Frigidaire GLDB958A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR
GLDB958AB0 GLDB958A GALLERY black
GLDB958AQ0 GLDB958A GALLERY bisque
GLDB958AS0 GLDB958A GALLERY white
MARKET
North America
Publication No.
5995358784
010910
-EN/SERVICE /ECL
821
24" Built-In
DISHWASHER
Model No.
GLDB958A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
DISHWASHER
SERVICE DATA SHEET # - 154396101
OWNER’S GUIDE # - 154399901
INSTALLATION INSTRUCTIONS # - 154373601
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917

09/01 2
Publication No. GLDB958A
5995358784
CONTROL PANEL

# = Fast Moving Part 3 09/01
* = Non-Illustrated Part
GLDB958A Publication No.
5995358784
CONTROL PANEL
A = GLDB958A (GLDB958AS0)
B = GLDB958A (GLDB958AB0)
C = GLDB958A (GLDB958AQ0)
POS. NO PART NO DESCRIPTION
1 154370301 A - - Panel,control ,white
1 154370303 - B - Panel,control ,black
1 154370304 - - C Panel,control ,bisque
2 154403201 A - - Insert,control panel ,white
2 154403203 - B - Insert,control panel ,black
2 154403204 - - C Insert,control panel ,bisque
3 # 154362809 A B C Control
3* 154200401 A B C Screw,6-10 x 3/8 ,pan plask
4 154287901 A B C Cover-control
18 154399801 A - - Nameplate Assy,white
18 154399803 - B - Nameplate Assy,black
18 154399804 - - C Nameplate Assy,bisque
20 154228301 A B C Duct,dynamic
25 154229201 A B C Seal,chamber
26 154303901 A B C Gasket,vent
27 154226701 A B C Actuator,wax
28 154226901 A B C Valve,vent
29 154226403 A B C Gasket,valve
30 154226802 A B C Blower,crossflow
31 154228101 A B C Chamber,vapor
34 # 154369701 A B C Keypad,12pad
35 154393501 A B C Board,display
* 154391601 A B C Harness,wiring
* 154227501 A B C Thermister
* 154283901 A B C Screw,#8-10 ,3/8 phillips

09/01 4
Publication No. GLDB958A
5995358784
DOOR

# = Fast Moving Part 5 09/01
* = Non-Illustrated Part
GLDB958A Publication No.
5995358784
A = GLDB958A (GLDB958AS0)
B = GLDB958A (GLDB958AB0)
C = GLDB958A (GLDB958AQ0)
POS. NO PART NO DESCRIPTION
1 154365701 A B C Spring,door ,(2)
1A 154325201 A B C Linkage,door spring ,(2)
2 154093301 A B C Screw,arm assy ,(4)
3 154325304 A B C Arm Assy,LH
3A 154325303 A B C Arm Assy,RH
* 154400601 A B C Pin,arm assy
5 154079601 A B C Nut,arm assy ,(4)
7 154299002 A B C Door,inner assy
7A 154226601 A B C Grate,liner
9 154230102 A B C Dispenser,det/rinse aid ,w/ level ind.
9* 154294701 A B C Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B C Screw,latch mtg ,(2)
12 # 154361201 A - - Latch assy,white
12 # 154361203 - B - Latch assy,black
12 # 154361204 - - C Latch assy,bisque
20 154359001 A - - Door,white
20 154359003 - B - Door,black
20 154359005 - - C Door,bisque
20* 154253201 A B C • Insulation,door
22 154388801 A B C Cap,Rinse aid
49 154297602 A B C Gasket,door ,bottom
50 154211401 A B C Support,door hinge
51 154320301 A B C Clamp,drip loop ,wire
DOOR

09/01 6
Publication No. GLDB958A
5995358784
TUB

# = Fast Moving Part 7 09/01
* = Non-Illustrated Part
GLDB958A Publication No.
5995358784
A = GLDB958A (GLDB958AS0)
B = GLDB958A (GLDB958AB0)
C = GLDB958A (GLDB958AQ0)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C Tub assy,w/frame parts
2 154211601 A B C Strike,door
3 # 154211801 A B C Gasket,tub
4 154200602 A B C Screw,10-16 x 3/8 ,hex
5 154333901 A B C Roller,tub
6 5303943103 A B C Screw,w/washer ,(8)
22 154239801 A B C Tubing,water inlet
23 5303318539 A B C Clamp,tubing ,(2)
24 # 154225602 A B C Hose,drain
25 # 154209701 A B C Float
28 # 154225501 A B C Switch,float
28A 154386601 A B C Bracket,float switch
28A* 154333301 A B C Screw,bracket mtg ,ph truss head
29 # 154290204 A B C Thermostat,re-settable
30 154241101 A B C Retainer,thermostat
30* 154297701 A B C Screw,retainer-thermo
* 154238304 A B C Insulation,tub
* 154360201 A B C Insulation,blanket ,back
* 154041001 A B C Screw,plask #1 ,10-10 x 9/16
* 5300807270 A B C Screw,(2) ,countertop mtg.
TUB

09/01 8
Publication No. GLDB958A
5995358784
MOTOR & PUMP

# = Fast Moving Part 9 09/01
* = Non-Illustrated Part
GLDB958A Publication No.
5995358784
A = GLDB958A (GLDB958AS0)
B = GLDB958A (GLDB958AB0)
C = GLDB958A (GLDB958AQ0)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B C Heater
1* 154106201 A B C Nut,heater ,(2)
1* 154289801 A B C Shield,heater terminal
2 154359701 A B C Bracket,heater ,(2)
10 154245501 A B C Cover,volute
13 154246801 A B C Gasket,sump
14 154365901 A B C Housing,sump
16 154246502 A B C Retainer,sump
24 154250801 A B C Spray arm,lower
24A 154313601 A B C Spray arm,center
24A* 154252001 A B C Nut,spray arm ,center
32 154251701 A B C Tube,delivery
32A 154358901 A B C Gasket,delivery tube
40 154348401 A B C Clamp,red ,pump
40 154348501 A B C Clamp,silver ,pump
40* 154106801 A B C Clamp,hose ,(2)
54 154234401 A B C Hose,connector
55 154362301 A B C Bracket,motor ,askoll
55* 5303316032 A B C Screw,truss ss ,8 .625
58 154246402 A B C Check ball
59 154246901 A B C O-ring,rear
59A 154247001 A B C O-ring,front
60 154247502 A B C Drain Pump Assy
60* 154234501 A B C Bracket,motor ,drain
61 154359601 A B C Nozzle,3rd level ,spray arm
62 154294101 A B C Support,spray arm ,lower
63 154252201 A B C Base,soil director
64 154252301 A B C Filter,soil director
65 154283004 A B C Filter Assy
66 154252701 A B C Trap,glass
70 # 154395402 A B C Motor assembly,circulation ,w/o o’rings
71 154366101 A B C Sensor,turbidity
71* 154376001 A B C O-ring,turbidity
* 154338601 A B C Clamp-P,nylon
* 154200601 A B C Screw,#10-16 x 3/8
MOTOR & PUMP

09/01 10
Publication No. GLDB958A
5995358784
FRAME

# = Fast Moving Part 11 09/01
* = Non-Illustrated Part
GLDB958A Publication No.
5995358784
FRAME
A = GLDB958A (GLDB958AS0)
B = GLDB958A (GLDB958AB0)
C = GLDB958A (GLDB958AQ0)
POS. NO PART NO DESCRIPTION
3 # 154359801 A B C Valve,water
4 154208701 A B C Brace,front frame
8 154322901 A - - Toeplate,adjustable ,white
8 154322903 - B - Toeplate,adjustable ,black
8 154322905 - - C Toeplate,adjustable ,bisque
9 154397201 A - - Kickplate Assy,white ,w/ foam
9 154397203 - B - Kickplate Assy,black ,w/ foam
9 154397204 - - C Kickplate Assy,bisque ,w/ foam
9* 154249301 A B C Insulation,kickplate
10 154371301 A - - Screw,phillips head ,white
10 5300808658 - B - Screw,#8A x .375" ,black
10 154371303 - - C Screw,phillips head ,bisque
11 154200601 A B C Screw,#10-16 x 3/8
15 154210901 A B C Screw,leveling
20 154209601 A B C Cover,junction box
* 154321801 A B C Baffle,sound
* 154290101 A B C Guard,sound baffle ,wire
* 154290001 A B C Insulation,sound baffle ,side
* 154200602 A B C Screw,10-16 x 3/8 ,hex

09/01 12
Publication No. GLDB958A
5995358784
RACKS

# = Fast Moving Part 13 09/01
* = Non-Illustrated Part
GLDB958A Publication No.
5995358784
RACKS
A = GLDB958A (GLDB958AS0)
B = GLDB958A (GLDB958AB0)
C = GLDB958A (GLDB958AQ0)
POS. NO PART NO DESCRIPTION
1 154320906 A B C Rack assy,lower
2 154295201 A B C Basket,silverware
3 154321112 A B C Rack assy,upper
4 5304407064 A B C Wheel & bushing assy,upper rack
5 5300809927 A B C Cap,slide ,(4)
6 154232701 A B C Slide,rack ,(2)
7 154174501 A B C Wheel & bracket assy,lower rack
8 154304001 A B C Base,funnel
9 154251801 A B C Funnel
10 154238801 A B C Basket,utility ,white
11 154280303 A B C Holder,cup/stemware
12 154352401 A B C Bracket,cup shelf
13 154224902 A B C Fence,fold down ,white ,lower rack ,(2)
13A 154225403 A B C Fence,multi,3 wire ,upper rack ,(1)
13B 154225303 A B C Fence,multi,2 wire ,upper rack ,(1)
14 154376501 A B C Bracket,fold down fence ,lower rack ,(4)
14A 154242001 A B C Bracket,multi fence ,white ,upper rack ,(8)
14A* 154242101 A B C Bushing,multi fence ,upper rack ,(8)
15 154254001 A B C Handle,basket ,silverware
16 154254101 A B C Cover,basket ,white ,silverware
