Frigidaire FDB4315LF User manual

P30L0078.eps P30C0157.eps P30B0044.eps P30U0023.eps P30M0036.eps P30F0022.eps
P30R0106.eps
Product No. FDB4315LFB1 FDB4315LFC1 FDB4315LFS1
Series Built-in 24" Built-in 24" Built-in 24"
Color black stainless white
Owner's Guide English 154660001 154660001 154660001
Owner's Guide Spanish 154660003 154660003 154660003
Owner's Guide French 154660002 154660002 154660002
Service Data Sheet 154580201 154580201 154580201
Energy Guide 154540031 154540031 154540031
Installation Instructions 154427301 154427301 154427301
Market North America North America North America
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995510459
08/03/28
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
FDB4315LF
This Publication Supersedes
Publication # 5995504809
Copyright ©All rights reserved.

Publication No: 5995510459 FDB4315LF
03/08 2
CONTROL PANEL

FDB4315LF Publication No: 5995510459
# Functional Parts 3 03/08
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFDB4315LF (FDB4315LFS1)
BFDB4315LF (FDB4315LFB1)
CFDB4315LF (FDB4315LFC1)
POS. NO PART NO. DESCRIPTION
1 154639201 A - - Console Panel, assembly, white, w/overlay & foam
1 154639203 - B - Console Panel, assembly, black, w/overlay & foam
1 154639208 - - C Console Panel, assembly, stainless/black, w/overlay & foam
3 # 154543602 A B C Board, control
4 154554601 A B C Cover, control
5 154478901 A B C Gasket, cover
8 # 154543401 A B C Board, display
21 154596601 A B C Insualtion, foam, 5.744/.717/.517, outer console
23 154592902 A B C Insulation, foam, 1.5/.9/.09, console RH
* # 154597601 A B C Harness, wiring, main
* 154540031 A B C Energy guide label
* 154200401 A B C Screw, 6-10 x 3/8, pan plask

Publication No: 5995510459 FDB4315LF
03/08 4
DOOR

FDB4315LF Publication No: 5995510459
# Functional Parts 5 03/08
* Non-Illustrated Parts
DOOR
Model Index: AFDB4315LF (FDB4315LFS1)
BFDB4315LF (FDB4315LFB1)
CFDB4315LF (FDB4315LFC1)
POS. NO PART NO. DESCRIPTION
1 154579101 A B C Spring, friction pulley, (2)
1A 154578801 A B C Cable, friction pulley, (2)
2 154093301 A B C Screw, arm assy, (4)
3 154598201 A B C Arm Assy, LH, w/foam
3A 154597701 A B C Arm Assy, RH, w/foam
* 154529101 A B C Pin, arm assy
5 154079601 A B C Nut, arm assy, and handle mtg.
6 154579201 A B C Pulley, friction, LH
6 154579202 A B C Pulley, friction, RH
7 154494304 A B C Liner, door assembly, grey, complete
9 154542104 A B C Dispenser, det/rinse aid, w/read
9* 154294701 A B C Screw, #7 plas .375, (6), disp. assy.
10 154103702 A B C Screw, latch mtg, (2)
12 # 154543901 A B C Latch assy, black
20 154580708 A - - Door Assy, outer, white, w/badge
20 154580707 - B - Door Assy, outer, black, w/badge
20 154580701 - - C Door Assy, outer, stainless, w/badge
20* 5304428306 A B C Screw, door mtg., (2)
40 154585001 A B C Backer, handle mtg, (2)
41 154543701 A - - Towel bar assy, white
41 154543703 - B - Towel bar assy, black
41 154543705 - - C Towelbar assy, stainless
49 154588201 A B C Gasket, door wiper
50 154598501 A B C Support, door hinge, w/foam
51 154320301 A B C Clamp, drip loop, wire
53 154425001 A B C Nut, Keps, (2), handle mtg.
* 154200601 A B C Screw, #10-16 x 3/8
* 154409401 A B C Screw, #8-18 x .375

Publication No: 5995510459 FDB4315LF
03/08 6
TUB

FDB4315LF Publication No: 5995510459
# Functional Parts 7 03/08
* Non-Illustrated Parts
TUB
Model Index: AFDB4315LF (FDB4315LFS1)
BFDB4315LF (FDB4315LFB1)
CFDB4315LF (FDB4315LFC1)
POS. NO PART NO. DESCRIPTION
1 # 154643302 A B C Tub assy, w/frame parts, & vent hole
* 154598801 A B C Foam, tub, (2)
2 154544601 A B C Strike, door
3 # 154561001 A B C Gasket, tub
4 154200602 A B C Screw, 10-16 x 3/8, hex
5 154579402 A B C Roller Assy, tub, front, (2)
5A 154581102 A B C Roller Assy, tub, rear, (2)
6 154572801 A B C Screw, tub roller, (8)
9 # 154562802 A B C Vent assy, blower, grey
10 154562902 A B C Bezel, vent, gray
22 154446002 A B C Tubing, water inlet
23 5303318539 A B C Clamp,tubing, (2)
24 # 154606701 A B C Hose, drain
25 # 154209702 A B C Float, grey
28 154408701 A B C Switch Assy, float
29 # 154642901 A B C Thermostat, hi limit
30 154241101 A B C Retainer, thermostat
30* 154297701 A B C Screw, retainer-thermo
* 154528701 A B C Cabinet Seal Kit
* 154635001 A B C Insulation,blanket
* 154635101 A B C Insulation, back
* 154041001 A B C Screw, plask #1, 10-10 x 9/16
* 5300807270 A B C Screw, (2), countertop mtg.

Publication No: 5995510459 FDB4315LF
03/08 8
MOTOR & PUMP

FDB4315LF Publication No: 5995510459
# Functional Parts 9 03/08
* Non-Illustrated Parts
MOTOR & PUMP
Model Index: AFDB4315LF (FDB4315LFS1)
BFDB4315LF (FDB4315LFB1)
CFDB4315LF (FDB4315LFC1)
POS. NO PART NO. DESCRIPTION
1 # 154482901 A B C Heater, round
1* 154106202 A B C Nut, heater, (2)
1* 154289801 A B C Shield, heater terminal
2 154465101 A B C Bracket, heater, (2)
10 154245501 A B C Cover, volute
13 154246801 A B C Gasket, sump
14 154461902 A B C Housing, sump
16 154246502 A B C Retainer, sump
24 154467702 A B C Spray arm, grey, lower
24A 154468502 A B C Spray arm, grey, center
24B 154478202 A B C Spray arm, 3rd level, grey
32 154464101 A B C Tube, delivery
32* 154491101 A B C Screw, delivery tube
32A 154406401 A B C Gasket, delivery tube
40 154106801 A B C Clamp, hose, 1.29" open, worm gear, (2)
40* 154380601 A B C Clamp, hose, 1.5" open, worm gear, (5)
54 154491201 A B C Hose, connector, drain pump
55 154595901 A B C Bracket, motor
55* 5303316032 A B C Screw, truss ss, 8 .625, (7)
58 154246402 A B C Check ball
59 154246901 A B C O-ring, rear
59A 154247001 A B C O-ring, front
60 # 154580301 A B C Pump Assy, drain
61 154463402 A B C Grommet, delivery tube
62 154294102 A B C Support, spray arm, grey, lower
63 154252201 A B C Base, soil director
64 154252302 A B C Filter, soil director, grey
65 154283005 A B C Filter Assy, grey
66 154252702 A B C Trap, glass, grey
70 # 154579701 A B C Motor & Pump Assy, johnson
71 # 154473901 A B C Sensor, turbidity
71* 154376001 A B C O-ring, turbidity
* 154200601 A B C Screw, #10-16 x 3/8

Publication No: 5995510459 FDB4315LF
03/08 10
FRAME

FDB4315LF Publication No: 5995510459
# Functional Parts 11 03/08
* Non-Illustrated Parts
FRAME
Model Index: AFDB4315LF (FDB4315LFS1)
BFDB4315LF (FDB4315LFB1)
CFDB4315LF (FDB4315LFC1)
POS. NO PART NO. DESCRIPTION
3 # 154637401 A B C Valve, water
4 154595801 A B C Brace, front frame
8 154589401 A - - Toeplate, adjustable, white
8 154589403 - B C Toeplate, adjustable, black
8* 154528101 A B C Insulation, toeplate
9 154589501 A - - Kickplate Assy, white
9 154589503 - B C Kickplate Assy, black
10 154371301 A - - Screw, phillips head, white
10 5300808658 - B C Screw, #8A x .375", black
11 154200701 A B C Screw, #10-32 x 3/8
11A 154200601 A B C Screw, #10-16 x 3/8
15 154571101 A B C Leg, leveling, (4)
20 154597001 A B C Cover, junction box
* 154041001 A B C Screw, plask #1, 10-10 x 9/16
* 154409401 A B C Screw, #8-18 x .375

Publication No: 5995510459 FDB4315LF
03/08 12
RACKS

FDB4315LF Publication No: 5995510459
# Functional Parts 13 03/08
* Non-Illustrated Parts
RACKS
Model Index: AFDB4315LF (FDB4315LFS1)
BFDB4315LF (FDB4315LFB1)
CFDB4315LF (FDB4315LFC1)
POS. NO PART NO. DESCRIPTION
1 154432604 A B C Rack assy, lower, grey
2 154424002 A B C Basket, silverware, grey, main
2A 154424102 A B C Basket, silverware, grey, (2), side
3 154494404 A B C Rack assy, upper, grey
4 154572403 A B C Roller, upper rack, (4)
5 5304440996 A B C Cap, slide, grey, (4)
6 154572201 A B C Slide, rack, (2)
7 154174503 A B C Wheel & bracket assy, grey, lower rack, (8)
10 154466902 A B C Basket, utility, grey
11 154436104 A B C Shelf, cup, half width, grey
13 154425503 A B C Fence, fold down, grey, lower rack, (2), full length
13A 154598602 A B C Fence, multi, 3 wire, LH, upper rack
13B 154598402 A B C Fence, multi, 4 wire, RH, upper rack
14 154428402 A B C Bracket, fold down fence, grey, lower rack, (6)
14A 154242002 A B C Bracket, multi fence, white, upper rack, (4)
14A* 154242102 A B C Bushing, multi fence, upper rack, (4)
16A 154424303 A B C Cover, side basket, grey, (2), silverware
20 154530702 A B C Handle, pull, grey, front, upper rack
21 154530902 A B C Handle, pull, grey, rear, upper rack
30 154581802 A B C Bracket, adjustment, upper rack, LH, assembly
30* 154581702 A B C Bracket, adjustment, upper rack8, RH, assembly
