Frigidaire FDBB2040F User manual

P30L0065.eps P30C0149.eps P30B0037.eps P30U0021.eps P30M0040.eps P30F0022.eps
P30R0098.eps
Product No. FDBB2040FB0 FDBB2040FC0 FDBB2040FQ0 FDBB2040FS0
Series Built-in 24" Built-in 24" Built-in 24" Built-in 24"
Color black stainless bisque white
Owner's Guide English 154577801 154577801 154577801 154577801
Owner's Guide Spanish 154577803 154577803 154577803 154577803
Owner's Guide French 154577802 154577802 154577802 154577802
Service Data Sheet 154526501 154526501 154526501 154526501
Energy Guide 154540024 154540024 154540024 154540024
Installation Instructions 154427301 154427301 154427301 154427301
Market North America North America North America North America
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995463386
06/03/16
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
FDBB2040F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995463386 FDBB2040F
03/06 2
CONTROL PANEL

FDBB2040F Publication No: 5995463386
# Functional Parts 3 03/06
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFDBB2040F (FDBB2040FB0)
BFDBB2040F (FDBB2040FC0)
CFDBB2040F (FDBB2040FQ0)
DFDBB2040F (FDBB2040FS0)
POS. NO PART NO. DESCRIPTION
1 154486003 A B - - Panel, control, black
1 154486004 - - C - Panel, control, bisque
1 154486001 - - - D Panel, control, white
2 154577303 A B - - Insert, control panel, 9 pad, black
2 154577304 - - C - Insert, control panel, 9 pad, bisque
2 154577301 - - - D Insert, control panel, 9 pad, white
3 154555001 A B C D Board, control
3* 154200401 A B C D Screw, 6-10 x 3/8, pan plask
4 154554601 A B C D Cover, control
4* 154478901 A B C D Gasket, cover
8 # 154474701 A B C D Switch, selector, 9 pad
8* 5303318719 A B C D Screw, mtg.
8A 154486201 A B C D Shield, tactile switch
20 154423601 A B C D Vent assy, active dry, w/actuator
20* 154436201 A B C D Screw, dry duct, (3)
27 154433501 A B C D Actuator, active dry vent
28 154474401 A B C D Adapter, vent
* # 154547001 A B C D Wiring Harness
* 154227501 A B C D Thermistor
* 154540024 A B C D Energy guide label

Publication No: 5995463386 FDBB2040F
03/06 4
DOOR

FDBB2040F Publication No: 5995463386
# Functional Parts 5 03/06
* Non-Illustrated Parts
DOOR
Model Index: AFDBB2040F (FDBB2040FB0)
BFDBB2040F (FDBB2040FC0)
CFDBB2040F (FDBB2040FQ0)
DFDBB2040F (FDBB2040FS0)
POS. NO PART NO. DESCRIPTION
1 154430501 A B C D Spring, door, (2)
1A 154325201 A B C D Linkage, door spring, (2)
2 154093301 A B C D Screw, arm assy, (4)
3 154558103 A B C D Arm Assy, LH
3A 154558503 A B C D Arm Assy, RH
* 154529101 A B C D Pin, arm assy
5 154079601 A B C D Nut, arm assy, and handle mtg.
7 154494601 A B C D Liner, door assy.
9 154542103 A B C D Dispenser, det/rinse aid, w/o reed
9* 154294701 A B C D Screw, #7 plas .375, (6), disp. assy.
10 154103702 A B C D Screw, latch mtg, (2)
12 154529403 A B - - Latch assy, black
12 # 154529404 - - C - Latchassy,bisque
12 154529401 - - - D Latch assy, white
20 154524903 A - - - Door Assy, black, outer
20 154533401 - B - - Door, stainless
20 154436804 - - C - Door Assy, bisque, outer
20 154524901 - - - D Door Assy, white, outer
20* 154253201 A B C D Insulation, door
20* 5304428306 A B C D Screw, door mtg., (2)
49 154297603 A B C D Gasket, door, bottom
50 154211401 A B C D Support, door hinge
51 154320301 A B C D Clamp, drip loop, wire
* 154200601 A B C D Screw, #10-16 x 3/8

Publication No: 5995463386 FDBB2040F
03/06 6
TUB

FDBB2040F Publication No: 5995463386
# Functional Parts 7 03/06
* Non-Illustrated Parts
TUB
Model Index: AFDBB2040F (FDBB2040FB0)
BFDBB2040F (FDBB2040FC0)
CFDBB2040F (FDBB2040FQ0)
DFDBB2040F (FDBB2040FS0)
POS. NO PART NO. DESCRIPTION
1 # 154534701 A B C D Tub assy, w/frame parts
2 154429101 A B C D Strike, door
3 # 154561001 A B C D Gasket, tub
4 154200602 A B C D Screw, 10-16 x 3/8, hex
5 154333902 A B C D Roller, tub
6 5303943103 A B C D Screw, w/washer, (8)
22 154446002 A B C D Tubing, water inlet
23 5303318539 A B C D Clamp, tubing, (2)
24 # 154525301 A B C D Hose, drain
25 # 154209701 A B C D Float
28 154408701 A B C D Switch Assy, float
29 # 154290204 A B C D Thermostat, re-settable
30 154241101 A B C D Retainer, thermostat
30* 154297701 A B C D Screw, retainer-thermo
* 154447102 A B C D Insulation,blanket
* 154041001 A B C D Screw, plask #1, 10-10 x 9/16
* 5300807270 A B C D Screw, (2), countertop mtg.

Publication No: 5995463386 FDBB2040F
03/06 8
MOTOR & PUMP

FDBB2040F Publication No: 5995463386
# Functional Parts 9 03/06
* Non-Illustrated Parts
MOTOR & PUMP
Model Index: AFDBB2040F (FDBB2040FB0)
BFDBB2040F (FDBB2040FC0)
CFDBB2040F (FDBB2040FQ0)
DFDBB2040F (FDBB2040FS0)
POS. NO PART NO. DESCRIPTION
1 # 154482901 A B C D Heater, round
1* 154106201 A B C D Nut, heater, (2)
1* 154289801 A B C D Shield, heater terminal
2 154465101 A B C D Bracket, heater, (2)
10 154245501 A B C D Cover, volute
13 154246801 A B C D Gasket, sump
14 154461901 A B C D Housing, sump
16 154246502 A B C D Retainer, sump
24 154414102 A B C D Spray arm, lower, w/heat shield
24A 154468502 A B C D Spray arm, grey, center
24B 154478201 A B C D Spray arm, 3rd level
32 154464101 A B C D Tube, delivery
32* 154491101 A B C D Screw, delivery tube
32A 154406401 A B C D Gasket, delivery tube
40 154348401 A B C D Clamp, red, pump
40 154348502 A B C D Clamp, red, pump
40* 154106801 A B C D Clamp, hose, worm/drain
40* 154380601 A B C D Clamp, hose, worm/gear
54 154234401 A B C D Hose, connector
55 154362301 A B C D Bracket, motor
55* 5303316032 A B C D Screw, truss ss, 8 .625
58 154246402 A B C D Check ball
59 154246901 A B C D O-ring, rear
59A 154247001 A B C D O-ring, front
60 154491301 A B C D Pump, drain
60* 5303318719 A B C D Screw, mtg.
61 154463402 A B C D Grommet, delivery tube
62 154294101 A B C D Support, spray arm, lower
63 154252201 A B C D Base, soil director
64 154252301 A B C D Filter, soil director, white
65 154252401 A B C D Filter, polypro
66 154252701 A B C D Trap, glass
70 # 154520501 A B C D Motor Assembly, circulation, w/o o'rings
* 154200601 A B C D Screw, #10-16 x 3/8

Publication No: 5995463386 FDBB2040F
03/06 10
FRAME

FDBB2040F Publication No: 5995463386
# Functional Parts 11 03/06
* Non-Illustrated Parts
FRAME
Model Index: AFDBB2040F (FDBB2040FB0)
BFDBB2040F (FDBB2040FC0)
CFDBB2040F (FDBB2040FQ0)
DFDBB2040F (FDBB2040FS0)
POS. NO PART NO. DESCRIPTION
3 # 154476101 A B C D Valve, water
4 154208701 A B C D Brace, front frame
8 154322903 A B - - Toeplate, adjustable, black
8 154322905 - - C - Toeplate, adjustable, bisque
8 154322901 - - - D Toeplate, adjustable, white
9 154397203 A B - - Kickplate Assy, black, w/foam
9 154397204 - - C - Kickplate Assy, bisque, w/foam
9 154397201 - - - D Kickplate Assy, white, w/foam
10 5300808658 A B - - Screw, #8A x .375", black
10 154371303 - - C - Screw, phillips head, bisque
10 154371301 - - - D Screw, phillips head, white
11 154200701 A B C D Screw, #10-32 x 3/8
11A 154200601 A B C D Screw, #10-16 x 3/8
15 154419301 A B C D Screw, leveling
20 154209601 A B C D Cover, junction box
* 154041001 A B C D Screw, plask #1, 10-10 x 9/16
* 154200602 A B C D Screw, 10-16 x 3/8, hex
* 154409401 A B C D Screw, #8-18 x .375

Publication No: 5995463386 FDBB2040F
03/06 12
RACKS

FDBB2040F Publication No: 5995463386
# Functional Parts 13 03/06
* Non-Illustrated Parts
RACKS
Model Index: AFDBB2040F (FDBB2040FB0)
BFDBB2040F (FDBB2040FC0)
CFDBB2040F (FDBB2040FQ0)
DFDBB2040F (FDBB2040FS0)
POS. NO PART NO. DESCRIPTION
1 154319706 A B C D Rack assy, lower
2 154556101 A B C D Basket, silverware, white
3 154319524 A B C D Rack assy, upper
4 154522901 A B C D Wheel & bushing assy, upper rack, (8)
5 5304440996 A B C D Cap, slide, grey, (4)
6 154232701 A B C D Slide, rack, (2)
7 154174502 A B C D Wheel & bracket assy, lower rack
11 154436101 A B C D Shelf, cup, half width, white
16A 154424301 A B C D Cover, side basket, (2), silverware
18 154548303 A B C D Nameplate, Frigidaire, grey, spacer
