Frigidaire FFBD2411NB Installation instructions

frigidaire.com
Drop-In Cooktop
FPEC3085K S 30" Electric
Signature Features
24" Built-In
Dishwashers
FFBD2411N S / M / W / B / Q
Eco-Friendly
ENERGY STAR® qualified dishwasher also
features an Energy Saver Plus Cycle that
uses less energy without compromising
cleaning performance.
Quiet Dishwasher
A quiet performance every time so it
won’t interrupt your time at home.
Energy Saver Dry Option
No heat dry option.
Built With American Pride
Appliances that are high-performing,
more accessible, and more innovative
than ever — designed, built and
engineered in the U.S. A.
Product Dimensions
Height (Adjustable) 33-1/2" – 35"
Width 24"
Depth (Including Door) 25"
More Easy-To-Use Features
NSF® Certified
Sanitize cycle removes 99.9% of
common household bacteria.
Delay Start
2-4-6-hour Delay Start Option. Set your
dishwasher to run on your schedule.
Fits-More™ Capacity
Our large capacity, tall-tub dishwwasher
fits up to 14 place settings so you can
wash even more at once.
SpaceWise® Silverware Basket
There’s a place for all of your silverware
in our multicompartment, removable
basket.
Ready-Select® Controls
Easily select options with the touch
of a button.
5 Wash Cycle Options
High Temperature Wash
Control Lock Option
Attractive Stainless Steel Exterior1
ENERGY STAR®
NSF® International
Certification
Available in:
1 Select model only.
Stainless
(S)
Bisque
(Q)
Black
(B)
White
(W)
Silver Mist
(M)

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFBD2411N 03/12 © 2012 Electrolux Home Products, Inc.
Features
Control Design
Digital Display
Door Latch
Stay-Put Door Hinge Design
Low Rinse-Aid Indicator Light
Interior Design
Interior Color
Wash System
Wash Levels / Wash Speeds
Sound Package
Filter
Filter Trap
Soft Food Disposer
dB Level
Drying System
Cycles
Number of Cycles
Heavy
Normal
Light
Delicate
Favorite
China / Crystal
Rinse Only
Energy Saver Plus
Upper Rack Wash Only
Cycle Indicator Light
Control Lock
Options
Heat / No Heat Dry
Hi-Temp Wash
NSF® Certified Sanitize Rinse
Delay Start
Rack System
Rack Design / Rack Coating
Upper Rack –
Stemware / Champagne Glass Holders
Fold-Down Tines
Cup Shelves
Lower Rack –
SpaceWise® Silverware Basket
Fold-Down Tines
Small Items Cover
Certifications
ENERGY STAR®
NSF® International Certification
Specifications
Water Inlet Location
Water Usage (Gallons)
Water Pressure (PSI)
Integral Air Gap on Supply
Leveling Legs
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts 1
Amps @ 120 Volts
Shipping Weight (Approx.)
Ready-Select®
Yes
Yes
Tall Tub
White
Direct
5 / 1
UltraQuiet™ 3
Plastic
Removable
Yes
55
Active Vent
5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes / Yes
Yes
Yes
2-4-6 Hour
Deluxe / PVC
Ultra 1
Yes
Yes
Left Bottom Front
6.0
20 – 120
Yes
4
Right Bottom Front
120V / 60 Hz / 15A
1.44
10
64 Lbs.
1 For use on adequately wired 120V, dedicated circuit having
2-wire service with a separate ground wire. Appliance must be
grounded for safe operation.
Dishwashers
FFBD2411N S / M / W/ B / Q 24" Built-In
Product Dimensions
A - Height (Adjustable)
B - Width
C - Depth (Including Door)
D - Depth (To Tub Flange)
Depth with Door Open 90˚
33-1/2" – 35"
24"
25"
22-1/2"
49-1/4"
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Depth (Min.)
34-1/4"
35-1/4"
24"
24"
NOTE: For planning purposes only. Always consult local and national electric and plumbing codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
B
A
D
C
24" Built-In Dishwashers
Frigidaire Baseline
Meets requirements
of ASSE 1006
Accessories information available
on the web at frigidaire.com

Specifications
subject to change.
Meets
requirements of
ASSE 1006
24" Built-In Dishwasher w/Ready-Select Controls (RSC)
Baseline
Dishwasher Specifications
•Product Shipping Weight (approx.) – 64 Lbs.
•Voltage Rating – 120V / 60 Hz / 15 Amps (maximum 20 Amps if
connected with disposer)
•Connected Load (kW Rating) @ 120 Volts = 1.44 kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•Amps @ 120V = 10 Amps
•Always consult local and national electric & plumbing codes.
Meets requirements of ASSE 1006 — integral air gap on supply.
•Water Pressure – Hot water line to dishwasher must provide
between 20 and 120 pounds per square inch (psi).
•Make sure location has right drain, water and electrical outlets
to make connections.
•Keep back free of drain, water & electrical supply.
•Electrical and water supplies should enter cabinet opening on floor,
or through back or side walls, as shown in shaded areas.
•Connections preferably located toward left side of dishwasher. Do not
cross drain, water or electrical lines in front of motor, blower or frame.
•When installing adjacent to wall, cabinet or other obstruction that
extends beyond front edge of unit, allow 2" minimum clearance
between opened door and obstruction.
•When installing at end of cabinet line, sides must be fully enclosed.
•Do not install unit under a cooktop, damage will occur.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFBD2411N 03/12 © 2012 Electrolux Home Products, Inc.
Dishwashers
FFBD2411N S / M / W/ B / Q 24" Built-In

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 02/12 © 2012 Electrolux Home Products, Inc.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 02/12 © 2012 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_FDR FR 02/12 © 2012 Electrolux Home Products, Inc.
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
General Installation Guidelines
with French Door Refrigerator
