Frigidaire FDB636GFT0 User manual

READ AND SAVE THESE INSTRUCTIONS P/N 154255703 (9808)
Record All Information
For Future Reference
Brand: Purchase Date:
Model #:
Serial #:
(see Features page for location)
Questions? 1-800-444-4944
(United States)
1-800-661-9913
(Canada)
Dishwasher
Use & Care Manual
600 Series
Visit Frigidaire Companys
Web Site at
http://www.frigidaire.com
Consumer Services
Warranty & Service ........................... 15-16
Versión en español ................................. 15
Solutions to Common
Dishwashing Problems .... 13-14
Changing
Color Panels ........................ 12
Care and
Cleaning ............................... 11
Factors Affecting
Performance ........................ 10
Dishwasher Dispenser
and Detergents ................. 9-10
Preparing and
Loading Dishes ................... 7-8
Operating
Instructions ......................... 4-6
Normal Operating
Sounds ................................... 4
Features .................................3
Safety
Instructions ............................2
Product Registration Card
Please fill in completely, sign and return promptly!

2
Important Safety Instructions
©1998 White Consolidated Industries, Inc.
All rights reserved.
 Read all instructions before using your
dishwasher.
 Use your dishwasher only as instructed in
this Use and Care Manual.
 This Manual does not cover every possible
condition and situation that may occur.
Use common sense and caution when
installing, operating and maintaining any
appliance.
 DISHWASHER MUST BE ELECTRICALLY
GROUNDED. Read the Installation
Instructions for details.
 This dishwasher is designed to operate on
regular house current (120 V, 60 Hz). Use a
circuit equipped with a 15 ampere fuse or
circuit breaker. Use a 20 ampere fuse if
dishwasher is connected with a food waste
disposer.
 Do not operate dishwasher unless all
enclosure panels are in their proper place.
 Dispose of discarded appliance and
shipping or packing material properly.
 To avoid entrapment and/or suffocation,
remove door or door latch mechanism
from any dishwasher that is discarded or
not in use.
 Keep young children and infants away from
dishwasher when it is operating.
 Do not let children abuse, sit, stand or play
on door or racks of a dishwasher.
 Use only detergents and rinse agents
recommended for use in a dishwasher.
Printed in U.S.A.
SAVE THESE
INSTRUCTIONS
 Store dishwasher detergent and rinse
agents out of the reach of children.
 Do not wash plastic items unless marked
dishwasher safe or the equivalent. Check
with manufacturer for recommendations, if
not marked. Items that are not dishwasher
safe may melt and create a potential fire
hazard.
 If the dishwasher drains into a food
disposer, make sure disposer is completely
empty before running dishwasher.
 Disconnect electrical power to dishwasher
before servicing.
 Repairs should be done by a qualified
technician.
 Do not tamper with controls.
 Do not touch the heating element during
or immediately after use.
 When loading items to be washed:
- Load sharp items and knives so that they
are not likely to damage the door seal or
tub.
- Load sharp items and knives with the
handles up to reduce the risk of cut-type
injuries.
 Under certain conditions, hydrogen gas
may be produced in a hot water system
that has not been used for 2 weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If
hot water system has not been used for
such a period, before using dishwasher,
turn on all hot water faucets and let water
flow from each for several minutes. This
will release any accumulated hydrogen gas.
HYDROGEN GAS IS FLAMMABLE. Do not
smoke or use an open flame during this
time.
 Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
To reduce the risk of fire, electrical shock,
or injury when using your dishwasher,
follow basic precautions including the
following:
This symbol will help alert you to such
dangers as personal injury, burns, fire and
electrical shock.

3
Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms
against soiled surfaces. Each cycle begins with a pre-drain. Next, the dishwasher fills with water
covering the filter area. Water is then pumped through the filter and spray arms. Soil particles go
down the drain as the water is pumped out and replaced with clean water. The number of water
fills will vary with the cycle being used.
Dishwasher Features
Serial Label
(located on right
side of tub)
Bottom Rack
page 8
Heating Element
page 11
Glass Trap
page 11
Self-Cleaning Filter
page 11
Tub Gasket
page 11
Lower Spray Arm
pages 8,13
Overfill Protector
page 11
Top Rack
page 7
Funnel
pages 7,13
Middle Spray Arm
pages 7,8,13
Detergent Dispenser
page 9
Nozzle and Upper Spray
Prewash Detergent Cup
page 9
Rinse Aid
Dispenser
page 10
Vent
pages 4,6,14

4
Operating Instructions
Vent Latch
Model FDB636
Getting Started
1. Load dishwasher (See Preparing and
Loading Dishes).
2. Add detergent (See Dishwasher Dispenser
& Detergents).
3. Add rinse aid, if needed (See Rinse Aid).
4. Turn dial clockwise to select cycle (See
Wash Cycle Selections) or number of hours
for delay start.
5. Select desired energy OPTIONS (See
Energy Options). The indicator will show
red when selected.
6. If using DELAY START, go to step number
8.
7. Run hot water faucet nearest dishwasher
until water is hot. Turn water off.
8. To start, close door to latch.
Very Important
InformationRead Before
Operating Your Dishwasher!
Normal Operating
Sounds
This dishwasher does not sound like most
dishwashersITS QUIETER.
The new Precision Wash System uses
energy efficient motors for the wash and
drain portions of the cycle you select. Each
cycle has a series of water fills and drains
for washing and rinsing dishes. As each
cycle begins, you mayor may nothear the
drain motor.
The next sound you will hear is the
splashing water as it enters the tub. Then
the lower arm rotates and circulates water.
This is followed by a pause and a slightly
different sound as the middle arm sprays
water. If you listen closely, you will hear the
change in sound as the wash action
switches from one arm to the other.
PLEASE BE ADVISED: If you compare
this dishwasher to previous models, you
may be surprised at what you DONT
hear!

5
Operating Instructions (continued)
Wash Cycle Selections
Note: Cycle times are approximate and will
vary with options selected. Hot water is
necessary to activate dishwasher detergent and
melt fatty food soils. An automatic sensor will
check the incoming water temperature and, if
it is not hot enough, the timer will be delayed
for automatic water heating in the main wash
of all cycles. This happens even though HI-
TEMP WASH ON option has not been selected.
When HI-TEMP WASH ON is selected, an even
higher temperature will be guaranteed to
handle heavier soil loads.
Delay Start
Allows you to delay starting the POTS & PANS
cycle up to 6 hours.
 Turn dial to select number of hours.
 Select HI-TEMP WASH ON option and other
desired options.
 Close door to latch. The DELAY START light
will come on.
 DO NOT USE detergent.
 Turn dial to RINSE/HOLD.
 Turn dial to SHORT WASH.
 Select desired OPTIONS.
 Turn dial to NORMAL WASH.
 Select desired OPTIONS.
gal.
imp. gal.
liters
2 washes
3 rinses
75 min.*6.0
5.0
22.7
For regularly soiled
dishes and silverware.
gal.
imp. gal.
liters
1 wash
3 rinses
67 min.*4.8
4.0
18.2
For lightly soiled or
pre-rinsed dishes and
silverware.
For rinsing dishes that
will be washed later.
1 rinse4 min.gal.
imp. gal.
liters
1.2
1.0
4.5
 Turn dial to POTS & PANS/HEAVY
WASH.
 Select HI-TEMP WASH ON option.
 Select other desired OPTIONS.
gal.
imp. gal.
liters
2 washes
4 rinses
81 min.*7.2
6.0
27.3
*Includes dry time.
Cycle Chart
Description Time
(approx.)
Washes/
Rinses
Water
(approx.)
To Select CycleCycle
Pots &
Pans
Normal
Wash
Short
Wash
Rinse/
Hold
gal.
imp. gal.
liters
2 washes
4 rinses
81 min.*7.2
6.0
27.3
For heavily soiled
dishes and silverware.
Heavy
Wash
For pots, pans,
casseroles, and
dinnerware with
dried-on or baked-on
soils.
 Turn dial to POTS & PANS/HEAVY
WASH.
 Select desired OPTIONS.

6
Hi-Temp Wash Option
When HI-TEMP WASH ON option is selected,
the dishwasher heats water in main wash to
approximately 140°F (60°C). Wash action will
continue but timer will not advance until
proper temperature is reached. The hotter
water provided by this option helps activate
dishwasher detergent to clean food grease
and soil from dishes. HI-TEMP WASH ON
option can be used with any cycle except
RINSE/HOLD.
To turn off option, select HI-TEMP WASH OFF.
Hi-Temp Rinse Option
When HI-TEMP RINSE ON option is selected,
the dishwasher heats water in final rinse to
approximately 140°F (60°C). This will speed
drying and reduce spotting. HI-TEMP RINSE
ON option can be used with any cycle except
RINSE/HOLD.
To turn off option, select HI-TEMP RINSE
OFF.
Heat Dry Option
HEAT DRY ON option provides faster drying
since the heating element is on during the
drying portion of cycle.
HEAT DRY OFF option saves electricity since
the heating element is off during drying
portion of cycle. With either option, a fan
circulates air inside the dishwasher to speed
drying. You may wish to open the door
slightly after the cycle is complete since some
water droplets may remain on door and tub
and in areas where dishes touch silverware
basket and rack.
You may see water vapor coming from vent
during drying portion of cycle. The vent is
closed during washing to hold moisture and
sound inside and then opens for drying.
The drying option may be changed at any
time during the cycle and affects only the
drying period.
Energy Options
Status Indicator Lights
When DELAY START option is selected, the
Delay Start light will glow as timer counts
down to begin cycle.
The HEATING DELAY light means the cycle is
being extended to heat water to proper
temperature in the main wash or final rinse,
based on options selected.
CLEAN light comes on when a cycle is
complete. To turn it off, turn dial slightly until
light goes off.
Operating Instructions (continued)

7
Preparing and Loading Dishes
Loading the Top Rack
Important: Do not cover the funnel when
loading.
The top rack is designed for cups, glasses
small plates, saucers and bowls.
Load glasses in top rack. Damage may occur if
placed in bottom rack.
Load plastic items in top rack only. Melting
may occur if placed in bottom rack.
Load items with open ends facing down for
better cleaning and draining.
Damage may occur if delicate items touch
each other during dishwasher operation.
Long-handled knives and utensils can be
placed in top rack.
Be sure nothing protrudes through the
bottom of the rack to block rotation of middle
spray arm. Do not cover funnel
Dish Preparation
Scrape away large pieces of food, bones, pits,
toothpicks, etc. The continuous filtered wash
system will remove remaining food particles.
Burned-on foods should be loosened before
loading. Empty liquids from glasses and cups.
Foods such as mustard, mayonnaise, vinegar,
lemon juice and tomato based products may
cause discoloration of stainless steel and
plastics if allowed to sit for a long period of
time. Unless the dishwasher is to be operated
at once, it is best to rinse off these food soils.
 Load racks so that large items do not
prevent the detergent dispenser from
opening.
 Check manufacturers recommendations
before washing items in question.
 If the dishwasher drains into a food
disposer, be sure disposer is completely
empty before starting dishwasher.

8
Preparing and Loading Dishes (continued)
Loading the Silverware Basket
Mix spoons, forks and knives to prevent
nesting. Mixing items gives better cleaning
and drying.
For safety, load sharp knives and forks with
handles up.
Be sure nothing protrudes through bottom of
basket or rack to block the spray arm.
Do not mix silver and stainless to avoid
damaging the silver finish.
Loading the Bottom Rack
Make sure tall items do not block spray arm
rotation.
Place plates and platters so that they do not
touch.
Place bowls, casseroles and sauce pans with
the soiled surface facing down or toward the
center. Tilt slightly for better drainage.
Be sure pan handles do not protrude through
the bottom of the rack and block the spray
arm rotation.
Adding a Dish
To add or remove items after wash cycle
starts:
 Unlatch door and wait a few seconds until
wash action stops before opening.
 Add the item and wait a few seconds to
allow cold air to slowly expand inside
dishwasher.
 Close door firmly to latch and resume cycle.

9
Dishwasher Dispenser & Detergents
 Use only fresh automatic dishwashing
detergent. Other types will cause
oversudsing.
 Add detergent just before starting cycle.
 Store detergent in a cool, dry location.
Moist or caked detergent will not dissolve
properly.
Filling the Detergent Dispenser
The detergent dispenser has one covered and
one uncovered cup. Detergent in the
uncovered cup falls into the dishwasher when
the door is closed. The covered cup opens
automatically in the main wash.
* 12 grains and higher is extremely hard
water. Detergent alone may not be enough.
A water softener is recommended to
improve water quality and dishwashing
performance.
How much Detergent to use
The amount of detergent to use depends on
the water hardness. Water hardness is
measured in grains per gallon. Using too little
detergent can result in poor cleaning and
hard water filming or spotting. Using too
much detergent in soft water can cause
permanent etching on glassware. Your local
water company, water softener company or
county extension agent can tell you the water
hardness in your area.
More detergent may be needed if the
phosphorus content is 8.7% or less.
The phosphorus content is shown on the
detergent label.
Cover
Fill to second line
when using standard
dishwashing
detergent.
Fill to first line
when using ultra
or concentrated
detergent.
Fill covered
cup only for
Short Wash.
Fill both cups
for Pots & Pans,
Heavy and
Normal.
Detergent Chart
Amount per Cup
2 Teaspoons
5 Teaspoons
10 Teaspoons
(fill level with top)
Water Hardness
Soft (0-3 grains)
Medium (4-8 grains)
Hard (9+ grains*)

10
Dishwasher Dispenser
& Detergents (continued)
Rinse Aid
Rinse aid greatly improves drying and
reduces water spots and filming. Water
sheets off dishes rather than forming water
droplets that cling and leave spots.
A dispenser, located next to the detergent cup,
automatically releases a measured amount of
rinse aid during the last rinse. If spotting and
poor drying are problems, increase the
amount of rinse aid dispensed by rotating the
dial to a higher number. The dial is located
under the dispenser cap. The indicator will be
dark when full and will show clear when it is
time to refill.
To add liquid rinse aid, turn dispenser cap 1/4
turn counterclockwise and lift out. Pour in
rinse aid until liquid touches the indicated fill
level. Replace cap.
Do not overfill since this can cause
oversudsing. Wipe up any spills with a damp
cloth.
The dispenser holds enough for 35 to 140
washes, depending on setting.
Adjustable setting
Factors Affecting
Performance
Water Pressure
The hot water line to dishwasher must
provide water pressure between 20 and 120
psi.
Low water pressure may occur when laundry
or showers are in operation. Wait until water
use is reduced before starting dishwasher.
Water Temperature
Hot water is needed for best dishwashing and
drying results. Water entering dishwasher
should be at least 120°F (49°C) to give
satisfactory results.
To check water temperature entering
dishwasher:
 Turn on hot water faucet nearest
dishwasher for several minutes to clear cool
water from pipes.
 Hold a candy or meat thermometer in
stream of water to check the temperature.
 If temperature is below 120°F (49°C), have
a qualified person raise the hot water
heater thermostat setting.
Important: Before starting a cycle, run
hot water to clear cool water from pipe.
Dispenser Opening Indicator
Dispenser Cap

11
Winterizing
A dishwasher left in an unheated place should
be protected from freezing. Have a qualified
person do the following:
To Disconnect Service:
1. Turn off electrical power to the dishwasher
at the supply source by removing fuses or
tripping circuit breaker.
2. Shut off water supply.
3. Place a pan under the inlet valve.
Disconnect water line from inlet valve and
drain into pan.
4. Disconnect drain line from pump and
drain water into pan.
To Restore Service:
1. Reconnect the water, drain, and electrical
power supply.
2. Turn on water and electrical power supply.
3. Fill both detergent cups and run
dishwasher through a NORMAL cycle.
4. Check connections to make sure they do
not leak.
Note: See Installation Instructions for more
details.
Care and Cleaning
OutsideOccasionally wipe with a mild
nonabrasive detergent and water. Rinse and
dry.
InsideThe inside of the dishwasher is self-
cleaning with normal use. If needed, clean
around the tub gasket area with a damp
cloth.
The filter is self-cleaning. A glass trap located
in the center of the filter is designed to
collect pieces of broken glass, straws, bones
and pits. To remove items in glass trap, grasp
handle, lift out, empty and replace.
Note: Hard water may cause lime deposit
buildup on the interior of the dishwasher.
For cleaning instructions see Removing
Spots and Film section.
Care of Drain Air Gap
If a drain air gap was installed for your built-
in dishwasher, check to make sure it is clean
so the dishwasher will drain properly. A drain
air gap is usually mounted on countertop and
can be inspected by removing the cover. This
is not part of your dishwasher and is not
covered by warranty.
Overfill Protectorkeeps dishwasher from
overfilling and is located in the left front
corner of the tub.
 Clean occasionally with household
cleaner containing
vinegar or bleach to
dissolve any buildup.
 Overfill Protector
should move up and
down freely about one
inch. If it does not
move, lift and clean
underneath.
Property Damage Hazard
Freezing temperatures may cause water
lines to rupture. Be sure all supply lines to
and circulating lines within dishwasher are
protected.
Failure to do so could result in property
damage.
Burn Hazard
Allow heating element to cool
before cleaning the interior.
Failure to do so can result in
burns.

12
Changing Color Panels
Some models come with reversible door panel
inserts.
To change the color panel:
1. Remove snap-on bottom trim by pulling
forward. Support color panel(s) at bottom
while removing trim. Slide color panel(s)
downward 1/2.
2. Grasp top and bottom of panel(s) and
bow slightly until they are clear of trim.
DO NOT REMOVE SPACER.
3. Arrange panel(s) so desired color is facing
out. Place one side of panel under side
trim and bow slightly until other side fits
under opposite trim. Slide panel(s) up to
fit under control panel.
4. Replace bottom trim by fitting slot over
bottom edge of door and press to secure.
Customized Wood Panels
Your dishwasher can be customized with
1/4 wood panels. Refer to your installation
instructions for more information.
Bottom
Trim
Spacer
STEP 2
STEP 4
Color
Panel(s)
Side
Trim
Control Panel
Color Panel(s)
Color Panel(s)
Bottom
Trim
Bottom Edge of Door
STEP 1
STEP 3
Metal door panels are sharp
and should be handled with
care. Wear gloves to protect
hands.
Failure to do so can result in
injury.
Cut Hazard

13
Solutions to Common Dishwashing Problems
 Check to see that proper amount of
detergent is being used for cycle selected.
Also, check phosphate level. (See Detergent
Dispenser.)
 Home water pressure may be too lowit
should be 20 to 120 pounds per square
inch (psi).
Dishware Chipped
 Load with care and do not overload. (See
Preparing and Loading dishes.)
 Place delicate items in top rack.
 Place glasses securely against pins and not
over pins.
 Load items so they are secure and dont jar
loose when moving racks in and out. Move
racks in and out slowly.
 Make sure tall glasses and stemware will
clear top of tub when rack is pushed in.
 Fine antique china and crystal should be
hand-washed.
Dishware Stained or Discolored
 Tea and coffee can stain cups. Remove the
stains by hand washing in a solution of 1/2
cup (120 ml) bleach and one quart (1 L) of
warm water. Rinse thoroughly.
 Iron deposits in water can cause a yellow or
brown film. A special filter installed in the
water supply line will correct this problem.
(See Removing Spots and Film.)
 Aluminum utensils can leave gray/black
marks when they rub against other items.
Load properly.
 Certain high acid foods can cause
discoloration of stainless steel and plastics
if allowed to sit for a long period. Use the
Rinse & Hold cycle or rinse by hand if not
operating dishwasher at once.
 Mixing stainless steel and silver utensils in
silverware basket can cause pitting of the
stainless steel blades. Avoid mixing stainless
steel and silver.
Etching
 Using too much detergent in soft or
softened water causes this film that cannot
be removed.
 Adjust the amount of detergent based on
the water hardness. (Check Detergent
Chart.)
 Lower the water temperature.
 Use the Heat Dry Off option.
Before calling for service, review this list.
It may save you both time and expense.
This list includes common experiences
that are not the result of defective
workmanship or material in your
dishwasher.
Food Soils Left on Dishes
 Choose another cycle for longer washing
time.
 Check rack loading section for proper
loadingavoid nesting items.
 Home water pressure may be too low
should be 20 to 120 pounds per square
inch (psi).
 Check incoming water temperature. It
should be at least 120°F (49°C). (See
Factors Affecting Performance.)
 Check water hardness. For extremely hard
water, it may be necessary to install a water
softener. (See Detergent Chart.)
 Use fresh detergent.
 Check to make sure funnel in top rack is
not blocked.
 Make sure items are not blocking the spray
arms, preventing them from rotating.
 Check to see if the rinse aid dispenser
needs refilling.
Dishes not Dry
 Select Heat Dry option.
 Make sure the rinse aid dispenser is filled.
 Increase the amount of rinse aid. (See Rinse
Aid.)
 Check the incoming water temperature. Be
sure it is at least 120°F (49°C).
 Check for proper loadingavoid nesting
items.
 Plastic items may need to be towel dried.
 Cups with a concave bottom will collect
water.
Glassware/Flatware Spotted or Cloudy
 Check water hardness. For extremely hard
water, it may be necessary to install a water
softener. (See Detergent Chart.)
 Water temperature may be low. Avoid
extremely low or high temperatures. (See
Factors Affecting Performance.)
 Avoid overloading and improper loading.
(See Preparing and Loading Dishes.)
 Use fresh detergent. Old detergent is
ineffective.
 Make sure rinse aid dispenser is filled.

14
Solutions to Common Dishwashing Problems (continued)
 Check to see if drain hose is kinked.
 Make sure cycle is complete, not in a pause.
Cycle Takes a Long Time
 Is cycle in a water heating delay?
 Has the delay start option been selected?
Dishwasher Wont Fill
 Is water supply turned on?
 Does overfill protector move up and down
freely? (See Overfill Protector section.)
Dishwasher Has an Odor
 Soiled dishes left in dishwasher too long
can create an odor. Use Rinse & Hold cycle.
 There will be a new smell when first
installed. This is normal.
 Check to see if unit is draining properly.
(See Dishwasher Does Not Drain Properly.)
Stains on Tub Interior
 Washing large amounts of dishware with
tomato based soil can cause a pink/orange
appearance. This will not affect
performance and will gradually fade over
time. Pre-rinsing or using the Rinse & Hold
cycle will reduce the chance of staining.
Using Heat Dry Off option will lessen
staining.
Removing Spots and Film
Hard water can cause lime deposit buildup on
the interior of the dishwasher. Dishes and
glasses may also get spots and film for a
number of reasons. (See Glassware/Flatware
Spotted or Cloudy section.) To remove
buildup, spots and film, clean using the
following instructions:
1. Load clean dishes and glasses in normal
manner. Do not load any metal utensils or
silverware.
2. Do not add detergent.
3. Select the POTS & PANS cycle. Close and
latch door to start.
4. Allow dishwasher to run for 25 minutes to
reach the main wash portion of cycle.
5. Unlatch and open door and pour 2 cups of
white vinegar into the bottom of
dishwasher.
6. Close and latch door and allow the cycle to
finish.
Note: If these conditions persist, a home water
softener should be considered.
Detergent Left in Cups
 Detergent may be old. Discard and use
fresh detergent.
 Be sure water action can reach the
dispenser.
 Check to see if cycle has been completed.
 Make sure items do not prevent the
detergent dispenser from opening.
Dishwasher Leaks
 Use only fresh detergent designed for
automatic dishwashers. Measure detergent
carefully. Try a different brand.
 Spilled rinse aid can cause foam and lead to
overflowing. Wipe up any spills with a
damp cloth.
 Check to see that dishwasher is level. (See
Installation Instructions.)
Normal Sounds You Will Hear
 Normal sounds include water fill, water
circulation and motor sounds.
 There is a noticeable change in sound when
the wash action switches between the
lower and middle spray arm. This is normal
since each spray arm has its own sound.
 It is normal for dishwasher to pause (no
sound) when the wash action is switching
between the lower and middle spray arms.
Water in Bottom of Tub
 Water left in bottom of tub after cycle is
complete is not normal. If water remains in
the bottom of the tub, dishwasher may not
be draining properly. (See Dishwasher
Does Not Drain Properly.)
Vapor at Vent
 Water vapor escapes from the vent when
the dishwasher goes into the drying part of
cycle. This is normal.
Dishwasher Wont Run
 Check to see if circuit breaker is tripped or
if a fuse is blown.
 Make sure water supply is turned on.
 Check to see if cycle is set correctly. (See
Operating Instructions.)
 Is dishwasher set for delay start option?
 Make sure door is closed and latched.
Dishwasher Does Not Drain Properly
 If unit is hooked up to a food waste
disposer, make sure the disposer is empty.
 Check to see if the knockout plug has been
removed from inside the food waste
disposer inlet.

15
Keep your bill of sale, delivery slip or some other appropriate
payment record. The date on the bill establishes the
warranty period should service be required.
Consumer Services
Versión en español
Si desea obtener una copia en español de este Manual del Usuario,
sírvase escribir a la dirección que se incluye a continuación. Solicite
la P/N 154285002.
Spanish Use & Care Manual
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
For Parts and Service
Contact Frigidaire Home Products at:
8004444944
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
Dishwasher Warranty
Warrantor: Frigidaire Company, a division of White
Consolidated Industries, Inc.
Covered
Full One Year Parts and Labor Warranty
For one year from date of purchase, Frigidaire Company
will repair or replace any part of the appliance that
proves to be defective in materials or workmanship.
Limited One Year Parts and Labor Warranty
(State of Alaska only)
All terms stated above apply except all of the technician's travel
costs to the home for service and any costs for pickup and delivery
of the appliance (required because of service), are excluded.
Extended Limited 2nd Year Warranty
For two years from date of purchase, Frigidaire Company will
provide a replacement (or functional equivalent), for any part in
the water distribution system that proves to be defective in
materials or workmanship. Associated inlet and drain plumbing
parts are not included. The consumer must pay for all labor and
service charges, and the cost to ship the part(s) to the nearest
authorized servicer.
Extended Limited 2nd-5th Year Warranty
(Electronic Controls and Nylon Racks) For models with
electronic controls, provide a replacement electronic control that
fails because of a manufacturing defect. For models with nylon-
coated racks, provide a replacement nylon-coated rack if the
original upper or lower nylon-coated rack peels or rusts because
of a manufacturing defect. The consumer will be responsible for
cost of shipping the replacement part(s) to the nearest
authorized servicer, and for all labor and service charges.
Extended Limited 2nd-10th Year Warranty
For ten years from date of purchase, Frigidaire Company will
provide a replacement tub or door liner if the original tub or door
liner fails to contain water because of a manufacturing defect.
Door seals are not included. The consumer must pay for all labor
and service charges, and the cost to ship the replacement part(s)
to the nearest authorized servicer.
Warranty (continued)
Not Covered
1. Service calls where the problem is not the fault of the
product. Examples that apply to various product types
include but are not limited to the following:
a. Service calls to remove shipping devices/packing
materials; to level product; to correct leaks at water inlet hose
connections; to correct improper placement of drain hose in
drain; to turn gas supply line on; to correct an improper
exhaust system or to connect product to an exhaust duct; to
advise user on proper setting of controls or on proper use of
product; to correct installation of product; to replace owner-
accessible light bulbs or fluorescent tubes.
b. Service calls where the problem is due to house wiring or
improper voltage supply; a blown fuse or tripped circuit
breaker; a slow or backed-up drain; a weak or spongy floor;
insects, rodents or pests; frozen water lines in product or
house; improper power cord connections to product; blockage
or restrictions in house exhaust duct or hood; product installed
outside, exposed to elements.
2. Damages due to commercial use or from product being used in
dwellings with multiusers (such as in community-type complexes).
3. Damage to product caused by misuse, fire, flood, acts of God, or
by using parts and/or service not authorized by Frigidaire or one of
its servicers.
4. Consequential or incidental damages such as property damage and
incidental expenses resulting from any breach of this written or
any implied warranty. Note: Some states do not allow the
exclusion or limitation of incidental or consequential damages, so
this limitation or exclusion may not apply to you.
5. Expenses to make product accessible for servicing (for instance,
removal of cabinets, cabinet doors or trim).
6. Service calls to products with serial plates that have been removed,
altered or cannot be read.
Conditions
1. This warranty gives you specific legal rights; you may
have other rights, which vary from state to state. We
authorize no one to change or make additions to this
warranty. This warranty applies only in the 50 States
of the U.S.A. and Puerto Rico.
2. All service and installation must be performed by Frigidaire
Home Products or one of its authorized servicers per the terms
stated in this warranty. Use only genuine Frigidaire Home
Products parts.
3. Product features/specifications are subject to change without
notice.
4. If the product cannot be repaired, a usage charge will be
incurred.
5. The consumer must:
 properly use and care for product.
 read and follow all warning/safety instructions and all other
instructions provided with the product.
 have product properly installed according to all local,
plumbing, electrical and/or gas codes. Product must be
properly connected and grounded to a power supply of
sufficient voltage.
 have product moved out of place and back into place (if
moving the product is essential for service). If product cannot
be moved by the consumer, the servicer will not be liable for
damages to the floor or to the finish after installation.
Visit Frigidaire Companys Web Site at
http://www.frigidaire.com

16
WARRANTY APPLIES TO:
a) Products purchased and installed in Canada for personal single family household use.
b) Defects resulting or arising out of the manufacturing process.
c) Products bearing legible manufacturers model and serial numbers.
d) Replacement parts only for the remainder of the original warranty.
WARRANTY DOES NOT APPLY TO:
a) Transportation damage.
b) Supply and replacement of porcelain, fuses, glass and light bulbs.
c) Parts and service supplied or obtained from other than FRIGIDAIRE PARTS AND SERVICE or FRIGIDAIRE PARTS AND
SERVICE authorized depots.
d) Damage or failure as the result of abuse, improper or commercial use.
CONSUMER/OWNER RESPONSIBILITY:
a) To provide proof of the original date of purchase by means of a bill of sale or payment record verifying purchase date.
b) To pay all costs to make the appliance readily accessible for service.
c) To ensure proper power supply and connection of the appliance to same.
d) Proper installation, control setting and care of finish.
This warranty is in addition to any statutory warranties contained in any applicable legislation. The terms and conditions
of this warranty are not intended to exclude or limit your rights under those statutes. The warrantor however reserves the
right to charge transportation and travelling costs for distances in excess of 48 kilometres (30 miles) from the nearest
FRIGIDAIRE PARTS AND SERVICE authorized service depot.
This warranty plus the statutory warranties mentioned are the only warranties given to the consumer/owner for this product.
Consumer Services
Frigidaire Gallery Dishwasher Warranty
Canada
For service under this warranty, contact your local dealer/
retailer, authorized FRIGIDAIRE PARTS AND SERVICE
depot, or:
FRIGIDAIRE PARTS AND SERVICE
7075 Ordan Drive
Mississauga, Ontario
L5T 1K6
Tel.: [phone]
Fax: [phone]
WARRANTOR WILL THROUGH ITS AUTHORIZED
SERVICE DEPOT:
Pay all costs to repair or replace any defective parts.
Pay all costs (excluding labour) to repair or replace
defective heating element and water distribution system
including the circulation pump/motor, drain pump/motor,
lower spray arm system, middle spray arm system, delivery
tube system and filtration system.
Pay all costs (excluding labour) to repair or replace a
defective polypropylene tub or inner door liner arising
out of the manufacturing process.
WARRANTOR:
Frigidaire Home Products
7075 Ordan Drive
Mississauga, Ontario
L5T 1K6
This dishwasher is a branded product of Frigidaire Home
Products.
WARRANTY PERIOD:
For the first two years after purchase by the original
consumer/owner:
For the third year after purchase by the original consumer/
owner:
For the third year after purchase by the original consumer/
owner:
