Frigidaire FDB2410HIC User guide

Trouble Shooting Tips
To replace dispenser:
• shut off electricity to dishwasher,
• remove outer door panel assembly,
• disconnect wiring to the actuator,
• remove the six screws,
• remove the dispenser,
• replace and reinstall screws,
• rewire actuator.
Check the Following
1. Fuse (blown or tripped).
2. 120 VAC supply wiring connection
faulty.
3. Electronic control board defective.
4. No 12 VAC power to control.
5. Motor (inoperative).
6. Door switch (open contacts).
7. Door latch not making contact with
door switch.
8. Touch pad circuit defective.
9. No indicator lamps illuminate when
STARTorOPTIONSare pressed.
1. Motor(bad bearings).
2. Motor stuck due to prolonged
non-use.
1. Improper voltage.
2. Motor windings shorted.
3. Glass or foreign items in pump.
1. Heaterelement(open).
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Hi-Limit thermostat defective.
1. Latch mechanism defective.
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Broken spring(s).
5. Defective actuator.
1. Drain restricted.
2. Electronic control board defective.
3. Defective drain pump.
4. Blockedimpeller.
5. Openwindings.
6. Wiring or terminal defective.
1. Water supply turned off.
2. Defective water inlet fill valve.
3. Check fill valve screen for
obstructions.
4. Defective float switch.
5. Electronic control board defective.
6. Wiring or terminal defective.
7. Pressure Switch Stuck.
1. Drain hose (high) loop too low.
2. Drain line connected to a floor drain
not vented.
1. Detergentallowedtostandtoolongin
dispenser.
2. Dispenser wet when detergent was
added.
3. Detergentcoverheldclosedorblocked
by large dishes.
4. Improperincomingwater
temperature to properly dissolve
detergent.
5. See "Detergent cover will not open."
Always disconnect the dishwasher from the electrical power source before adjusting or
replacing components.
Personal Injury Hazard
Heater
Refer to the cycle chart on the reverse side to
determine when the heater is on during the
wash cycle. The heater cycles ON and OFF for
brief periods during the drying cycle.
Voltage checks of the heater should be made in
the dry portion of the service test mode.
The drain hose must have a loop at a
minimum
height of 32 inches
in order to insure proper
drainage.
PumpAssembly
The pump assembly is driven by a synchronous
motor. Themotor drivesa pumpwhich supplies
100 percent filtered water
Draining is accomplished by using a small
separate synchronous drain pump mounted to
the side of the sump. The drain pump is
connected to the main pump by a small rubber
hose. The drain check valve is located at the
dischargeendof the drainpump. The drainhose
is attached by a clamp to the discharge end of
the drain pump.
DetergentandRinseAidDispenser
The detergent and rinse aid dispenser is a one
piece component consisting of a molded
detergent cup and a built-in rinse aid dispenser.
The detergent cup has a spring loaded cover
and the rinse aid dispenser has a removable
cover.
Liquid rinse aid is added to the dispenser up to
the fill line indicator. The amount of rinse aid
released can be adjusted by turning the arrow
indicator from one, being the least amount, to
four, being the greatest amount.
Remedy
1. Replace fuse or reset breaker.
2. Repair or replace wire fasteners at
dishwasher junction box.
3. Replace control board.
4. Replace control board.
5. Replacemotor/impellerassembly.
6. Replace latch assembly.
7. Replace latch assembly.
8. Replace console assembly.
9. Replace console assembly.
1. Replace motor assembly.
2. Rotatemotorimpeller.
1. Check voltage.
2. Replacemotor/impellerassembly.
3. Clean and clear blockage.
1. Replace heater element.
2. Replace control board.
3. Repair or replace.
4. Replacethermostat.
1. Replacedispenser.
2. Replace control board.
3. Repair or replace.
4. Replacedispenser.
5. Replacedispenser.
1. Clear restrictions.
2. Replace control board.
3. Replacepump.
4. Check for blockage, clear.
5. Replacepumpassembly.
6. Repair or replace.
1. Turn water supply on.
2. Replace water inlet fill valve.
3. Disassemble and clean screen.
4. Repair or replace.
5. Replace control board.
6. Repair or replace.
7. Repair or replace.
1. Repair to proper
32-inch minimum
height
.
2. Install air gap at counter top.
1. Instruct customer/user.
2. Instruct customer/user.
3. Instruct customer/user on proper
loading of dishes.
4. Incoming water temperature of
120°F is required to properly
dissolve dishwashing detergents.
Symptom
Dishwasherwillnotoperatewhen
turnedon.
Motor hums but will not start or run.
Motortrips outon internalthermal
overloadprotector.
Dishwasherruns but will not heat.
Detergent cover will not latch or
open.
Dishwasherwillnotpumpout.
Dishwasher will not fill with water.
Dishwasherwatersiphonsout.
Detergentleftindispenser.
StandardDry Air Flow
The heated, moist air leaving the dishwasher
through the console vent causes drier air to be
drawnintotheunitbywayofintakeventslocated
at the bottom of the door.
020905
The water on the dishes is evaporated into drier
air and the venting process continues. The
heatingelementisturnedONandOFFduringthe
entire drying cycle.
ProductSpecifications
Electrical
Rating...................................120 Volts, 60Hz
Separate Circuit..15 amp min.- 20 amp max.
Motor (Amps) ...................................0.6 - 0.9
Heater Wattage.......................... 475 - 630W
Total Amps (load rated) .......................... 7.0
TempAssure.............................. 135°F ±5°F
(60°C±3°C) [with outer door in place]
TempBoost ................................ 140°F ±5°F
Heated Wash/Heated Rinse
Hi-Limit Thermostat ............... 200°F (93°C)
Water Supply
Suggested minimum incoming water
temperature ............................ 120°F (49°C)
Pressure (PSI) min./max................... 20/120
Connection (NPT) ..................................... 3/8"
Consumption (Normal Cycle) ......................
.......................................... 5.2 - 5.6 U.S. gal
Watervalve flow rate (U.S. GPM) ............ 0.9
Water recirculation rate (U.S. GPM) ..............
................................................. approx. 5.28
Water fill time ................................... 36 sec.

Pots and Pans
Normal
China Crystal
Energy Saver
Rinse and Hold
Washing
Drying
Clean
Time in Minutes
Water Valve
Pump Motor
Drain Motor
Heater
Dispensers
WATER HEAT DELAY WATER HEAT DELAY
Outputs
MAIN WASH 5
35 MIN.
RINSE 6
8 MIN.
RINSE 7
8 MIN.
DRY (HOT OR COOL)
19.5 MIN
PRE-WASH
1
8 MIN.
PRE-WASH
2
8 MIN.
PRE-
WASH 3
8 MIN.
PRE-
WASH 4
8 MIN.
LED
Cycle Selection Options
Cycles
