Trouble Shooting TipsExploded View of Wash System
Tub and Door Seal
The door seal is pressed into the tub channel for
an interference fit. To install the seal, locate the
center mark on the seal back and press into
ProductSpecifications
Electrical
Rating...................................120 Volts, 60Hz
Separate Circuit..15 amp min.- 20 amp max.
Motor (Amps) ........................................... 1.8
Heater Wattage.......................................900
Total Amps (load rated)......................... 10.0
TempAssure .............................. 140°F ±5°F
(60°C±3°C) [with outer door in place]
TempBoost.............145°F ±5°F (63°C ±3°C)
Heated Wash/Heated Rinse
Sanitize ..................150°F ±5°F (66°C ±3°C)
Hi-Limit Thermostat ................ 200°F (93°C)
Water Supply
Suggested minimum incoming water
temperature............................. 120°F (49°C)
Pressure (PSI) min./max.................... 20/120
Connection (NPT) ..................................... 3/8"
Consumption (Normal Cycle) .......................
.............4.9 - 9.7 U.S. gal., 18.5 - 36.7 liters
Water valve flow rate (U.S. GPM)........... .83
Water recirculation rate (U.S. GPM) ..............
.................................................... approx. 12
Water fill time.....................................87 sec.
To replace dispenser:
• shut off electricity to dishwasher,
• remove outer door panel assembly,
• disconnect wiring to the actuator,
• remove the six screws,
• remove the dispenser,
• replace and reinstall screws,
• rewire actuator.
Check the Following
1. Fuse (blown or tripped).
2. 120 VAC supply wiring connection
faulty.
3. Electronic control board defective.
4. No 12 VAC power to control.
5. Motor (inoperative).
6. Door switch (open contacts).
7. Door latch not making contact with
door switch.
8. Touch pad circuit defective.
9. No indicator lamps illuminate when
STARTorOPTIONSarepressed.
1. Motor(badbearings).
2. Motor stuck due to prolonged
non-use.
1. Improper voltage.
2. Motor windings shorted.
3. Glass or foreign items in pump.
1. Heaterelement(open).
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Hi-Limit thermostat defective.
1. Latch mechanism defective.
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Broken spring(s).
5. Defective actuator.
1. Drain restricted.
2. Electronic control board defective.
3. Defective drain pump.
4. Blockedimpeller.
5. Openwindings.
6. Wiring or terminal defective.
1. Water supply turned off.
2. Defective water inlet fill valve.
3. Check fill valve screen for
obstructions.
4. Defective float switch.
5. Electronic control board defective.
6. Wiring or terminal defective.
7. Float stuck in “UP” position.
1. Drain hose (high) loop too low.
2. Drain line connected to a floor drain
not vented.
1. Detergentallowedtostandtoo longin
dispenser.
2. Dispenser wet when detergent was
added.
3. Detergentcoverheldclosedorblocked
by large dishes.
4. Improperincomingwater
temperature to properly dissolve
detergent.
5. See "Detergent cover will not open."
Always disconnect the dishwasher from the electrical power source before adjusting or
replacing components.
Personal Injury Hazard
isattachedbyawormgearclamptothedischarge
end of the drain pump.
The drain hose must have a loop at a
minimum
height of 32 inches
in order to insure proper
drainage.
The main pump can easily be removed by
disconnecting the upper spray arm supply tube
hose,thedrain pump connector hose,the wiring
harness connections made at the circulation
motor, the water heat thermistor located on the
bottom of the pump and rotating the four sump
retainers toward the middle of the sump.
PumpAssembly
The pump assembly is driven by a synchronous
motor. Rotation is in the counterclockwise
directionat 3600RPM. Themotor drives apump
which supplies 100 percent filtered water at a
rate of approximately 12 GPM to one spray arm
atatime.The sprayarm’soperationisalternated
by small “pauses” of the motor during the wash
cycle.
Draining is accomplished by using a small
separate synchronous drain pump mounted to
the side of the sump. The drain pump is
connected to the main pump by a small rubber
hose. The drain check valve is located at the
dischargeend ofthe drainpump. Thedrainhose
Short Turn
Gasket Cross Section
DetergentandRinseAidDispenser
The detergent and rinse aid dispenser is a one
piece component consisting of a molded
detergent cup and a built-in rinse aid dispenser.
The detergent cup has a spring loaded cover
and the rinse aid dispenser has a removable
cover.
Liquid rinse aid is added to the dispenser up to
the fill line indicator. The amount of rinse aid
released can be adjusted by turning the arrow
indicator from one, being the least amount, to
four, being the greatest amount.
Mounting
Rib
Tub
Interior
Remedy
1. Replace fuse or reset breaker.
2. Repair or replace wire fasteners at
dishwasher junction box.
3. Replace control board.
4. Replace control board.
5. Replacemotor/impellerassembly.
6. Replace latch assembly.
7. Replace latch assembly.
8. Replace console assembly.
9. Replace console assembly.
1. Replace motor assembly.
2. Rotatemotorimpeller.
1. Check voltage.
2. Replacemotor/impellerassembly.
3. Clean and clear blockage.
1. Replace heater element.
2. Replace control board.
3. Repair or replace.
4. Replacethermostat.
1. Replacedispenser.
2. Replace control board.
3. Repair or replace.
4. Replacedispenser.
5. Replacedispenser.
1. Clear restrictions.
2. Replace control board.
3. Replacepump.
4. Check for blockage, clear.
5. Replacepumpassembly.
6. Repair or replace.
1. Turn water supply on.
2. Replace water inlet fill valve.
3. Disassemble and clean screen.
4. Repair or replace.
5. Replace control board.
6. Repair or replace.
7. Clean float.
1. Repair to proper
32-inch minimum
height
.
2. Install air gap at counter top.
1. Instruct customer/user.
2. Instruct customer/user.
3. Instruct customer/user on proper
loading of dishes.
4. Incoming water temperature of
120°F is required to properly
dissolve dishwashing detergents.
Symptom
Dishwasherwillnot operatewhen
turnedon.
Motor hums but will not start or run.
Motortripsoutoninternalthermal
overloadprotector.
Dishwasherrunsbutwillnotheat.
Detergent cover will not latch or
open.
Dishwasherwillnotpumpout.
Dishwasher will not fill with water.
Dishwasherwatersiphonsout.
Detergentleftindispenser.
Standard Dry Air Flow
Whenthecontrol advancestothe “dry”portionof
the cycle, a vent actuation solenoid is closed.
Thisopensthevent valve and startstheventfan
bothlocatedinthe toprightrearcornerof thetub.
The fan draws in the air from outside the tub,
forcing the hot, humid air down and out the
020905
bottom of the outer door panel. This outside,
cooler, dryer air helps to speed evaporation of
water from the hot dishes. At the same time the
heatingelement is continuallycycledon andoff.
On some models the dry portion of the cycle can
be extended to improve drying performance.
place. Next, install the bottom of the seal by
creating a short turn at the bottom of the tub
channel and ensuring the seal extends to the
locatorridgeat the bottomof the tub. Then align
andgently pressthe sealintothe channelin only
a few spots. Next, close and latch the door to
allowthegaskettoseat properlyintothechannel.
Cycle Selection Options
SERVICE DATA SHEET
P/N: 154889701
Electronic Series
Color Code
BK............. Black
BU....... ......Blue
PK..............Pink
R................Red
R-BK......Red/Blk
W.............White
Y-BK..Yellow/Blk
Wiring Diagram
Display Codes (LED)Display Codes (Readout)
To start
To delay start Close and latch door. Press START/CANCEL pad.
Close and latch door. Press DELAY START pad to
select desired delay time.
To select a new
cycle or option Press desired cycle and/or option pad. The indicator
lights will change. Press START/CANCEL within 15
seconds to begin cycle.
To cancel cycle Press START/CANCEL. Dishwasher will drain for
90 seconds, then shut off.
For controls
lock . . . . . . . . . Press and hold the RINSE ONLY or AIR DRY
pad for 3 seconds.
To unlock, press and hold the
pad for 3 seconds. RINSE ONLY or
AIR DRY
SENSING
WASHING
SANITIZED
DRYING
CLEAN
OPTION LED's Flashing
---------------------- Turbidity sensor is checking the condition of the wash/rinse water.
No sensing for LIGHT WASH (UPPER RACK), LIGHT WASH (LOWER
RACK) and CHINA/CRYSTAL.
---------------------- Wash portion of cycle.
-------------------- The SANITIZED criteria has been met. Indicator light will switch off
when door is opened.
----------------------- Drying portion of cycle.
------------------------ Shows completion of cycle. Indicator light will switch off when door is
opened.
-- HI-TEMP WASH and NO HEAT DRY/POWER DRY OFF LED's flashing
indicates power failure has occurred. Press START/CANCEL pad and
This information is intended for use by
persons having electrical and
mechanical training and a level of
knowledge of these subjects generally
considered acceptable in the appliance
repair trade. Electrolux Home Products
North America cannot be responsible,
nor assume any liability, for injury or
damage of any kind arising from the
use of this Service Data Sheet.
Operation
PF
Hd or HO
CL
‘01-24’
..........A power failure has occurred
.........Water heating delay
..........Close and latch the door
ER/ER....Switch Failure
ER/CE....Configuration Error
ER/uo.....Vent will not close
ER/uF.....Fan not running
...Hour(s) delay before Start (some models)
To activateWater/ServiceTest
place unit in Power Failure or
Idle Mode and the press”DRY
or“AIR DRY”(model dependent)
and the START/CANCEL keys for
3 seconds.
The dishwasher will then step
through the test cycle per the
chart, if at any time,the START/
CANCEL key is pressed, the
current step is terminated, while
the test sequence advances to
The next cycle step.
Water/Service Test
27
45
0.4
75
60
90
90
447
60 1
1
0
0
0
0
0
0
0
0
1
1
1
0
0
0
0
0
0
0
0
1
1
0
0
0
1
1
1
0
X
1
1
0
1
0
1
0
0
0
1
1
1
1
1
0
0
0
0
0
1
00
0
0
0
0
0
1
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
1
0
1
2
3
4
FILL/DISPENSER
STEP
TOTAL TIME (SEC)
WATER VALVE
CIRCULATION MOTOR
DRAIN MOTOR
HEATER
DISPENSER
FAN UNIT
WASHING LED
SANITIZED LED
DRYING LED
CLEAN LED
FILL
WASH/HEAT/DISP.
PAUSE
WASH/HEAT
WASH/HEAT/DISP.
DRAIN
DRY
TOTAL
CLEAN LED stays on until door is opened or cycle is started.
X - denotes selectable option
5
6
7
8
(Some models)
0
0
0
0
0
0
SENSING LED
RINSE LED
1
1
1
0
0
0
0
0
1
0
0
0
1
1
0
0
0
1
Device being monitored
Display flashes when
Detection of failure
Fan Damper
Turbidity
Hall Sensor
Thermistor
Fan Speed
Rinse Aid
Uo
Tu
HS
Th
UF
RA
