4,7
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210WLL 10 1000/2500 15/12 2,5 80 44/64 920 4,0 1039 52
PA4215WLL 15 1500/3600 15/13 4,7 81 45/65 1330 5,8 1549 70
PA4220WLL 21 2100/5200 15/12 7, 5 82 46/66 1930 8,4 2039 95
PA4225WLL 26 2700/6200 15/12 9,6 83 47/67 2280 9,9 2549 11 5
Voltage motor: 230V~
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
*1) Lowest/highest airflow of totally 5 fan steps.
*2) Sound power (LWA) measurements according to ISO 27327-2: 2014, Installation type E.
*3) Sound pressure (LpA). Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent
absorption area: 200 m². At lowest/highest airflow.
*4) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*5) Applicable at water temperature 60/40 °C, air temperature, in +18 °C.
*6) Applicable at water temperature 80/60 °C, air temperature, in +18 °C.
*7) Applicable at water temperature 40/30 °C, air temperature, in +18 °C.
