Frigidaire FDBB944C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR
FDBB944CB0 FDBB944C Built-in 24" black
FDBB944CC0 FDBB944C Built-in 24" stainless
FDBB944CQ0 FDBB944C Built-in 24" bisque
FDBB944CS0 FDBB944C Built-in 24" white
MARKET
North America
Publication No.
5995386322
030221
-EN/SERVICE /ECL
821
24" Built-In
DISHWASHER
Model No.
FDBB944C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
DISHWASHER
SERVICE DATA SHEET # - 154459001
OWNER’S GUIDE # - 154446701
INSTALLATION INSTRUCTIONS # - 154427301
ENERGY GUIDE LABEL # - 154399013
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917

02/03 2
Publication No. FDBB944C
5995386322
CONTROL PANEL

# = Fast Moving Part 3 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
CONTROL PANEL
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
1 154370301 A - - - Panel,control ,white
1 154370303 - B C - Panel,control ,black
1 154370304 ---D Panel,control ,bisque
2 154445001 A - - - Insert,control panel ,white
2 154445003 - B C - Insert,control panel ,black
2 154445004 ---D Insert,control panel ,bisque
3 # 154445801 A B C D Control,electronic
3* 154200401 A B C D Screw,6-10 x 3/8 ,pan plask
4 154287901 A B C D Cover,control
18 154422301 A - - - Nameplate,white
18 154422303 - B C - Nameplate,black
18 154422304 ---D Nameplate,bisque
20 154433001 A B C D Vent assy,static dry
20* 154436201 A B C D Screw,dry duct ,(3)
34 # 154442101 A B C D Keypad,9pad
* # 154460001 A B C D Wiring Harness,main
* 154227501 A B C D Thermistor
* 154399013 A B C D Label,energy guide
* 154283901 A B C D Screw,#8-10 ,3/8 phillips

02/03 4
Publication No. FDBB944C
5995386322
DOOR

# = Fast Moving Part 5 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
1 154430601 A B C D Spring,door ,(2)
1A 154325201 A B C D Linkage,door spring ,(2)
2 154093301 A B C D Screw,arm assy ,(4)
3 154325304 A B C D Arm Assy,LH
3A 154325303 A B C D Arm Assy,RH
* 154400601 A B C D Pin,arm assy
5 154079601 A B C D Nut,arm assy ,and handle mtg.
7 154299004 A B C D Door,inner assy
9 154230103 A B C D Dispenser,det/rinse aid ,includes #22
9* 154294701 A B C D Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B C D Screw,latch mtg ,(2)
12 154434101 A - - - Latch assy,white
12 154434103 - B C - Latch assy,black
12 # 154434104 ---D Latch assy,bisque
20 154359006 A - - - Door,white
20 154359007 - B - - Door,black
20 154359012 - - C - Door,stainless
20 154359008 ---D Door,bisque
20* 5304428306 A B C D Screw,door mtg. ,(2)
22 154388801 A B C D Cap,Rinse aid
49 154297603 A B C D Gasket,door ,bottom
50 154211401 A B C D Support,door hinge
51 154320301 A B C D Clamp,drip loop ,wire
* 154200601 A B C D Screw,#10-16 x 3/8
DOOR

02/03 6
Publication No. FDBB944C
5995386322
TUB

# = Fast Moving Part 7 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C D Tub assy,w/frame parts
2 154429101 A B C D Strike,door
3 # 154211801 A B C D Gasket,tub
4 154200602 A B C D Screw,10-16 x 3/8 ,hex
5 154333902 A B C D Roller,tub
6 5303943103 A B C D Screw,w/washer ,(8)
22 154239801 A B C D Tubing,water inlet
23 5303318539 A B C D Clamp,tubing ,(2)
24 # 154411003 A B C D Hose,drain
25 # 154209701 A B C D Float
28 154408701 A B C D Switch assy,float
29 # 154290204 A B C D Thermostat,re-settable
30 154241101 A B C D Retainer,thermostat
30* 154297701 A B C D Screw,retainer-thermo
* 154447102 A B C D Insulation,blanket
* 154041001 A B C D Screw,plask #1 ,10-10 x 9/16
* 5300807270 A B C D Screw,(2) ,countertop mtg.
TUB

02/03 8
Publication No. FDBB944C
5995386322
MOTOR & PUMP

# = Fast Moving Part 9 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B C D Heater
1* 154106201 A B C D Nut,heater ,(2)
1* 154289801 A B C D Shield,heater terminal
2 154359701 A B C D Bracket,heater ,(2)
10 154245501 A B C D Cover,volute
13 154246801 A B C D Gasket,sump
14 154365902 A B C D Housing,sump
16 154246502 A B C D Retainer,sump
24 154414101 A B C D Spray arm,lower ,w/heat shield
24A 154313601 A B C D Spray arm,center
24A* 154252001 A B C D Nut,spray arm ,center
32 154406601 A B C D Tube,delivery
32A 154406401 A B C D Gasket,delivery tube
40 154348401 A B C D Clamp,red ,pump
40 154348501 A B C D Clamp,silver ,pump
40* 154106801 A B C D Clamp,hose ,(2)
40* 154380601 A B C D Clamp,hose ,(1)
54 154234401 A B C D Hose,connector
55 154362301 A B C D Bracket,motor ,askoll
55* 5303316032 A B C D Screw,truss ss ,8 .625
58 154246402 A B C D Check ball
59 154246901 A B C D O-ring,rear
59A 154247001 A B C D O-ring,front
60 154407401 A B C D Drain Pump Assy
60* 154426201 A B C D Bracket,motor ,drain
61 154406501 A B C D Nozzle,3rd level ,spray arm
62 154294101 A B C D Support,spray arm ,lower
63 154252201 A B C D Base,soil director
64 154252301 A B C D Filter,soil director
65 154252401 A B C D Filter,polypro
66 154252701 A B C D Trap,glass
70 # 154395403 A B C D Motor assembly,circulation ,w/o o’rings
* 154200601 A B C D Screw,#10-16 x 3/8
MOTOR & PUMP

02/03 10
Publication No. FDBB944C
5995386322
FRAME

# = Fast Moving Part 11 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
FRAME
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
3 # 154373303 A B C D Valve,water
4 154208701 A B C D Brace,front frame
8 154322901 A - - - Toeplate,adjustable ,white
8 154322903 - B C - Toeplate,adjustable ,black
8 154322905 ---D Toeplate,adjustable ,bisque
9 154397201 A - - - Kickplate Assy,white ,w/foam
9 154397203 - B C - Kickplate Assy,black ,w/foam
9 154397204 ---D Kickplate Assy,bisque ,w/foam
10 154371301 A - - - Screw,phillips head ,white
10 5300808658 - B C - Screw,#8A x .375" ,black
10 154371303 ---D Screw,phillips head ,bisque
11 154409401 A B C D Screw,#8-18 x .375
11A 154200601 A B C D Screw,#10-16 x 3/8
15 154419301 A B C D Screw,leveling
20 154209601 A B C D Cover,junction box
* 154041001 A B C D Screw,plask #1 ,10-10 x 9/16
* 154200602 A B C D Screw,10-16 x 3/8 ,hex

02/03 12
Publication No. FDBB944C
5995386322
RACKS

# = Fast Moving Part 13 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
RACKS
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
1 154319706 A B C D Rack assy,lower
2 154424001 A B C D Basket,silverware ,main
2A 154424101 A B C D Basket,silverware ,(2) ,side
3 154319524 A B C D Rack assy,upper
4 5304407064 A B C D Wheel & bushing assy,upper rack
5 5300809927 A B C D Cap,slide ,(4)
6 154232701 A B C D Slide,rack ,(2)
7 154174501 A B C D Wheel & bracket assy,lower rack
8 154304001 A B C D Base,funnel
9 154251801 A B C D Funnel
10 154238801 A B C D Basket,utility ,white
11 154436101 A B C D Shelf,cup ,half width ,white
