Frico TPT16 User manual

TPT16 / TPT16WF
1
EN
Setup
This manual describes the most essential
functions and technical specications of the
thermostat. These instructions help the user to
control the thermostat, and the electrician to
install and setup the thermostat.
Technical specications
Display: 1.8” TFT, 128x160 resolution
Power supply: 230V - 50/60 Hz
Maximum load: 16A (resistive)
Setpoint temperature range: +5 °C/+40 °C
Usage temperature range: 0 °C/+40 °C
Temperature setback: Pilot wire 230V - 50/60 Hz
IP class: IP21
Standard Color: White RAL9003
Sensors: Built-in room sensor and oor sensor
NTC 10kΩ included
Wi-Fi: 2.4GHz 802.11bgn (TPT16WF)
Approvals: EN 60730-1, EN 60730-2-9,
EN 300 328 V2.2.2
Installation
Installation must be done by a qualied
electrician in accordance with wiring and
building regulations.
Before installation, disconnect any power to the
thermostat’s mains. During installation of the
thermostat, power to the thermostat must be
disconnected or isolated AT ALL TIMES!
Release the front cover by pressing with
screwdriver from the ejector latch at the
bottom of the thermostat. Open the spring and
remove the frame.
Next, position the thermostat and fasten it onto
the wall’s mounting box using 2-4 screws. Open
the frame retaining spring, position the frame
and close the spring. Then attach front part,
make sure the connector between front and
bottom part is correctly placed. Press front part
until it snaps in place. Front part can later be
removed by pressing the ejector latch.
Installation and operating instructions
PILOT:
LOAD (N):
N:
L:
LOAD (L):
SENSOR:
Pilot Wire (if applicable)
Heating Cable connection (Neutral)
Power connection (Live)
Power connection (Neutral)
Floor temp sensor NTC type
Heating Cable connection (Live)
Now connect the wires to the thermostat’s
terminals:
Wires must be stripped 9-10 mm. Wires can be
released by pressing the connector’s release
pin. Floor sensor must be placed into protective
tube in concrete. Make sure there is no water in
the tube.

TPT16 / TPT16WF
2
EN
Symbols
Start-up
After connecting the power to the thermostat
for the rst time, or after performing a factory
reset, a start-up wizard will prompt the
following questions:
Note: Wooden oor requires that a oor sensor
is connected. Thus, oor temp is limited to
27 °C.
User manual
Control
The thermostat is controlled directly or
via App Frico TPT (TPT16WF), see "Wi-
settings (TPT16WF)" and "Phone applications
(TPT16WF)"
The thermostat has three touch sensitive
capacitive buttons. These are:
• Left (Up)
• Center (Conrm)
• Right (Down)
Each button has its own background light.
At any time, when any of the buttons’
backgroundlight is lit, the button is available for
use.
TIP: Holding the left button for 2 seconds at
any time, will make a quick return to the main
screen.
TIP: While browsing the thermostat’s menu,
pause at any menu item for a while, and a help
text will be shown.
Away
Anti-frost
Heating
enabled
Cooling
enabled
Wooden oor has reached the
maximum temperature 27°C,
thus heating is being limited.
Home
Gradual
heating
Power
regulation
Cooling
14:20
21.4 °C
22.5 °C
1 2 3
5
4
6
Timezone compared to
GMT
Set current date & time
Heating or cooling
Floor Temp limit
Floor (Slow), Floor (Fast),
Other (Fast)
Regulate
Gradual heating
Floor type
Heating system
Set timezone
Daylight saving in use Y/N
Date / Time
Thermostat use
Concrete or wood
ON or OFF, used with
new concrete oors to
limit temperature rise
time
Daylight saving
Room/oor or power reg.
6-40 (concrete) 6-27 (wood)
Language Set language
Load size Specify load
Open
window
function
Standby and Main screen
When the thermostat remains untouched for a
while, it will automatically go to standby screen.
While in standby, touching any of the buttons
will display the main screen below:
1. Time
2. Operation mode
3. Wi-Fi indicator (TPT16WF)
4. Heating switched
5. Setpoint
6. Measured temp
(Room or oor sensor)
In the main screen, pressing the center button
will access the main menu. Pressing left or right
button will change the set temperature.
Schedule

TPT16 / TPT16WF
3
EN
Home
Pre-set temperature while you are
home. The temperature setting can be
changed by the user and it is saved.
TIP: “Energy Consumption” shows
consumption statistics over different time
periods. Press center button to change unit or
to reset statistics.
TIP: Select “Child Lock” and press center button
three times to activate/deactivate key lock.
Menu items
Away
Pre-set (reduced) temperature while
you are away. The temperature setting
can be changed by the user and it is
saved. External pilot signal will also
change operation mode between
Home and Away.
Anti-frost
This mode drops setpoint to 7 °C. It
can be used e.g. in summer cottage
during winter time.
Power regulation
Fixed power mode, which operates
without feedback from sensors. Relay
conduction time is selected e.g. 20%
which means relay is ON 20% and 80%
OFF during the cycle time. Cycle time is
30 minutes.
Settings
Wi-Fi
Energy consumption
Child Lock
Info
Shut down Switch thermostat on/off
Thermostat information
Show energy
consumption
Adjust Wi-Fi settings
(TPT16WF)
Adjust settings
Settings
Brightness
Color theme
Standby screen
Backlight delay
Show help
Advanced settings
Dark/Light
ON/OFF
5-30s
No/2-15s
Go to advanced settings
Language Set language
Operation mode
The thermostat has three main modes: Home,
Away and Schedule. The additional modes are
Anti-frost and Power regulation.
Operation mode See "Operation Mode"
See "Schedule"Schedule
Adjust display brightness
Schedule
Create customized daily schedules to minimize
energy consumption and maximize comfort.
There can be up to ve set points per day. A
set point is given a target set time and a target
set temperature for the thermostat to regulate
automatically.
You can view your daily heating schedule in this
menu. Set points can be added and removed
according to your preferences.
TIP: Create a daily schedule for a weekday
according to your preferences. Then use the
copy/paste function to duplicate the given day’s
scheme to other weekdays.
Activate key lock
Back
Back
Schedule
Thermostat follows the settings
programmed in the Schedule menu.
Programming can also be done with
phone application(TPT16WF).
Open window function
If the room temperature drops rapidly, the
mode will be changed to Anti-Frost mode.
When the temperature raises, thermostat will
return to earlier used mode. The Open window
function will automatically deactivate after 30
minutes. The function is disabled as default.
Go back to main screen
Go back to main screen

TPT16 / TPT16WF
4
EN
Main offi ce
Frico AB Tel: [phone]
Industrivägen 41
SE-433 61 Sävedalen [email protected]
Sweden www.frico.net
For latest updated information and information
about your local contact: www.frico.net
2022-12-14 HH/CH
CONNECT TO CLOUD
134
458
Cancel
Advanced settings
WARNING: Advanced Settings is recommended
only for expert users. Consult your supplier or
use with extreme caution! Incorrect settings
may damage your oor or heating system!
Advanced settings menu contains the following
items:
*ADAPTIVITY: The thermostat will automatically
start/stop heating proactively to reach the
set temperature at the set time. If adaptivity
is switched off, the thermostat will start/stop
heating at the set time instead of operating
proactively to reach the set temperature at the
set time.
Wi-Fi settings (TPT16WF)
When the thermostat is not connected to
the cloud “Connect to cloud” can be started
from Wi-Fi settings menu. Connection is
done together with phone application “Add
thermostat”. Thermostat will show two three
digit PIN codes, which will be copied to the
phone application. The password for the
selected Wi-Fi network will be given in the
phone application.
When the Add Thermostat operation is nalized
thermostat will reboot. After the thermostat
is connected to the cloud the Wi-Fi settings
menu will offer possibility to turn Wi-Fi OFF/
ON. Existing Wi-Fi settings will be used when
turning Wi-Fi back to ON. To change Wi-Fi
network or password please use Connect to
cloud menu together with phone application’s
Recongure Wi-Fi menu.
Phone applications (TPT16WF)
Download ”Frico TPT” from App store or Google
Play.
Packaging
Packaging materials are chosen with
consideration to the environment and are
therefore recyclable.
Handling of product at end of working
life
This product may contain substances necessary
for the functionality of the product but
potentially dangerous for the environment. The
product should not be disposed of mixed with
general household waste but delivered to a
designated collection point for environmental
recycling. Please contact the local authority
for further details of your nearest designated
collection point.
Heating Setup
NTC sensor
Hysteresis
Calibration
Temperature limits
Pilot wire
*Adaptivity
Factory reset
Restart device
Change heating or
cooling setup
Change NTC type
Change temp
variation
Fine tune temp
measuring
Set limits for room and
oor temp
Change pilot wire
settings
Perform reboot
Perform full factory
reset
Back Go back to settings
See below.
L
LN
N
Sensor
<3600W
Sensor
LoadPilot
230V~/16A (AC1)
230V~
Ext.
Sensor
TPT16
°C
Wiring diagrams
