Trouble Shooting TipsExploded View of Wash System
Tub and Door Seal
The door seal is pressed into the tub channel for
aninterferencefit.Centerthegasket(markedon
back) at the tub top center and press in place
Product Specifications
Electrical
Rating .................................. 120 Volts, 60Hz
Separate Circuit..15 amp min.- 20 amp max.
Motor (HP).................................................1/12
Motor (Amps) ........................................... 3.4
Heater Wattage ....................................... 900
Total Amps (load rated) ......................... 11.0
TempAssure................................136°F ±5°F
(58°C±3°C) [with outer door in place]
TempBoost............... 144°F ±5°F (62°C ±3°C)
Heated Wash/Heated Rinse
Hi-Limit Thermostat..................200°F (93°C)
Water Supply
Suggested minimum incoming water
temperature ..............................120°F (49°C)
Pressure (PSI) min./max. ...................20/120
Connection (NPT)......................................3/8"
Consumption (Normal Cycle) ........................
......... 6.0 U.S. gal., 5.0 Imp. gal., 22.7 liters
Water valve flow rate (U.S. GPM) .......... .83
Water recirculation rate (U.S. GPM)..............
.................................................... approx. 12
Water fill time..................................... 87 sec.
• remove the six screws,
• remove the dispenser,
• replace and reinstall screws,
• rewire actuator.
To replace actuator:
• shut off electricity to dishwasher,
• disconnect wiring to the actuator,
• placeaflatheadscrewdriverundertheactuator
body and between the dispenser housing and
terminal side, twist and lift up on the actuator
being careful not to damage the retainer
snap-fits,
• replace with new actuator by pressing into
place,
• rewire actuator.
Power Dry Air Flow
The Power Dry configuration is the same as the
Standardexceptithasacrossflowblowerlocated
in the air discharge path. The blower assists the
heating element in producing power to drive the
moist air out of the dishwasher.
Check the Following
1. Fuse (blown or tripped).
2. 120 VAC supply wiring connection
faulty.
3. Electronic control board defective.
4. No 12 VAC power to control.
5. Motor (inoperative, check
resistances).
6. Door switch (open contacts).
7. Door latch not making contact with
door switch.
8. Touch pad circuit defective.
9. No indicator lamps illuminate when
START or OPTIONS are pressed.
1. Motor(badbearingsorlocked rotor).
2. Motor stuck due to prolonged
non-use.
1. Improper voltage.
2. Seal faces binding.
3. Motor shaft binding.
4. Motor windings shorted.
5. Glass or foreign items in pump.
1. Heater element (open).
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Hi-Limit thermostat defective.
1. Latch mechanism defective.
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Broken spring(s).
5. Defective actuator.
1. Drain restricted.
2. Electronic control board defective.
3. Defective drain pump.
4. Air lock in drain hose.
5. Blocked impeller.
6. Open windings.
7. Wiring or terminal defective.
1. Water supply turned off.
2. Defective water inlet fill valve.
3. Check fill valve screen for
obstructions.
4. Defective float switch.
5. Electronic control board defective.
6. Wiring or terminal defective.
7. Float stuck in “UP” position.
1. Drain hose (high) loop too low.
2. Drain line connected to a floor drain
not vented.
3. Drain hose not connected to side of
tub.
1. Detergent allowed to stand too long
in dispenser.
2. Dispenser wet when detergent was
added.
3. Detergent cover held closed or
blocked by large dishes.
4. Improper incoming water
temperature to properly dissolve
detergent.
5. See "Detergent cover will not open."
Always disconnect the dishwasher from the electrical power source before adjusting or
replacing components.
Personal Injury Hazard
Nozzle
Funnel
Nut
Funnel Base
Center Spray Arm
Lower Spray Arm
900 Watt Heater
Refer to the cycle chart on the reverse side to
determinewhentheheaterisonduringthewash
cycle. The heater cycles ON and OFF for brief
periods during the drying cycle.
Voltage checks of the heater should be made in
the dry portion of the service test mode.
airlock.Thedrainlooponthesideofthetubmust
be kept in place after servicing.
The main pump can easily be removed by
disconnecting the upper spray arm supply tube,
the drain pump connector hose, and the wiring
harness connections made at the circulation
motor and the water heat thermistor located on
the bottom of the pump.
Once the pump assembly is removed from the
dishwasher,themotor/impellerassembly canbe
removed from the sump by taking out the three
(3) T-20 Torx head screws from the aluminum
motor bracket and then the three (3) T-20 Torx
headscrewsfromthevolutecover.Using a large
flat head screwdriver inserted between the
impellerscrewandthe sump’s volute, the motor/
impeller assembly can be gently pried out of the
sump. Use the screwdriver as a lever.
Pump Assembly
The pump assembly is driven by a 1/12 HP,
shaded pole motor. Rotation is in the
counterclockwisedirectionat3100to3200RPM.
The motor drives a pump which supplies 100
percent filtered water at a rate of approximately
12 GPM to one spray arm at a time. The spray
arm’s operation is alternated by small “pauses”
of the motor during the wash cycle.
Draining is accomplished by using a small
separate synchronous drain pump mounted to
thesideofthesump.Thedrainpumpisconnected
to the main pump by a small rubber hose. The
draincheckvalveislocatedattheentrancetothe
drain pump. The drain hose is attached by a
worm gear clamp to the discharge of the drain
pump.The drain isthenrouted up thesideofthe
dishwasher and attached to the side of the tub.
This drain loop insures that an air pocket cannot
formnearthedrainpump and cause the pumpto
withoutstretchingorbunching.Thegaskettakes
a short turn at the bottom of the tub channel
before ending at the channel end wall.
Short Turn
Incoming Water Supply
Drain Hose
Spray Arm
Support
Glass Trap
Heating
Element
Filter
Soil Director
Volute Cover
Drain Motor
Delivery Tube
Connector Hose
Motor Bracket
Circulation Motor
Water Inlet Tube
Water Valve
Check Ball
Impeller
Sump
Impeller Screw
Gasket Cross Section
Detergent and Rinse Aid Dispenser
The detergent and rinse aid dispenser is a one
piece component consisting of a molded
detergent cup and a built-in rinse aid dispenser.
Thedetergentcup hasaspringloadedcover and
the rinse aid dispenser has a removable cover.
Liquid rinse aid is added to the dispenser up to
the fill line indicator. The amount of rinse aid
released can be adjusted by turning the arrow
indicator from one, being the least amount, to
four, being the greatest amount.
To replace dispenser:
• shut off electricity to dishwasher,
• remove outer door panel assembly,
• disconnect wiring to the actuator,
Mounting
Rib
Tub
Interior
Remedy
1. Replace fuse or reset breaker.
2. Repair or replace wire fasteners at
dishwasher junction box.
3. Replace control board.
4. Replace transformer.
5. Replace motor/impeller assembly.
6. Replace door switch.
7. Replace latch assembly.
8. Replace console assembly.
9. Replace console assembly.
1. Replace motor.
2. Rotate motor fan or impeller.
1. Check voltage.
2. Rotate motor fan or impeller, or
replace.
3. Clear blockage or replace.
4. Replace motor/impeller assembly.
5. Clean and clear blockage.
1. Replace heater element.
2. Replace control board.
3. Repair or replace.
4. Replace thermostat.
1. Replace dispenser.
2. Replace control board.
3. Repair or replace.
4. Replace dispenser.
5. Replace actuator.
1. Clear restrictions.
2. Replace control board.
3. Replace pump.
4. Make sure hose is attached in proper
position on side of tub.
5. Check for blockage, clear.
6. Replace windings.
7. Repair or replace.
1. Turn water supply on.
2. Replace water inlet fill valve.
3. Disassemble and clean screen.
4. Repair or replace.
5. Replace control board.
6. Repair or replace.
7. Clean float.
1. Repair to proper height.
2. Install air gap at counter top.
3. Reattach drain hose.
1. Instruct customer/user.
2. Instruct customer/user.
3. Instruct customer/user on proper
loading of dishes.
4. Incoming water temperature of
120°F is required to properly
dissolve dishwashing detergents.
Symptom
Dishwasher will not operate when
turned on.
Motor hums but will not start or
run.
Motor trips out on internal thermal
overload protector.
Dishwasher runs but will not heat.
Detergent cover will not latch or
open.
Dishwasher will not pump out.
Dishwasher will not fill with water.
Dishwasher water siphons out.
Detergent left in dispenser.
Seal
Barrel Front
Macerator
Barrel Rear
Standard Dry Air Flow
Whenthecontroladvancestothe “dry” portion of
thecycle,alinearactuatorretractsavalve,which
opens a vent path through the console into the
kitchen.This venting method eliminates
discharging heated moisture into the motor
compartment. The heated, moist air leaving the
dishwasher through the console vent causes
drierairto be drawn into theunitby way of intake
vents located at the bottom of the door. The
water on the dishes is evaporated into drier air
and the venting process continues. The heating
element is turned ON and OFF during the entire
drying cycle.
961203 (ELEC)
