Frient Electricity Meter Interface User manual

AA
_
AA
+
_
AA
+
AA
_
AA
+
_
AA
+
i.
j.
eng
Resetting
Resetting is needed if you want to reconnect
your Electricity Meter Interface or if you need
to perform a factory reset to remove abnormal
behaviour.
STEPS FOR RESETTING
1. Open the casing of the device.
2. Press and hold the menu button until the
LED ashes numerous times in a row, and
then release the button again.
3. After a successful reset the green LED
will start ashing which indicates network
search.
Installation steps
The Electricity Meter Interface is equipped
with an optical probe, which is easily attached
to your meter.
1. Insert the end of the probe into the
indicated socket on the Electricity Meter
Interface.
NOTE: Press the end of the probe rmly
into the socket to ensure it is fully inserted.
Getting started
1. Open the casing of the device by pressing
the button on the back of the monitor
casing and pulling the casing upwards.
Product description
The Electricity Meter Interface collects
readings from your existing electricity meter
and, via a compatible hub, the data is sent to a
connected device, e.g. your smartphone.
This way, the Electricity Meter Interface
enables you to follow your electricity
consumption remotely.
INSTALLATION MANUAL
Electricity Meter Interface
Version 1.1
2. Place enclosed AA-batteries into the
device respecting the polarities.
• Do not remove the product label as it
contains important information.
• It is a good idea to take a picture of the
electricity meter before installation so
you can save the number of imp/kWh.
Occasionally, the number is close to the
LED and by attaching the probe you might
cover the number.
Precautions
3. The Electricity Meter Interface will now
start searching (up to 15 minutes) for a
Zigbee network to join.
4. Make sure that the Zigbee network on
your hub is open for joining devices and
will accept the Electricity Meter Interface.
5. While the Electricity Meter Interface is
searching for a Zigbee network to join, the
LED ashes green.
3. Close the casing and re-attach the interface
to the meter.
a.
b.
c.
d.
Battery replacement
CAUTION: When removing cover for battery
change - Electrostatic Discharge (ESD) can
harm electronic components inside
1. To remove the batteries, open the casing of
the interface.
2. After removing the used batteries, insert
new AA-batteries respecting the polarities.
CAUTION: RISK OF EXPLOSION IF BATTERIES
ARE REPLACED BY AN INCORRECT
TYPE. DISPOSE OF THE BATTERIES IN
ACCORDANCE WITH INSTRUCTIONS.
h.
HOOK AND LOOP TAPE
1. If you are using the hook and loop tape,
peel o the loops from the probe and
remove the cover from the sticky back of
the loops.
2. Place the hole in the tape directly over
the ashing LED labeled ”imp/kWh.” Be
as precise as possible when placing the
hole over the ashing LED to ensure the
best reading.
f.
g.
6. When the LED stops ashing, the
Electricity Meter Interface has
successfully joined the Zigbee network.
e.
2. Depending on the type of probe included
for your Electricity Meter Interface, you
can mount it on your meter either via the
magnet in the probe or with the hook and
loop tape attached to the probe.
MAGNET
1. If you are using the magnet connection,
place the probe on the ashing LED
labeled ”imp/kWh.”
Placement
Place the interface indoors at a temperature
between -20 and +60°C, close to the electric-
ity meter.
