Fridgemaster MC55264DS User manual

MC55264DS
MC55264DB
MC55264DS

2
Safety and warning information_ _ _ _ _ 2
Description of the appliance _ _ _ _ _ _
Operation_ _ _ _ _ _ _ _ __ _ _ _ _ _ _
Helpful hints and tips _ _ _ _ _ _ _ _ _ _
Cleaning and care _ _ _ _ _ _ _ _ _ _ _
Installing your new appliance_ _ _ _ _ _
Reversing the door _ _ _ _ _ _ _ _ _ _ _
11
12
15
7
8
Troubleshooting_ _ _ _ _ _ _ _ _ _ _ _ _
Disposal of the appliance_ _ _ _ _ _ _ _
16
18
19
Safety for children and others
who are vulnerable people
For your safety and correct
usage, before installing and
first using the appliance,
read this user manual
carefully, including its hints
and warnings.
To avoid unnecessary
mistakes and accidents, it is
important to make sure that
all people using the appliance
are thoroughly familiar with its
operation and safety features.
Save these instructions and
be sure that they remain
with the appliance if it is
moved or sold, so that
anyone, using it throughout
its life, will be properly
informed on usage and
safety notices.
For the safety of life and
property, keep the precautions
of these user's instructions
as the manufacturer is not
responsible for damages
caused by omission.
This appliance can be used
by children aged from 8
years and above and
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
Keep all packaging away
from children as there is risk
of suffocation.
If you are discarding the
appliance, pull the plug out
of the socket, cut the
This appliance is in accordance with the following EU guidelines:
2014/35/EU and EMC 2014/30/EU and 2009/125/EC and EC 643/2009
and EU.1060/2010 and 2011/65/EU
LVD
Using your appliance _ _ _ _ _ _ _ _ _ _ 13

3
connection cable (as close
to the appliance as you
can) and remove the door
to prevent children playing
from suffering an electric
shock or from closing
themselves inside it.
If this appliance, featuring a
magnetic door seals, is to
replace an older appliance
having a spring lock (latch)
on the door or lid, be sure
to make the spring lock
unusable before you
discard the old appliance.
This will prevent it from
becoming a death trap for a
child.
General safety
WARNING - This
appliance is intended
to be used in household and
similar applications such as
-staff kitchen areas in
shops, offices and other
working environments;
-farm houses and by
clients in hotels, motels
and other residential type
environments;
-bed and breakfast type
environments;
-catering and similar non-
retail applications.
WARNING - Do not store
explosive substances
such as aerosol cans with
a flammable propellant in
this appliance.
WARNING - If the supply
cord is damaged, it must be
replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid a
hazard.
WARNING - Keep
ventilation openings, in the
appliance enclosure or in
the built-in structure, clear
of obstruction.
WARNING - Do not use
mechanical devices or other
means to accelerate the
defrosting process, other
than those
recommended by the
manufacturer.
WARNING - Do not damage
the refrigerant circuit.
WARNING - Do not use
electrical appliances inside
the food storage
compartments of the
appliance, unless they are
of the type recommended
by the manufacturer.
WARNING - The refrigerant
and insulation blowing gas
are flammable.
When disposing of the
appliance, do so only at an
authorized waste disposal
center. Do not expose to
flame.

4
power plug is not crushed
or damaged. A crushed or
damaged power plug may
overheat and cause a fire.
3. Make sure that you can
access the main plug of the
appliance.
4. Do not pull the main
cable.
5. If the power plug socket
is loose, do not insert the
power plug. There is a risk
of electric shock or fire.
6.You must not operate the
appliance without the
interior lighting lamp cover.
7.The fridge is only applied
with power supply of single
phase alternating current of
220~240V/50Hz. If
fluctuation of voltage in the
district of user is so large
that the voltage exceeds the
above scope, for safety
sake, be sure to apply A.C.
Automatic voltage regulator
of more than 350W to the
fridge. The fridge must
employ a special power
socket instead of common
one with other electric
appliances. Its plug must
match the socket with
ground wire.
The refrigerant isobutene
(R600a) is contained within
the refrigerant circuit of the
appliance, a natural gas
with a high level of
environmental compatibility,
which is nevertheless
flammable. During
transportation and
installation of the appliance,
ensure that none of the
components of the
refrigerant circuit becomes
damaged.
The refrigerant (R600a) is
flammable.
Refrigerant
If the refrigerant circuit
should be damaged:
-Avoid opening flames and
sources of ignition.
-Thoroughly ventilate the
room in which the appliance
is situated.
It is dangerous to alter the
specifications or modify this
product in any way.
Any damage to the cord
may cause a shortcircuit,
fire, and/or electric shock.
Caution:risk of
Electrical safety
1.The power cord must not
be lengthened.
2. Make sure that the
Daily use
Do not store flammable gas
or liquids in the appliance,
There is a risk of

an explosion.
Do not operate any
electrical appliances in the
appliance(e.g.electric ice
cream makers, mixers etc.).
When unplugging always
pull the plug from the mains
socket, do not pull on the
cable.
Do not place hot items near
the plastic components of
this appliance.
Do not place food products
directly against the air outlet
on the rear wall.
Store pre-packed frozen
food in accordance with the
frozen food manufacture’s
instructions.
The appliances
manufactures storage
recommendations
should be strictly adhered
to. Refer to relevant
instructions for storage.
Do not place carbonated or
fizzy drinks in the freeze
compartment as it creates
pressure on the container,
which may cause it to
explode, resulting in
damage to the appliance.
Frozen food can cause frost
burns if consumed straight
from the freezer
compartment.
Do not place the appliance
in direct sunlight.
Keep burning candles,
lamps and other items with
naked flames away from the
appliance so that do not set
the appliance on fire.
The appliance is intended
for keeping food stuff and/or
beverages in normal
household as explained in
this instruction booklet The
appliance is heavy. Care
should be taken when
moving it.
Do not remove or touch
items from the freezer
compartment if your hands
are damp/wet,as this could
cause skin abrasions or
frost/freezer burns.
Never use the base,
drawers, doors etc. to
stand on or as supports.
Frozen food must not be
refrozen once it has been
thawed out.
Do not consume ice
popsicles or ice cubes
straight from the freezer as
this can cause freezer burn
to the mouth and lips.
To avoid items falling and
causing injury or damage to
the appliance, do not
overload the door racks or
put too much food in the
crisper drawers.
5

6
leads to overheating. To
achieve sufficient
ventilation, follow the
instructions relevant to
installation.
Wherever possible the back
of the product should not be
close to a wall to avoid
touching or catching warm
parts (compressor,
condenser) to prevent the
risk of a fire, follow the
instructions relevant to
installation.
The appliance must not be
locate close to radiators or
cookers.
Make sure that the mains
plug is accessible after the
installation of the appliance.
For electrical connection
carefully, follow the
instructions given in this
manual.
Unpack the appliance and
check if there are damages
on it. Do not connect the
appliance if it is damaged.
Report possible damages
immediately to the place
you bought it. In this case
retain packing.
It is advisable to wait at
least four hours before
connecting the appliance
to allow the oil to flow
back in the compressor.
Adequate air circulation
should be around the
appliance, lacking this
Installation Important!
caution!
Care and cleaning
Before maintenance, switch
off the appliance and
disconnect the mains plug
from the mains socket.
Do not clean the appliance
with metal objects, steam
cleaner, ethereal oils,
organic solvents or abrasive
cleansers.
Do not use sharp objects to
remove frost from the
appliance. Use a plastic
scraper.
Service
Any electrical work required
to do the servicing of the
appliance should be carried
out by qualified electrician
or competent person.
This product must be
serviced by an authorized
Service Center, and only
genuine spare parts must
be used.
1)If the appliance is Frost
Free.
2)If the appliance
contains freezer
compartment.

In order to improve
efficiency of the cooling system and
save energy, it is necessary to maintain
good ventilation around the appliance. For
this reason, sufficient clear space should
be available around the refrigerator.
It is advisable for there to be at least
(50~70)mm of space from the back to the
wall, at least 100mm from its top,at last
100mm from its side to the wall and a
clear space in front to allow the doors to
open 135°. Please see the following
diagrams.
Installing your new appliance
Ventilation of appliance
Before using the appliance for the first
time, you should review the following tips.
Note:
This appliance performs well within the
climate class from SN to T showed in the
table below.
It may not work properly if left at a
temperature above or below the indicated
range for a long period.
●
Climate class Ambient temperature
SN
N
ST
T
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
Stand your appliance in a dry place to
avoid moisture damage.
Keep the appliance out of direct sunlight,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
●
●
●
1800
966
100 100
653~673
1130~1150
For sufficient leveling and air circulating in
the lower rear section of the appliance,
the bottom feet may need to be adjusted.
You can adjust them manually using a
suitable spanner.
To allow the doors to self-close, tilt the top
backwards by about 10mm.
Leveling of appliance
●
≤10mm
7
50~70

The side at which the door opens can be
changed, from the right side (as supplied)
to the left side, if trequired.
Warning! When reversing the door, the
appliance must not be connected to the
mains. Ensure that the plug is removed
from the mains socket.
Tools you will need
Left Hinge Cover
8mm wrench
8mm socket wrench
Monkey wrench
Thin-blade
screwdriver
Cross-shaped
screwdriver
2. Use a putty knife or thin-blade
screwdriver to prize the screw hole cover
which is at the top left corner of the
refrigerator, and the upper hinge cover
which is at the top right corner of the
refrigerator.
Reversing the door
Note: If required you may lay the
refrigerator on its back in order to gain
access to the base, you should rest it
on soft foam packaging or similar
material to avoid damaging the
backboard of the refrigerator. To reverse
the door, the following steps are
generally recommended.
1. Stand the refrigerator upright. Open
the upper door to take out all door
racks and tank(to avoid damage) and
then close the door.
Water tank
Door racks
Putty knife
3. Unscrew the special flange self-tapping
screws which are used for fixing the right
upper hinge part by a 8mm socket driver
or a spanner (please support the upper
door with your hand when doing it) .
right upper hinge part
special flange
selftapping screws
4.Remove the upper hinge axis, transfer it
to reversed side and tighten securely, then
put it in a safe place.
① ② ③
5. Remove the upper door from the
middle hinge by carefully lifting the door
straight up.
NOTE: When removing the door, watch
for washer(s) between the center hinge
and the bottom of the freezer door that
may stick to the door. Do not lose.
Reversing the door
8
upper hinge
cover (right)
screw hole cover

①
① Lower hinge part (right)
② Front feet fixed board
②
④
④ Self-tapping screws
③
③ Adjustable bottom feet part
9
6. Place the upper door on a smooth
surface with its panel upwards. Loose
screw ② and part ①, then Install
them to the left side and tighten securely.
7. Unscrew the two special flange self-
tapping screws which are used for fixing
the middle hinge part, then remove the
middle hinge part that hold the lower door
in place.
① Stop block
①
② Self-tapping screw
②
NOTE: When removing the door, watch
for washer(s) between the center hinge
and the bottom of the freezer door that
may stick to the door. Do not lose.
middle hinge part
special flange
selftapping screws
8. Place the lower door on a smooth
surface with its panel upwards. Loose
screw ② and part ①, then Install
them to the left side and tighten securely.
9. Change screw hole covers on middle
cover plate from left to right (as shown in
figure below).
① Stop block
② Self-tapping screw
①
②
screw hole covers
screw hole covers
10. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts, and
remove the front feet board and the lower
hinge part by unscrewing the special
flange self-tapping screws.

washer
Note: washer may stick to lower door
10
14.Upturn the middle hinge part the
direction 180 degree, transfer it and adjust
its position, make the middle hinge axis
into the upper hole of the lower door, tight
the bolts.
16. Transfer the upper hinge part and
make the upper hinge axis into the upper
hole of the upper door, and adjust the
position of the upper door (please support
the upper door with your hand when doing
it), fixing the upper hinge part with the
special flange self-tapping screws.
12.Replace the lower hinge part to the left
side and fixing it with the special flange
self-tapping screws. Replace the front feet
fixed board to another side and fixing it
with the special flange self-tapping
screws. Install the adjustable bottom feet
parts.
Lower hinge part (left)
front feet fixed board
13.Transfer the lower door to the property
position, adjust the lower hinge part, make
the hinge axis into the lower hole of the
lower door, then tight the bolts.
11. Unscrew the bottom hinge axis and
remove it to the hole which is side by side
and screw it.
15. Transfer the upper door to the
appropriate position. Secure the door’s
level, make the middle hinge axis into the
lower hole of the upper door.
middle hinge part
selftapping screws
upper hinge part
17. Install the screw hole cover on the top
right corner of the refrigerator. Install the
upper hinge cover (which is in the plastic
bag) on the left corner. Put the other
upper hinge cover into the plastic bag.
